  • Page 1 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 3121/3122...
  • Page 2 Contents TSM Océ 3121 CAS-C Océ 3121 INSTALLATION IMAGE QUALITY TROUBLE SHOOTING GENERAL 01 - PHOTOCONDUCTOR 02 - CHARGING 04 - EXPOSURE 05 - DEVELOPING 06 - TRANSFER 07 - CLEANING 08 - IMAGE PROCESSING 10 - RDF 11 - DIGITAL DOCUMENT HANDLING...
  • Page 3 Océ 3121 CAS-C 01.Photoconductor 05.Developing 10.RDF 001 Unit positioning 161 Developing roller 361 Fax document separation/ 002 OPC, mechanical damage 162 Developing clutch CL4 output 003 OPC, end of life 163 Toner agglomeration 362 * Separation assy 004 Potential sensor & PBA...
  • Page 4 Océ 3121 CAS-C 413 Controller 465 * Separation roller 737 * Mechanical connections 414 * Controller PBA 466 * Feeding roller 738 * Electrical connections 415 * Controller interface PBA 467 * Paper pick-up PBA 739 * Others 416 * Controller hard disk...
  • Page 5 Océ 3121 CAS-C 24.Accessories 958 Mechanical connections 959 Electrical connections 960 Others 25.Customer/ environment/ material/ installation 961 No fault on arrival 962 Customer 963 * Speciality incorrectly posi- tioned 964 * Original incorrectly posi- tioned 965 * Paper jam incorrectly...
  • Page 6 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 INSTALLATION...

  • Page 7: Table Of Contents

    Contents Installation 1 The site 1 2 Unpacking and installation 3 3 Relocating the Machine 24 4 Installing the Control Card V 25 5 Installation of the Cassette unit 29 6 RDF Installation procedure 32 7 Sorter installation 36 8 The 3-tray delivery unit 47 9 Installation of the Fax 55 10 Installing the expansion memory 64 ed.1...

  • Page 8: Installation

    Installation 1 The site Requirements: A mains supply of the correct rating. The site must be 7.5° to 32.5°C in temperature and 5% to 85% in humidity. Avoid areas near water faucets, water boilers, humidifiers, refrigerators; near to sources of fire, or dust or ammonia gas; places subject to direct sunshine. Further requirements are: The site must be well ventilated.
  • Page 9 6.5 cm 170 cm min. 180 cm min. 6.5 cm 70 cm min. 210 cm min. 6.5 cm 170 cm min. 200 cm min. TSM Océ 3121 Installation...

  • Page 10: Unpacking And Installation

    2 Unpacking and installation Condensation can occur when a machine arrives at the destination. If the copier has just been moved from a cold place, allow it to acclimatise for at least one hour before unpacking. Unpacking No. Adjustments Remarks Unpack the machine, and remove the plastic covers.
  • Page 11 Lever for the feeding unit Loosen the screw, releasing Dummy drum Screw the dummy drum. Keep the removed screw. It is to secure the OPC unit. Pull the dummy drum out to the front. Dispose of the dummy drum. TSM Océ 3121 Installation...
  • Page 12 Filling toner No. Adjustments Remarks Holding the ivory coloured Developing unit Developing assembly grip, pull out the developing unit, until it stops. Ivory colour grip Ivory-color grip Shake the toner cartridge sev- eral times. Place the toner cartridge on Toner cartridge Toner cartridge the developing unit.
  • Page 13 Remove the toner cartridge Push in the developing unit until it stops. Turn the locking lever in the direction of the arrow, to lock the developing unit in place. locking lever Developing assembly locking lever TSM Océ 3121 Installation...
  • Page 14 Stirring the Toner No. Adjustments Remarks Insert the brush into the release opening, locking the fuser unit. cleaning brush Separation static eliminator cleaning brush Insert the dummy actuator in the door switch. Door switch actuator Door switch actuator Connect the mains supply cable.
  • Page 15 Toner Stirring screen. 5) Press ‘START’. Then, press ‘OK ‘. – The stirring of the toner will start. The stirring of the toner takes 4 minutes. It will stop automatically. Install the output tray. TSM Océ 3121 Installation...
  • Page 16 Installing the OPC No. Adjustments Remarks Turn OFF the main power switch. Release the developing unit lever. Remove the static elimina- tor, and clean with the spe- cial cleaning brush. After cleaning, put back the static eliminator. (Push it until a click is felt.) static eliminator Seperation static eliminator...
  • Page 17 Drum unit Drum unit 120V model: Do not remove the drum cover Drum unit Drum unit Drum cover Drum cover Secure the OPC unit, using Drum unit Drum unit the screw that was previously Screw Screw removed. TSM Océ 3121 Installation...
  • Page 18 No. Adjustments Remarks Enter the data on the label. Attach the label to the front date counter notes cover of the drum unit. date Datum note Notiz compteur Zähler compteur Zähler Turn the lever, locking the developing unit in place. Lock the feeding unit in place.
  • Page 19 Fix the appropriate label to Label Label the rotary switch. (the recess in the label should fit exactly over the notch on the dial). Note: Ensure that the correct label is used: for A/B or Inch configu- ration. Notch Boss TSM Océ 3121 Installation...
  • Page 20 No. Adjustments Remarks Holding the lever of the width guide and the length guide, slide the guides to suit the index of the appro- priate paper size. Set the paper size dial to the appropriate paper size. Paper size Paper size ed.1 Installation 13...
  • Page 21 Note: Sizes A3 and 11” x 17” cannot be handled by the cassettes 3 and 5. As counted from the top. Place copy paper in the cas- sette. P5-14-6 (1) P5-14-6 (2) TSM Océ 3121 Installation...
  • Page 22 Machine Specifications: Setting Mode (* 5 *) No. Adjustments Remarks Turn ON the main power switch. Press ‘user mode ‘. Set the following: Date Time Place the machine in mixed Switch the machine OFF/ON. text/photo mode, so that the Select Custom Copy Settings (in additional function LCD displays the text mode, features).
  • Page 23 Press the “down” key to open the 2/3 screen. Then, press 'Selecting Line Type'. Select the appropriate telephone line type, and press 20 pps ’OK’. 10 pps Touch tone Press the 'Close' key several times to return to the Stand- ard screen. TSM Océ 3121 Installation...
  • Page 24 Adjusting the transmission level No. Adjustments Remarks Enter *8* in service mode Press ‘#5 TYPE ‘. Select the appropriate country. Then, press ‘OK ‘. Press '#2. MENU' on the Menu screen, and press ’OK’. Press ' ATT (P) ', opening the Value Input screen.
  • Page 25 Press ‘FAX ‘to select the FAX screen. sure that the images are nor- mal. Press ‘Special features‘. Press ‘Test print ‘. Place a document, and press ‘OK‘. Try communications tests to check the operation and the images. TSM Océ 3121 Installation...
  • Page 26 Checking the copy images No. Adjustments Remarks If in service mode, press the Reset If the front door is open, remove the switch actuator and the brush. Then, close the front key twice to end it. door. If the copier is not on a pedestal, install the lower right cover as shown.
  • Page 27 GDA1 xxH GD2 xxH CDA3 CDA4 xxH ADDA5 xxH D-ODD xxH D-EVN xxH Press ‘AUTO SHADING START’ on the LCD, causing it to highlight. Press ‘OK ‘. Shading will be executed. Shading will stop when ‘Now [END] ‘is displayed. TSM Océ 3121 Installation...
  • Page 28 Automatic Density Adjustment No. Adjustments Remarks Execute the automatic density adjustment. Execute ‘PD’, ‘200PWM’, and ‘600PWM’. Press ‘Reset ‘once, to end service mode. ‘$’ will be indicated in the upper left corner of the screen. Holding the feeder or the platen cover at about 45°, make two A4 copies (solid black).
  • Page 29 Proceed as described for the PD A= + xxx, B= + xxx, D= + xxx xx xx xx xx xx xx xx density adjustment. xx xx xx xx xx xx xx MULTI > CASSETTE1 A4 1 CASSETTE 2 A4 1 Ð TSM Océ 3121 Installation...
  • Page 30 No. Adjustments Remarks Press to turn pages to the 600PWM Density Automatic * 4* FUNCTION 06 CANCEL Adjustment screen. 600PWM PRINT (START) WHITE MEASURE (OK) Perform the 600PWM density DENSITY SANPLING (OK) adjustment. DATA SET Proceed as described for the PD A= + xxx, B= + xxx, D= + xxx density adjustment.

  • Page 31: Relocating The Machine

    Hold the copier’s grips, and lift the copier upright so that the pedestal’s pin will slide off the holes. (Work in a group of two.) Lower the copier on the floor or on a desk. TSM Océ 3121 Installation...

  • Page 32: Installing The Control Card V

    4 Installing the Control Card V Ensure that the MEMORY TX/RX indicator is OFF, before switching Warning: off the copier. Removing the Control Panel Remove the following, so that the inside cover can be removed: Front door Fuser cover OPC unit (Release the developing unit.) The lever of the feeding unit The knob of the registration roller The upper cassette...
  • Page 33 Position the Control Card (1) on the control panel, using four screws (2). Slide a card in and out, and fix the Control Card V when a card can be Note: moved smoothly. Check that the connector (3) for the printer is aligned over the hole. Note: TSM Océ 3121 Installation...
  • Page 34 Connect the earthing wire (4) of the Control Card V, taking care not to trap the wires. Fit the control panel to the copier. Fit the fuser control PBA (5). At this time, be sure to fix the grounding wire (6) of the Control Card V in place by tightening the screw.
  • Page 35 Position the plastic (12) in the hole in the control panel. Remove the backing sheet from the face plate. Attach the face plate (13) to the control panel. Attach the memory record and the transparent sheet. Switch OFF. Check the functioning of the Control Card V. TSM Océ 3121 Installation...

  • Page 36: Installation Of The Cassette Unit

    5 Installation of the Cassette unit Unpacking DO NOT LIFT label Cassette unit label set Contents: Cassette unit: 1 unit. ’Do not lift’ label: 1pc. Label set: 2 or 4 sets Preparations If the lower right cover is fitted to the copier, remove it. Disconnect the mains supply cable.
  • Page 37 Open the right-hand panel. Open the vertical transport unit. Vertical transport unit right door Holding the copier by its grips, carefully place the copier on the pedestal. Close the vertical transport unit, and close the right door. TSM Océ 3121 Installation...
  • Page 38 Ensure that the mains supply cable is disconnected. Connect the cable from the cassette feeding unit to the copier Continue with the work for each cassette as described at ‘Installing the Cas- settes’ on page Attach the ’DO NOT LIFT’ label, as shown. label Perform ‘Adjusting the Registration in Rear/Front Direction’...

  • Page 39: Rdf Installation Procedure

    Unpacking the machine RDF 1 unit Stepped screw 1 pc. Delivery tray 1 pc. Tray hinge 1 pc. Hinge cover 1 pc. Screw (M4x30) 1 pc. Screw (M3x4) 2 pcs. Guide base 1 pc. Stamp 1 pc. TSM Océ 3121 Installation...
  • Page 40 Fitting the RDF Ensure that the copier has been properly installed. Keep the mains supply cable disconnected during the installation work. Identify the screws by type (length, diameter, location). Some screws come with a washer to protect against static electricity. Ensure that these are used.
  • Page 41 Ensuring that the bolts of the supports are at the bottom of the holes. Close the RDF. Supports Remove the connector cover. RDF connector Connect the RDF connector. Ensure that the mains supply cable is disconnected. Warning: TSM Océ 3121 Installation...
  • Page 42 Remove the cap and fit the stamp in the RDF. Stamp Stamp Do not touch the stamp face. Immediately rinse your hands if you Caution: touch the ink. Checks after Installation After installation, adjust the following: the height of the RDF, see 10: adjustment 1 the document position, see 10: adjustment 2, 3 &...

  • Page 43: Sorter Installation

    Stapling position label B, 1 pc. Reinforcement plate, 1 pc. Tray label, 1 pc. Binding screw (black M4 x 6) 3 Stepped screw (6 x 11), 2 pcs. pcs. Cable bushing 1 pc. Cable retainer, 1 pc. Latch plate, 1 pc. TSM Océ 3121 Installation...
  • Page 44 Unpacking and removing the metal fixings Remove the packing material and keep the sorter upright. Remove the two screws and two butterfly screws. Then remove the metal fix- ing A from the sorter. Remove the screw and remove the metal fixing B. Butterfly screw Butterfly screw Metal fixing A Screw...
  • Page 45 Installation Mount the delivery guide. Delivery guide Install the latch plate with the two stepped screws (6 dia. x 11). Cushioning material Stepped screws Mounting hole TSM Océ 3121 Installation...
  • Page 46 Remove the hinge cover of the copier’s left cover, using a screwdriver. Hinge cover Fix the reinforcement plate in place to the copier with two screws (black M4 x Reinforce- ment plate Screw ed.1 Installation 39...
  • Page 47 Be sure to support the bottom of the sorter when lifting the sorter. Do Warning: not hold the stapler cover. Cut-offs Stapler cover To facilitate the work, put cushioning material as shown in the figure and Note: extend the rail. Cushioning materials TSM Océ 3121 Installation...
  • Page 48 Fix the sorter in place with two stepped screws (6 dia. x 27.5). Stepped screw Stepped screw Remove the connector cover from the rear of the copier. For 3-tray output unit Be sure that the mains cable is disconnected. Warning: Connect the sorter’s cable to the copier.
  • Page 49 Screw (with toothed washer) Solenoid cable Rear right cover Screws (with toothed washers) Right cover Check to make sure that bit 4 of the DIP-switch SW1 on the tray controller PBA is at ON. Tray controller PBA TSM Océ 3121 Installation...
  • Page 50 Installing the paper on tray indicator Attach the cable bushing. Cable bushing Insert the cable into the hole. Indicator Cable bushing Magnet plate ed.1 Installation 43...
  • Page 51 Harness band Cable retainer Cable Attach the guide plate. Paper on Tray indicator Guide plate Install the rear right cover and close the right cover. Then set the sorter on the copier. TSM Océ 3121 Installation...
  • Page 52 Attaching the labels Attach the label A to the rear of the platen. Label A 5 mm platen Attach the label B so that the leftmost illustration on the Warning label on the DF is hidden. Label B Warning label Attach the appropriate tray label to the side of each tray.
  • Page 53 TSM. Supply the stapler with staples. (instructions in the stapler door). Check the following operations: Connection/disconnection between the copier and the sorter. Up/down movement of the bins. Feeding of copy paper. Auto stapling TSM Océ 3121 Installation...

  • Page 54: The 3-Tray Delivery Unit

    8 The 3-tray delivery unit Unpacking Height adjusting plate, 1 pc. Interlock retaining plate 2, 1 pc. Delivery unit, 1 pc. Tray sticker, 1 pc. External cover, 1 pc. Tray, 2 pcs. Edge saddle, 1 pc. Hinge, 1 pc. Stop spacer, 1 pc. Delivery unit spacer, 1 pc.
  • Page 55 Open the front cover. Open the delivery unit and remove the connector cover (1). (The cover is hooked in place, use a finger to snap it off). Release the hook (3) of the lower cover (2) TSM Océ 3121 Installation...
  • Page 56 Close the delivery unit and shift the lower cover to remove. Remove the hinge cover (1) with a small flat-blade screwdriver. Disconnect the connector of the delivery unit. Open the delivery unit and remove the wire (1) from the copier (2 screws (2)). Pull out the spacer (1) from the right side of the delivery unit.
  • Page 57 Remove the lower delivery guide (3) (4 screws (2)). While paying attention to the spring, release the hook of the lever (4) with a flat-blade screwdriver and remove the lever. Detach the wire from the delivery unit side (1 screw). TSM Océ 3121 Installation...
  • Page 58 Replace the interlock retaining plate 1 (5) with the one for the 3-tray delivery unit. The fixing shaft, lower delivery guide, lever, wire and interlock retaining plate 1 will not be used. Place the 3-tray delivery unit (1) on its side so that the tray side is at the bottom. Install the delivery unit to the 3-tray delivery unit with 4 screws (pay attention to the spring (3) on the 3-tray delivery unit side.
  • Page 59 Check to make sure that the hole used to fix the height adjusting plate in place is tapped. If not, use the stepped screw from the wires to tap the hole. Install the height adjusting plate (1) using the binding screw that comes with the tray. TSM Océ 3121 Installation...
  • Page 60 Placing the 3-tray delivery unit on the hinge Holding the delivery door by its latch with one hand and the bottom of the 3-tray unit with the other, place the 3-tray unit on the hinge pins (1) of the hinge. (At this time, make sure that you set the 3-tray unit on the bottom shaft and then the top shaft).
  • Page 61 Perform a copy job while testing the sorting function of the delivery unit. Identifying the obsolete parts Lever Hinge unit cover Bushing Spacer Delivery unit lower cover Lower delivery guide Fixing shaft Wire Interlock retaining plate 1 TSM Océ 3121 Installation...

  • Page 62: Installation Of The Fax

    9 Installation of the Fax INSTALLATION Preparation The Basic Expansion Kit is required. If the Basic Expansion Kit is already installed, remove its component units be- fore starting. Ensure that the mains supply cable is disconnected before starting. If a PBA other than the FAX PBA is fitted in the Base Unit, first remove that PBA before installing the FAX PBA..
  • Page 63 Fit the speaker and the speaker shell in the expansion unit. Fit the notches on the speaker shell into the holes in the expansion unit. Turn it to lock. Speaker holder (with Speaker hol der speaker inside) ( w i t h speaker i nsi de) TSM Océ 3121 Installation...
  • Page 64 Setting the NCU To operate the unit, make correct settings using the following NCU switches. NCU Switch Configuration (The NCU for France has no switches.) NCU PBA N C U PC B SW 1 SW 2 SW 3 NCU Switch Settings Europe (general) Sweden UK/Australia/Asia/Ocea-...
  • Page 65 Position the core in the Base Unit. Using the cable tie, seccure the core in the appropriate manner. Type 1, with a Square Hole (4 holes) Core Base unit Base U ni t C O R E Hole Tie wrap Ti e- w r ap H ol e TSM Océ 3121 Installation...
  • Page 66 Type 2, with a Round Hole (1 hole) Core Tie wrap C O R E Ti e- w r ap Modular Unit Harness Connect the modular unit to the connectors J2, J3, and J4 on the NCU PBA of the FAX PBA. Harness of modular unit H ar ness of m odul ar uni t NCU PBA...
  • Page 67 Lead behind Ql. Speaker Speaker Lead behind Q1 Lead behi nd Q 1 Earth cable AR G cabl e Core C O R E (round) ( r ound) Square bush Squar e bush TSM Océ 3121 Installation...
  • Page 68 Arrange the core of the harness for the modular unit, as shown. Insert the FAX PBA in the Expansion Kit. Harness of modular unit Core (cube) H ar ness of m odul ar uni t C O R E ( cube) Lock support Earth cable AR G cabl e...
  • Page 69 5- pi n connect or ( l ar ge) Before fitting the front cover. Ensure that all bits of the switch, as shown in the figure, are shifted to the top positions. Bit switch Bi t sw i t ch TSM Océ 3121 Installation...
  • Page 70 Secure the earth cable (blue), as shown earth cable Screw (+ washer) AR G cabl e Scr ew ( w / w asher ) Shift the slide switch SW2 from OFF to 3. O FF Fit the cover to the expansion unit. Be careful not to trap any wires. Screw (+ washer) Remove the jack cover from the rear panel of the copier.

  • Page 71: Installing The Expansion Memory

    SW 2 Open the claw of the slot. Insert the expansion memory straight down in the slot. Turn ON SW2 on the Fax PBA. Slide the Fax PBA back into the original position, and replace the covers. TSM Océ 3121 Installation...
  • Page 72 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 IMAGE QUALITY...
  • Page 73 Contents Image quality 1 Initial check 1 2 Image adjustment basic procedure 3 3 Check and adjustment of the image registration 4 4 Trouble shooting: image faults 6 5 Isolating a PBA : FAX image fault 21 6 Shading for service 22 7 Automatic correction of the copy density 24 8 Shading for R&D and factory 28 9 AE adjustment 30...

  • Page 74: Image Quality

    Image quality 1 Initial check The site Ensure that the mains supply voltage is according to specifications. Make sure that the site is not subject to ammonium gas. The quality of the documents Define whether the problem is due to the quality of the documents, or the func- tion of the machine.
  • Page 75 10 to 20 minutes. The image adjustment: basic procedure should be followed if any of Warning: the following occur:- uneven density (difference in density between front and rear),- light images,- or a grey background . TSM Océ 3121 Image quality...
  • Page 76 Confidential © 1998 Océ-Technologies B.V.

  • Page 77: Check And Adjustment Of The Image Registration

    2. The LASER-Write position. Sub scanning direction: the leading edge marging Check the leading edge margin. This margin must be 2.5 ±1.5mm Adjustment: *3* ADJUST 04 RESIST This adjustment adjusts the timing of the registration clutch. TSM Océ 3121 Image quality...
  • Page 78 Main scanning direction: left right registration: Check the the margin on the front. The margin must be 2.5 ±1.5mm Adjustment: *3*ADJUST 04 PVE-OFST (offset LASER centre) This adjustment influences the result for all the cassettes in the same way.) 3 The cassette position For the different cassettes the front margin of the copy must be the same (2.5 ±1.5mm) .

  • Page 79: Trouble Shooting: Image Faults

    Is there an even coating Check the developing of toner on the develop- unit. ing roller? Scanner (dirty) Clean the mirror, the lens Yes End. and the exposure aper- Replace the OPC unit ture. Is the image cor- rected? TSM Océ 3121 Image quality...
  • Page 80 The copy is too light. (including solid black) Cause Step Checks Y/N Action Carry out the image Yes End. adjustment procedure. Is The image will be much the problem corrected? lighter if the pattern print is placed in reverse (left/right) orientation. Ensure correct orienta- tion of the test chart.
  • Page 81 OPC unit Replace the OPC unit. Is Yes End. the problem corrected? Image processor PBA Try replacing the image Analogue processor processor PBA , or the analogue processor PBA. TSM Océ 3121 Image quality...
  • Page 82 The copy is very light (overall) Cause Step Checks Y/N Action Carry out the image Yes End. adjustment procedure. Is The image will be much the problem corrected? lighter if the pattern print is placed in reverse (left/right) orientation. Ensure correct orienta- tion of the test chart.
  • Page 83 J205-1 and the side of the developing unit, and between J205-1 and the side frame of the machine. Developing unit 5 Replace the power supply PBA. Is Yes End. the problem solved? Replace the DC control TSM Océ 3121 Image quality...
  • Page 84 The copy has vertical lines of background The copy has black lines. (vertical, thick, fuzzy) Cause Step Checks Y/N Action Charging roller Clean the charging roller in user Yes End. mode. Is the problem solved? Scanner (dirty) Clean the mirror, the lens and the Yes End.
  • Page 85 Change the value of ( ‘ * ence strip and all the mir- 3 * ‘ ), ‘ ADJ-S ‘ in serv- rors. ice mode, and change the Is the problem solved? point of shading meas- urement. TSM Océ 3121 Image quality...
  • Page 86 The copy has white spots (horizontal). Cause Step Checks Y/N Action Developing unit Execute ( ‘ * 4 * ‘ ) , ‘ Yes Go to step 4. L-TEET1 ‘ in service mode. Are there white lines in the resulting image? Developing unit Is the problem repeated...
  • Page 87 Clean the entry guide for the fusing unit. Transfer roller Execute cleaning of the roller, in user mode. Make several black cop- Is there excessive soiling Yes Replace the transfer unit. of the transfer roller? TSM Océ 3121 Image quality...
  • Page 88 The copy has faults with the fusing Cause Step Checks Y/N Action Paper Is the paper in use a thick Yes Set ( ‘ * 5 * ‘ ) , ‘ type of paper, or a paper SPCL-PPR ‘ to 1. Then, that is difficult to fuse? set the following and advise the user:...
  • Page 89 Gear for the developing Is the problem repeated Yes Check the developing roller at intervals of 35 mm? unit. OPC drive Check the drive of the OPC unit Replace the OPC unit TSM Océ 3121 Image quality...
  • Page 90 The copy has horizontal lines of background Cause Step Checks Y/N Action Is the location of the Yes Go to step 4 problem area on the copy consistent for all copies made in direct mode? Scanning lamp, power Does the scanning lamp Yes Check the scanning lamp supply PBA flicker while the scanner...
  • Page 91 Replace the laser unit processor PBA unit and make a copy of a Replace the image solid black document. Is processor PBA a laser beam striking the OPC? OPC unit Yes Replace the OPC unit. TSM Océ 3121 Image quality...
  • Page 92 The copy is completely black Cause Step Checks Y/N Action Scanning lamp Does the scanning lamp Refer to: The scanning remain ON during copy- lamp fails to switch ON. ing? Charging roller Is there a correct contact, Reconnect and a correct connection between J205-3, on the power supply PBA, and the charging roller?
  • Page 94 Confidential © 1998 Océ-Technologies B.V.

  • Page 95: Shading For Service

    Separ at i on st at i c el i m i nat or cl eani ng br ush Insert the switch actuator in the door switch. Using a thin pin, press the service switch. A ‘ $ ’ will be displayed in the upper corner of the screen. TSM Océ 3121 Image quality...
  • Page 96 Press ‘ * ‘ twice The Service Mode Menu screen will be displayed. Press ‘ FUNCTION ’ (‘ * 4 * ‘) . It will highlight. Then, press ‘OK’. Press the Page key to bring up the shading screen (3rd screen). Press ‘...

  • Page 97: Automatic Correction Of The Copy Density

    Separ at i on st at i c el i m i nat or cl eani ng br ush Insert the switch actuator in the door switch. Using a thin pin, press the service switch. A ‘ $ ’ will be displayed in the upper corner of the screen. TSM Océ 3121 Image quality...
  • Page 98 Press ‘ * ‘ twice The Service Mode Menu screen will be displayed. Press ‘ FUNCTION ’ (‘ * 4 * ‘) . It will highlight. Then, press ‘OK’. Press the Page key to bring up the shading screen (3rd screen). Execute ‘...
  • Page 99 The scanner will make 13 scans. At the end of the sequence, check that the values A, B and D on the LCD are as follows. If incorrect, restart the adjustment at step 7, as the adjustment may be wrong. TSM Océ 3121 Image quality...
  • Page 100 A, B and D are approximate values. Optimum images may still be obtained even if the values are outside the range. You may omit ‘ temporary remedy ‘ if the images are optimum. For PD and 200 PWM 20 <= A <= 50 -40 <= B <= 40 0 <= D <= 8 For 600 PWM...

  • Page 101: Shading For R&D And Factory

    Insert the switch actuator in the door switch. Using a thin pin, press the service switch. A ‘ $ ’ will be displayed in the upper corner of the screen. Press ‘ * ‘ twice, to exit service mode. TSM Océ 3121 Image quality...
  • Page 102 Press ' FUNCTION ' on the Menu screen ( ‘ * 4 * ‘ ).Press ‘ OK ‘. Press the Page key to bring up the Shading screen (12th screen). Place 5 to 10 sheets of paper on the platen. C opy paper C opyboar d gl ass Press ‘...

