1. Use the animation or the tabulated steps to complete the cabling between the controllers and the
switches:
Animation - Cable a switched cluster
Step Perform on each controller module
Cable the HA interconnect ports:
• e0b to e0b
• e1b to e1b
[drw asac800 ha pair cabling]
Cable the cluster interconnect ports to the 100 GbE cluster interconnect switches.
e0a
e1a
[drw asac800 switched clust cabling]
Cable the management ports to the management network switches [Illustration showing
location of the management ports on the back of the system]
DO NOT plug in the power cords at this point.
2. To perform optional cabling, see:
[Option 1: Connect to a Fibre Channel host]
◦
[Option 2: Connect to a 10GbE host]
◦
[Option 3: Connect to a single direct-attached NS224 drive shelf]
◦
[Option 4: Connect to two direct-attached NS224 drive shelves]
◦
3. To complete setting up your system, see
=== Optional cabling: Cable configuration-dependent options
You have configuration-dependent optional cabling to the Fibre Channel or iSCSI host networks or direct-
attached storage. This cabling is not exclusive; you can have cabling to a host network and storage.
==== Option 1: Cable to a Fibre Channel host network
Fibre Channel ports on the controllers are connected to Fibre Channel host network switches.
Before you begin
Contact your network administrator for information about connecting the system to the switches.
Be sure to check the illustration arrow for the proper cable connector pull-tab orientation.
214
Step 4: Complete system setup and configuration.
