If the impaired controller is
displaying...
System prompt or password
prompt (enter system password)
= Replace the boot media - ASA C800
:icons: font
:relative_path: ./asa-c-800/
:imagesdir: /tmp/d20231020-12297-25s5m0/source/./asa-c-250/../media/
To replace the boot media, you must remove the impaired controller module, install
the replacement boot media, and transfer the boot image to a USB flash drive.
== Step 1: Remove the controller module
You must remove the controller module from the chassis when you replace the controller module or
replace a component inside the controller module.
1. If you are not already grounded, properly ground yourself.
2. Unplug the controller module power supplies from the source.
3. Release the power cable retainers, and then unplug the cables from the power supplies.
4. Loosen the hook and loop strap binding the cables to the cable management device, and then unplug
the system cables and SFP and QSFP modules (if needed) from the controller module, keeping track
of where the cables were connected.
Leave the cables in the cable management device so that when you reinstall the cable management
device, the cables are organized.
5. Remove the cable management device from the controller module and set it aside.
6. Press down on both of the locking latches, and then rotate both latches downward at the same time.
The controller module moves slightly out of the chassis.
Then...
Take over or halt the impaired controller from the healthy
controller:
storage failover takeover -ofnode
impaired_node_name
When the impaired controller shows Waiting for giveback..., press
Ctrl-C, and then respond y.