  • Page 103: Ae Adjustment

    (black) and background (white), can be adjusted under ‘ AE_SLOP ’. In service mode ( ‘ * 3 * ‘ , ‘ ADJUST ‘ ). ‘ AE-SLOP ‘: A higher setting makes the image darker. (value 1 ~19). TSM Océ 3121 Image quality...
  • Page 104 ‘ AE_LIGHT ‘ or ‘ AE_DARK ‘ The AE table, selected as a result of a pre-scan, may be corrected to suit the preference of the user. ‘ AE-LIGHT ‘: A higher setting emphasises the background of the document. A lower setting softens the background of the document. (value: 0 ~ 40, default = 20.
  • Page 105 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 TROUBLE SHOOTING...
  • Page 106 Contents Trouble shooting 1 Introduction to this chapter 1 2 Error codes descriptions 2 3 Detecting errors on the composite power supply PBA 10 4 Self diagnosis of the RDF and the 12-bin sorter 11 5 Detection of jams 12 Error code solving / machine fault solving 1 E000 The fixing temperature fails to rise.
  • Page 107 55 The counter fails to operate. 46 56 The ‘Add Paper’ display remains ON. 46 57 The ‘Jam‘ display remains ON. 47 58 The ‘Add Toner‘ display remains ON. 47 59 The fax error display remains ON. 48 TSM Océ 3121/3122 Contents...
  • Page 108 RDF Self Diagnosis FAX related error codes Trouble shooting ed.2...

  • Page 109: Trouble Shooting

    Trouble shooting 1 Introduction to this chapter The Océ 3121/3122 has several ways to inform you about malfunction. The most important is the self-diagnosis system which generates an error code if there is something wrong with the basic machine. Besides that, the composite power supply of the machine can indicate malfunction in the power supply ar- ea, by a flashing LED on the composite power supply PBA.

  • Page 110: Error Codes Descriptions

    2 Error codes descriptions The Océ 3121/3122 has a self diagnostic mechanism that indicates a code on the control panel upon detection of an error. Code Main cause Description E000 The fixing temperature fails to rise. The main thermistor (TH1) detects Thermistor (TH1;...
  • Page 111 Code Main cause Description E002 The fixing temperature fails to reach a The main thermistor detected less specific value. than 105°C for 200 ms 1 sec after it Thermistor (TH1, TH2; off contact, has detected 90°C. poor contact, open circuit) The main thermistor (TH1) detected Fixing heater (open circuit;...
  • Page 112 An error has occurred in the serial The communication data is not updat- communication between the DC con- ed within 8 sec. trol PBA and the composite power Three consecutive errors occur with supply PBA. the check sum of the communication. TSM Océ 3121/3122 Trouble shooting...
  • Page 113 Code Main cause Description E202 The scanner home position cannot be The scanner does not return to home detected. No code position after it has started to move. Scanner home sensor PS1 indica- Scanner motor M2 tion. DC control PBA Keys on control panel...
  • Page 114 MS 7 does not switch with- in 1 second after the stapler motor CCW signal is subsequently generat- The stapler position sensor PI4 is not switched off within 1 second after motor M5 was started. TSM Océ 3121/3122 Trouble shooting...
  • Page 115 Code Main cause Description E540 The bin shift motor M1 does not ro- The cam home sensor PI1 does not (12-bin tate. switch OFF within 1 second after the output motor M1 drive signal has been gen- unit) erated. E601 The communication between the An error exists in the communication machine and the SCS1 board has a...
  • Page 116 The rpm failed to reach a specific val- (Cassette Pedestal control PBA is faulty ue within 10 second, after the pedestal unit) motor was turned on. The rpm deviated from a specific val- ue for 3 sec or more. TSM Océ 3121/3122 Trouble shooting...
  • Page 117 Action in response to error codes When the diagnostic system has switched ON, and an error has been logged, the machine can be reset by switching the ON/OFF switch OFF, then ON. E000, E001, E002, E003, E004, and E007–01, and E717 cannot be reset by switching OFF and ON.

  • Page 118: Detecting Errors On The Composite Power Supply Pba

    A communication error: DC con- communica- trol PBA to composite power sup- tion with the ply PBA. The communication DC controller data was not renewed within 8 seconds. LED100 may fail to flash. E191 is logged. TSM Océ 3121/3122 Trouble shooting...

  • Page 119: Self Diagnosis Of The Rdf And The 12-Bin Sorter

    Pattern Message Description 6 seconds ON, 6 seconds Low voltage: Unacceptable difference between control error the +24VR output and the actual during copy- control value. ing * Error data is transmitted to the DC control PBA. E803 is logged. 8 seconds ON, 8 seconds +5.1V out- Output is incorrect.

  • Page 120: Detection Of Jams

    Sensor for the vertical transport PDP 4 J113-A2 PS11 Sensor for the re-pick entry PDP 5 J103-2 PS12 Sensor for the re-feed unit PDP 6 J105-B2 PS13 Sensor for the output tray PDP 7 J105-A2 TSM Océ 3121/3122 Trouble shooting...
  • Page 121 Types The microprocessor identifies jams as follows: Delay The paper did not reach the appropriate sensor within the specified time: i.e. the sensor is not ON. Stationary The paper did not leave the appropriate sensor within the specified time: i.e. the sensor does not switch OFF.

  • Page 122: Error Code Solving / Machine Fault Solving

    Replace the fuser unit. Is End. contact. the problem corrected? Fixing heater driver 5 Replace the fixing heater End. driver. Is the problem DC control PBA Replace the DC control corrected? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 123: E001 The Fixing Temperature Is Abnormally High

    2 E001 The fixing temperature is abnormally high. Cause Step Checks Yes/No Action Thermistor: Clear the error using ‘ERROR’ in service Replace the short circuit. mode (*4*). Let the fixing assembly to fixing unit. cool; then, disconnect J50, and measure the resistance of the thermistor.

  • Page 124: E007-01 The Fixing Film Does Not Realign

    ‘FILM COME- BACK’ in service mode (*4*). Is the operation of the fixing film motor (M5) normal? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 125: E010 Main Motor Fails To Lock

    6 E010 Main motor fails to lock Cause Step Checks Yes/No Action Does the main motor Go to step 4. rotate until ‘E010’ is indicated? Main motor Is MLCK 0 V (main Replace the main motor. (including motor motor specific speed sig- driver PBA) nal), while the main motor is running?

  • Page 126: E032 The Copy Data Controller Is Faulty

    J115. tor (poor con- tact) Motor for the Replace the horizontal registration End. side registra- motor. Is the problem corrected? tion DC control Replace the DC control PBA TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 127: E064 The High Tension Supply Is Faulty

    11 E064 The high tension supply is faulty. Cause Step Checks Yes/No Action Trapped Turn OFF/ON the power Check the harness of cables switch, and set the copy the DC controller PBA count to ‘1’. Is ‘E064’ indi- and the composite cated after copying? power supply PBA.

  • Page 128: E100 A Beam Detection Error Has Occurred

    Clean the face of the BD End. (soiled face) PBA. Is the problem solved? Try replacing the follow- BD PBA, ing items: laser unit, BD PBA image proc- essor PBA Laser unit Image processor PBA TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 129: E110 Scanner Motor Fails

    13 E110 Scanner motor fails Cause Step Checks Yes/No Action J153 Inspect the connection of Connect the connector. J153, to the laser driver PBA. Perform key operation during Go to step 4. stand-by. Is the sound of the rotation of the laser scanner motor heard? Check the wiring DC power...

  • Page 130: E191 Error In Serial Communication Between Dc Controller Pba And Composite Power Supply Pba

    PS1. the DC controller PBA to PS1; if normal, replace PS1. Scanner Replace the scanner motor. Is End. motor M2 the problem solved? DC control Replace the DC control TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 131: E220 The Scanning Lamp Operates Incorrectly

    17 E220 The scanning lamp operates incorrectly. Cause Step Checks Yes/No Action Does the scanning lamp See “The scanning lamp switch ON? fails to turn ON.” Scanning Are both ends of the scanning Replace the scanning lamp (low lamp black? lamp.

  • Page 132: E243 Error In Communication Between Control Panel And Image Processor

    J209 on the composite power supply PBA good? DC control Replace the DC control PBA. Is the problem corrected? Composite Replace the composite Power sup- Power supply PBA ply PBA TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 133: E310 The Intensity Of The Scanning Lamp Is Incorrectly Adjusted

    21 E310 The intensity of the scanning lamp is incorrectly adjust- Cause Step Checks Yes/No Action Press the copy button. Does See “The scanning lamp the scanning lamp switch fails to turn ON.” Connector Check the cables between the Correct it. (poor con- DC control PBA and the tact)

  • Page 134: E401

    RDF controller PBA. Does if normal, replace the belt the reading of the meter change motor (M3). to 23 V when the Copy Start key Replace the RDF control- is pressed? ler PBA. TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 135: E403

    25 E403 Cause Step Checks Y/N Action Feeding motor Set the meter to the 20VDC Check the wiring from clock sensor range, and connect the + probe the feeding motor clock (S9) to J9-15 and the – probe to J9-16 sensor (S9) to the RDF on the RDF controller PBA.

  • Page 136: E500/E713

    Check the copier’s 24V range. Connect the + to power supply. J1-2 and the – to J1-1 on the tray control PBA. Does the voltage change to approximately 24 V? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 137: E510

    Cause Step Checks Yes/No Action Tray control PBA Replace the tray control End. PBA. Is the problem cor- DC controller PBA Replace the copier’s DC rected? (copier’s) controller PBA. 28 E510 Cause Step Checks Yes/No Action Switch on joint sensor. Go to step 3.

  • Page 138: E515

    Connect the + to J10-1 and PBA. the – to J10-2 on the tray control Motor clock Replace the clock sensor PBA. Does the voltage change to sensor PI6. PI6. approximately 24 V? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 139: E521

    30 E521 Cause Step Checks Y/N Action Switch on the joint sensor. Set the Replace the tray motor DIP switch SW3, on the tray control PBA, as follows: Does the tray motor M7 rotate in response to each press on the man- ual staple button? Connector Check the connection of J12 to the...

  • Page 140: E531

    Connect the + to J7-8 and the – home position sensor to J7-7 on the tray control MS7. If undamaged, PBA. Is the voltage approxi- replace the sensor. mately 5 V? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 141: E540

    33 E540 Cause Step Checks Y/N Action Does the bin unit move up or Go to step 4. down when SW2 or SW3 is pressed? (On the tray control PBA). Drive belt for the Is the drive belt correctly fitted? No Fit the belt correctly.

  • Page 142: Scsi Interface E601 (The Communication Between The Scsi Board And The Machine Has A Fault.)

    Fuse Is there electrical continuity in Replace the fuse. the fuse on the SCSI board? Is there conti- Replace the SCSI board. nuity in the fuse on the SCSI board? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 143: Fax Unit E674 (The Fax Unit Has A Fault.)

    37 Fax Unit E674 (The fax unit has a fault.) Cause Step Checks Yes/No Action Connector Is the connection of the follow- Correct the connection. ing normal? At this time, check the between fax PBA and system pins for deformation. motherboard Fax PBA Replace the fax PBA.

  • Page 144: Communication Errors E710 (The Ipc Communication Chip On The Image Processor Pba Has A Fault.)

    OFF/ON the main power sup- ply. Is the problem corrected? Copy Data Replace the Copy Data Con- Controller troller. Is the problem cor- rected? DC control Replace the DC control TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 145: E803 24 V Output Error From The Composite Power Supply Pba

    43 E803 24 V output error from the composite Power supply PBA. Cause Step Checks Yes/No Action Turn OFF/ON the main power switch. Is the problem corrected? Scanning Does the scanning lamp If the lamp does not lamp remain OFF?. Or does the turn ON, see “The scan- scanning lamp remain dim, ning lamp fails to turn...
  • Page 146 Is the tor for contact; if normal, resistance 0 ohm when the replace the noise filter. switch is turned ON and ° ohm when the switch is turned OFF? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 147: There Is No Dc Power

    45 There is no DC power. Cause Step Checks Yes/No Action Error code Turn ON the main power sup- See the description for ply switch. Is the error code the relevant error code. indicated? AC power Is there an AC supply? See “AC power is supply absent.”...

  • Page 148: The Opc Does Not Rotate

    ACC Power supply PBA Connector Output J142 +24V +24V J143 +24V +24V 46 The OPC does not rotate Cause Step Checks Yes/No Action Is ‘E010’ indicated? See the descriptions for ‘E010’. TSM Océ 3121/3122 Error code solving / machine fault solving...
  • Page 149 Cause Step Checks Yes/No Action Position of Reposition the OPC unit. Is the OPC the problem corrected? OPC drive Remove the drum drive assembly, and correct or replace the parts as nec- essary. ed.2 Trouble shooting 41...

  • Page 150: No Pick-Up From The Cassette

    . smoothly, when lifted by hand? Sensor for the Is the lifter position sensor Replace the lifter posi- lifter normal? tion sensor. TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 151: Pick-Up Failure: Specialities

    Cause Step Checks Yes/No Action Lifter drive Is the lifter drive assembly Correct it. normal? Pick-up Replace the pick-up assembly unit. 49 Pick-up failure: specialities Cause Step Checks Yes/No Action Pick-up Select speciality pick-up, and Check the wiring. If it is clutch CL2 press the copy button.

  • Page 152: The Scanner Fails To Move Forward Or In Reverse

    0V to approximately 24 V the pre-exposure lamp. when the copy button is DC control Replace the DC control pressed? TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 153: The Scanning Lamp Fails To Switch On

    53 The scanning lamp fails to switch ON. Cause Step Checks Yes/No Action Scanning Are both ends of the scanning Replace the scanning lamp lamp black? lamp. Position of Is the scanning lamp posi- Refit it. the scanning tioned correctly? lamp Connector Is the connection of the relay...

  • Page 154: The Counter Fails To Operate

    Check the sensor lever; check ‘P-SENS’ in service if normal, replace the mode (*1*; 7th page). Is the sensor in question. value ‘0’? (upon detection, DC control Replace the DC control ‘1’) TSM Océ 3121/3122 Error code solving / machine fault solving...

  • Page 155: The 'Jam' Display Remains On

    57 The ‘Jam‘ display remains ON. Cause Step Checks Yes/No Action Is there paper around the sen- Remove all paper. sor which has turned on? (Check by referring to the jam code in service mode (*1*; JAM).) Sensor Inspect the sensor, identified Replace the sensor.

  • Page 156: The Fax Error Display Remains On

    Is the fax reception normal? Check the connection to the telephone system. Image proc- Replace the image processor essor PBA PBA. Is the problem solved? FAX PBA Replace the fax PBA. TSM Océ 3121/3122 Error code solving / machine fault solving...
  • Page 157 RDF Self Diagnosis RDF Self Diagnosis The microprocessor, on the RDF control PBA, is equipped to check the condi- tion of the machine. When it detects an error, the copier will display an error code on the screen. Code Cause Description Fault with data commu- The communication is monitored at...
  • Page 158 The size or the thickness of the document is Make a standard size copy of the document, outside the specifications. and restart. The internal mechanism has a fault. Check the electrical connections (e.g., PBA of the feeder; sensors, motors). TSM Océ 3121/3122 FAX related error codes...
  • Page 159 #003 (trans/recep) Time-out occurred while transmitting or receiving a single-page document. Main cause Action The document is too long: requiring longer Split the document into several pages, and than specified for transmission or scanning. restart. Reception is taking longer than specified. The internal mechanism has a fault.
  • Page 160 Main cause Action Broadcasting transmission or multi-polling Register the telephone number of the other reception was used, without registering the machine for auto dialling. telephone number of the other machine for auto dialling. TSM Océ 3121/3122 FAX related error codes...
  • Page 161 #037 (recep) The memory overflowed during reception. Main cause Action The volume of reception (document) ex- Ask the other party to delete unnecessary ceeded the limit, during reception. image data, prior to transmission. #039 (trans) Failure of closed net transmission. Main cause Action The closed-net transmission switch is off.
  • Page 162 0 To transmit a 1650-Hz tone signal, when bit 5 is set to 1. bit 7: 1 To transmit a tone signal, before sending a CED signal. 0 Not to transmit a tone signal, before sending a CED signal. TSM Océ 3121/3122 FAX related error codes...
  • Page 163 Change service data #1SSSW SW03 bit 1. bit 1: 1 To transmit an echo protect tone. 0 To transmit an echo protect tone. To adjust NL equaliser, Set service data #2MENU Parameter No. 05 to ON. To reduce the start speed of transmission. Reduce the transmission speed, by changing user data [SYSTEM SET- TINGS] [TX START SPEED].
  • Page 164 Prevent echoes, using SW03 of #1 SSSW. an echo. Pause for a relatively long time after the tel- ephone number, when requesting auto dial, so that the machine will not respond to the first DIS. TSM Océ 3121/3122 FAX related error codes...
  • Page 165 ##101 (trans/recep) The modem speed of the machine doe not match that of the other party. Main cause Action (during transmission) The modem speed of the machine doe not No corrective action is available. (Some machines do not offer certain communication match that of the other party.
  • Page 166 Pause for a relatively long time after the tel- ephone number, when requesting auto dial, so that the machine will not respond to the first DIS. Ask the other party to decrease the level of transmission. TSM Océ 3121/3122 FAX related error codes...
  • Page 167 ##106 (reception) The protocol signal is not received for 6 seconds, during recep- tion. Main cause Action The line condition is poor. Preventing cor- Ask the other party to decrease the level of rect reception of the protocol signal. transmission, permitting correct receipt of the protocol signal.
  • Page 168 #111 (trans/recep) A memory error has occurred. Main cause Action Due to noise, an error occurred during the Print all data, delete it, and store it once printing of data stored in image memory. again. TSM Océ 3121/3122 FAX related error codes...
  • Page 169 #114 (recep) RTN has been received during reception. Main cause Action The line condition is poor. Preventing cor- Ask the other party to increase the level of rect reception of the image signals. transmission, permitting correct receipt of the image signals. Ask the other party to decrease the start speed of the transmission.
  • Page 170 Ask the other party to decrease the start speed of the transmission. Adjust the NL equaliser. Permitting correct receipt of the signals. Loosen the transmission conditions, using 02 through 04 of #3 NUMERIC Parameters. TSM Océ 3121/3122 FAX related error codes...
  • Page 171 ##204 (trans) DTC was received in the absence of transmission data. Transmission data is absent, even though DIS has been received. after transmitting image data in abbreviated procedure 2 of direct transmission. Main cause Action (if during DTC reception) Record the communication procedure There is an error in the protocol signal.
  • Page 172 ##261 (trans/recep) A system error has occurred in the modem, or the gate array. Main cause Action The internal unit has a fault. When RS is set Replace the modem PBA. to 1, CS will not change to 1. Replace the system control PBA. TSM Océ 3121/3122 FAX related error codes...
  • Page 173 ##280 (trans) The number of times that the protocol signal has been transmitted during transmission has exceeded the limit. Main cause Action The level of transmission is too low. The Increase the level of transmission of the mo- other machine cannot correctly receive the dem, using parameter 07 of #2 MENU.
  • Page 174 ##290 (trans) A signal, other than PIN, RIP, MCF, RTP, or RTN, has been received after transmitting MPS during transmission. Main cause Action There is an error in the protocol signal. Record the communication procedure on DAT, for analysis by a technical centre. TSM Océ 3121/3122 FAX related error codes...
  • Page 175 ##750 (trans) The appropriate signal could not be received, after transmitting PPS-NULL during ECM transmission. And, the number of times that the protocol signal was transmitted exceeded the limit. Main cause Action The line condition is poor. Preventing trans- Increase the level of transmission of the mo- mission of PPS-NULL.
  • Page 176 Increase the level of transmission of the mo- rect reception of the PPS-MPS signal. dem, using parameter 07 of #2 MENU. Per- Stop has been pressed during communica- mitting correct receipt of the PPS-MPS tion. signal. Try transmission once again. TSM Océ 3121/3122 FAX related error codes...
  • Page 177 ##758 (trans) T5 time out (60 seconds) has occurred. Or, the number of times the protocol signal has been sent has exceeded the limit in ECM transmission after transmitting PPS-MPS. Main cause Action The page buffer of the other machine is full Increase the T5 timer setting, to avoid an er- or busy.
  • Page 178 The line condition is poor. PPS-EOM has been transmitted, PPR has been received four times, CTC has been transmitted. But, the other machine cannot receive the appro- priate signal. TSM Océ 3121/3122 FAX related error codes...
  • Page 179 ##765 (recep) The appropriate signal could not be received, after transmitting PPS-EOP during ECM transmission. And, the number of times that the protocol sig- nal was transmitted exceeded the limit. Main cause Action The line condition is poor. Preventing cor- Increase the level of transmission.
  • Page 180 Permitting correct receipt of the signals. The line condition is poor. PPR has been transmitted, PPR has been received four times, CTC has been transmitted. But, the machine cannot receive the appropriate sig- nal. TSM Océ 3121/3122 FAX related error codes...
  • Page 181 ##770 (trans) The appropriate signal could not be received, after transmitting EOR-NULL during ECM transmission. And, the number of times that the protocol signal was transmitted exceeded the limit. Main cause Action The line condition is poor. Preventing cor- Increase the level of transmission. Permit- rect reception of the EOR-NULL signal.
  • Page 182 The line condition is poor. Preventing cor- Increase the level of transmission. Permit- rect reception of the EOR-MPS signal. ting correct receipt of the EOR-MPS signal. Stop has been pressed during communica- Try transmission once again. tion. TSM Océ 3121/3122 FAX related error codes...
  • Page 183 ##778 (trans) T5 time out (60 seconds) has occurred. Or, the number of times the protocol signal has been sent has exceeded the limit in ECM transmission after transmitting EOR-MPS. Main cause Action The page buffer of the other machine is full Increase the T5 timer setting, to avoid an er- or busy.
  • Page 184 DIS. Ask the other party to decrease the level of transmission, so that it will not receive ech- oes. TSM Océ 3121/3122 FAX related error codes...
  • Page 185 ##785 (trans) The appropriate signal could not be received, after transmitting EOR-EOP during ECM transmission. And, the number of times that the protocol signal was transmitted exceeded the limit. Main cause Action The line condition is poor. Preventing cor- Increase the level of transmission. Permit- rect reception of the EOR-EOP signal.
  • Page 186 Ask the other party to decrease the start cause of a CFR echo. speed of the transmission. Ask the other party to increase the level of transmission, permitting correct receipt of the signals. Prevent echoes, using SW03 of #1 SSSW. TSM Océ 3121/3122 FAX related error codes...
  • Page 187 ##795 (trans/recep) An error has occurred in the decoding processing, during com- munication. Main cause Action The coding mechanisms for communication Switch OFF, then ON. are occupied. Replace the system control PBA. ##799 (trans) A system error has occurred. Main cause Action An attempt was made to transmit EOR: as a Switch OFF, then ON.
  • Page 188 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 GENERAL...
  • Page 189 Contents General operation 1 System 1 2 Nomenclature 2 3 Image Formation 4 4 Auxiliary Process 10 5 High voltage system 10 ed.1 General operation...

  • Page 190: General Operation

    General operation 1 System Principle of operation The following optionals can be added to the machine configuration: FAX PBA Printer PBA Sorter SCSI PBA FAX Motherboard PBA CORE/IP PBA Protocol control PBA System motherboard PBA 1st copying In this mode, specific jobs of the copier, fax, or printer are executed continu- ously.

  • Page 191: Nomenclature

    Quick start mode Anti-condensation function ON SLEEP 2 (bottom): Power saving mode Anti-condensation function OFF Switch for the cassette heater (option- SLEEP 1 Service-mode switch SLEEP 2 Counter (total) Counter (prints) Contrast control for LCD display TSM Océ 3121 General operation...
  • Page 192 Cross-section 9 10 11 12 13 14 15 16 1 Mirror 3 Cassette pick-up (upper) 2 Mirror 2 Cassette 2: separation roller 3 Mirror 1 Cassette 2: feeding roller 4 Scanning lamp (fluorescent lamp) Cassette 2: pick-up roller 5 Laser unit Cassette 1: separation roller 6 OPC cleaning unit Cassette 1: feeding roller...

  • Page 193: Image Formation

    3 Image Formation Outline The Océ 3121 employs an indirect photographic method of reproduction. Copyboard glass Scanning lamp Lens Image processing assembly Primary charging Laser scanner assembly roller Developing assembly Pre-exposure lamp Drum unit assembly Copy paper Copy paper Fixing assembly...
  • Page 194 Pre-exposure Charging (AC + negative DC) laser exposure Development (AC + negative DC bias) Transfer (positive DC) Separation (negative DC) Fusing OPC cleaning The OPC has a layer construction. The outer layer is a photo-conductive layer of OPC. The inner layer is a conductive aluminium substrate. photoconductive layer Photoconductive layer substrate...
  • Page 195 A laser beam, containing the darker areas of the document image, is directed onto the surface of the OPC. This neutralises the charges. The areas of this la- ser image on the OPC will later attract toner, during the development phase. TSM Océ 3121 General operation...
  • Page 196 The Océ 3121 deposits toner over the areas on the surface of the drum whose charges have been neutralised by a laser beam (light areas); for this reason, the polarity of the toner is negative, which is the same as the polarity of primary charging.
  • Page 197 OPC to the copy paper. The Océ 3121 uses a roller transfer method, which requires less transfer volt- age than a corona transfer method and generates virtually no ozone.
  • Page 198 Fusing Main thermistor (TH1) main thermistor (TH1) sub thermistor (TH2) Sub thermistor (TH2) fixing film Fixing film fixing heater Fixing heater toner Toner fixing cleaning Fixing lower fixing roller copy paper Lower fixing roller Copy paper roller cleaning roller After separation, the copy paper is passed between the fusing film and the fuser roller.

  • Page 199: Auxiliary Process

    The power supply PBA also incorporates the circuits for the lamp regulation and for the control of the power supply for the lamp. composite power supply primary charging roller developing unit drum HVT circuit transfer guide static lower fix- transfer roller elimi- ing roller nator TSM Océ 3121 General operation...
  • Page 200 Timing of operations Main power Copy Start Control panel power supply ON key ON supply OFF SCFW INTR1 STBY INTR2 LSTR STBY SLEEP SCFW Main motor (M1) Fixing heater (H4) HPsearch Scanner motor (M2) Scanner home position sensor (PS1) Scanning lamp (FL1) Vertical path roller paper sensor (PS8) Registration clutch (CL1) Primary charging roller bias DC component...
  • Page 201 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 01 PHOTOCONDUCTOR...
  • Page 202 Contents Dis-/assembly 1 Replacing the OPC unit 401 Functional description 1 Resistance of the OPC drum 501 ed.1 01 Photoconductor...
  • Page 203 Dis-/assembly 1 Replacing the OPC unit When you replace the OPC, record the date and the latest counter reading on the label. Attach the label to the front cover of the new OPC. ed.1 01 Photoconductor 401...
  • Page 204 Functional description 1 Resistance of the OPC drum The resistance of the OPC tends to decrease as time elapses. The Océ 3121 makes use of this phenomenon to determine the deterioration of the drum. To measure the resistance, the surface of the OPC is charged to a uniform level at a specific voltage (DC + AC).
  • Page 205 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 02 CHARGING...
  • Page 206 Contents Functional description 1 Limiting the charging bias 501 2 Roller cleaning 503 ed.1 02 Charging...
  • Page 207 Functional description 1 Limiting the charging bias Outline The bias for the charging roller is controlled by the power supply PBA, follow- ing the instructions from the DC control PBA. In addition, an AC bias is applied to the charging roller to ensure stable charg- ing.
  • Page 208 The CPU and the DC control PBA compute the data, and the results are sent to the power supply PBA in serial communication mode. The power supply PBA, in response, uses the data to determine the DC charge level. TSM Océ 3121 Functional description...
  • Page 209 2 Roller cleaning Outline The copier is equipped to automatically clean the charging roller. Solenoid (SL1) is switched ON, while the charging roller is rotating, to move the cleaning pad against the charging roller. The cleaning pad oscillates in the axial direction of the charging roller.
  • Page 210 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 04 EXPOSURE...
  • Page 211 Contents Dis-/assembly 1 Removing the Scanner Motor 401 2 Removing the Scanner Cable 402 3 Routing the Scanner Cable 404 4 Preparing the tool for the positioning of the mirror 405 5 Adjusting the position of the mirror 406 6 Replacing the exposure lamp 407 7 Replacing the CCD Unit 409 8 Removing the Fan Duct 1 410 9 Replacing the Laser Unit 411...

