NetApp ASA C Series Install page 147

1. Remove the power supply:
PSU locking tab
Power cable retainer
a. Rotate the cam handle so that it can be used to pull the power supply out of the chassis.
b. Press the blue locking tab to release the power supply from the chassis.
c. Using both hands, pull the power supply out of the chassis, and then set it aside.
1. Move the power supply to the new controller module, and then install it.
2. Using both hands, support and align the edges of the power supply with the opening in the
controller module, and then gently push the power supply into the controller module until the
locking tab clicks into place.
The power supplies will only properly engage with the internal connector and lock in place one
way.
To avoid damaging the internal connector, do not use excessive force when sliding
the power supply into the system.
3. Repeat the preceding steps for any remaining power supplies.
== Step 3: Move the NVDIMM battery
To move the NVDIMM battery from the impaired controller module to the replacement controller module,
145
