Polaris RZR XP Turbo Service Manual page 486

ELECTRICAL
FUSE / RELAY BOX (DYNAMIX)
The fuse box is located below the lower dash, to the left of the EPS unit.
CIRCUIT
Start Relay
Term Accy 7.5A Fuse
Instr Accy 7.5A Fuse
EPS Relay
Key 7.5A Fuse
Fan 30A Fuse
Accy Relay
EPS 25A Fuse
Shocks 7.5A Fuse
Lights Relay
11.56
PIN
1
2
7
8
3
9
4
10
3
4
11
12
13
19
14
20
15
16
21
22
17
23
18
24
25
9928491 R04 - 2017-2018 RZR XP Turbo / XP4 Turbo Service Manual
FUNCTION
Coil High
Power In
Power Out
Coil Low
Power In
Power Out
Power In
Power Out
Coil High
Power In
Power Out
Coil Low
Power In
Power Out
Power In
Power Out
Coil High
Power In
Power Out
Coil Low
Power In
Power Out
Power In
Power Out
Coil High
© Copyright Polaris Industries Inc.