  • Page 212: Dis-/Assembly

    Dis-/assembly 1 Removing the Scanner Motor Remove the rear cover (4 screws). Remove the flywheel (3 screws). Detach the spring (3) and remove the scanner motor (1) (3 screws). ed.1 04 Exposure 401...

  • Page 213: Removing The Scanner Cable

    The rear covers, the right cover and the left cover. Remove the metal clamps (1) (front and rear) from the scanner cable. Release the front cable spring (2) and the rear cable spring (2) screws (3). TSM Océ 3121 Dis-/assembly...
  • Page 214 Loosen the set screw (4), and remove the cable (front and rear). ed.1 04 Exposure 403...

  • Page 215: Routing The Scanner Cable

    Place the steel ball into the pulley hole. Wind the cable 3.5 times toward the inside Pulley and 6 times toward sleeve the outside. Prepare the tool for Then, snap on the positioning of the pulley the mirror. sleeve. Steel ball TSM Océ 3121 Dis-/assembly...

  • Page 216: Preparing The Tool For The Positioning Of The Mirror

    4 Preparing the tool for the positioning of the mirror Before using the positioning tool, the arrangement of the pins needs to be set. The figures show the positions (1), (2) and (3) for the pins and A, B, and C. (the pins arranged for the front of the machine) The arrangement of the pins for the front and the rear of the machine.

  • Page 217: Adjusting The Position Of The Mirror

    Fit the positioning tool to the mirror support No. 1 and to the mirror support No. 2.(Both front and rear). For rear Mirror support No. 1 For front Mirror supports No. 2 & 3 Tighten the set screw of the pulley. Remove the tools. TSM Océ 3121 Dis-/assembly...

  • Page 218: Replacing The Exposure Lamp

    6 Replacing the exposure lamp Warning: 1) Ensure that the surface of the exposure lamp has cooled before starting the work. 2) Do not leave fingerprints on the surface of the exposure lamp. (in partic- ular, on the transparent side). 3) If the surface of the exposure lamp is soiled, wipe it with a clean, dry cloth.
  • Page 219 2) Keep the transparent side of the lamp facing the reflector. 3) Do not touch the transparent side of the lamp. Transparent side of the lamp Reflector Execute: ‘* 4 *; FUNCTION’: 12: ‘R & D SHADING’. TSM Océ 3121 Dis-/assembly...

  • Page 220: Replacing The Ccd Unit

    7 Replacing the CCD Unit Disconnect the mains supply cable. Remove the platen. Remove the CCD cover (1). Remove the screw that holds the document-size sensor (2), and move the sen- sor away from the CCD unit. Remove the retaining spring (3) that holds the CCD unit (1 screw). Disconnect the connector (4).

  • Page 221: Removing The Fan Duct 1

    Remove the rear cover (4 screws). Remove the cooling fan. Remove the flywheel (3 screws). Release the clips, and remove the cable guide. Remove the fan duct (1) by sliding it to the left (2 screws). TSM Océ 3121 Dis-/assembly...

  • Page 222: Replacing The Laser Unit

    9 Replacing the Laser Unit Remove the rear cover, and fan duct. Remove the platen, the CCD cover, the IP cover, and the IP PBA. Remove the fan duct 2 (1), by sliding it to the rear. Release the clips, and remove the cable guide (3). Remove the cable (4), and the five screws (5).

  • Page 223: Replacing The Analogue Processor Pba

    If you replace the analogue processor PBA, (part of the CCD unit) you Note: must execute (*4* Function 03 Shading Auto Start) 11 Standard white plate If you replace the standard white plate, you must execute (*4* Function Note: 13 R&D Shading Start). TSM Océ 3121 Dis-/assembly...

  • Page 224: Functional Description

    Functional description 1 The Document Exposure System Outline The document exposure system refers to the illumination of a document, and the projection of the reflected image onto the CCD. Document exposure system Original exposure system Scanning lamp Scanning lamp mirror 2 number 2 mirror mirror 1 number 1 mirror...
  • Page 225 (reduction), when writing into line memory. Or reading a multiple number of times (enlargement), when reading from the line memory. The reproduction ratio in the reverse direction is changed by moving the mirror faster (reduction) or slower (enlargement). TSM Océ 3121 Functional description...

  • Page 226: Scanner Motor

    3 Scanner Motor Outline The scanner motor (M2) is a stepping motor. The motor is controlled by the DC control PBA. The CPU on the DC control PBA transmits signals through the I/O circuit to the motor controller PBA. The signals are: clockwise rotation (moving the scanner forward), counter-clockwise rotation (moving the scanner in reverse), and rotation speed.

  • Page 227: Controlling The Exposure Lamp

    Copy button. Preheating may be initial preheating or exposure lamp ON preheating. Initial Preheating Power is applied during initial rotation. Preheating in ON situation Power is applied during the copying operation. TSM Océ 3121 Functional description...
  • Page 228 Switching the exposure lamp ON and OFF The exposure lamp is switched ON and OFF by the lamp ON signal (FLPWM). The signal is from the DC control PBA. The FLPWM signal is sent to the logic circuit together with the MPCLK (pulse signals), generated by the power supply PBA.

  • Page 229: Identifying The Size Of Documents

    When the platen cover is lowered to approximately 30°, the sensor (PS3), lo- cated at the rear of the copier, is switched ON. The vane interrupts the light beam to PS3. TSM Océ 3121 Functional description...
  • Page 230 The output level of each sensor is read for 15 seconds. Or, when the platen cov- er is down, at intervals of 0.128 seconds until the copy button is pressed. If the output level remains unchanged during the period, a document is presumed to be present at the sensor position.
  • Page 231 The size is de- termined when the document is picked up. The applicable sizes are any of the default sizes, as follows: A-configuration: A5, A4, A4R, A3. B-configuration: B5, B5R, B4. Inch-configuration: STMT, LTR, LTRR, FOOLSCAP, LGL, 11”x17”. TSM Océ 3121 Functional description...

  • Page 232: Laser Exposure System

    Laser Exposure System 1 Laser Processing Unit Outline The main components of the laser unit are: a laser unit, as the source of laser beams a scanner motor, which is equipped with a 6-facet mirror a BD detection PBA, for the detection of the laser beams. The laser beam generated by the laser unit is directed to the 6-facet mirror.
  • Page 233 Document exposure system Exposure lamp mirror 2 mirror 1 Lens Analogue processor mirror 3 Image processing system Image Processor CORE/IP PBA Print- Laser Laser beam Laser driver Laser Mirror Laser exposure system drum outline TSM Océ 3121 Laser Exposure System...
  • Page 234 Image processor PBA Image processor PCB DC control PBA DC controller PCB Laser motor Laser scanner motor 6-facet mirror 6-facet mirror Laser scanner Laser scanner Imaging BD PBA BD PCB Imaging motor drive PBA motor drive PCB lens lens Laser mirror Laser unit Laser mirror Laser unit...
  • Page 235 This determines the value of the laser bias current. This laser bias current is varied continuously to com- pensate for the changes in temperature, so ensuring a specific output. TSM Océ 3121 Laser Exposure System...
  • Page 236 This procedure occurs several times during each signal line of scanning. Laser driver PBA Sample Laser driver PCB Sample hold signal (SH) signal (SH) Intensity selec- Intensity selection tion signal 0 signal 0 (SW0) Intensity selec- Setting cir- Intensity selection tion signal 1 cuit for the Laser intensity...
  • Page 237 Laser scanner motor drive PBA DC controller PCB Laser scanner motor drive PCB 24VU 24VU Laser Laser scanner scanner motor motor Motor drive (M3) Motor drive (M3) circuit circuit Hall IC Hall IC LOCK output LOCK output TSM Océ 3121 Laser Exposure System...
  • Page 238 Switching the Laser Scanner Motor ON and OFF The timing of the start of the laser scanner motor (M3) varies in accordance with the setting of the ‘time to quiet mode’. This is set (in user mode) to ‘1–9’ or ‘0’. If the time is set to ‘1–9’, rotation starts when the following occurs during stand-by: a button is pressed...
  • Page 239 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 05 DEVELOPING...
  • Page 240 Contents Adjustments 1 Adjusting the doctor blade 301 Dis-/assembly 1 Developing Clutch 401 2 Removing the Toner Sensor 402 3 Blade Mount 403 4 The position of the magnetic seal in the developing unit 404 Functional description 1 Controlling the Developing Bias 501 2 The cleaner in the developing unit 503 ed.1 05 Developing...

  • Page 241: Adjusting The Doctor Blade

    Adjustments 1 Adjusting the doctor blade This is a factory adjustment. Blade Blade approx 0.21mm 0.21±0.03mm Developing cylinder Developing cylinder The gap between the developing roller and the doctor blade is adjusted Note: in the factory (high precision). Do not try to adjust it in the field. ed.1 05 Developing 301...
  • Page 242 TSM Océ 3121 Adjustments...

  • Page 243: Dis-/Assembly

    Dis-/assembly 1 Developing Clutch Remove the following: rear cover (4 screws), flywheel (3 screws), and the cable clip (high-voltage cable). Disconnect the connector (3), and remove the developing clutch (2 screws). ed.1 05 Developing 401...

  • Page 244: Removing The Toner Sensor

    Remove the developing unit. Remove the screw (2). Disengage the hook (3). Then, remove the grip (1) from the developing unit. Remove the two screws (4) . Disconnect the connector (5), and take out the ton- er sensor. TSM Océ 3121 Dis-/assembly...

  • Page 245: Blade Mount

    3 Blade Mount Disengage the four fasteners (3). Remove the two screws (2) and take off the cover (1). Remove the two screws (5) , and remove the blade mount (4). ed.1 05 Developing 403...

  • Page 246: The Position Of The Magnetic Seal In The Developing Unit

    When fitting the magnetic seal, hold it firmly against the opening. Ensure that the magnetic seal and the housing are in firm contact. Magnetic seal Magnetic seal Opening (reference for Magnetic seal Opening Magnetic seal butting) (Rear) (Front) (reference for butting) (rear) (front) TSM Océ 3121 Dis-/assembly...

  • Page 247: Functional Description

    Functional description 1 Controlling the Developing Bias Outline The circuit for the control of the developing bias, on the power supply PBA , has the following functions: Switching the AC developing bias ON and OFF. Switching the DC developing bias ON and OFF. Limiting the DC developing bias to a specific voltage.
  • Page 248 Then, varying the bias DC to maintain correct gradation. To compensate for variations in the OPC, the control is carried out according to a specific timing. (with AGS measurement to increase the developing bias). TSM Océ 3121 Functional description...

  • Page 249: The Cleaner In The Developing Unit

    2 The cleaner in the developing unit Outline The developing unit is locked mechanically by the locking levers on each of the developing rails. The drive from the main motor rotates the following: the developing roller, the stirring rod in the developing unit, the rotary blade inside the drum cleaner.
  • Page 250 T2. Based on the results, the absence of toner is assumed for the following: (T1 + T2) > 20 seconds: toner absent, level 1 (T1) or (T2) > 160 seconds: toner absent, level 2 TSM Océ 3121 Functional description...
  • Page 251 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 06 TRANSFER...
  • Page 252 Contents Adjustments 1 Adjusting the bias for the transfer roller 301 Functional description 1 Transfer 501 2 Controlling the bias to the transfer roller 502 3 Controlling the bias for the transfer roller 504 4 Controlling the bias for the Static Eliminator during separation 505 5 Controlling the bias for the transfer guide and the bias for the fixing roller ed.1 06 Transfer...

  • Page 253: Adjusting The Bias For The Transfer Roller

    Adjustments 1 Adjusting the bias for the transfer roller If image faults occur, as a result of an incorrect transfer charging roller bias, the transfer bias may be adjusted. Carry out ‘TRN-1’, ‘TRN-2TS’, or ‘TRN-20L’ in service mode (*3*; ADJUST). An image fault may be any of the following: Background is noted in the margin along the trailing edge, because of stray to- ner.

  • Page 254: Functional Description

    Functional description 1 Transfer Transfer guide Transfer guide Transfer Transfer roller roller The transfer roller applies a positive charge to the rear of the copy paper. This is to transfer the toner image from the surface of the OPC to the copy paper. A roller transfer method is employed.

  • Page 255: Controlling The Bias To The Transfer Roller

    24VR T101 drive Overcurrent circuit detection Q605 J209-B4 J209-B5 J209-A4~A9 J102-B7 J102-A1~A7 J102-B6 IC101 DC controller PCB Transfer Bias This positive bias is used to transfer the image from the OPC to the copy paper. TSM Océ 3121 Functional description...
  • Page 256 Cleaning Bias As the machine uses direct transfer, toner from the OPC could stick to the transfer roller (because of a jam). To counteract this, a negative voltage is ap- plied. This returns the toner from the transfer roller to the OPC: During the initial rotation, after a press on the Copy button.

  • Page 257: Controlling The Bias For The Transfer Roller

    The bias for the transfer roller bias is switched ON and OFF by the transfer bias control signal (TFWPWM) and the transfer bias ON signal (TFWON). When the TFWON signal is ‘0’, the transformer T502 switches ON. TSM Océ 3121 Functional description...

  • Page 258: Controlling The Bias For The Static Eliminator During Separation

    4 Controlling the bias for the Static Eliminator during separation Switching ON and OFF the bias for the static eliminator The CPU (Q605) on the power supply PBA, receives the separation static elim- inator ON signal (SEBON). This causes the separation static eliminator bias drive circuit to apply a bias to the static eliminator.

  • Page 259: Controlling The Bias For The Transfer Guide And The Bias For The Fixing Roller

    Pay attention to the orientation of the lower roller if you have removed it. Fixing Photosensitive drum assembly Composite power supply PCB T101 Transfer guide T101 drive circuit Q605 J209-A4~A9 J102-A4~A7 DC controller PCB IC101 TSM Océ 3121 Functional description...
  • Page 260 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 07 CLEANING...
  • Page 261 Contents Functional description 1 Waste Toner 501 ed.1 07 Cleaning...
  • Page 262 Functional description 1 Waste Toner The waste toner that has been scraped by the cleaning blade is moved away to the waste container at the rear. The toner is moved by the rotary blade situated below the drum cleaner. The drive claw is pushed against the rotary blade by a spring. This transmits the drive of the main motor to rotate the blade.
  • Page 263 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 08 IMAGE PROCESSING...
  • Page 264 Contents Dis-/assembly 1 Replacing the IP PBA 401 2 IP software update 403 Functional description 1 Image Processing 501 2 Analogue Image Processing 503 3 Digital Image Processing 505 ed.1 08 Image processing...

  • Page 265: Dis-/Assembly

    Dis-/assembly 1 Replacing the IP PBA Disassembly Before you disassemble the IP PBA: Use (*4* Function 18 PRM_PRNT) to print out all registration data (one touch dialing, speed dialing, user data list, etc; these are important if the ma- chine is equipped with the fax PBA). Take notes of the settings in user mode and others.
  • Page 266 Execute (*4* Function 03 Auto Shading Start). Execute (*4* Function 04 PD Print). Execute (*4* Function 05 200 PWM Print). Execute (*4* Function 06 600 PWM Print). Enter the relevant settings/values under (*5* Options) and in user mode. TSM Océ 3121 Dis-/assembly...

  • Page 267: Ip Software Update

    2 IP software update The software for the image processing system resides in two flash ROM’s (IC103 and IC104). These are of the DIMM-type (Dual In-line Memory Mod- ule). There are two ways to update the system software: By replacing the flash ROM. By downloading new software to the existing flash ROM.
  • Page 268 Holding it at an angle, insert the new flash ROM into the slot. Press flash ROM downwards, Press it down until “click’ is heard. Refit the removed covers. Connect the mains supply cable. Then, switch ON. TSM Océ 3121 Dis-/assembly...
  • Page 269 A diskette with the new system software installed A RS232C null-modem cable. If the download utility, and the Océ 3121 system software are already installed on your laptop, then continue with step 8. Insert the diskette with the download programme in your laptop.
  • Page 270 The next step is to install the file with the new system software for the image processor. Initially, you will have this file on a floppy, in a compressed format. You must use the following procedure to install it on your PC. TSM Océ 3121 Dis-/assembly...
  • Page 271 Start the download programme. You can use the [Start] button in Windows 95. Select then [Programs] -> [Download] -> [Download]. The next dialog box will appear Select the baud rate to 19200 bps. Then click [OK]. Click [Save ROM Image: Click [Create File]: ed.1 08 Image processing 407...
  • Page 272 When all is correct, the files will be extracted and installed on your PC. You will return to the [Create File] menu. Next, you will connect the PC to the copier: with the null-modem cable. TSM Océ 3121 Dis-/assembly...
  • Page 273 Shut down and switch off the PC and the copier. Connect the null-modem cable to the COM-port of your PC and to the service connector of the copier. Cover Switch on the copier and enable service mode. Select (*5* Option 2 > Baud rate). Put this on “0”. This specifies 19200 bps. Then set the copier in downloading mode: Use (*4* Function 13).
  • Page 274 The next instruction will appear, click [OK]. The next screen appears, check if the device name is as shown. Then click [Se- lect File]. Then click on the appropriate file and click [Select]. TSM Océ 3121 Dis-/assembly...
  • Page 275 Ensure that the confirmation is correct: Start the download process by clicking on [START]: The next message will appear during the download process. This will last for 10 minutes (changing language) up to 60 minutes (complete system software download). Normal termination: ed.1 08 Image processing 411...
  • Page 276 After clicking [OK], the next instruction appears: Follow the instructions to finish the procedure. TSM Océ 3121 Dis-/assembly...

  • Page 277: Functional Description

    Functional description 1 Image Processing Outline The image processing system converts the optical image on the CCD into elec- trical signals (image signals) for correction and processing. The routing of the correction functions and processing functions. Analog processor Laser driver Image processor PCB conversion Image...
  • Page 278 Reproduction ratio processing tronic sorter) (for fax images and printer default transmission) FAX PBA Coding/decoding To the telephone line Rotation Protocol con- Protocol control troller PBA Protocol exchange (between printer PBA and Network Inter- face PBA) TSM Océ 3121 Functional description...

  • Page 279: Analogue Image Processing

    2 Analogue Image Processing Outline The Analogue processor PBA converts CCD drive signals and CCD output signals (Analogue signals) to digital signals. (It also executes AE measure- ment.) CCD/CCD Driver The copier’s CCD is a linear image sensor consisting of a single line of 7500 photocells.
  • Page 280 Identifies the A-D conversion circuit output signal level. Varies the reference voltage, based on the results of identification. The reference voltage obtained here is sent to the A-D conversion circuit. The “priority on speed” function can be adjusted in service mode (*3*). TSM Océ 3121 Functional description...

  • Page 281: Digital Image Processing

    3 Digital Image Processing Outline The digital image processing serves to process image signals from various PBA. Shading Correction The output of the CCD will not be constant for the following factors (even when the light reflected by a document with even density is projected to the CCD).
  • Page 282 The shading correction value is used to correct variations among CCD pixels that occur during the scanning. This is to ensure a specific image density level. TSM Océ 3121 Functional description...
  • Page 283 CCD output Characteristics after correction Target value Measurement data Characteris- tics before correction Exposure reference Document density strip Total Processing The total processing block handles the following: Reproduction ratio Shift Mirror image Slanting Repeat Folding Reproduction Ratio Horizontal Reproduction Ratio (forward scanning direction) When writing image data into memory, data units may be skipped for reduc- tion.
  • Page 284 Shift Processing Samples of image shifting, and conceptual outlines of shifting in the forward scanning direction and in the reverse scanning direction. TSM Océ 3121 Functional description...
  • Page 285 Shift in the reverse scanning direction <Document> Shaft in main scanning direction <Original> The forward scanning Main scanning <Copy> <Copy> direction --> direction a b c a b c a b c Principle When data for a single scanning line is read Principle : When data for a single scanning line is from line memory, reading starts with a midway read from line memory, reading is started...
  • Page 286 25% and 800%. Shift processing and overlay processing are controlled as explained on the next page. The table shows which modes are available in relation to different com- binations of the RDF and the duplexing unit. TSM Océ 3121 Functional description...
  • Page 287 Mode Duplexing Lengthwise Widthwise unit ratio ratio 2-on-1 Required Not required (overlay) 2-on-1 Not required Required (continuous) 2-on-1 Required Required (two-sided) 4-on-1 Not required Not required 2-on-1 mode Document (A4 x 2) Copy (A4R x 1) (continuous, two-sided) Mode Orientation of docu- Image after copy- Remarks ments on the platen...
  • Page 288 Book mode Document Copy Combines the following: Reduced copying Image shifting Overlay copying copying copying copying copying RDF in use Document Copy Combines the following: Reduced copying Image shifting Overlay copying copying copying copying copying TSM Océ 3121 Functional description...
  • Page 289 4-on-1 4 documents (A4) 1 copy (A4) Mode Copying Orientation of Image after cop- Remarks the documents ying (arrow indi- on the platen cating the feeding direction Book mode 1st copying Document Copy Combines the follow- ing: Reduced copying Image shifting Overlay copying 2nd copying Document Copy...
  • Page 290 2) 1-on-2 two-sided --> One sided 2) 1-on-2 two-sided One sided Back Face Face Back The image (document width) of continuous 2-on-1 is divided vertically for output. The document (document length) is divided horizontally for output. TSM Océ 3121 Functional description...
  • Page 291 4-on-1, Generating 4 Outputs Outputs Document Original Output 4 + 3 + 2 + 1 No number of effective areas of the last document is specified; i.e., if section 4 of the document is blank, output 4 will be blank. 4-on-1 Two-Sided, Generating 8 Outputs Outputs Document...
  • Page 292 Thereby slanting S. A specific image is repeated by re- the image. peating these operations. Address Address 1 pixel (1 bye) 1 pixel (1 byte) Reading 1st line Reading 2nd line 3rd line 4th line TSM Océ 3121 Functional description...
  • Page 293 Sharpness/Filter Processing In sharpness/filter processing, computations are performed so that a crisp or soft image may be obtained as specified on the control panel. Figure B shows the output level occurring as the result of selecting ‘sharpness mode weak’ for the image data shown in figure A. In ‘sharpness mode weak’, the variations in the density of an image are smoothed out to generate a soft image.
  • Page 294 When image data input is as shown in figure F, the CPU assumes the presence of a photo and does not initiate outline processing. Black Main scanning direction White Negative/Positive Reversal The negative/positive reversal circuit executes the following image processing: Negative/positive reversal Framing Blanking Pasting TSM Océ 3121 Functional description...
  • Page 295 a) Negative/Positive Reversal Level conversion is executed so that the white area of a document will be black and the black area will be white on copies. Output level (Document) (Copy) Input level b) Framing/Blanking For framing/blanking, areas may be as many as 4 areas; for a rectangle, as many as 10 points may be specified.
  • Page 296 The relationship between the density as perceived by the naked eye and the output of the CCD are as shown. CCD output Black White Density of document To correct the discrepancy, the correction curve is used to execute level conver- sion. Output level Input level TSM Océ 3121 Functional description...
  • Page 297 b) Density Processing The correction curve for density processing varies according to the following: Setting of the Copy Density key on the control panel. Results of AE measurement Selection of text and photo mode, or photo mode Results of OPC resistance According to the setting of the Copy Density, the curve will be for darker or lighter: see figure A.
  • Page 298 Binary processing is executed in text mode, and text and photo mode. D-A Conversion The D-A conversion circuit is used to convert multiple-value image signals into analogue signals. D-A conversion is executed in photo mode. TSM Océ 3121 Functional description...
  • Page 299 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 10 RDF...
  • Page 300 Contents Adjustments 1 Adjusting the RDF Switch (MS1) 301 2 Switch (MS2) for the upper cover 302 3 Adjusting the height of the RDF 302 4 Adjusting the Solenoid SL2 303 5 Adjusting the Solenoid SL3 305 6 Adjusting the document width (VR1) 305 7 Parallel transport 2 307 8 Adjusting the parallel transport 2 309 9 Adjusting the transport distance 311...
  • Page 301 18 Reversing guide 431 19 Removing the stop solenoid 434 20 Fixing the stop solenoid 434 21 Stamping Solenoid SL4 435 22 Feeding Belt 438 23 Cleaning the belt 440 24 Sensors 440 25 Cleaning the sensor S1 441 TSM Océ 3121 Contents...
  • Page 302 Functional description 1 Features 501 2 Specifications 502 3 Nomenclature 504 4 Operation 506 5 Functional design 508 6 Communication with the copier 509 7 Inputs to the RDF Control PBA 510 8 Outputs from the RDF Control PBA 512 9 Principle of operation 513 10 Checking the quality of the documents 519 11 Pick-up of documents for copying 526...

  • Page 303: Adjusting The Rdf Switch (Ms1)

    Adjustments 1 Adjusting the RDF Switch (MS1) Two micro-switches are fitted. These prevent operation of the RDF when Note: either the body is opened, or the upper cover is opened. MS1 monitors the body, MS2 monitors the upper cover. As a rule, skip the following adjustment; make adjustments only when neces- sary.

  • Page 304: Switch (Ms2) For The Upper Cover

    + 0.1 mm a=0.2+0.1mm Horizontal ument guide size plate Copier Copier Rear cover Rear cover Platen Copyboard glass (copier) Bolt Bolt (copier) Also, at the front, check that both of the rubber feet are touching the platen glass. TSM Océ 3121 Adjustments...

  • Page 305: Adjusting The Solenoid Sl2

    4 Adjusting the Solenoid SL2 Prepare a test sheet. Cut a sheet of A4 or LTR copy paper (64 g/m2) lengthways into strips of about 70 mm wide. 70 mm (approx.) Vertical direction Remove the front cover and remove the cover from the RDF control PBA. Shift bit 5 and 6 to ON: DIP switch (DSW1) on the RDF control PBA.
  • Page 306 When the test sheet is pulled, the one-way clutch prevents the delivery Note: roller from rotating. If the delivery roller does not rotate when the test sheet is inserted, repeat the adjustment: starting with step 3. Shift the bits back to the initial positions: DIP switch DSW1. TSM Océ 3121 Adjustments...

  • Page 307: Adjusting The Solenoid Sl3

    5 Adjusting the Solenoid SL3 Remove the cover. Adjust the position of the solenoid (1), so that the stroke is 4.5 mm. 6 Adjusting the document width (VR1) Loosen the screw (2), and remove the side guide. Fully open the rear guide (3) and the front guide (4). ed.1 10 RDF 305...
  • Page 308 Fit the gear (5). Turn the width gear (6) fully counter-clockwise. Then, turn it clockwise (a half of a tooth). Equivalent of 1/2 tooth Fit the lock for the side guide. Adjust the document width. TSM Océ 3121 Adjustments...

  • Page 309: Parallel Transport 2

    7 Parallel transport 2 Parallel transport 2 Remove the RDF cover (1 screw). Cover Cover Screw Screw Shift bit 1 to ON: DIP switch (DSW1) on the RDF control PBA. LED1 LED2 SW1 SW3 DSW1 Place a sheet of A4 or 11”x 17” paper (80 g/m2) on the document tray. Press once on the switch (SW3) on the RDF control PBA.
  • Page 310 When turning the adjusting screw, force the hinge in the direction of the arrow Hinge (right) Adjusting screw Right support Turning the Adjusting Screw and l1 / l2 Rotation L1 and L2 Clockwise l1 < l2 Counter-clockwise l1 > l2 After adjustment, fix the adjusting screw with the nut. TSM Océ 3121 Adjustments...

