the replacement battery into the controller module.
1. Open the air duct cover and locate the NVDIMM battery in the riser.
Attention: The NVDIMM battery control board LED blinks while destaging contents to the flash
memory when you halt the system. After the destage is complete, the LED turns off.
2. Locate the battery plug and squeeze the clip on the face of the battery plug to release the plug from
the socket, and then unplug the battery cable from the socket.
3. Grasp the battery and lift the battery out of the air duct and controller module, and then set it aside.
4. Remove the replacement battery from its package.
Air duct riser
NVDIMM battery plug
NVDIMM battery pack