  • Page 311: Adjusting The Parallel Transport 2

    8 Adjusting the parallel transport 2 Adjust the parallel transport 2 only after adjusting parallel transport. Note: Shift bit 1 to ON: DIP switch (DSW1) on the RDF control PBA. LED1 LED2 DSW1 SW1 SW3 Place a sheet of A3 or 11”x 17” paper (80 g/m2) on the document tray. Press once on the switch (SW3) on the RDF control PBA.
  • Page 312 RDF document tray. Adjust the position of the RDF document tray. delivery tray Fixing screw Fixing screw Positioning screw RDF Original Tray Movement and L3 Direction of movement L3 Decreases Increases After adjustment, tighten the screws securing the RDF document tray. TSM Océ 3121 Adjustments...

  • Page 313: Adjusting The Transport Distance

    9 Adjusting the transport distance Adjust the transport distance only after adjusting the parallel transport Note: 1 and the parallel transport 2. Copier mode Shift bits 1 and 4 to ON: DIP switch (DSW1) on the RDF control PBA. Place a sheet of A3 or 11”x 17” paper (80 g/m2) on the document tray. Press once on the switch (SW3) on the RDF control PBA.
  • Page 314 After pressing the switch SW1 five times, press once on switch SW3. The pa- per will be ejected and the value will be stored. Fax mode Shift bits 1, 4, and 5 to ON: DIP switch (DSW1) on the RDF control PBA. TSM Océ 3121 Adjustments...
  • Page 315 Place an A3 or 11” x 17” document (80 g/m2) on the document tray. Press once on the switch SW3 on the RDF control PBA. The paper will be picked up, and carried onto the platen. Open the RDF slowly, and measure the stop position l4 of the document; then, close the RDF slowly.

  • Page 316: Adjusting The Sheet Distance: In Image Composition Mode

    The paper will be picked up, and stopped on the platen. Open the RDF slowly, and measure the distance l5 between the two sheets of paper; then, close the RDF slowly. platen Paper Paper Standards: Sheet gap L5 = 0 ± 3 mm TSM Océ 3121 Adjustments...
  • Page 317 Use the switches SW1 and SW2 on the RDF control PBA to adjust the trans- port distance. Each press on the switch changes the sheet distance by 0.34 mm. When the position is appropriate, press once on the switch SW3. The paper will be ejected and the value will be stored.
  • Page 318 Switch ON. Check that the RDF functions correctly. Shift bit 7 to ON: DIP switch (DSW1). Only if the document size (length Note: in feeding direction) is as follows: RDF-configuration Document size (length in feeding direction) 220 to 250mm INCH 220 to 260mm TSM Océ 3121 Adjustments...

  • Page 319: Adjusting The Switch (Ms1)

    11 Adjusting the Switch (MS1) .Remove the cover. Open and close the RDF. Adjust the retaining plate (2) until switch MS1 (1) switches on and off when the lower edge of the RDF is between 10 and 100 mm from the platen. (1) RDF switch (MS1), (2) Retaining plate Right Hinge 10~100 mm...

  • Page 320: Adjusting The Pressure Of The Separation Belt

    Put a length of cellophane tape on both sides, and make a hole. 70 mm (approx.) Vertical direction paper(A4) 10 mm (approx.) Stick the tape on both sides Make a hole 70 mm (approx.) 35 mm 20 mm (approx.) 300 mm (approx.) TSM Océ 3121 Adjustments...
  • Page 321 Copier mode Remove the cover from the RDF control (1 screw). Screw Cover Shift bit 2 to ON: DIP switch (DSW1) on the RDF control PBA. Select the continuous pick-up and delivery mode. Switch ON. Place five to ten sheets of A4 LTR paper on the document tray. Press the switch SW3 on the RDF control PBA: to select continuous pick-up and delivery mode.
  • Page 322 Measuring the belt tension (front) Open the cover of the RDF. Loosen the lock nut (1). Turn the screw (2) until the correct tension is reached. Tighten the lock nut (1). glued to lock glued to lock TSM Océ 3121 Adjustments...
  • Page 323 Test sheet tension in gr. 64 g/m2 paper 520±20 80 g/m2 paper 570±20 Guide: the tension should be equal at the front and at the rear. Turning Tension Clockwise Decreases Counter-clockwise Increases Guide: A 90° turn of the adjusting screw changes the power of feeding by about 25 g.
  • Page 324 Upper cover Test sheet Gauge Centre While taking measurements, keep the trail- ing edge of the test sheet in line with the edge of the document tray. Spring gauge: range 0 - 600 g. Measuring the tension (centre ) TSM Océ 3121 Adjustments...
  • Page 325 Open the cover of the RDF. Loosen the lock nut (1). Turn the screw (2) until the correct tension is reached. Tighten the lock nut (1). glued to lock Test sheet tension in gr. 64 g/m2 paper 270±20 80 g/m2 paper 300±20 Tension Turning...

  • Page 326: Adjustment Of The Electrical System

    The document width detection (VR1). Adjusting the sensor (S1) in the document tray, and the registration sen- sor (S3) Remove the RDF cover. Shift bit 4 to ON : DIP switch (DSW1) on the RDF control PBA. TSM Océ 3121 Adjustments...
  • Page 327 With no document on the document tray, press the switch (SW3) on the RDF control PBA. LED 1 and 2 switch ON . On the RDF control PBA. If LED 1 and 2 fail to switch ON within 30 seconds, there is probably a fault in the sensor (S1), for document tray , or a fault on the RDF control PBA.
  • Page 328 LED1 and LED2 are on, on the RDF control PBA . The function test is fin- ished. If an error is found, LED1 and LED2 start to flash. Shift the bits back to the initial positions. DIP switch (DSW1). TSM Océ 3121 Adjustments...

  • Page 329: Location Of The Electrical Parts

    14 Location of the electrical Parts Motors, Solenoids, and Sensors LED 102 LED 101 ed.1 10 RDF 327...
  • Page 330 RDF open or closed Upper cover Photo-transistor Paper in the document tray Registration Sensor Upper cover Pick-up roller Delivery roller Pick-up Reversal Feeding clock Clock sensor Registration clock Delivery 2 Re-circulation LED101 Set indication LED 102 Set indication TSM Océ 3121 Adjustments...
  • Page 331 B.PCB Name Number Description RDF control PBA Controls the RDF Display PBA Indicates the presence of a document ed.1 10 RDF 329...

  • Page 332: Components On The Pba: Variable Resistors (Vr), Light-Emitting Diodes (Led), : Check Pins

    1.Some LED’s emit dim light when off because of leakage current; this is a nor- mal condition and should be kept in mind. 2.VRs that may be used in the field <symbol > Black VR VRs that must not be used in the field <symbol > White VR TSM Océ 3121 Adjustments...
  • Page 333 Display LED1 Use it to check the output of the original tray paper sensor. LED2 Use it to check the output of the registration sensor. LED on the RDF Control PBA Display TP1-1 TP1 -2 TP1 -3 TP1 -4 TP1 -5 Earth TP1 -6 Test Pins on the RDF Control PBA...
  • Page 334 ON, in FAX mode, puts a stamp mark during delivery. (fax mode) To execute the pick-up, to Each press on the switch (SW3) reversal, to delivery oper- repeats the pick-up, then the reversal ation and, finally, the delivery operations. (copier mode) TSM Océ 3121 Adjustments...
  • Page 335 Purpose DSW1 settings Description To adjust parallel trans- After a press on the switch (SW3), a port 1 document is fed and placed on the platen. Then, using the switches and SW2 , the parallel transport 1 is (copier mode) adjusted.

  • Page 336: Dis-/Assembly

    Dis-/assembly 1 External View (1) Upper cover; (2) Body cover; (3) Original tray; (4) Body front cover. Remove the covers as necessary when cleaning, checking, or repairing the ma- chine. ed.1 10 RDF 401...

  • Page 337: Removing The Rdf

    Standing at the rear of the copier, pull the RDF vertically to remove it. The hinge feet are equipped with a locking mechanism to prevent slip- Note: page. Open it fully, before removing it from the copier. TSM Océ 3121 Dis-/assembly...
  • Page 338 3 Removing the Body Cover Remove the seven screws (1). Remove the two screws (2), and remove the document tray (3). The original tray is connected with a cable. Take adequate care not Warning: to damage it during work. Remove the body cover and the body front cover. ed.1 10 RDF 403...

  • Page 339: Lock For The Side Guide

    Loosen the screw (4), and remove the lock. Plate Lock Screw Before making copies, make sure that the size guide is adjusted to the Warning: size of the original. If not set correctly, the originals tend to move askew. TSM Océ 3121 Dis-/assembly...

  • Page 340: Removing The Pick-Up Motor Unit

    5 Removing the Pick-Up Motor Unit Remove the cover. Remove the cable tie. Disconnect the connector J12 (2) from the RDF control PBA (1). Remove the screw (3), and remove the cable guide (4). Disconnect the connector (5) from the sensor (S4). Remove the two screws, and remove the pick-up motor (7).

  • Page 341: Removing The Feeding Motor

    Disconnect the connector J11 (2) from the RDF control PBA (1). Disconnect the connector (3) for sensor (S9) and remove the two screws (4). Detach the two drive belts (5), and remove the feeding motor (6). TSM Océ 3121 Dis-/assembly...

  • Page 342: Removing The Belt Motor

    7 Removing the belt motor Remove the RDF from the copier. Remove the feeding motor. Remove the cable tie. Remove the screw (1), and remove the cable clip (2). Remove the four screws (3), and remove the right hinge (4). ed.1 10 RDF 407...
  • Page 343 Remove the feeding motor. Disconnect the connectors J6(5), J7(6), and J13(7) from the RDF control PBA. Disconnect the connector (8) for the sensor (S10). TSM Océ 3121 Dis-/assembly...
  • Page 344 Using a scriber, mark the position of the belt motor (9). Remove the three screws (10). (10) (10) (10) Detach the belt (11) from the roller (12). Remove the belt motor (9). (11) (12) ed.1 10 RDF 409...

  • Page 345: Replacing The Belt Motor Unit

    ±1 mm, when the timing belt (1) is pressed down with a force of 200 ±20 g. Spring gauge: range 0 - 600 g. Pull the belt tensioner (4), with a force of 500 ±50 g, and fix it with the screw (5). Spring gauge: range 0 - 600 g. TSM Océ 3121 Dis-/assembly...

  • Page 346: Removing The Clutch Unit

    9 Removing the clutch unit Remove the belt motor (1). Detach the drive belt (2). Remove the E-ring (3). Slide the bush (4), in the direction of arrow A, and remove the clutch unit (5). When installing the clutch unit, make sure that the stop ring (6) is engaged with the stopper (7) of the mount.

  • Page 347: Pick-Up Roller Unit

    10 Pick-up roller unit Remove the cover. Remove the two screws (1). Remove the support (2). Remove the two screws, and remove the guide (4). TSM Océ 3121 Dis-/assembly...
  • Page 348 Remove the pick-up motor Remove the E-ring (5), and remove the gear (6). (Take care not to drop the pin). Remove the E-ring (7), and remove the bush (8). Remove the screw (10), and remove the solenoid (9). (10) ed.1 10 RDF 413...
  • Page 349 Detach the timing belt (11), and remove the E-ring (12) and the gear (13). (11) (13) (12) Remove the bush (14), and remove the pick-up roller (15). (14) (15) TSM Océ 3121 Dis-/assembly...

  • Page 350: Pick-Up Roller

    11 Pick-up roller Remove the cover. Remove the two screws (1). Remove the support (2). Remove the two screws (3), and remove the guide (4). Rotate the pick-up rollers (5), so that they are as shown. Then, remove the screws (6), and remove the pick-up rollers (5). ed.1 10 RDF 415...

  • Page 351: Separation Belt

    12 Separation Belt Remove the cover. Remove the drive belt (1). Remove the two screws (2) and remove the separation belt (3), together with the fixing plate (4). TSM Océ 3121 Dis-/assembly...

  • Page 352: Feeding Rollers

    13 Feeding Rollers Remove the cover. Remove the two screws (1). Remove the support (2). Remove the two screws (3) , and remove the guide (4). Remove the separation belt. Remove the four screws (5), and remove the guide plate (6). ed.1 10 RDF 417...
  • Page 353 Remove the E-ring (11), and remove the idler gear (12). Remove the E-ring (13), and remove the gear (14) and the timing belt (15). (Take care not to drop the pin.) (11) (15) (12)) (13) (14) TSM Océ 3121 Dis-/assembly...
  • Page 354 Remove the E-ring (16), and slide the arm (17) and the gear (18) inwards. (16) (17) (18) Remove the E-ring (19), and slide the bush (20) inwards. Then, remove the feeding roller (21). (21) (19) (20) ed.1 10 RDF 419...

  • Page 355: Registration Roller

    14 Registration roller Remove the RDF from the copier. Remove the cover. Remove the feeding roller. Remove the five screws (2), and remove the right hinge. Remove the E-ring (3), and remove the bush (4). TSM Océ 3121 Dis-/assembly...
  • Page 356 Remove the screw (5) , and remove the solenoid support (6). Detach the spring (7) and the screw (8). Then, remove the arm (9). ed.1 10 RDF 421...
  • Page 357 !0 !1 Remove the two screws (13), and remove the sensor support (14). (14) (13) Remove the following: E-ring (15), spring (16), bush (17), and the two screws (18) (16) (18) (17) (15) !7 !5 (18) TSM Océ 3121 Dis-/assembly...
  • Page 358 Remove the following: grip ring (19), disc (20), sensor support (21), and the spring (22) (21) (18) (20) (22) Remove the following: grip ring (23), spring (24), bushing (25), and two screws (26). Then, remove the registration roller (27). (25) (26) (24) (23)

  • Page 359: Delivery And Reversing Roller

    Remove the pick-up roller Remove the registration roller. Remove the following: E-ring (5), gear (6), timing belt (7), and bush (8). Remove the grip ring (9)of the gear (10). (Take care not to drop the pin.) (10) TSM Océ 3121 Dis-/assembly...
  • Page 360 Remove the gear while unlocking it. Remove the grip ring (11), and remove the bush (12). (12) (11) Detach the spring (13) and remove the screw (14). Then, remove the strip (15). (15) (14) (13) ed.1 10 RDF 425...
  • Page 361 Remove the spring (16). (16) Remove the screw (18), and remove the sensor cover (17). Then, disconnect the sensor connector (19). Remove the registration sensor (20): pulling it upwards. (18) (17) (20) (19) TSM Océ 3121 Dis-/assembly...
  • Page 362 Remove the paper guide (21). (21) Remove the two screws (22) at the front, and the two screws (23) at the rear. Then, remove the reverse clip (24): pulling it downwards. (22) (24) (23) ed.1 10 RDF 427...
  • Page 363 Remove the screw (25), and remove the strip (26). (25) (26) Remove the delivery and reversing roller (27). (27) TSM Océ 3121 Dis-/assembly...

  • Page 364: Delivery Roller (Copier Mode)

    16 Delivery Roller (copier mode) Remove the cover. Remove the pick-up motor. Remove the screw (1). Remove the E-ring (2). Remove the screw (3), and remove the pin (4). Then, remove the delivery roller (5). ed.1 10 RDF 429...

  • Page 365: Delivery Roller (Fax Mode)

    17 Delivery Roller (fax mode) Remove the cover. Remove the screw (1), and the spring (2). Then, disconnect the connectors (3). Remove the three screws (4), and remove the delivery roller (5). TSM Océ 3121 Dis-/assembly...

  • Page 366: Reversing Guide

    18 Reversing guide Remove the cover. Remove the grip ring (1), and the gear (2). Remove the timing belt (3). Remove the gear while unlocking it. Note: ed.1 10 RDF 431...
  • Page 367 Detach the springs (4) and (5) from each end of the reversing guide. Remove the screw (1), and remove the solenoid (2). TSM Océ 3121 Dis-/assembly...
  • Page 368 Disconnect the sensor (6), and disconnect the earth cable (7). Remove the following: Screw (8), the strip (9), screw (10), the pin (11). Then, remove the reversing guide (12). (12) (11) (10) ed.1 10 RDF 433...

  • Page 369: Removing The Stop Solenoid

    Fix the solenoid (1) in place where the stopper (3) (rubber block) comes into contact with the trailing edge of the stopper plate (2) when the plunger of the solenoid is at the end of its stroke. TSM Océ 3121 Dis-/assembly...

  • Page 370: Stamping Solenoid Sl4

    21 Stamping Solenoid SL4 Remove the delivery roller (fax mode) Remove the screw (1), and the spring (2). Remove the guide (3). Remove the E-ring (4), and remove the bush (5). ed.1 10 RDF 435...
  • Page 371 Remove the two screws (10) at the front, and the two screws (11) at the rear. Then, remove the paper guide (12). (11) (12) (10) Remove the vane of the sensor (13). Disconnect the connector (14). (13) (14) TSM Océ 3121 Dis-/assembly...
  • Page 372 Remove the three screws (15), and remove the support (16). (16) (15) Remove the delivery roller (17), and remove the support for SL4 (18). (18) (17) Release the clips (20), and remove the solenoid SL4 (19). (18) (20) (19) ed.1 10 RDF 437...

  • Page 373: Feeding Belt

    Remove the cover. Remove the spring at the front(1). Detach the spring at the rear (2) from the hook (3). Attach the spring to the tem- porary hook (4). Remove the screw (5), and remove the solenoid (6). TSM Océ 3121 Dis-/assembly...
  • Page 374 Remove the four screws (8), and the side plate (7). Remove the three screws (9), and remove the outer frame (10). (10) (9) Pull the feeding belt (11) out to the front. (11) ed.1 10 RDF 439...

  • Page 375: Cleaning The Belt

    (The pick-up sensor S7, the delivery sensor S6 and the reversal sensor S8 are sensors with interrupter vanes.) The orifice of a sensor attracts dust. The dust can lead to faulty operation. The sensors should be cleaned as follows: TSM Océ 3121 Dis-/assembly...
  • Page 376 25 Cleaning the sensor S1 Remove the two screws (1). Remove the support (2). Clean the sensor S1 (3). 2. Sensor LED1 for S1 Remove the separation belt. Remove the four screws (2), and remove the guide plate (1). ed.1 10 RDF 441...
  • Page 377 Clean the orifice of the LED1 (3). The led is located behind the guide plate (1). Registration sensor S3. Remove the separation belt. Remove the four screws (2), and remove the guide plate (1). Remove the two screws (4), and remove the inside guide (3). TSM Océ 3121 Dis-/assembly...
  • Page 378 Clean the sensor S3. The sensor is fitted to the inside guide (4). Sensor LED3 for S3. Remove the screw (3), and remove the cover (2) from the LED3. Reversing roller (1). Remove the reversing guide. Disconnect the connector (4) from the LED3. Withdraw the LED (5) vertically. ed.1 10 RDF 443...
  • Page 379 Remove the separation shoes: rear (1) and front (2). The separation shoes can be removed by pushing in the arrowed direction. Clean the shaded areas of the separation shoes. Wipe only in the document feed direction. TSM Océ 3121 Dis-/assembly...
  • Page 380 Separation guide Remove the separation belt. Remove the separation shoes: front and rear. Clean the shaded areas (12 areas) of the separation guide. Wipe only in the document feed direction. Lubrication The RDF requires no lubrication. Apply lubricant as necessary when replacing gears, etc.
  • Page 381 Pick-Up Drive Lubricate the following parts: Rear Lubricate Areas to apply lubricant Pick-up motor (M1) Pick-up motor unit Front Lubricate Area to apply lubricant Delivery Drive. Lubricate Area to apply lubricant TSM Océ 3121 Dis-/assembly...

  • Page 382: Functional Description

    Functional description 1 Features Handles fax documents for page collation. The RDF offers two feeding modes: copier and fax. In copier mode: it feeds the bottom page first. In fax mode: it feeds the top page first. Stamping function. The RDF has a stamping function. The fax documents are stamped, to indicate that they have been processed.

  • Page 383: Specifications

    Measuring the side of the The length (in feeding documents direction) and the width Detection of document in Possible, in combination the tray with copier systems Continuous feeding Provided In fax mode only. TSM Océ 3121 Functional description...
  • Page 384 Item Specifications Remarks Mode for various sizes of Provided Of the same width only. documents Stamping function Provided In fax mode only. Communication with IPC communication 2 copier Power supply From copier (24 VDC) Maximum power con- 170 W. sumption Weight 14.1 kg/31 lbs.

  • Page 385: Nomenclature

    3 Nomenclature External View w e r (3) (4) 1. Upper cover 5. Document tray 2. Side guide 6. Tray 3. T-O-T-S bar 7. Cover 4. Set indication 8. Output tray TSM Océ 3121 Functional description...
  • Page 386 Cross Section (2) (3) (10) e r t y u i o (14) (13) (15) (11) (16) (12) 7. Delivery/pick-up 12. Retaining roll 1. Reversing roller roller 2. Paper deflecting plate 8. Paper holding plate 13. Feeding belt 3. Feeding roller 9.

  • Page 387: Operation

    Open the RDF cover, and remove any document that is jammed. Then, open the RDF to clear the warning. Remove any documents from the platen. Sort the documents into their original sequence. Replace the stack of docu- ments in the document tray. TSM Océ 3121 Functional description...
  • Page 388 Replacing the stamp If stamp marks are no longer readable, replace the stamp using a pincet. Stamp Stamp Tweezers Tweezers ed.1 10 RDF 507...

  • Page 389: Functional Design

    In turn, the CPU generates signals to activate the various electrical com- ponents, according to pre-programmed instructions. RDF controller PCB Sensor Motor (Q1) Variable (Q2) Solenoid resistor (Q4) Clutch Communi- cation IC (Q3) Brake 5VDC Display power Motor LED PCB supply Power supply circuit Copier TSM Océ 3121 Functional description...

  • Page 390: Communication With The Copier

    6 Communication with the copier An IPC communication mode is used for the communication between the RDF and the copier. An error message “ E400 ‘ or ’ E712 ‘ is displayed if any errors occur with the IPC communication. Copier ed.1 10 RDF 509...

  • Page 391: Inputs To The Rdf Control Pba

    7 Inputs to the RDF Control PBA 1. Inputs to the RDF Control PBA TSM Océ 3121 Functional description...
  • Page 392 2. Inputs to the RDF Control PBA ed.1 10 RDF 511...

  • Page 393: Outputs From The Rdf Control Pba

    8 Outputs from the RDF Control PBA 1. Outputs from the RDF Control PBA TSM Océ 3121 Functional description...

  • Page 394: Principle Of Operation

    9 Principle of operation Outline Three motors and a clutch are used in the RDF. These are used to pick-up the documents, feed the documents and eject the documents. The pick-up motor (M1) picks up the documents. The feeding motor (M2) delivers and reverses the documents. The belt motor (M3) carries the documents to the platen, stops the documents and ejects them after they have been scanned.
  • Page 395 One of the following operations will be executed, according to the instructions from the copier: TSM Océ 3121 Functional description...
  • Page 396 1) Single sided documents Mode The RDF picks up the bottom page of the stack on the document tray, and car- ries the document to the platen. When the scanning is completed, the document is taken off the platen, and re- turned to the document tray.
  • Page 397 3) Image Composition Mode In this mode, the RDF places two documents on the platen for a reduced copy. The following sizes of documents can be used for this mode: A/B-configured RDF INCH-configured RDF STMT TSM Océ 3121 Functional description...
  • Page 398 A/B-configured RDF INCH-configured RDF ed.1 10 RDF 517...
  • Page 399 Delivery of the 1st document and, Delivering the 1st original and then the 2nd original. then, the 2nd document Reversing from the 1st side to the Reversing from the 1st side to the 2nd side. 2nd side TSM Océ 3121 Functional description...
  • Page 400 4) Feeding document for faxing The RDF picks up the top page of the stack on the document tray, and carries the document to the platen. When the scanning is completed, the document is taken off the platen, and ejected to the output tray. Positioning the document Setting an original.

  • Page 401: Checking The Quality Of The Documents

    The document sensor S1 generates the original detection signal DEP1. When the RDF control PBA receives the DEP1 signal, the PBA switches on the set indicator (LED101 and LED 102). RDF controller PCB LED101,102 LED1 Display Original TSM Océ 3121 Functional description...
  • Page 402 Set indication Original Set indicator Document Original Document tray Original tray Measuring the Size of Documents Outline The measurements of the document are monitored to obtain correct control and, for fax applications, for use in the communication protocol. Document size (length in feeding direction) The length of a document, in the feeding direction, is checked by the sensor (S3) and by the clock sensor (S11).
  • Page 403 For the vertical length: the default size will be the default size ±10 mm. for the width dimension: the default size will be the default size ±5 mm. Other lengths are not considered to be default sizes. TSM Océ 3121 Functional description...
  • Page 404 RDF is configured for INCH Default size Vertical length Width of the document STMT 140mm LTRR 279mm 211 to 221mm FOOLSCAP 330mm 356mm 216mm COMPUTER paper 381mm 274 to 284mm 11”x 17” 432mm For the vertical length: the default size will be the default size ±10 mm. for the width dimension: the default size will be the default size ±5 mm.
  • Page 405 (LDD) is generated. RDF control PBA RDF controller PCB T-O-T-S bar Re-circulating lever Sensor (S12) Re-circulating sensor (S12) RDF control PBA RDF controller PCB T-O-T-S bar Re-circulating lever Sensor (S12) Re-circulation sensor (S12) Document Original TSM Océ 3121 Functional description...
  • Page 406 Detection of the trailing edge of the last document. Copiers with a long feeding path (from cassette to drum) usually pick up copy paper early. This is to speed up the copying operation. Copy paper is frequent- ly picked up before the document arrives on the platen. For this reason, the RDF is programmed to pick up a document at the same time as the copy paper is picked up.
  • Page 407 You may disable this count function in theuser mode. Copier Copier TSM Océ 3121 Functional description...

  • Page 408: Pick-Up Of Documents For Copying

    11 Pick-up of documents for copying 1) Outline There are two pick-up methods: Copier mode: the first document if fed from the bottom of the stack. Fax mode: the first document if fed from the top of the stack. Separate feed mechanisms are used for each of the two modes. Pick-up: copier mode Pick-up: fax mode ed.1...
  • Page 409 Pick-up motor (M1) Pick-up motor (M1) Switching Separation belt Separation belts Switching (fax mode) 3)Pick-up: copier mode 3a) Operation The following occurs when the documents have been placed in the tray, and the copy button is pressed: TSM Océ 3121 Functional description...
  • Page 410 Pick-up The paper stop is lowered, and the pressure plate is lowered. This allows the last page to be picked off the stack. The document is fed between the separation belt and the feeding roller. This is to make sure that only one document is fed. The pressure plate is always lowered for the first document.
  • Page 411 For small size documents: the second and subsequent documents are fed Note: slightly farther than the registration roller. This shortens the time required to feed the documents. Feeding roller Registration roller Feeding belt Slightly farther than the registra- Scanner tion roller TSM Océ 3121 Functional description...
  • Page 412 Confidential © 1998 Océ-Technologies B.V. Original set Cop Start key ON Starting scanner/picking Feeding/ Feeding Picking up original Starting scanner up 2nd original delivery Pick-up sensor (S7) (S3) Registration paper sensor Reversal sensor (S8) Delivery sensor (S6) Arching Pick-up motor (M1) Feeding motor (M2)
  • Page 413 Bulge The document is fed against the registration roller. A bulge is created. 1st page of stack Pressure plate Separation belt Stop plate Feeding roller Pick-up sensor (S7) Bulge Registration roller TSM Océ 3121 Functional description...
  • Page 414 Feeding The feeding belt and the registration roller are rotated. The document is carried to the platen. Picking up the 2nd document When the document reaches a specific position on the platen, the scanner starts to move forwards. The second document is picked up. If stamping is selected, the second document is not picked up.
  • Page 415 Copy Start key ON Moving scanner Picking up/feeding 1st original Starting scanner/picking up 2nd original Feeding 2nd original forward Pick-up sensor (S7) (S3) Registration paper sensor Delivery sensor 2 Pick-up motor (M1) Feeding motor (M2) Low speed Low speed Low speed Belt motor (M3) Clutch...

  • Page 416: Turning The Documents Over

    12 Turning the documents over Operation The documents are turned over only in copy mode. The turning over can be from the first side to the second side, or from the second side to the first side. The description is based on the situation applicable for turning over from the first side to the second side.
  • Page 417 Deflector Turning over, from the 2nd side to the 1st Turning over, from the 2nd side to the 1st side Timing of operations: turning over TSM Océ 3121 Functional description...

  • Page 418: Image Composition Mode

    13 Image Composition Mode a) Operation The image composition mode differs for copy mode and for fax mode. After selection of the required mode, and after pressing the copy button, the following occurs: As the last page is picked up first, the sequence of the documents needs to be reversed.
  • Page 419 Two documents are moved simultane- ously. The sequence of the documents has changed. The two documents overlap slightly: for sheet gap adjustment. Deflector 1st document 2nd document Deflector Registration roller Reversing roller 1st document Feeding belt TSM Océ 3121 Functional description...
  • Page 420 Reversing roller Feeding belt (overlay) Adjusting the gap between documents. The clutch (CL1) de-energises. The feeding belt is slowly rotated coun- ter-clockwise, eliminating the overlap and adjusting the gap between the doc- uments. Feeding When the gap between the two documents has been adjusted to a specific val- ue, the clutch (CL1) is energised.
  • Page 421 The third document is picked up and stopped at the registration roller. Feeding up the 2nd document The feeding belt is rotated clockwise. This carries the second document from the platen to the reversing roller. TSM Océ 3121 Functional description...
  • Page 422 Returning the second document and picking up the third document The clutch (CL1) is energised. The difference in speed between the reversing roller and the feeding belt is eliminated. The second document is returned to the tray, and the document is picked up and carried onto the platen. Subsequently, the same procedure is repeated: starting at 1.
  • Page 423 2nd document Feeding belt 3rd document delivery roller 1st document 2nd document TSM Océ 3121 Functional description...
  • Page 424 Confidential © 1998 Océ-Technologies B.V. Picking up Copying Delivering 1st and 2nd originals; picking up Reversing first original Feeding 2nd and 1st originals simultaneously first original 3rd original, and separating 4th original (S7) Pick-up sensor Registration paper (S3) sensor (S8) Reversal sensor (S6) Delivery sensor...
  • Page 425 Simultaneous feeding of the first and the second documents. The clutch (CL1) energises. This eliminates the difference in speed between the reversing roller and the feeding belt. Two documents are moved simultane- ously. 2nd document 1st document TSM Océ 3121 Functional description...
  • Page 426 Returning the first document and the second document When the documents have been scanned, the feeding belt is rotated coun- ter-clockwise to deliver the first and the second documents. If a third and fourth documents exist, the operations are repeated starting with pick-up.

  • Page 428: Delivery

    14 Delivery a) Outline There are two methods for returning the documents to the document tray: Copier mode Fax mode In copier mode, the documents are returned to the document tray. In fax mode, the documents are delivered to the output tray. Document tray output tray b) Return in copier mode...
  • Page 429 The deflecting solenoid (SL3) is de-energised. The deflecting plate is closed, and the document is returned. to the document tray. The next document is carried onto the platen. Feeding belt Scanner Reversing roller Feeding roller Reversal sensor (S8) Deflector Document tray TSM Océ 3121 Functional description...
  • Page 430 Return to the Document tray When the trailing edge passes the reversal roller, the feeding motor is switched to low speed. The document return is slowed. Scanner ed.1 10 RDF 549...
  • Page 432 Confidential © 1998 Océ-Technologies B.V.
  • Page 434 b) Return in fax mode Operation Documents are carried from the platen for delivery to the output tray. If applicable, the stamp marks the documents. Feeding the first document The feeding belt is rotated counter-clockwise. This carries the document ap- proximately 30 mm.
  • Page 435 Starting scanner/ Moving 1st original to Feeding Starting scanner/ Feeding 2nd original stamping position Picking up 2nd original second original Picking up 3rd original to stamping position Pick-up sensor (S7) Registration (S3) paper sensor Feeding equivalent of 20 mm Feeding equivalent of 20 mm Delivery sensor 2 (S12) Pick-up motor...
  • Page 436 Confidential © 1998 Océ-Technologies B.V. Starting scanner/ Starting scanner/ Feeding 3rd original/ Feeding second original Picking up 2nd original Picking up 3rd original Picking up 1st original Pick-up sensor (S7) Registration paper (S3) sensor Delivery sensor 2 (S12) Pick-up motor (M1) Feeding motor (M2)

  • Page 437: Stamping Function

    RDF control PBA generates the stamp solenoid drive signal (STSLD). The so- lenoid (SL4) energises. The stamp face, attached to the tip of the plunger of the solenoid, is brought down onto the surface of the document. TSM Océ 3121 Functional description...
  • Page 438 Solenoid (SL4) STSLD Stamp controller Fax document Sensor (S12) Reference: Each new stamp can stamp approximately 7,000 documents. Note: Timing of operations (stamping) ed.1 10 RDF 557...

  • Page 439: Controlling The Pick-Up Motor

    The three signals trigger the drive circuit to drive the pick-up motor. The control circuit is not equipped with a monitor circuit. The SMPWM signal remains at a constant level. RDF control PBA Pick-up motor SMON SDIR Drive circuit SMPWM TSM Océ 3121 Functional description...
  • Page 440 Relationship between the Pick-Up Motor and the signals (SMON), (SDIR) and (SMPWM). (SMON) (SDIR) (SMPWM) Operation of the pick-up motor ‘1’ ‘1’ Pulse The pick-up motor rotates in the pick-up direction for copier mode (counter-clock- wise). ‘1’ ‘1’ ‘0’ The pick-up roller rotates in the pick-up direction for copier...

  • Page 441: Controlling The Belt Motor

    (PMPWM), The speed of the belt motor (M3) is fixed at a specific level at all times. RDF control PBA Belt BMON Drive BDIR circuit BMPWM Clock sensor BMCLK TSM Océ 3121 Functional description...
  • Page 442 Relationship between the feeding belt and the signals (BMON), (BDIR) and (BMPWM). Belt motor drive Belt motor rota- Belt motor rota- Operation signal (BMON) tion direction tion speed con- signal (BDIR) trol signal (BMPWM) ‘1’ ‘1’ The feeding belt rotates in the pick-up direction (counter-clock- wise).
  • Page 443 These checks are compared to an internal timing memory. The monitoring is carried out by various sensors. The table shows the various situations that are monitored during document handling. If a jam is detected, the copier displays a message. TSM Océ 3121 Functional description...
  • Page 444 Character- Sensor Situation Code istic of jam Loss of doc- S1,S7 The sensor (S7) does not detect the leading edge of a ument document. And, the sensor (S1) did not detect a docu- ment within 1500 ms after the motor M1 was switched Pick-up The sensor S7 did not detect the leading edge of a doc- delay...
  • Page 445 If the jam detection concerns the first document, the RDF will generally Note: assume that the document has been positioned incorrectly If the condition concerns the second document or the subsequent documents, the RDF will assume that a document has jammed. TSM Océ 3121 Functional description...

  • Page 446: Document Is Positioned Incorrectly

    19 Document is positioned incorrectly Re-circulating MS1 MS2 Stop plate Paper sensor S1 for the document Pick-up sensor S7 tray Registration sensor S3 Recirculation sensor S13 Incorrect positioning of the documents can cause damage to occur. To ensure the correct positioning of the document, the RDF monitors the movement of the documents.
  • Page 447 2. The sizes of the documents are ments: for not the same. image compo- sition mode. See Note 1. To reset the RDF control, remove the documents from the document tray. Note: Then open the RDF. TSM Océ 3121 Functional description...
  • Page 448 Supplement: Example After counting the 7 originals The originals are put 10 originals are placed The 8th original that have been copied, back in order, i.e., 10 copying resumes starting on the original tray. jams. originals are set. with the 8th original. (7 originals copied) The RDF stops operation 3 originals are set on...

  • Page 449: Power Supply

    Motor (M1 through M3) Circuit breaker (CB1) Sensor (S1 through S13) Original width volume (VR1) Logic system Fuse resistor Display LED (LED101, 102) (R26) 24VL J2-1 Regulator Re-circulating motor (M4) IC (Q14) Copier RDF controller PCB TSM Océ 3121 Functional description...
  • Page 451 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 11 DIGITAL DOCUMENT HANDLING...
  • Page 452 Contents Functional description 1 PRODUCT OUTLINE 501 2 SPECIFICATIONS 502 3 BASIC CONSTRUCTION 509 ed.1 11 Digital document handling...
  • Page 453 Functional description 1 PRODUCT OUTLINE The Océ 3121 is a digital black-and-white copier equipped with communica- tion functions that use telephone lines so that it can serve as a fax transmis- sion/reception device as well as a copier. ed.1 11 Digital document handling 501...
  • Page 454 ITU-T V.29 (9600/7200 bps) ITU-T V.27ter (4800/2400 bps) Compression method MMR/MR/MH Communication mode G3 (no G2/G1/MF) Error correction method ITU-T ECM method (may be disabled) Communication speed 6 sec (ECM-MMR/14400 bps; using Canon FAX Standard Chart No. 1) TSM Océ 3121 Functional description...

  • Page 455: Rdf

    Recording System Item Description Maximum original size A3 (297 x 420 mm) Transmission original size A3, A4, A4R, A5, A5R, A6, B4, B5, B5R, LTR, LTRR, LGL, 11x17, STMT, STMTR ADF-F1: supports stream reading, long original (630 mm max.) RDF-G1: supports two-sided original Recording paper size A3, A4, A4R, A5, A5R, B4, B5, B5R, LTR, LTRR, LGL, 11x17, STMT, STMTR (cassette...
  • Page 456 200 addresses max.; 32 times Rotation transmission Provided DONE stamp Provided (w/ RDF in use); READ stamp, SENT stamp (direct Dual access transmission only) Interrupt transmission Provided (100 reservations max.) Error re-transmission Provided (direct transmission) TSM Océ 3121 Functional description...
  • Page 457 Reception Item Description Confidential reception Provided (using memory box; 70 boxes max.) Relay broadcasting Provided (using memory box; 70 boxes max.) 200 addresses (1 box) Substitute reception Provided (about 52 pages; auto output) Memory reception Provided (about 52 pages; time may be set for start/end) Polling reception Provided...
  • Page 458 At time of shipment, auto printing after 40 communi- reporting cations (transmission/reception separation, time-spe- cific printing selection) Memory box reception At time of shipment, ‘yes’ (‘yes/no’ selection) reporting Multiple communica- Provided tions control reporting Memory clear reporting Provided TSM Océ 3121 Functional description...
  • Page 459 Transmission Original Editing Item Description Continuous/two-sided Page separation Two-sided reading (RDF only) Reduction/enlargement Default ratio (50% to 200%) transmission Original frame erasing Provided Area selection Framing, blanking (keypad input; up to 4 areas) 2-on-1 transmission Provided (w/ RDF in use) Reading size At time of shipment, auto reading size (reading size may be set in manual;...
  • Page 460 What is called the "master password" is the one to be used during servicing or when the user forgets his/her password. Master Password “4559769” The master password is intended for use by the technician only. Be sure Note: not to disclose it to the user. TSM Océ 3121 Functional description...
  • Page 461 3 BASIC CONSTRUCTION Basic Functional Construction The FAX Board can be divided as shown in the figure below, and the functions are controlled by the CPU (IC506) mounted on the image processor PCB. ed.1 11 Digital document handling 509...
  • Page 462 Inputs to and Outputs from the FAX Board TSM Océ 3121 Functional description...
  • Page 463 Reading Operations Reading for Memory Transmission Originals are placed on the glass platen and are read one by one so that multiple pages may be transmitted. When a feeder is used, on the other hand, multiple originals set in it are read. An original placed on the glass platen and an original picked up from the feeder cannot be joined for reading.
  • Page 464 In addition to a test shot, the machine allows test printing (‘test print’ or ‘VID- EO test’) using #10 TEST mode. See the figure for the flow of image signals. TSM Océ 3121 Functional description...
  • Page 465 ed.1 11 Digital document handling 513...
  • Page 466 (toward 3, for back-up). If the board is to be installed as an accessory (post-installation) to the Océ 3121, be sure to shift SW2 from OFF to 3 at time of installation. NCU Board 230V Areas (outside France) TSM Océ...
  • Page 467 The NCU in the French model do not have SW1 through SW3. Note: Notation Description Fax controller Board interface connector Connector for telephone line jack Connector for extension phone jack. (Note that a face plate is pro- vided over the modular jack upon shipment from the factory.) Connector for handset jack Not used ARG cable terminal...
  • Page 468 CORE/IP Board TSM Océ 3121 Functional description...
  • Page 469 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 12 PAPER...
  • Page 470 Contents Adjustments 1 Adjusting the Registration in Rear/Front Direction 301 Dis-/assembly 1 Removing the Main Motor 401 2 Removing the Pick-Up drive Unit 402 3 Vertical Path Assembly 404 4 Removing the Pick-Up Assembly 406 5 Removing the Pick-Up/Feeding/Separation Roller 407 6 Installing the Pick-UP/Feeding/Separation Roller 407 7 Removing the Feeding Assembly 407 8 Removing the Feeding Fan 408...

  • Page 471: Adjusting The Registration In Rear/Front Direction

    Adjustments 1 Adjusting the Registration in Rear/Front Direction Aim: Check to make sure that the margin along the image front is 2.5 ±1.5 mm on copies. (Try all cassettes.) ( + ) 2.5 1.5mm Correction: If the margin is not as indicated, perform the following: Slide out the cassette from the holder to be adjusted.
  • Page 472 Rear Horizontal regis- Horizontal tration plate registration plate Hex screw Hex screw Adjust the horizontal registration plate by matching the inner side of the Note: L shape on the horizontal plate at a specific scale notch. TSM Océ 3121 Adjustments...

  • Page 473: Dis-/Assembly

    Dis-/assembly 1 Removing the Main Motor Disconnect the power plug, and remove the following: Rear cover (4 screws) Flywheel (3 screws) Remove the four screws (2), and disconnect the two connectors (3); then, re- move the main motor (1). ed.1 12 Paper trays 401...

  • Page 474: Removing The Pick-Up Drive Unit

    Rear cover (4 screws) Flywheel (3 screws) Scanner cooling fan (hook, connector) Remove the pick-up assembly. Release the belt (1). Remove the harness retainer (2), two high-voltage cables (3), and power sup- ply cord mount (4) (2 screws). TSM Océ 3121 Dis-/assembly...
  • Page 475 Disconnect the seven connectors (5). Remove the registration roller clutch (6). Remove the four screws (8), and remove the pick-up drive unit. ed.1 12 Paper trays 403...

  • Page 476: Vertical Path Assembly

    Remove the two screws (1) from behind the machine. Release the feeding lever, and remove the three screws to remove the feeding lever and the feeding assembly locking assembly. Remove the screw (2), grounding screw (3), and E-ring (4). TSM Océ 3121 Dis-/assembly...
  • Page 477 Disconnect the connector (6), and remove the vertical path assembly. ed.1 12 Paper trays 405...

  • Page 478: Removing The Pick-Up Assembly

    Detach the cable of the right door (2) from the hook (3); then, remove the right door. Disconnect the connector (4) of the pick-up assembly, and remove the ground- ing screw (5). Remove the four screws (7), and remove the pick-up assembly (6). TSM Océ 3121 Dis-/assembly...

  • Page 479: Removing The Pick-Up/Feeding/Separation Roller

    5 Removing the Pick-Up/Feeding/Separation Roller Slide out the cassette. Holding the knob assembly (1), pull it off in the axial direction. Separation Roller Separation Roller Feeding Roller Feeding Roller Pick-up Roller Pick-up Roller 6 Installing the Pick-UP/Feeding/Separation Roller Holding the knob assembly, push it in until a click is heard. 7 Removing the Feeding Assembly Open the front door, and remove the fixing inside cover;...

  • Page 480: Removing The Feeding Fan

    Disconnect the connector (5), and remove the feeding belt (6) as if to displace Release the hook assembly (8) of the feeding fan cover (7) with a small flat-blade screwdriver. Remove the feeding fan (9). TSM Océ 3121 Dis-/assembly...

  • Page 481: Removing The Registration Roller

    9 Removing the Registration Roller Remove the following: DC controller PCB harness guide Power supply mount Drive unit Developing assembly Drum unit Remove the screw (1), spring (2), and two E-rings (3) from the rear of the ma- chine. Remove the screw (4), spring (5), and two E-rings (6) from the front of the ma- chine.

  • Page 482: Functional Description

    Functional description 1 Pick-up and feeding Outline The copier has a centre reference. The copy paper moves along the centre of the pick-up and feeding unit. The pick-up system comprises two cassettes (up- per, lower) and the speciality tray. Copy paper from one of the cassettes, or the speciality tray, is controlled by the registration roller.
  • Page 483 Registration roller Feeding unit Specialities: pick-up roller Fusing unit Vertical transport roller TSM Océ 3121 Functional description...
  • Page 484 Name Clutch for the registration roller Clutch for the speciality roller Clutch for the vertical transport Clutch for the lower refeed Solenoid for the re-pick entry Solenoid for the paper deflector main motor Motor for the retarding roller Motor for the lower refeed Motor for the output roller D C co n tro ller P C B M a in m oto r...
  • Page 485 Clutch for the registration roller RGCD* J114-B11 Clutch for the vertical transport CL3D* J114-A4 Solenoid for lowering the pick-up SL2D* J114-A5 roller Pulse signal: this cannot be checked ( 0, 1) by a meter. Note: TSM Océ 3121 Functional description...
  • Page 486 DC control PBA DC controller PCB cassette pick-up PBA cassette pick-up PBA Cassette pick-up PCB Cassette pick-up PCB Photosensitive drum Registration roller main Registration roller Main motor motor pick-up unit Pick-up unit pre-registration roller pre-registration roller motor for cas- Cassette pck-up sette pick-up roller drive motor vertical...
  • Page 487 The upper cassette cassette pick-up PBA The upper cassette TSM Océ 3121 Functional description...
  • Page 488 Timing of operations Cassette 1, A4, 2 Copies, Continuous Sequence of pick-up operations (cassette) Operation of the ramp in the cassette When the cassette is in use, the ramp is raised continuously, so maintaining the height of the top sheet in the cassette. Movement of the ramp during the copying cycle The level of the paper is maintained as follows: The movement of the ramp is started when the shaft of the pick-up roller re-...
  • Page 489 Pick-u p ro ller spring spring Spring Spring ramp L ifter Paper C o py pa pe r <lifter up> <lifter at rest> < Lifte r u p > < Lifte r a t R est > TSM Océ 3121 Functional description...
  • Page 490 Releasing the ramp When the cassette is withdrawn, it releases the ramp. One claw raises the ramp, another claw holds the ramp up. When the machine is at stand-by, the ramp is held by the retaining claw. When the cassette is opened, the retaining claw is released, and the ramp drops.
  • Page 491 Pick-up drive for the upper cassette: pick-up motor rotating clockwise. feeding roller Motor M4 for cassette pick-up pick-up roller separation roller gear 1 Pick-up drive for the upper cassette: pick-up motor rotating clockwise. TSM Océ 3121 Functional description...
  • Page 492 c) Movement of the pick-up roller M1 provides the drive for the shaft of the pick-up roller. The cam is activated by the solenoid SL2 The raised position is the stand-by position of the shaft of the pick-up roller. The following occurs when a sheet is fed: - Solenoid SL2 energises.
  • Page 493 The motor M1, and the pick-up solenoid SL2 are switched on, following the signal from the size sensor. The trigger turns. The position of the shaft of the pick-up roller is controlled by the lever 1 and the trigger. TSM Océ 3121 Functional description...
  • Page 494 shaft of the pick-up roller feeding roller lever 1 pick-up roller cassette Movement of the lever 1 when the cassette is inserted b) the ramp is raised When the cassette is inserted, and the machine is ON, the shaft of the pick-up roller will be lowered pressing down the trigger.
  • Page 495 A bend is incorporated in the lever 1. This presses down the separation roller. As the lever 1 turns, when the cassette is withdrawn, the bend is rotated off the separation roller. This reduces the pressure. bend on the lever 1 separation roller cassette Releasing the separation roller TSM Océ 3121 Functional description...
  • Page 496 Releasing the ramp The ramp is released, when the cassette is withdrawn: in stand-by. Detecting the level of copy paper The ramp rises gradually as the paper depletes. Together with the ramp, the segment also rises. This moves a vane through the sensors Q1606 and Q1607. ramp vane Cassette is full...
  • Page 497 The stock of copy paper, the sensors and the displays. display Indication on stock Level Q1606 Q1607 control panel 500 sheets 500 sheets 1:The light-blocking plate is over the sensor. 0:The light-blocking plate is not over the sensor. TSM Océ 3121 Functional description...
  • Page 498 Detecting the size of the paper Outline The size of the paper is selected on the size dial, and a switch to select A/B or inch sizes. Location of the dial A/B or Inch switch ed.1 12 Paper trays 517...
  • Page 499 (mm) ning direction (mm) FLSO OFICIO A-OFI E-OFI B-OFI A-LGL U2 FOLIO U3 A-FLS SP-1 Set by user Set by user SP-2 Set by user Set by user ENV1 Set by user Set by user TSM Océ 3121 Functional description...
  • Page 500 Configuration Cassette Main scanning Reverse scan- direction (mm) ning direction (mm) Inch STMT STMTR A-LTR LTRR A-LTRR 11 ¥ 17 SP-3 Set by user Set by user SP-4 Set by user Set by user ENV2 Set by user Set by user rotary label: A/B rotary label: inch ed.1...
  • Page 501 Controlling the clutch for the registration roller The clutch CL1 times the feeding of the paper, so that the leading edge of the paper coincides with the leading edge of the image area on the OPC. TSM Océ 3121 Functional description...
  • Page 502 The timing of the operation of the clutch CL1 can be set in the service mode (* 3 * , RESIST). Selected mode Paper Movement Paper and (mm) Image one-sided original -> one-sided copy Between 0 and 20 mm; the drawings one-sided origi- copying on the 1st side show a move-...
  • Page 503 PDP 4 J113-A2 PS11 Sensor for the re-pick entry PDP 5* J103-2 PS12 Sensor for the refeed unit PDP 6* J105-B2 PS13 Sensor for the output tray PDP 7* J105-A2 *pin on the DC control PCB. TSM Océ 3121 Functional description...
  • Page 504 Types The microprocessor identifies jams as follows: Delay The paper did not reach the appropriate sensor within the specified time: i.e. the sensor is not ON. Stationary The paper did not leave the appropriate sensor within the specified time: i.e. the sensor does not switch OFF.
  • Page 505 Delay at the fuser sensor PS7 A delay will be signalled if the paper does not reach the sensor PS7 within a specified period of time after the paper passes the clutch CL1. Timing for delay at the fuser TSM Océ 3121 Functional description...
  • Page 506 Delay at the output tray PS13 A delay will be signalled if the paper does not reach the sensor PS13 within a specified period of time after the paper passes the sensor PS7. Timing for delay at the output tray Delay at the separation sensor PS6 A delay will be signalled if the paper does not reach the sensor PS6 within a specified period of time after the clutch CL1 has energised.
  • Page 507 A delay will be signalled if the paper does not reach the sensor PS12 within a specified period of time after the paper passes the sensor PS7. Timing for the refeed sensor PS12 (overlay copying) Timing for the refeed sensor PS12 (two-sided copying) TSM Océ 3121 Functional description...
  • Page 508 Delay at the sensor PS11 A delay will be signalled if the paper does not reach the sensor PS11 within a specified period of time after the paper passes the sensor PS12. Timing for PS12 Timing for delay at the sensor PS12 Record of jams The machine retains a history of the jams which have occurred.
  • Page 509 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 13 SPECIALITY INPUT...
  • Page 510 Contents Adjustments 1 The position of the multifeeder paper guide cam 301 2 Recording the VR settings 301 Dis-/assembly 1 Multi Clutch 401 2 Speciality tray 402 3 Fitting the timing belt 404 Functional description 1 Specialities input 501 ed.1 13 Speciality input...

  • Page 511: The Position Of The Multifeeder Paper Guide Cam

    Adjustments 1 The position of the multifeeder paper guide cam Adjust the cam so that it is horizontal, when the solenoid ring is touching the claw. Gear 1 Control ring Control ring Gear 1 Paper guide plate Paper guide plate Stop screw W/hex Stop screw hole...
  • Page 512 Check that the value of ‘AD’ is displayed. Then, press ‘ A4 ’, and press ‘ OK ‘. The value will be stored in ‘ A4 ’. Press ‘ Reset ‘ twice, to end service mode. Switch OFF. (297mm) (105mm) (210mm) paper width--> TSM Océ 3121 Adjustments...

  • Page 513: Dis-/Assembly

    Dis-/assembly 1 Multi Clutch Remove the following: - rear cover (4 screws) - flywheel (3 screws). Remove the two screws (2), and disconnect the connector (3). Then, remove the multi clutch. ed.1 13 Speciality input 401...

  • Page 514: Speciality Tray

    Remove the speciality tray When fitting the cover, align it at the top before pushing in the bottom. Note: Removing the pick-up roller Pull out the rolls. Detach the cable from the cable, and remove the right door (1). TSM Océ 3121 Dis-/assembly...
  • Page 515 Remove the bush (2), and slide the roller shaft (3) to the right. Remove the ring (4), and remove the pick-up roller (5). Pay attention to the pin at the rear of the pick-up roller. Warning: Install the new multifeeder pick-up roller (1) so that the side with a Warning: cross -2- on the collar is pointing towards the rear of the machine.

  • Page 516: Fitting The Timing Belt

    Move the rack gear against the side frame (A). Move the ‘T’ slide to the left. Timing belt Timing belt Pulley Pulley Rack plate Rack plate Pulley Pulley Section A Section A Slide volume Slide volume Carry out adjustment “Recording the VR settings”. TSM Océ 3121 Dis-/assembly...

  • Page 517: Functional Description

    Functional description 1 Specialities input Outline The paper is fed off the top of the stack in the speciality tray. The paper guide holds the paper against the pick-up roller. The pick-up roller is driven by the motor M1 and the clutch CL2. The interaction of the pick-up roller and the separation pad ensure that only one sheet of paper is carried to the registration roller.
  • Page 518 Sequence of pick-up (2 size A4 documents, speciality feed) Copy Start Key ON SCFW SCRV INTR SCFW Multifeeder relay releasing solenoid (SL3) Multifeeder pick-up clutch (CL2) Pre-registration roller sensor (PS5) Registration roller clutch (CL1) Main motor (M1) TSM Océ 3121 Functional description...
  • Page 519 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 16 DUPLEX...
  • Page 520 Contents Dis-/assembly 1 Duplex motor M7 401 2 Motor M6 402 3 The refeed unit 403 4 Horizontal Registration Motor 404 Functional description 1 Making Overlay Copies 501 2 Making Two-Sided Copies 503 3 The refeed unit 504 ed.1 16 Duplex...

  • Page 521: Dis-/Assembly

    Dis-/assembly 1 Duplex motor M7 Removing the duplex motor M7 Disconnect the mains supply cable. Remove the following: The rear cover (4 screws) The flywheel (3 screws) The support DC control PBA (2 screws, connectors) The power supply PBA (screws, connectors) Remove the two screws (2) .

  • Page 522: Motor M6

    The rear cover (4 screws) The flywheel (3 screws) The support DC control PBA (2 screws, connectors) The power supply PBA (screws, connectors) Remove the three screws (2), and disconnect the two connectors (3). Then, re- move the motor M6. TSM Océ 3121 Dis-/assembly...
  • Page 523 3 The refeed unit Remove the inside cover and the support. Lock the feeding unit in place. Remove the two screws (2), and remove the door support (right) (1). Remove the two screws (3). Take out the refeed unit. Disconnect the connector, and remove the refeed unit. ed.1 16 Duplex 403...

  • Page 524: Horizontal Registration Motor

    Remove the following: Pick-up assembly (Func 12) Pick-up drive unit (Func 12) Vertical path assembly (Func 12) Remove the two screws (2), and disconnect the two connectors (3); then, re- move the horizontal registration motor (1). TSM Océ 3121 Dis-/assembly...

  • Page 525: Functional Description

    Functional description 1 Making Overlay Copies Outline The figure below shows the paper path used to make overlay copies. Copy paper that has moved through the fixing assembly is sent to the lower feeding assembly by the movement of the paper deflecting plate*. In the lower feeding assembly, the set-back roller puts the incoming sheet in a staggered stack and waits for the next sheet.
  • Page 526 *pin on the DC control PCB. Electrical parts Signal Signal Jack Fuser sensor PS7 PDP3 J109-6 Solenoid for the DFLD* J105-A5 paper deflector Sensor for the refeed PS12 PDP6* J105-B2 unit Sensor for the output PS13 PDP7* J105-A2 tray TSM Océ 3121 Functional description...

  • Page 527: Making Two-Sided Copies

    2 Making Two-Sided Copies Outline The figure below shows the paper path used when making two-sided copies. After it leaves the fuser, the copy is directed towards the output tray. A short time after the copy passes the sensor PS7, the delivery roller reverses*. The motor M8 is switched on at a specified time after the copy passes PS7.

  • Page 528: The Refeed Unit

    Main motor Motor for the retarding roller Motor for the exit roller Sensor for the re-pick entry PS11 Lower feeding assembly inlet paper sensor PS12 Solenoid for the re-pick entry Clutch for the lower refeed TSM Océ 3121 Functional description...
  • Page 529 DC controller PCB PS 11 PS11 Re-pick up PS 12 PS12 roller Retarding roller Set-back rollers Re-pick up roller The refeed unit Lower feeding assembly Sizes Q'ty Paper sizes (mm; main ¥ sub scanning directions) 179.40 x 215.90 297.00 x 210.00 G-LTR 266.70 x 203.20 K-LGL...
  • Page 530 The retarding rollers are rotated in the reverse direction. The paper is carried back to a pre-determined position. Specific distance PS 12 PS12 Specific distance Retarding roller Re-pick up roller Paper Set-back rollers Re-pick up roller Copy paper TSM Océ 3121 Functional description...
  • Page 531 The 2nd copy paper moves into the refeed unit. PS 12 PS12 2nd copy 2nd copy paper 1st copy paper 1st copy Retarding roller Re-pick up roller Re-pick up roller Set-back rollers The copy paper is handled in the same manner as the 1st copy. PS 12 PS12 1st copy...
  • Page 532 When the trailing edge of the first copy passes the retarding rollers, the retard- ing rollers will reverse. The rollers carry the copy paper back to a position when the leading edge of the next sheet will not reach the sensor PS11. TSM Océ 3121 Functional description...
  • Page 533 Side alignment a) Outline The copies carried from the refeed unit, require alignment of the leading edge. The detection of the sides of the copy is carried out by the sensor PS14, to- gether with motor M9. The sensor and motor are located near to the vertical transport roller.
  • Page 534 The position of the edge of the paper differs, according to the size of the copy paper. The start position is also variable. HP: Home position of the registration sensor PS14. SP: Start of the detection by the registration sensor PS14. TSM Océ 3121 Functional description...
  • Page 535 Components for the side registration. DC controller PCB PS14 PS11 Re-pick up roller Set-back rollers Electrical components main motor Motor for the retarding roller Motor for the side registration Clutch for the vertical transport Clutch for the lower refeed Solenoid for the re-feed separator Sensor for the vertical transport PS11 Sensor for the refeed entry...
  • Page 536 Virtual home position If the image is displaced to the front, increase the value. Specific distance Specific distance Image area Image area Paper Edge Copy paper Edge Virtual home position Virtual home position Value decreased Value increased TSM Océ 3121 Functional description...
  • Page 537 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 17 FIXING...
  • Page 538 Contents Adjustments 1 Adjusting the pressure of the fusing film drive roller. 301 Dis-/assembly 1 Fuser drive 401 2 Fuser 403 3 Replacing the fusing film 408 Functional description 1 Controlling the bias for the fusing roller 501 2 Fusing the copies and output of the copies 502 ed.2 17 Fusing...

  • Page 539: Adjusting The Pressure Of The Fusing Film Drive Roller

    Adjustments 1 Adjusting the pressure of the fusing film drive roller. Carry out this adjustment after replacing the fusing film. Note: Open the front door, and insert the brush in the fuser release. Insert the switch actuator in the door switch. Switch ON.
  • Page 540 FILM SPEED (3), turn the white screw (see figure) for the number of clicks. (The number represents the number of clicks on the white screw) Example: If the number in parentheses under FILM SPEED (3) is ‘5’, turn the white screw clockwise for five clicks. TSM Océ 3121/3122 Adjustments...

  • Page 541: Dis-/Assembly

    Dis-/assembly 1 Fuser drive Removing the fuser drive Disconnect the mains supply cable. Remove the rear cover (4 screws). Remove the flywheel (3 screws). Remove the DC control PBA (2 screws, connectors). Release the tension spring (2), and remove the drive belt. Remove the two screws, and remove the support (3).
  • Page 542 Remove the two screws (7). Take out the fuser drive (6). TSM Océ 3121 Dis-/assembly...

  • Page 543: Fuser

    2 Fuser Separation claw. Open the output door Remove the screw (3). Then, remove the grip (2) of the separation claw (1). Remove the separation claw, by sliding it to the right. When fitting the separation claw, make sure that the flat surface (5) is adjacent to the limit strip (6).
  • Page 544 LANK and FIXER-RESIST. Open the output door Remove the inner cover (1) from the fuser (1 screw). Disconnect the four connectors (2). Remove the screw (3), and the earthing screw (4). Then, slide out the fuser unit. TSM Océ 3121 Dis-/assembly...
  • Page 545 Removing the upper guide Slide out the fuser unit. Press the notch (1), and remove the upper guide (2), by sliding it to the rear. Removing the cleaning roller Slide out the fuser unit. Remove the two screws (1). Remove the cleaning roller (2). ed.1 17 Fusing 405...
  • Page 546 Removing the lower roller from the fuser unit Slide out the fuser unit. Detach the springs (1). Remove the E-ring (3). Remove the lever (2), at the front. Remove the E-ring (6). Remove the lever (5), at the rear. TSM Océ 3121 Dis-/assembly...
  • Page 547 Detach the springs (7). Remove the separation claw. Remove the lower roller. The shaft of the roller is connected by an electrode, at the rear of the ma- Note: chine. When fitting the roller, ensure that the electrode connection is at the rear of the machine.

  • Page 548: Replacing The Fusing Film

    Before dismantling the unit, place paper under the unit. Warning: Do not touch the outer surface of the fusing film. If necessary, protect the fusing film with paper. Do not touch any paint-locked screws Detach the springs. spring spring TSM Océ 3121 Dis-/assembly...
  • Page 549 Remove the E-ring, the washer and the tension lever. From the front and the rear of the unit. Lever for the developing unit E-Ring Lever for the developing unit E-Ring Detach the springs. spring spring ed.1 17 Fusing 409...
  • Page 550 Open the upper unit. Upper unit Lower unit Remove the two screws from the rear of the upper unit. Then, separate the up- per unit and the lower unit. Screws Upper unit Lower unit Upper unit Lower unit TSM Océ 3121 Dis-/assembly...
  • Page 551 Removing the film Disconnect the connector, and remove the upper guide. Delivery guide Disconnect the heater, at the front (1 screw). Remove the alignment motor (3 screws). Then, disconnect the heater. Screw Alignment motor (M5) Screw Screw Remove the cable guide (3 screws). Screw Cable guide Screw...
  • Page 552 Fit the tension tool to the arm of the tension shaft: at the front. Arm of the tension shaft Tension tool Fit the tension tool to the arm of the tension shaft: at the rear. Tension tool Arm of the tension shaft TSM Océ 3121 Dis-/assembly...
  • Page 553 Remove the E-ring, and remove the tension arm. E-Ring Carefully remove the upper section of the unit (1 screw). Screw ed.1 17 Fusing 413...
  • Page 554 Do not touch the outer surface of the fusing film, or the surface of Warning: the heater. Fusing film Rubber ring If you do not have the pressure tools, push the arrowed point and remove Note: the fusing film. TSM Océ 3121 Dis-/assembly...
  • Page 555 Fitting the fusing film The film should be fitted with the alignment shaping at the rear Warning: (semi-transparent edge). First slide the semi-transparent edge of the film over the rollers. Semi-transparent edge Rubber Drive Fus- Tension Fusing ring roller roller film heater Remove the rubber ring, and align the straight edge (the darker edge) of the...
  • Page 556 Fit the cable guide (3 screws). Fit the alignment motor M5, making sure that the segment is correctly located in relation to the hole in the hinge arm. Hole in the hinge are Segment Reconnect the heater (1 screw). TSM Océ 3121 Dis-/assembly...
  • Page 557 The black spring is for the rear of the unit, with the smaller hook fitted to the spring post. Smaller hook Black spring spring Correct location of the springs. Smaller hook Black spring spring Reassemble the upper section and the lower section of the fuser unit. screws springs Fit the tension levers: to the front and to the rear.

  • Page 558: Functional Description

    Functional description 1 Controlling the bias for the fusing roller Bias for the transfer guide The negative bias (-600 V DC) for the transfer guide is used to prevent adhe- sion of toner to the transfer guide. The same potential is applied to the toner. Application of the bias continues when the control panel power remains ON.

  • Page 559: Fusing The Copies And Output Of The Copies

    Fixing assembly end temperature signal (TH2) Sub thermistor (TH2) Fixing temperature signal (TH1) Main thermistor (TH1) Fixing heater drive circuit Relay drive signal Relay Fixing heater drive signal (HTRD) Zero cross signal Composite power supply PCB TSM Océ 3121 Functional description...
  • Page 560 Controlling the temperature of the fuser The heater is switched OFF when the machine is in stand-by. If the temperature at copy start is less than 100°C, either of further five types of control is chosen depending on the count of copies: 1) 235°...
  • Page 561 Control 4) No of copies °C 1 - 30 31 - 40 41 - 50 51 - 100th Control 5) No of copies °C 1 - 40 41 - 50 51 - 100 TSM Océ 3121 Functional description...
  • Page 562 If the temperature is 100°C or more, or less than 140°C at copy start, one of further three types of control is chosen depending on the count of copies: 1) 215° through 180°C, 2) 205° through 180°C, 3) 195° through 180°C: Control 1) No of copies °C...
  • Page 563 The power to the heater is controlled by means of phase power control. The mi- croprocessor controls the output timing of the heater drive signal (HTRD) so that power appropriate to the target temperature of the heater may be supplied (through phase control). TSM Océ 3121 Functional description...
  • Page 564 Protection against excess temperature of the fuser Themistor TH2 monitors the rear end of the fusing film. This is to prevent an excessive temperature occurring, as this could damage the fusing film: partic- ularly when processing size B4 or smaller. When the output of TH2 exceeds 250°C.
  • Page 565 Heater ON detection circuit (200V model only) The time during which the heater drive signal (HTRD) remains OFF is moni- tored. If an error is detected, the power is switched OFF. (E004 is logged) TSM Océ 3121 Functional description...
  • Page 566 Alignment of the fusing film Outline During rotation, the fusing film tends to run towards the front or the rear of the machine. This movement is monitored by the film sensor PS2. The motor M5 is used to correct the alignment. The lower roller is released when the front door is open.
  • Page 567 If the film has become displaced so much that the correction mechanism can- not control it, ‘E007’ will be indicated. Control of the alignment motor The alignment motor is a stepping motor, rotated by the pulse signals A, A*, B, B*. TSM Océ 3121 Functional description...
  • Page 568 Locking the Fuser The locking of the film and the lower roller is designed to be released when the front door is opened. It is therefore necessary to secure the film and the roller when necessary for service work. The unit is locked by inserting the handle of the cleaning brush in the aperture.
  • Page 569 Brush Hinge arm TSM Océ 3121 Functional description...
  • Page 570 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 19 DELIVERY...
  • Page 571 Contents Adjustments 1 The position of the deflection solenoid SL5 301 Dis-/assembly 1 Output 401 Dis-/assembly of the 3-tray unit 2 Removing the covers 403 3 Removing the 3-tray unit 404 4 Removing the feeder motor (M9) 405 5 Removing the sensor PS19 and the sensor PS17 406 6 Removing the shift unit 407 7 Removing the shift motor M11 408 8 Removing the output sensor PS18 408...

  • Page 572: The Position Of The Deflection Solenoid Sl5

    Adjustments 1 The position of the deflection solenoid SL5 Remove the output unit Place the output unit vertically on a level surface. Press the plunger of the solenoid SL5 as far as it will go. The gap between the ring on the plunger and the housing of the solenoid should be 0.2 mm.

  • Page 573: Dis-/Assembly

    Dis-/assembly 1 Output Removing the lower cover from the delivery unit Switch OFF. Disconnect the mains supply cable. Open the front door Open the delivery unit, and remove the connector cover. The cover snaps open. Release the catch (3), holding the cover (2) of the delivery unit. Close the delivery unit.
  • Page 574 Withdraw the spacer (1) from the right side of the unit. Release the bushing (1), by shifting it to the left. Move the unit to the right. Remove the unit: sliding it to the left and, then, to the right. TSM Océ 3121 Dis-/assembly...

  • Page 575: Dis-/Assembly Of The 3-Tray Unit

    Dis-/assembly of the 3-tray unit 2 Removing the covers Remove the output tray Release the four catches for the cover (1): two at the top and two at the bottom. Use a small screwdriver to release the lower catches. ed.1 19 Delivery 403...

  • Page 576: Removing The 3-Tray Unit

    3 Removing the 3-tray unit Whenever you have to relocate the copier carry out the following procedure. Remove the cover (4 catches). Withdraw the strip (1). Open the 3-tray unit, and disconnect the connector (2). TSM Océ 3121 Dis-/assembly of the 3-tray unit...

  • Page 577: Removing The Feeder Motor (M9)

    Free the harness from the edge saddles adjacent to the hinge. Gripping the bottom of the 3-tray unit, remove the unit: supporting the top of the 3-tray unit, near to the catch. If the 3-tray unit is to be placed on the floor, place it with the trays Warning: underneath.

  • Page 578: Removing The Sensor Ps19 And The Sensor Ps17

    5 Removing the sensor PS19 and the sensor PS17 Remove the cover (4 catches). Disconnect the connector (1) and release the catch (2). Remove the 3-tray sen- sor PS19 (3) and the tray sensor PS17 (4). (PS19) (PS17) TSM Océ 3121 Dis-/assembly of the 3-tray unit...

  • Page 579: Removing The Shift Unit

    6 Removing the shift unit Remove the sorter from the copier. Remove the motor cover (1) (2 screws). Disconnect the connector (3). Remove the shift unit (4) (4 screws 5). ed.1 19 Delivery 407...

  • Page 580: Removing The Shift Motor M11

    Disconnect the connector (3), and remove the shift motor (1): (screw 2). 8 Removing the output sensor PS18 Remove the shift unit Disconnect the connector (1), and remove the output sensor PS18 (2). TSM Océ 3121 Dis-/assembly of the 3-tray unit...

  • Page 581: Removing The Output Roller

    9 Removing the output roller Remove the cover (4 catches). Release the catch (1), and remove the delivery roller (2). ed.1 19 Delivery 409...

  • Page 582: Functional Description

    Functional description 1 Output Outline Two delivery modes can be selected: face-up mode or face-down mode. a) Face-up output The copies are fed out with the image side upwards. Initially, face-up mode is selected, regardless of the selected copying mode. DC controller PS13 PS12...
  • Page 583 When the leading edge of the last copy reaches the sensor PS7 the deflector so- lenoid SL5 is energised, directing the copy paper to the lower delivery unit. PS13 PS12 Paper Copy paper Solenoid for the paper deflector 1 is energised TSM Océ 3121 Functional description...
  • Page 584 Shortly after the leading edge of the last copy reaches the sensor PS12, the mo- tor M7 starts to rotate in reverse. Later, the output motor M8 starts running for face-down delivery. SL5 OFF PS13 PS12 Solenoid for the paper deflector 1 is de-energised 2) Timing of operations The sequence of operations for the face-down output.

  • Page 585: Functional Description Of The 3-Tray Unit

    195 (117) x 485 x 262 195 is the total width, 117 is the width outside the copier panel- ling. Weight 6.1 kg (approximately) Maximum power consumption Specifications subject to change without notice. TSM Océ 3121 Functional description of the 3-tray unit...

  • Page 586: Nomenclature

    4 Nomenclature External View Copier’s delivery assembly 3-tray unit Tray 2 Tray 1 Output tray ed.1 19 Delivery 505...
  • Page 587 3 Delivery roller 2 9 Transport roller 2 4 Paper deflector 3 10 Delivery roller 3 5 Transport roller 1 11 Tray 2 6 Delivery roller 1 Cross section of 3-tray unit TSM Océ 3121 Functional description of the 3-tray unit...

  • Page 588: Operation

    5 Operation Settings are selected on the copier’s LCD. Of the copier settings, the following relate to the Multitray: Custom common settings To select custom common settings, select ‘ADDITIONAL FUNCTIONS’ and select ‘custom common settings’. Item Description Factory default PRINTING To set the level of priority: cop- Copier: 1 PRIORITY...

  • Page 589: Functional Design

    Copier Copier side Transport drive Feeding drive block Control system Control system DC control PBA (DC controller PCB) Drive for Tray shift drive shifting the block trays The functional blocks TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 590 Electrical circuitry The Multitray’s electrical mechanisms are controlled by the copier’s DC con- troller PCB. Copier 3-tray unit Multi-Output Tray-C1 Copier <Input block> (control system) <Input block> (control system) Photosensors Photosensors Sensor for the tray position PS16 Tray position sensor (PS16) Sensor for the Delivery 2 PS17 Delivery sensor 2 (PS17) Delivery sensor 3 (PS18)
  • Page 591 Paper deflecting During operation, the signal line is '0'. (SL8 turns On when SL3D* is ‘0’.) SL 8 (SL8 turns ON when SL3D∗ is '0'.) plate 3 solenoid deflector 3 SL3D∗ TSM Océ 3121 Functional description of the 3-tray unit...

  • Page 592: Principle Of Operation

    8 Principle of operation Outline The 3-tray unit collects the output, according to the usage mode, and allows for the selection of the required tray. Collecting the copier output The outputs may be sorted, and collected in the trays 1, 2 or 3. Collecting the printer output The outputs may be stacked, and collected in the trays 1, 2 or 3.
  • Page 593 Shortly after passing the sensor PS7, the paper is turned over and carried towards the 3-tray unit. Paper Copy paper The copy paper is collected in the tray Copier Copier side Paper Copy paper TSM Océ 3121 Functional description of the 3-tray unit...

  • Page 594: Feeding Drive System

    9 Feeding drive system Functional design Copy paper coming from the copier is controlled by the copier’s DC controller PCB and delivered to the delivery tray. The figure shows the transport drive system, and the location of the electrical components. Also included are the names of the various signals. DC controller PCB Main motor driver PCB...
  • Page 595 Solenoid SL8 for the paper deflec- J104-10 tor 3 *1 Stepping motor. *2 pin on the DC control PCB (signal line). *3 late when the sensor is ON. Electrical components, signals and signal lines TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 596 Transport drive Drive and sequence of operations (face-up delivery) Collection in the tray 2 The solenoid SL5 is energised at a specified time after the paper passes the sen- sor PS7. (Copy paper is delivered to delivery tray 3 when the paper deflecting plate 3 solenoid SL8 turns ON.) Copier side Paper deflecting...
  • Page 597 Sheet from the 3rd job tray Sheet from 3rd job Sheet from the 1st job Sheet from 1st job Sheets sorted on the tray Sheets sorted on delivery tray (top view) TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 598 Operation a) Drive for the shift M11 provides the drive for the shift of the copies. Gears and cams simultane- ously transmit the drive action to both the trays. The shift motor (M11) is a DC motor that rotates in one-direction only, and its speed and timing of rotation is controlled by the drive signals from the copier’s DC controller PCB.
  • Page 599 <Tray at Rear> <Tray at Front> Turning Turning Direction of rotation Direction of rotation Sensor for the tray position Tray position PS16 sensor (PS16) The traction gear and the position of the trays. TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 600 c) Timing of operations The motor M11 is switched ON when the leading edge of copy paper passes the inlet sensor PS19. LSTR LSTR Multitray inlet sensor (PS19) Delivery sensor 2 (PS17) Tray position sensor ∗ (PS16) Shift motor (M11) ∗1: Light-blocking plate over the sensor.
  • Page 601 A stationary jam is identified if the leading edge of copy paper does not reach the delivery sensor 2 (PS17) within a specific period of time after it has moved past the delivery sensor 2 (PS17). Delivery Sensor 2 Stationary Jam (A4, 2 copies) TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 602 Delivery Sensor 3 Delay Jam A delay jam is identified if the leading edge of copy paper does not reach the delivery sensor 3 (PS18) within a specific period of time after it has moved past the multitray inlet sensor (PS19). Delivery Sensor 3 Delay Jam (A4, 2 sheets) Delivery Sensor 3 Stationary Jam A stationary jam is identified if the leading edge of copy paper does not move...

  • Page 603: Location Of The Electrical Components

    The logging of the jams is displayed on the second screen: the types, the loca- tions, the history. I/O Display Mode The states of the sensors used in the 3-tray unit are displayed on the second screen. TSM Océ 3121 Functional description of the 3-tray unit...

  • Page 604: Self Diagnosis

    12 Self Diagnosis The microprocessor of the copier’s DC controller PCB is equipped with a mechanism to check the condition of the 3-tray unit (condition of sensors, in particular). The mechanism runs checks as necessary and indicates a specific code on the copier’s control panel if it finds an error. Self Diagnosis Code Cause Description...
  • Page 605 Delivery Paper Detection 2 signal DPD3 Delivery Paper Detection 3 signal INPD Inlet Paper Detection signal SHMD Shift Motor Drive Signal SL2D Solenoid 2 Drive Signal SL3D Solenoid 3 Drive Signal TSM Océ 3121 Functional description of the 3-tray unit...
  • Page 607 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 21 SORTER...
  • Page 608 Contents 1 Tray Controller PBA 201 Adjustments 1 Adjustment of the stapling position 301 2 Adjustment of the microswitch MS6 for the stack thickness. 302 Dis/assembly of the sorter 1 Removing the covers 402 2 Removing the sorter from the copier 403 3 Removing the transport Unit 404 4 Removing the bin unit 406 5 Refitting the bin unit 410...
  • Page 609 5 Basic Functions 508 6 Functional design 509 7 Principle of operation 517 8 Feeding drive system 533 9 Stapler unit: drive system 548 10 Bin unit: drive system 557 11 Power supply 570 Electrical diagrams 1 Sorter 701 TSM Océ 3121 Contents...

  • Page 610: Tray Controller Pba

    1 Tray Controller PBA Switch number Switch name Description Push switch To move up the bin unit. To move down the bin unit. DIP switch To set test-modes. (See the table below.) The functions of the DIP switch (SW3): Purpose SW3 setting Description Normal opera-...
  • Page 611 (M6) to rotate, shifting the special tray check mod e back and forth between the front and the rear . Solenoid Each press on the Manual Staple key causes all ON/OFF check solenoids to repeat turning on and off. mode TSM Océ 3121...

  • Page 612: Adjustment Of The Stapling Position

    Adjustments 1 Adjustment of the stapling position If the stapling position is not according to the specifications, adjust the position as follows: Execute stapling, and check the stapling position. <Specifications> Staple Staple 5±2mm 5±2mm Paper Copy paper Feeding direction Feeding direction If necessary, loosen the screw (1), and adjust the position of the stapler guide.

  • Page 613: Adjustment Of The Microswitch Ms6 For The Stack Thickness

    The microswitch MS6 operates when stapling a stack of less than 4.5 mm. Adjustment Insert a screwdriver (1), and loosen the screw. Using a hexagon socket key, turn the screw (2) to make adjustments. MS6 will not operate when the cover is removed from the stapler. Note: TSM Océ 3121 Adjustments...

  • Page 614: Dis/Assembly Of The Sorter

    Dis/assembly of the sorter Sorter Tray feeding Auxiliary trays ed.1 21 Sorter 401...

  • Page 615: Removing The Covers

    1 Removing the covers Stapler cover (2 screws) Stapler cover, inner (1 screw) Upper cover, front (2 screws) Upper cover, rear (3 screws) Lower cover TSM Océ 3121 Dis/assembly of the sorter...

  • Page 616: Removing The Sorter From The Copier

    2 Removing the sorter from the copier Release the latch, and pull the sorter away from the copier. Remove the two screws (2) from the rail (1). Gripping the front and the rear of the sorter, lift the sorter a little. Release the catches from the rail, and remove the sorter from the copier.

  • Page 617: Removing The Transport Unit

    Disconnect all the connectors from the tray control PBA. With the exception of: J10 (1), J11 (2), and J12 (3). Disconnect connector (4). Open the right cover, and remove the four screws (5). Carefully remove the transport unit. TSM Océ 3121 Dis/assembly of the sorter...
  • Page 618 Points to note when refitting the transport unit. Note: a)Make sure that the claws, that are located at the bottom of the unit, are in the holes in the cover. b) Securely connect all the connectors. Hole Hole Claw Claw Hole Hole Claw...

  • Page 619: Removing The Bin Unit

    If it is not at home position, turn off and then on the copier’s power switch. Remove the sorter from the copier. Remove the transport unit. Remove the stapler unit. Disconnect the earth cables (1). Disconnect the connector (2) for the shift motor and the feed motor. TSM Océ 3121 Dis/assembly of the sorter...
  • Page 620 Remove the three screws (3), and remove the cables. Remove the strip (4). Remove the four screws (5), and remove the detection plate (6). ed.1 21 Sorter 407...
  • Page 621 •Do not remove the string from the spring . It will be used when refitting Note: the bin unit. The situation with the spring relaxed. Note: Suspension spring Bin suspension spring String String TSM Océ 3121 Dis/assembly of the sorter...
  • Page 622 Remove the two screws (11). Remove the cable cover (12). Remove the cable clip (14) (1 screw), and release the cables. While holding the bin unit with one hand, turn the gear A to the right (arrowed direction). This releases the cam. Then, remove the bin unit. Gear A Gear A Lead cam...

  • Page 623: Refitting The Bin Unit

    When the fixed pin (3) is in the groove of the bin plate (4), insert the dummy pin (5) as indicated. Front Front Rear Rear Continue fitting the pins in the grooves of the bin plates. TSM Océ 3121 Dis/assembly of the sorter...
  • Page 624 When the fixed pin touches the cam, raise the unit as shown. The weight of the bins will move the pins into the grooves in the bin plates. While holding the bin unit with one hand, turn the gear A to the left (arrowed direction).

  • Page 625: Removing The Bins

    While paying attention to the spring (4), used to keep the guide bar and the front bin plate together, remove the four screws (6). Remove the upper cover (5). I Viewed from A Viewed from A TSM Océ 3121 Dis/assembly of the sorter...
  • Page 626 Remove the screw (8), and remove the guide (7). Loosen the screw (11), securing the front plate (9) to the base frame (10). Caution: Do not move the fixed pin (12). If pin (12) must be moved, mark its Warning: position with a scriber.

  • Page 627: Removing The Delivery Sensor

    Remove the transport unit Remove the two screws (1). Remove the guide (2). Disconnect the connector (3). Remove the two screws (5), and remove the sensor support (4). Remove the delivery sensor (6). TSM Océ 3121 Dis/assembly of the sorter...

  • Page 628: Removing The Delivery Roller

    8 Removing the delivery roller Remove the transport unit Remove the inlet guide. Remove the stapler unit. Remove the screw (2), and remove the delivery guide (1). Remove the delivery roller. 9 Removing the feeding unit Remove the bin unit. Remove the two screws (1).
  • Page 629 Disconnect the earth cables (3). Disconnect the connector (4) for the shift motor and the feed motor. TSM Océ 3121 Dis/assembly of the sorter...
  • Page 630 Remove the three screws (5), and remove the plate (6). Remove the two screws (8). Remove the stapler cover (7). Disconnect the connector J22 (9) from the control PBA. Remove the eight screws (12). These secure the plate (10) and the plate (11). Holding the units tightly together, remove the drive unit.

  • Page 631: Refitting The Drive

    IF the shift motor (1) or the feed motor (2) has been replaced, fit the Warning: cable clips (3) as shown, so protecting the cables from damage. The position of the cam requires adjustment whenever the drive has been Note: refitted. TSM Océ 3121 Dis/assembly of the sorter...
  • Page 632 Remove the E-ring (2) from the gear A (1). Disengage gear A from gear B. By turning the lead cam of the front drive assembly by hand, position it as in- dicated in “Installing the Drive Assembly”. Put the gear A back in its original position. Check the position of the cam, and refit the E-ring.

  • Page 633: Removing The Swing Motor

    Bin Unit” and C. “Removing the Bins.”) Remove the screw (2), and remove the harness cover (1) from the motor assem- bly. Remove the two screws (4) . Remove the swing motor (3). TSM Océ 3121 Dis/assembly of the sorter...

  • Page 634: Removing The Sensor P15 For The Guide-Home Position

    12 Removing the sensor P15 for the guide-home position Remove the transport unit Remove the bin unit and the bins from the sorter assembly. (See “Removing the Bin Unit” and “Removing the Bins.”) Remove the cable cover from the swing motor. Remove the screw (2), and remove the position sensor P15 (1).

  • Page 635: Removing The Stapler

    Remove the transport unit Remove the screw (2), and remove the cover (1). Disconnect the earth cable (3) and release the cable clip (4). Remove the two fasteners (5), and the cable ties (6) and (7). TSM Océ 3121 Dis/assembly of the sorter...
  • Page 636 Remove the spring (8). Remove the two screws (9). Pull out the slide rail, and remove the stapler. After refitting the stapler, ensure that the cables are fitted correctly. Warning: ed.1 21 Sorter 423...

  • Page 637: Removing The Stapler Mechanism

    (Remove the cover in the direction B while moving it in the direction A.) Remove the two screws (3). Remove the screw (4) . Disconnect the connector (5), and take out the stapler (6). TSM Océ 3121 Dis/assembly of the sorter...

  • Page 638: Removing The Slide Unit

    15 Removing the slide unit. Remove the stapler unit. Disconnect the three connectors (1). Remove the three screws (2), and remove the slide unit (3) in the direction of the arrow. ed.1 21 Sorter 425...

  • Page 639: Removing The Inlet Roller

    Remove the two E-rings (1). Then, slightly loosen the screw securing the drive solenoid (2). Remove the E-ring (4), and the gear (6) and the pulley (5). Then, while raising the deflecting plate (7), remove the inlet roller together with its shaft. TSM Océ 3121 Dis/assembly of the sorter...

  • Page 640: Removing The Feed Motor

    17 Removing the feed motor Remove the sorter from the copier. Remove the upper covers, and open the lower cover. Disconnect all connectors from the tray control PBA. Then, remove the two screws (1), and remove the tray control PBA. Remove the screw (3), and disconnect the earth cable (2).
  • Page 641 Remove the E-ring (6) from the rear of the deflecting plate. Then, raising the inlet guide (7), remove the deflecting plate (8). Remove the E-ring (9), from the belt tensioner, and remove the bush (10). TSM Océ 3121 Dis/assembly of the sorter...
  • Page 642 Remove the two screws (11). Remove the tensioner (12). Take the timing belt (13) off the gear (14). (14) (13) (11) (12) Remove the three screws (15), and remove the feed motor (16), complete with the support. (15) (16) ed.1 21 Sorter 429...

  • Page 643: Removing The Inlet Sensor Ps17

    Open the lower cover Remove the screw (1), and remove the sensor cover (2). Remove the screw (3), and disconnect the connector (4). Then, remove the inlet sensor PS17, complete with the support. TSM Océ 3121 Dis/assembly of the sorter...

  • Page 644: Removing The Delivery Sensor For Tray A

    19 Removing the delivery sensor for tray A Remove the upper covers, and open the lower cover. Remove the screw (1), and remove the sensor cover (2). Unscrew the two screws (3), and remove the right hinge. Open the right cover, and remove the right cover. Remove the bushing (4) from the front of the shaft of the deflecting plate.
  • Page 645 Remove the screw (6), and remove the sensor cover (7). Remove the screw (8), and disconnect the connector (9). Then, remove the inlet sensor PS17, complete with the support. Remove the sensor from the support plate. TSM Océ 3121 Dis/assembly of the sorter...

  • Page 646: Removing The Delivery Sensor For Tray B

    20 Removing the delivery sensor for tray B Remove the right cover. Remove the screw (1), and remove the sensor cover (2). Remove the screw (3), and disconnect the connector (4). Then, remove the delivery sensor. ed.1 21 Sorter 433...

  • Page 647: Removing The Solenoid For The Deflecting Plate

    22 Removing the solenoid for the deflecting plate 2. Remove the right cover. Remove the deflecting plate 2. Remove the screw (2), and disconnect the connector (2). Then, remove the solenoid, complete with the support. TSM Océ 3121 Dis/assembly of the sorter...

  • Page 648: Removing The Special Tray Assembly

    23 Removing the special tray assembly Remove the upper covers and the lower cover. Remove the screw (1), and remove the cover (2). Then, from inside, disconnect the three connectors. Remove the four screws (3), and remove the special tray assembly. 24 Removing the Shift Motor Remove the special tray assembly.

  • Page 649: Removing The Paper Sensor For Tray A

    25 Removing the paper sensor for tray A Remove the special tray assembly. Disconnect the earth cable (1). Remove the two screws (2), and remove the front (3) and rear (4) supports. TSM Océ 3121 Dis/assembly of the sorter...

  • Page 650: Removing The Paper Sensor For Tray B

    Remove the two screws (5). Remove the special tray A. Remove the two screws from the rear of the special tray A. Remove the paper sensor, together with the cover. Disconnect the connector, and remove the paper sensor. 26 Removing the paper sensor for tray B Remove the special tray assembly.

  • Page 651: Functional Description Of The Sorter

    Functional description of the sorter 1 Features of the sorter Separates fax output, printer output and copier output. Using specific trays, the sorter can separate the delivered documents accord- ing to type: fax mode or printer mode or copier mode. The trays A &...
  • Page 652 394 x 568 x 655 mm / 15.5 x 22.4 x 25.8 inch Weight Sorter 12 bin 25 kg / 55.1 lbs. (approximately) Sorter 25 kg / 55.1 lbs. (approximately) Power supply From copier (24 V DC) Maximum power consumption 70 W. TSM Océ 3121 Functional description of the sorter...

  • Page 653: Nomenclature

    3 Nomenclature External View The operating panel ‘Tray occupied’ lamp Bin unit (no. 1 to 10 bins) Manual Staple key Add Staple (Staple Ready indicator) indicator Special tray A Special tray B Latch Stapler Stapler cover Spare cartridge compart- ment ed.1 21 Sorter 503...
  • Page 654 Bin unit: delivery roller Paper deflector 1 Inlet roller Tray drive: inlet roller Vertical trans- port: roller 1 Tray A: delivery roller Paper deflector 2 Vertical trans- port: roller 2 Tray B: delivery roller TSM Océ 3121 Functional description of the sorter...

  • Page 655: Operation

    4 Operation Sorting: Fax or printer output With the sorter fitted to the copier. Documents from the fax or the host compu- ter may be sorted to specific tray A or B. The ‘tray occupied’ lamp switches on when a sheet is on the tray. The ‘tray occupied’...
  • Page 656 However, stapling will not occur if only one output has been delivered to each bin. Manual staple button Manual Staple key To stop stapling in the middle of operation, press the manual staple but- Note: ton once more. TSM Océ 3121 Functional description of the sorter...
  • Page 657 Manual insert stapling In addition to stapling outputs delivered to the sorter, manually insertion of sheets is also possible. Up to 20 sheets may be stapled: 80 g/m2 paper. More sheets may cause a sta- pling error. Remove all copy paper from the bin unit. Check that the bin unit is in the home position.

  • Page 658: Basic Functions

    Special tray A Special tray B Special tray B Multi Device Multi Device Host computer Host computer Controller (for Controller some copiers) (for some copiers) Copier Copier PS-GP Unit PS-GP Unit typical system configuration TSM Océ 3121 Functional description of the sorter...

  • Page 659: Functional Design

    6 Functional design Functional design The Speciality consists of six functional blocks: drive system for the bin unit drive system for the stapler feed system for the bin unit drive system for the tray feeding drive system for the tray shift control system.
  • Page 660 ¥Stapler assembly cover open/closed sensor (MS5) ¥Stapler safety sensor (MS6) ¥Stapling home position sensor (MS7) ¥Staple sensor (MS8) Sensors ¥Bin paper sensor (PT1) Communication IC controller *Multi-Output Tray 12-B2 only. PCB (copier) TSM Océ 3121 Functional description of the sorter...
  • Page 661 Inputs and outputs: Tray control PBA Inputs to the Tray control PBA (1/4) Tray controller PCB J8-6 When the lead cam makes a single rotation and Lead cam reaches home position, '1'. LCHP* home position sensor (The light-blocking plate is not blocking PI1.) J8-1 Bin unit Pulses according to the revolution of...
  • Page 662 SPUHP* When the stapler unit is sensor NO C at home position, '0'. J17-4 Stapler safety sensor SPLSFT* When the stapler safety sensor NO C is pushed, '0'. * : Negative logic. TSM Océ 3121 Functional description of the sorter...
  • Page 663 Inputs to the Tray control PBA (4/4) Tray controller PCB Control panel PCB SPLOK* When '0', the LED turns ON. J9-4 Staple Ready indicator When '0', the LED turns ON. STEMP* Add Staple indicator Manual Staple key MNSPL* When the Staple key is pressed, '0'.
  • Page 664 See p. 2-42. J4-13 Guide bar See p. 2-60. swing motor J7-1 Stapler See p. 2-46. swing motor J10-1 Tray drive motor See p. 2-31. J12-13 Tray shifting motor See p. 2-33. TSM Océ 3121 Functional description of the sorter...
  • Page 665 Outputs from the Tray Control PBA (2/2) Tray controller PCB J11-2 Paper deflecting plate 1 drive solenoid SL1D* When '0', the solenoid turns ON. J11-4 Paper deflecting plate 2 drive solenoid SL2D* When '0', the solenoid turns ON. J6-1 Inlet roller roll releasing solenoid When '0', the solenoid turns ON.
  • Page 666 Microprocessor Communication Communication Microprocessor essor (Q7) cation IC essor (Q7) essor cation IC (Q7) (Q11) tray controller PBA DC controller PBA Tray controller PCB DC controller PCB sorter copier (Multitray) (copier) TSM Océ 3121 Functional description of the sorter...

  • Page 667: Principle Of Operation

    7 Principle of operation The Multitray offers the following modes, selected on the copier’s control pan- Non-sort Mode Sort mode Group mode Staple sort mode Special tray mode Paper flow in non-sort, sort, group and staple sort Flow of paper in non-sort, sort, group, and mode staple sort mode The output generated in copier mode may be processed in non-sort, sort, group,...
  • Page 668 (lower limit sensor ON). The special trays A and B do not move up or down. Note: Normal sorting Reverse sorting Normal sorting Reverse sorting TSM Océ 3121 Functional description of the sorter...
  • Page 669 Principle of operation The sequence of operations for each mode is as follows: Non-sort mode (using bin 1) If the copier is used in copier mode, while selecting non-sort mode, the opera- tions will be as follows: The copier’s Copy Start key is pressed The bin unit moves to the home position.
  • Page 670 , the guide bar is moved to the escape position and kept in wait for delivery. á During this period, the bin shift motor (M1) rotates to return the bin to home position. TSM Océ 3121 Functional description of the sorter...
  • Page 671 Sort Mode (using No. 1 through 10 bins) The copier’s Copy Start key is pressed. The bin unit moves to the home position. The guide bar moves from the home position to the escape position, and stops. (The escape position differs, depending on the paper size.) guide bar home position Guide bar home position escape posi-...
  • Page 672 The next document is fed, and the bin unit commences the reverse sorting procedure. Operations 3 through 8 are repeated for each original that is fed. The required number of copies are made. The guide bar moves to the home position. TSM Océ 3121 Functional description of the sorter...
  • Page 673 If the DF is not used, the bin unit returns to the home position each time Note: a new document is positioned, and the copy button key is pressed. In this way, no reverse sorting takes place. If the copy count is set to ‘11’ or higher (in excess of the count allowed Note: for the number of bins), a message will be indicated on the copier’s control panel to that effect.
  • Page 674 The guide bar moves to the escape position. Operations 3 through 6 are repeated for the required number of copies. The next document is fed, and the bin unit moves down one bin. TSM Océ 3121 Functional description of the sorter...
  • Page 675 Operations 3 through 8 are repeated for each original that is fed. The copying runs ends, and the guide bar moves to the home position. If the DF is not used, the bin unit returns to the home position each time Note: a new document is positioned, and the copy button key is pressed.
  • Page 676 Copy Start key ON Copier registration roller ON signal (REGD) Copier delivery sensor (CEJCT) Bin unit delivery sensor (PI3) Bin unit feeder motor (M2) Tray feeder motor (M6) Bin shifting motor (M1) Guide bar swing motor CW/CCW (M4) Guide bar home position Arrange Escape Arrange...
  • Page 677 Staple sort mode (using No. 1 through 10 bins) The same operations as in sort mode are performed, and all outputs are de- livered to the bins. The guide bar remains in the escape position. escape position Escape position copy paper Copy paper The first copy of the final document is delivered.
  • Page 678 The guide bar moves to the escape position. The bin unit moves down one bin. Operations 2 through 5 are repeated for each bin to complete the stapling. The guide bar moves to the home position. TSM Océ 3121 Functional description of the sorter...
  • Page 679 Confidential © 1998 Océ-Technologies B.V. Copy Start key ON Copier registration roller ON signal (REGD) Copier delivery sensor (CEJCT) Bin unit delivery sensor (PI3) Bin unit feeder motor (M2) Tray feeder motor (M6) Bin shift motor (M1) Bin UP Bin DOWN Bin UP Guide bar swing motor Arrange...
  • Page 680 *For the first stapling operation, the guide bar swings twice to hold the paper twice. Then, the guide bar swings once to hold the paper for each shift of the bin unit. TSM Océ 3121 Functional description of the sorter...
  • Page 681 Special tray mode The following occurs when special tray A or B is selected for delivery of out- puts from the host computer or the fax: The Device Controller or the PS-GP Unit sends a command to the copier to print out the received pages.
  • Page 682 Represents the sequence in which the special tray shifts from the front to the rear. The tray shift motor (M7) does not rotate (and the tray does not shift) if the output is of the data from the host computer. TSM Océ 3121 Functional description of the sorter...

  • Page 683: Feeding Drive System

    8 Feeding drive system The figure shows the feeding drive system. The output from the copier is de- livered to the bin unit or the special tray, according to the mode selected by the tray control PBA. bin unit delivery sensor P13 Bin unit delivery sensor (P13) bin unit delivery roller Bin unit delivery roller...
  • Page 684 The circuit for the drive of the bin unit. Tray controller PCB J5-1 Bin unit feeder motor BFMD J8-1 BFMC Bin unit feeder motor clock sensor Bin unit drive motor drive circuit TSM Océ 3121 Functional description of the sorter...
  • Page 685 Overstacking (bin unit) The number of sheets that can be stacked in each bin is limited. Any excess will be an overstacking error. Non-sort Mode Maximum stacking All sizes 100 Copies Sort or staple sort Maximum stacking mode Small sizes 30 sheets Medium sizes 25 sheets...
  • Page 686 The output from the copier is carried through the feeding path, formed by the deflecting plate 1. This is controlled by the solenoid SL1. TSM Océ 3121 Functional description of the sorter...
  • Page 687 The deflecting plate 2 is located in the tray drive. The solenoid SL2 is switched off and on, to rotate the deflecting plate 2 and to form a path to one of the spe- cial trays. Each paper path has sensors to monitor the movement of the output. inlet sensor PI7 tray A sensor PI8 tray B sensor PI9.
  • Page 688 Special tray B delivery signal(TAB) Tray B delivery sensor (PI9) Tray shift motor drive signal(TSMD) Tray controller PCB J10-1 Tray feeder motor TFMD J11-13 TFMC Tray feeder motor clock sensor Tray drive motor drive circuit TSM Océ 3121 Functional description of the sorter...
  • Page 689 Movement of the trays (special tray mode) The special tray moves to the front or to the rear, prior to the commencement of a job, to displace the output on the tray. The output on the special tray is stacked as shown. The tray movement motor M7 does not rotate when the output is a Warning: print from the host computer.
  • Page 690 ∗1 The Multi Device Controller sends a command to the copier for a printout of the 1st communication. ∗2 The Multi Device Controller sends a command to the copier for a printout of the 2nd communication. TSM Océ 3121 Functional description of the sorter...
  • Page 691 c. Monitoring the position of the trays The position of the trays is monitored by the microprocessor Q7 on the tray control PBA. The tray position detection signal (TPD) is emitted by the posi- tion sensor PI12. Moving the tray to the rear The microprocessor (Q7) on the tray controller PCB judges that the special tray has shifted to the rear when the edge of the crescent pulley blocks the tray position sensor (PI12), i.e., when TPD goes from ‘0’...
  • Page 692 The pressure is released by the solenoid S3, lifting the roll away from the inlet roller. inlet roller roll Inlet roller roll inlet roller roll releasing sole- Inlet roller roll releasing tray drive assembly noid S3 Tray drive assembly solenoid (S3) inlet roller inlet roller TSM Océ 3121 Functional description of the sorter...
  • Page 693 Sequence of operations (two-sided copying) Inlet roller roll releasing solenoid drive signal ON Inlet roller roll releasing solenoid drive signal OFF Copier delivery roller Tray drive motor (M6) Inlet roller roll pressure releasing solenoid (SL3) : CCW rotation Detection of jams When the sorter detects a jam, the jam signal (JAM) is transmitted to the copier.
  • Page 694 2.5 sec after the copier’s delivery sensor has detected pa- per (PDP=1). Copier delivery signal Tray feeder motor (M6) Tray drive sensor Normal Error (PI8, PI9) Jam signal (JAM) ∗Depends on the model. (unit: sec) TSM Océ 3121 Functional description of the sorter...
  • Page 695 Stationary Delivery sensor: stationary With the copier in copier mode. The delivery sensor in the copier does not switch off within 3.8 seconds after the delivery sensor P13 has detected pa- per. Copier delivery signal Normal Error Tray feeder motor (M6) Bin unit feeder motor (M2)
  • Page 696 The JAM signal is generated if any of the following sensors is on when the copy button is pressed: Tray drive: inlet sensor PI7 Bin unit: delivery sensor PI3 Tray A: delivery sensor PI8 Tray B: delivery sensor PI9 TSM Océ 3121 Functional description of the sorter...
  • Page 697 Power-on jam (persistent paper jam) The JAM signal is generated if any of the following sensors is on when the cop- ier’s power switch is turned on: Tray drive: inlet sensor PI7 Bin unit: delivery sensor PI3 Tray A: delivery sensor PI8 Tray B: delivery sensor PI9 Door open: persistent jam The JAM signal is generated if the sorter is moved away from the copier, or the...

  • Page 698: Stapler Unit: Drive System

    Stapling motor motor stapler home Stapler home staple detection signal (SPEMP) Staple detection signal (SPEMP) position detection position detection stapler home position detection signal (SPLHP) Stapler home position detection signal (SPLHP) TSM Océ 3121 Functional description of the sorter...
  • Page 699 Stapling The motor M3 rotates and operates a cam to move the stapler up and down. The stapler detection cam makes a single rotation each time the stapler is activated. The rotation of the cam is monitored by the sensor MS7. stapling home position detection MS7 Stapling home position detection (MS7) stapling detection cam...
  • Page 700 The stapling motor is rotated CCW; if the state of the stapling home position sensor (MS7) does not change for 1 sec or more thereafter (i.e., stapler not re- turning to stapling home position), ‘E531’ will be indicated on the copier’s control panel. TSM Océ 3121 Functional description of the sorter...
  • Page 701 Detecting the absence of staples Sensor MS8 monitors the stock of stapes in the cartridges. The staples inside the staple cartridges are pressed against the sensor MS8. When all staples have been moved to the end of the stapler, the sensor MS8 opens.
  • Page 702 Sensor MS6 opens when the actuator in the stapler is raised. Gap A for the movement of the actuator is 4.5 to 5.8 mm. MS6 will not operate when the cover is removed from the stapler. Warning: Stapler safety sensor (MS6) Actuator Stapler TSM Océ 3121 Functional description of the sorter...
  • Page 703 Controlling the movement of the stapler The stapler is moved to prevent interference with the paper in the bin. paper Paper stapler unit Stapler unit stapling (top view) Stapling (top view) paper Paper stapler unit Stapler unit bin shifting(top view) Bin shifting (top view) ed.1 21 Sorter 553...
  • Page 704 Detection of the position of the stapler during the movement The position of the stapler is determined by combinations of the states (ON/OFF) of two sensors: Stapler: detection of position PI4 Stapler: home sensor MS4 TSM Océ 3121 Functional description of the sorter...
  • Page 705 Sensor Stapling position (left Stapler in home posi- picture) tion (right picture) Stapler: detection of position PI4 Stapler: home sensor swinging arm joint Swinging cam Joint swing- stapler Swinging Stapler joint Joint ing arm stapler Stapler copy paper Copy paper copy paper Copy paper stapling position (top view)
  • Page 706 Stapler position sensor (PI4) Stapling home position sensor (MS7) Stapler home position sensor (MS4) Stapler safety sensor (MS6) <Bin unit> Bin shift motor (M1) Lead cam home position sensor Shift by bin (PI1) TSM Océ 3121 Functional description of the sorter...

  • Page 707: Bin Unit: Drive System

    10 Bin unit: drive system The figure below shows the drive system for the bin unit. The bin unit moves each of the bins up and down, to sort the output from the copier. The home position of the bin unit is where the bin unit is moved up an equiv- alent of a single rotation of the lead cam from its bottom position (bin home sensor MS1 is ON).
  • Page 708 It is held in position by rolls and cams fitted to the front and the rear of the bin frame. The suspension by two springs reduces the load on the cams during the move- ment of the bins. fixed pin Fixed pin dummy Dummy pin roll Roll TSM Océ 3121 Functional description of the sorter...
  • Page 709 Movement of the dummy Pin A dummy pin is provided between the fixed pin and the roll, on both sides of the bin unit. The dummy pin prevents the bin unit moving down too far. The dummy pin en- gages with the lead cams and the fixed pins after the bin unit has reached its lower limit.
  • Page 710 Lead cam When the cams rotate, and the rolls move up or down through the grooves of the cams, the connected bin will also move up or down. rolls Rolls lead Lead cam TSM Océ 3121 Functional description of the sorter...
  • Page 711 A flat section is cut in the lead cam. This is to prevent the lead cam from rotat- ing under the weight of the bin unit. When the bin unit is stationary, the cam home sensor (PI1) monitors the situa- tion.
  • Page 712 Over slope Over level Over slope section section section section Movement of roll on lead cam (station- (station- Height Bin shift (stationary) Height Bin shift constant ary) constant ary) Over level section TSM Océ 3121 Functional description of the sorter...
  • Page 713 Bin: home sensor MS1 The home position of the bin unit is determined when the detecting plate press- es against the bin home sensor MS1. When the bin unit moves to the home position, the bin unit first moves down, then up, for a single rotation of the lead cam: after detection of the home posi- tion by the sensor MS1.
  • Page 714 (BMDWN) The bin shift motor rotates CCW. The bin unit moves down. The bin shift motor rotates CW. The bin unit moves up. The bin shift motor stops. The bin unit stops. TSM Océ 3121 Functional description of the sorter...
  • Page 715 a.Moving the bin UP To move the bin up, the microprocessor (Q7) generates: the bin shift motor UP signal BMUP=1 and the bin shift motor DOWN signal BMDWN=0 BMUP=1 Q39 is switched ON. Q16 is switched ON. Q17 is switched OFF. 24 V is applied to the motor M1.
  • Page 716 In addition, MS4 communicates to the microprocessor that MS4 is not in the home position. If the microprocessor generates BMDWN=1 or BMUP=1 at this time, Q42 and Q44 switch off. The motor M1 will not rotate. TSM Océ 3121 Functional description of the sorter...
  • Page 717 Controlling the guide bar The guide bar is inside the bin unit. The bar swings each time an output is de- livered to position the output against the side guide. In addition, the guide bar swings for stapling operation, holding the sheets in position.
  • Page 718 Paper width Paper size Paper width Length R A3/A4 B4/B5 22.5 A5/A4R Paper holding position The guide bar swings, jogging the output against the front guide. guide plate Guide plate TSM Océ 3121 Functional description of the sorter...
  • Page 719 Stapling wait position (manual stapling) If copies are made in sort mode and outputs are stapled manually, the guide bar is held in wait position at a point ‘paper size + 8 mm’ while bins are shifted. 8 mm Controlling the motor M4 Motor M4 is a 2-phase stepping motor.

  • Page 720: Power Supply

    24VPB cover open/closed sensor is on. : Multi-Output Tray 12-B2 only. Sorter 12 bin only. Tray shift motor TSM Océ 3121 Functional description of the sorter...

  • Page 721: Electrical Diagrams

    Electrical diagrams ed.1 21 SORTER 701...
  • Page 722 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 22 POWER & CONTROL...
  • Page 723 Contents Dis-/assembly 1 DC control PBA 401 2 Power supply PBA 402 3 LCD PBA and CPU PBA 403 Functional description 1 Electrical Circuitry 501 2 Fans 518 3 Power supply 520 4 SLEEP Mode 524 5 Signals and Abbreviations 527 Location of components 1 Location of the extension boards 601 2 Clutches and solenoids 603...

  • Page 724: Dis-/Assembly

    Dis-/assembly 1 DC control PBA Replacing the DC Control PBA Disconnect the mains supply cable. Remove the rear cover (4 screws). Remove the two screws (1) . Disconnect all the connectors. Then, remove the DC control PBA (2). Replace the new PBA with the actions in reverse order. After replacement, execute (*4* Function 12 R&D Shading Start) Note: ed.1...

  • Page 725: Power Supply Pba

    Enter the values, which are recorded on the label attached to the composite power supply PBA, in (*3* Adjust 03). Execute (*4* Function 03 Auto Shading Start). Execute (*4* Function 04 PD Print). Execute (*4* Function 05 200 PWM Print). Execute (*4* Function 04 600 PWM Print). TSM Océ 3121 Dis-/assembly...

  • Page 726: Lcd Pba And Cpu Pba

    3 LCD PBA and CPU PBA Removing the LCD PBA and the CPU PBA Remove the inside, front cover (See Miscellaneous Page ..) Remove the magnetic latch plate (1 screw) of the RDF: at the front of the plat- Remove the RDF and the sorter power supply unit (top left). Remove 2 x black and 2 x silver coloured screws, to remove the control panel from the machine.

  • Page 727: Functional Description

    1 Electrical Circuitry Control The Océ 3121’s electrical mechanisms are controller by the CPU on the PBAs shown in the “Block diagram of the CPU”. See the tables for an idea of the functions of the CPU and the functions of the ROMs/RAMs and the ICs around the CPU.
  • Page 728 Controls the power supply system Controls the HT supply Monitors the inputs to the power switch and the de-humidi- fier switch Monitors the calling indicator (fax call signal) Controls the loading of the power supply Controls the scanning lamp TSM Océ 3121 Functional description...
  • Page 729 Block Diagram of the CPU 2. Block Diagram of the CPU Control panel Serial communication Image processor PC CORE/IP G3FAX Board Board Mother- Telephone board line Modem IC506 IC564 MASK ROM SIMM J527 IC650 Selector FLASH Memory control IC651 FLASH Coding/ decoding Memory Memory...
  • Page 730 Clutch Solenoid Motor Sensor Etc. Laser scanner motor System Mother- board controller Network I/F Board (option) The CORE/IP board, FAX motherboard come standard with the Océ Note: 3121. The G3 FAX board is optional TSM Océ 3121 Functional description...
  • Page 731 Inputs to the major PBA Power supply circuit Sorter ACC power supply PCB Main switch Composite power supply PCB System System power Motherboard supply PCB J210 (option) DC power supply circuit J201 Front door switch Noise filter Fluorescent heater Fixing heater switch Fixing heater...
  • Page 732 J519 Laser driver See p. 3-54 Power supply LEDON indicator LED When '1', LED turns ON. (Turns ON when the main power switch is ON.) Power saving mode switch J560 J183 Control Card V (option) TSM Océ 3121 Functional description...
  • Page 733 Image processor PBA (2/3): inputs and outputs. ed.1 22 Power & Control 507...
  • Page 734 Image processor PBA (3/3): inputs and outputs. TSM Océ 3121 Functional description...
  • Page 735 DC Control PBA (1/3): inputs ed.1 22 Power & Control 509...
  • Page 736 DC Control PBA (2/3): inputs TSM Océ 3121 Functional description...
  • Page 737 DC Control PBA (3/3): inputs ed.1 22 Power & Control 511...
  • Page 738 Set-back motor See p. 3-110 24V24V J105-B6 Duplexing assembly See p. 3-108 inlet motor 24V24V J105-A8 Delivery reversing motor See p. 3-127 -A10 (GP215 only) -A11 24V24V J115-1 See p. 3-114 Holizontal motor FIG. 3-111 TSM Océ 3121 Functional description...
  • Page 739 DC control PBA (2/3): outputs 24VU J114-B10 Registration clutch -B11 RGCD* When '0', CL1 turns ON 24VU J114-B8 Multifeeder pick-up clutch MFCD* When '0', CL2 turns ON 24VU J113-B13 Developing clutch -B14 DVCD* When '0', CL4 turns ON 24VU J122-5 Lower feeding assembly re-pick up When '0', CL5 turns ON...
  • Page 740 DC control PBA (3/3): outputs TSM Océ 3121 Functional description...
  • Page 741 Main power ON Copy Start key ON Control panel power OFF INTR1 STBY INTR2 SCFW STBY SLEEP SCFW LSTR Main motor (M1) Fixing heater (H4) Scanner motor (M2) Scanner HP sensor (PS1) Scanning lamp (FL1) Shading measurement Cassette pick-up solenoid (SL2) Pick-up motor (M4) Vertical path roller clutch (CL3) Vertical path roller paper sensor (PS8)
  • Page 742 CCD, via tion ratio. mirrors and ..lenses. SCRV (scan reverse) While the scanner is Returns the moving in reverse. scanner to the home position, preparing for the next copy- ing operation. TSM Océ 3121 Functional description...
  • Page 743 Period Purpose Remarks LSTR (last rotation) From the end of Cleans the sur- Delivers the last SCRV until the copy face of the output. passes the output sen- drum: dissipa- Two minutes sor. tion of resid- after the end of ual charge.

  • Page 744: Fans

    Exhausts heat. FM4 Laser cooling fan Suction Cools the laser unit. FM5 Electrical unit fan Suction Exhausts the heat from the electrical unit. FM6 Refeed cooling fan Exhaust Cooling the copy paper in the refeed unit TSM Océ 3121 Functional description...
  • Page 745 Timing of operations main power Star key Control panel power switch ON switch OFF INTR SLEEP STBY SCFW SCFW LSTR STBY Feedding fan (FM1) Exhaust fan ½ (FM2/3) Laser cooling fan (FM4) Electrical unit cooling fan (FM5) High-speed rotation Low-speed rotation 1: Quite mode is set to either 1 through 9 min;...

  • Page 746: Power Supply

    PBA. The printer functions are not enabled. Economy mode is disabled for printer mode. The same applies if the fax mode is set to start at a specific time of the day. TSM Océ 3121 Functional description...
  • Page 747 Quick-start mode (SLEEP 1) In quick start mode, the image processor PBA and the DC CONTROL PBA (white areas in figure “Outline of Power Supply in SLEEP 1 (quick start mode)”) are supplied with power. In this mode, FAX and printer functions are enabled.
  • Page 748 Outline of the power supply: SLEEP1 (quick start mode) *Power is not supplied to the shaded functions. TSM Océ 3121 Functional description...
  • Page 749 Outline of the power supply: SLEEP2 (economy mode) *Power is not supplied to the shaded functions. ed.1 22 Power & Control 523...

  • Page 750: Sleep Mode

    SLEEP 2 to SLEEP 1 Occurs when an incoming call is detected. SLEEP 2 to Standby During off-hook. When the ON/OFF switch on the operating panel is switched ON. When the economy switch is switched ON (moved up). TSM Océ 3121 Functional description...
  • Page 751 State Device Description CPU on the CPU on power sup- the image image ply PBA processor memory Power Stops Stops Stops Retained None by battery Retained SLEEP 2 Operates Fax reception is by power enabled; after supply receipt, it moves to sleep 1 SLEEP 1 Operates...
  • Page 752 Cycle of SLEEP Mode States Top: SLEEP 1 Bottom: SLEEP 2 SLEEP 1 SLEEP 2 TSM Océ 3121 Functional description...

  • Page 753: Signals And Abbreviations

    5 Signals and Abbreviations Signals 1RPD0 UPPER CASSETTE PAPER DETECTION 0 signal 1RPD1 UPPER CASSETTE PAPER DETECTION 1 signal 2RPD0 LOWER CASSETTE PAPER DETECTION 0 signal 3RPD1 LOWER CASSETTE PAPER DETECTION 1 signal ACON AC DEVELOPING BIAS DRIVE command APCON AUTO POWER CONTROL ON command ASCNTP ASSIST COUNTER PULSE signal...
  • Page 754 PDP7 PAPER DETECTION signal 7 PEXP PRE-CONDITIONING EXPOSURE LAMP LIT command RDOD RIGHT DOOR OPEN DETECTION signal RFLD REPICK UP ROLLER SECTION SOLENOID DRIVE signal RGCD REGIST CLUTCH DRIVE signal RTEMP DRUM TEMPERATURE DETECTION signal TSM Océ 3121 Functional description...
  • Page 755 Signals SCHP SCANNER HOME POSITION signal SEBON SEPARATION STATIC ELIMINATOR ON command SAMPLE HOLD signal SL2D SOLENOID DRIVE signal 2 SRGPD SIDE REGISTRATION PAPER DETECTION signal Laser ON ANTI-CONDENSATION HEATER SWITCH DRIVE com- mand LIGHT INTENSITY SW0 LIGHT INTENSITY SW1 TONER EMPTY signal FIXING THERMISTOR 1 signal FIXING THERMISTOR 2 signal...

  • Page 756: Location Of Components

    Location of components 1 Location of the extension boards 1 SCSI PBA 6 System motherboard PBA 2 CIST PBA 7 System power supply 3 CORE/IP PBA 8 Protocol control PBA 4 FAX Motherboard PBA 9 Network interface PBA 5 Printer PBA 10 FAX PBA ed.1 22 Power &...
  • Page 757 The copier has two power switches: the ON/OFF switch, and the power switch on the operating panel. The ON/OFF switch should be operated first. Control panel: ON/OFF switch ON/OFF switch Main power supply lamp TSM Océ 3121 Location of components...

  • Page 758: Clutches And Solenoids

    2 Clutches and solenoids CL1 Drives the registration roller SL1 Drives the cleaner for the charging roller CL2 Drives the pick-up roller for specialities SL2 Lowers the pick-up roller CL1 Drives the vertical transport roller SL3 Releases the specialities CL4 Drives the developing roller SL4 Drives the deflecting plate for the re-feed CL5 Drives the refeed assembly pick-up SL5 Drives the deflecting plate for output...

  • Page 759: Motors

    M6 Motor for the retarding roller M2 Scanner motor M7 Duplex motor M3 Laser scanner motor M8 Motor for the output roller M4 Pick-up motor M9 Horizontal registration: sensor drive motor M5 Fusing film motor TSM Océ 3121 Location of components...

  • Page 760: Fans

    4 Fans FM1 Feeding fan FM4 Laser cooling fan FM2 Delivery fan 1 (rear) FM5 Electrical unit fan FM3 Delivery fan 2 (front) FM6 Lower feed: inlet fan ed.1 22 Power & Control 605...

  • Page 761: Sensors

    SD1 Document size sensor 1 PS8 Detects ‘paper in front of the vertical SD2 Document size sensor 2 transport’ PS9 Detects ‘right door open/closed’ SD3 Document size sensor 3 PS10 Detects ‘waste toner’ SD4 Document size sensor 4 TSM Océ 3121 Location of components...

  • Page 762: Switches And Counters

    6 Switches and counters CNT1 CNT2 CNT3 SQ1 ON/OFF switch CNT2 Counter 2 SW2 Front door switch CNT3 Counter 3 SW3 Economy-mode switch VZ1 Pre-registration guide varistor SW4 Cassette heater switch R1 High voltage resistor CNT1 Counter 1 FL1 Scanning lamp ed.1 22 Power &...

  • Page 763: Pba's

    Pick-up unit PBA Cassette size detection (upper) Cassette size detection (lower) Pre-exposure lamp Speciality paper width detection PBA Service switch PBA LCD intensity adjust- ment PBA LCD PBA (control panel) CPU PBA (control panel) TSM Océ 3121 Location of components...

  • Page 764: Fax Related Pba's

    8 Fax related PBA’s 1 CORE/IP PBA 5 Modular jack PBA 2 FAX Motherboard PBA 6 Speaker 3 FAX PBA 7 Expansion memory (option 3 MB or 9 MB, image memory) 4 NCU 8 Expansion memory (option 3 MB, page memory) ed.1 22 Power &...

  • Page 765: Image Processor Pba

    9 Image processor PBA J504 J502 J507 J509 J501 J561 J508 J527 SW501 J512 J505 J506 J514 J526 J560 J517 J516 J519 J518 230V 100V 120V 230V AB/Inch Inch SW501 TSM Océ 3121 Location of components...

  • Page 766: Dc Control Pba

    10 DC control PBA LED100 LED 100 indicates the condition of the power supply PBA, by varying ON/OFF intervals. VR1 adjusts the intensity of the scanning lamp when executing ‘factory/R&D shading’ under *4* FUNCTION. 11 Power supply PBA ed.1 22 Power & Control 611...

  • Page 767: Fax Pba/Ncu

    RAM-B if RAM-A, 3 MB has been installed). SW1 to be used with all bits OFF SW2 to be OFF first when installing expansion memory. Then, ON after the work. LED1 ON when 5V is supplied normally. TSM Océ 3121 Location of components...

  • Page 768: Core/Ip Pba

    13 CORE/IP PBA J502 J510 J503 J501 J504 ed.1 22 Power & Control 613...

  • Page 769: Electrical Diagrams

    Electrical diagrams ed.1 22 POWER & CONTROL 1 701...

  • Page 770: Power & Control 2

    ed.1 22 POWER & CONTROL 2 702...

  • Page 772: Power & Control 4

    ed.1 22 POWER & CONTROL 4 704...
  • Page 773 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 23 DRIVE...
  • Page 774 Contents Dis-/assembly 1 Removing the main motor 401 Functional description 1 Main motor control PBA 501 2 Rotation 501 3 Controlling the Speed 502 ed.1 23 Drive...

  • Page 775: Dis-/Assembly

    Dis-/assembly 1 Removing the main motor Disconnect the mains supply cable. Remove the following: The rear cover (4 screws) The flywheel (3 screws) Remove the four screws (2), and disconnect the two connectors (3). Then, re- move the main motor (1). ed.1 23 Drive 401...

  • Page 776: Functional Description

    Functional description 1 Main motor control PBA Outline The main motor (M1) is controlled by the drive signal (MMD) generated by the DC control PBA. The motor drives: Developing unit Feeding unit Fusing unit Specialities: pick-up roller Registration roller Vertical transport: roller 1/2 Delivery roller 1 Refeed unit: exit roller The speed of the motor is controlled by the main motor control PBA.

  • Page 777: Controlling The Speed

    (‘E010’ will be indicated on the control panel.) Composite power supply Main motor driver PCB +24V Drive current Main Drive DC controller PCB motor circuit (M1) Encoder J114-B6 Control circuit Hall IC output MLCK* Output pulse J114-B7 Reference signal TSM Océ 3121 Functional description...
  • Page 778 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 MISCELLANEOUS...
  • Page 779 Contents Miscellaneous 1 Handling the cables 101 2 Covers 102 3 Removing the right cover 103 4 Inside Cover 104 ed.1 Miscellaneous...
  • Page 780 Miscellaneous 1 Handling the cables Exercise care when moving the harness retainer (square cable clip) to avoid damaging any cables. ed.1 01 Miscellaneous 101...
  • Page 781 External View Front door Right cover Rear cover Output unit cover Left cover Output tray Tray cover Lower output cover Remove the covers as necessary when cleaning, inspecting, or repairing the in- side of the machine. TSM Océ 3121 Miscellaneous...
  • Page 782 3 Removing the right cover Skip steps 4) and 5) if the lower right cover is not fitted. Note: Remove the rear cover (4 screws). Open the front door Slide open the cassette. Remove the screw (1) from the lower cover. While pulling the centre of the cover, disengage the hook and remove the cover.
  • Page 783 4 Inside Cover Remove the screw (1), and slide the two pins (2) out of the hinges to remove the front door. Remove the inner cover (3) from the fuser ( 1 screw ). TSM Océ 3121 Miscellaneous...
  • Page 784 Release the lever (5). Unscrew the button (6), and remove the OPC unit. Turn the lever (5), to lock the developing unit. Release the feeding unit. Remove the clip (8), the lever (7) and the knob (9). Slide out the upper cassette. Remove the inside cover (5 screws, index 10).
  • Page 785 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 PREVENTIVE MAINTENANCE...
  • Page 786 Contents Preventive maintenance 1 Points to note for scheduled servicing 1 2 Periodically Replacable Parts 2 3 Consumables and Durables 2 4 Scheduled Servicing Work Flow 3 5 Scheduled Cleaning 4 ed.1 01 Preventive maintenance...

  • Page 787: Preventive Maintenance

    Preventive maintenance 1 Points to note for scheduled servicing ed.1 01 Preventive maintenance 1...

  • Page 788: Periodically Replacable Parts

    200,000 Transfer roller ..200,000 Pick-up and feeding ..100,000 Copies produced roller Separation roller ..200,000 Copies produced Separation pad ..200,000 Pre-exposure lamp ..200,000 Developing roller ..400,000 ..400,000 ..TSM Océ 3121 Preventive maintenance...

  • Page 789: Scheduled Servicing Work Flow

    4 Scheduled Servicing Work Flow Step Adjustments Checks Remarks Consult the operator Enquire about machine perform- ance. Record the counter read- Check the copy quality, etc. ing. Make a series of test copies Check the following: Note: a Image density Standards: 2.5 ±1.0 b Background (for minimum) c Characters (for clarity)

  • Page 790: Scheduled Cleaning

    Reflector for the scanning lamp Clean The mirrors 1 to 3. Clean Lens Clean Document size sensor Clean Aperture glass Clean Developing unit The developing roller Clean Fusing unit Fuser entry Clean Lower fusing: separation claw Replace TSM Océ 3121 Preventive maintenance...
  • Page 791 RDF Consumables and durables Some parts may have to be replaced once or more during the period of warran- ty because of wear or damage. Replace such parts when they fail. No. Parts Parts No. Q’ty Life Remarks (copies) Feeding belt 200,000 If dirt cannot be removed Pick-up roller...
  • Page 792 Delivery roller (copier mode) Clean Pick-up roller (pick-up assembly) Clean Feeding belt Clean Delivery roller (fax mode) Clean Stamping cartridge Check/Replace Platen retainer (right) Clean Platen Clean Separation front guide Clean Vertical size plate Clean TSM Océ 3121 Preventive maintenance...
  • Page 793 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 TECHNICAL DATA...
  • Page 794 Contents Technical data 1 SPECIAL FEATURES Screen 1 2 Functions 2 3 Features 7 4 Specifications 8 ed.1 01 Technical data...
  • Page 795 Technical data 1 SPECIAL FEATURES Screen SPECIAL FEATURES Next screen Remarks screen TWO-PAGE SEPARATION TRANSP. INTERLEAVING Stack bypass Select A4, A4R, LTR, LTRR SHIFT Center Shift, Corner Shift (8 directions), Keypad Setting SHEET OVERLAY SHEET OVERLAY Requires a duplexing BOOK OVERLAY unit.
  • Page 796 (1) Adding Copy Paper (2) Copying on Copy Paper Shift: You can shift the position of the original anywhere Center Shift for copying. For corner shift, you may select one Corner Shift from eight directions. Keypad Shift TSM Océ 3121 Technical data...
  • Page 797 Description Overlay: You can lay two images on the same side of a single Sheet Overlay sheet of copy paper in any of three ways: Book Overlay Making an overlay copy from two one-sided ordinals. Making an overlay copy from an open original (book).
  • Page 798 You can select from among the following four types of Sheet Frame Erase frame erasing: Original Frame Erase (1) Original Frame Erase Book Frame Erase (2) Sheet Frame Erase Binding Erase (3) Book Frame Erase (4) Binding Erase TSM Océ 3121 Technical data...
  • Page 799 Description You can select any of the following modes after Image Creation: Mirror Image pressing the Image Create key. Image Repeat Negative/Positive Reversal Slant Image Image Comb.: You can reduce two or four originals to copy on a 2-on-1 single sheet of copy paper. For details, see the Oper- 4-on-1 ator’s Manual, as the specifics vary depending on 2-on-1 Two-Sided...
  • Page 800 You can select up to two Preference keys from ting among the extension mode keys for display on the Copier Basic screen. Custom Setting Initial- You can initialize the copier specifications settings to factory defaults. TSM Océ 3121 Technical data...
  • Page 801 Description You can store/initialize the combination of copying Standard settings: Store modes in response to power-on or a press on the Reset key. Init. ed.1 01 Technical data 7...
  • Page 802 **Standby state is when the main power is on. In copier/fax mode, 57 W or less. In copier mode, 50 W or less. TSM Océ 3121 Technical data...
  • Page 803 4 Specifications Type Item Specifications Body Desktop Copyboard Fixed Light source Fluorescent lamp Lens Lens array Photosensitive medium System Item Specifications Copying Indirect electrophotographic Charging AC roller charging Exposure Spot laser Copy density adjustment Automatic or manual Development Dry, single component toner projec- tion Pick-up Automatic 2 cassettes...
  • Page 804 A3 (297 x 420 mm; max.) / 11”x17” pick-up (279x432mm:max) A5 (STMT; min.) Multifeeder A3 (297 x 431.8 mm; max.) / 11”x17” (279x432mm:max) Postcard (A6 vertical) Paper source 500 sheets in each cassette, 50 sheets in multi- feeder (80 g/m2 paper) TSM Océ 3121 Technical data...
  • Page 805 120V 230V Types of Cassette Plain paper (64 to 80 g/m2), tracing paper *, copy paper colored paper*, recycled paper (64 to 80 g/m2), envelope *May be used but may not feed as expected Multifeeder Plain paper (64 to 128 g/m2), tracing paper* , transparency*, postcard, label sheet, recycled paper (64 to 80 g/m2), envelope *May be used but may not feed as expected...
  • Page 806 585 mm (pedestal, copyboard cover) Depth 700 mm (pedestal) Height 571 mm (pedestal, RDF) Weight Body only 72.4kg (w/ original glass cover) With RDF 84.7kg Consumables Copy paper Toner Keep copy paper wrapped to protect against humidity. TSM Océ 3121 Technical data...
  • Page 807 Copying Speed Reproduction Size Copy paper Copies/min ratio size Direct A3 (297 x 420mm) A4 (210 x 297mm) A4R (297 x 210mm) A5 (148.5 x 210mm) A5R (210 x 148.5mm) B4 (267 x 364mm) B5 (182 x 257mm) B5R (257 x 182mm) Reduce A3 - A5 A3 - B5...
  • Page 808 STMT STMT-R REDUCE LGL - LTRR 11x17 - LGL 11x17 - LTRR 11x17 - STMTR 11x15 - LTRR ENLARGE LGL - 11x17 LTR·R - 11x17 STMTR - 11x17 Specifications subject to change for product improvement. TSM Océ 3121 Technical data...
  • Page 809 Océ Océ Océ Océ Technical Service Manual Océ 3121/3122 SDS DESCRIPTION...
  • Page 810 Contents SDS Description 1 Outline 1 2 Starting Service Mode 2 Keys 3 Using Adjustment Mode and Settings Mode 4 3 *1* DISPLAY (control display mode) 6 *1* DISPLAY 01 Temperature Indication 6 *1* DISPLAY 02 Jam History 1 7 *1* DISPLAY 03 Error/Alarm Indication 10 ALARM (RDF) 10 Overstacking alarm (Multi Tray-12) 12...
  • Page 811 ‘ * 8 * 6 GENESIS ‘ 78 ‘ * 8 * 7 PRINTER ‘ 79 Service soft switch settings 79 ‘ 7 NUMERIC ‘ Parameter settings 82 ‘ * 8 * 8 CLEAR ‘ 84 TSM Océ 3121 Contents...
  • Page 812 ‘ * 8 * 9 ROM ‘ Info display 84 ‘ * 8 * 10 ‘ Test mode 85 ‘ * 8 * 10 TEST ‘, 1 DRAM test To execute a write or read check of data for all area of the D-RAM (D-RAM A (Q6, Q18), D-RAM B (Q8, Q20).

  • Page 813: Sds Description

    SDS Description 1 Outline The machine’s service mode is grouped into the following: Item Description *1* DISPLAY Display Mode Indicates the values controlled by the CPU, nature of control, and version number of the ROM. *2* I/O DISPLAY I/O Display Mode Indicates the elements controlled by the CPU or the input/output signals to and from options.

  • Page 814: Starting Service Mode

    Insert the door switch actuator into the door switch assembly. (If you want to execute a specific mode such as ‘I/O display’ while making copies, see the appropriate copying modes). Door switch actuator TSM Océ 3121 SDS Description...

  • Page 815: Keys

    Press the service switch with a hex key. ‘$’ will appear in the upper left corner of the LCD, indicating that the ma- chine has started service mode. Press the * key twice. The LCD changes to the Service Mode Menu screen (initial screen). Press the appropriate item to highlight.

  • Page 816: Using Adjustment Mode And Settings Mode

    AGS OFST PWN 600 MIN PRI DC OFST PWN 600 MAX PRI AC OFST1 PWN 200 MIN PRI AC OFST2 PWN 200 MAX TRNS OFST AE-SLOP FL OFST FIXER_RESIST Service Label; attached behind the front door TSM Océ 3121 SDS Description...
  • Page 817 Service Label; attached to the image processor PBA APVC GAIN APVC OFST PDC OFST PAC OFST1 PAC OFST2 ATVC OFST FL OFST DDC OFST Service Label; attached to the composite power supply PBA ed.1 SDS Description 5...

  • Page 818: Display 01 Temperature Indication

    MAIN_TH Indicates the temperature at the middle of the fix- Unit: °C ing assembly. (output of thermistor TH1) SUB_TH Indicates the temperature at the end of the fixing Unit: °C assembly. (output of thermistor TH2) TSM Océ 3121 SDS Description...
  • Page 819 *1* DISPLAY 02 Jam History 1 Use this mode to display a history of jams (jam data) covering the most re- cent 40 jams in reversed order of occurrence. Press the key to scan through the levels (screen Nos. 11 through 20, 21 through 30, and 31 through 40).
  • Page 820 35:delivery tray 3 paper sensor (multi tray 3; PS 18) 61:Multi tray 3 inlet sensor (PS19) 62:Duplexing unit inlet sensor (PS12) 63:re-pick up paper sensor (PS11) 11:door open 01:front door 02:right door 03:pedestal right door 00:multi tray 12/feeder See p. 7-51. TSM Océ 3121 SDS Description...
  • Page 821 ** Pick-Up Location Codes Code Pick-up location Cassette 1 Cassette 2 Cassette 3 Cassette 4 Cassette 5 Cassette 6 Multifeeder Two-sided/overlay re-pick up Multi tray 12-/Feeder-Related Jam Codes Unit Jam code Description Multi Tray-12 0003 Sorter feeding delay jam 0004 Sorter feeding stationary jam 0006 Sorter staple jam...

  • Page 822: Display 03 Error/Alarm Indication

    Refers to the copier. Refers to the feeder (ADF/RDF). Refers to the sorter. Copier-Related Alarm Code Description Replace the drum unit. ALARM (RDF) S1 Original tray paper sensor Pick-up sensor S3 Registration paper sensor S13 Re-circulation sensor TSM Océ 3121 SDS Description...
  • Page 823 Type Sensor Conditions RF operation Code Re-circulating The re-circulating lever swung Stops immediately lever idle swing idly without coming into con- upon detection. tact with an original immedi- ately after the re-circulating motor (M4) has started to oper- ate. Pick-up fault The sensor (S7) does not detect The separation belt, the leading edge of an original...

  • Page 824: Overstacking Alarm (Multi Tray-12)

    M1, guide bar ever, permits off and then swing motor M4 or delivery to the on the power. stapler swing motor tray. M5; the same type of error has occurred after turning off and on the power TSM Océ 3121 SDS Description...

  • Page 825: Stapler Alarm (Multi Tray-12)

    Stapler alarm (Multi Tray-12) Code Nature Cause Operation Display Resetting Staple jam The stapler safety sen- Stops stapling Flashes the Wait until the sor MS6 has turned on Manual Sta- machine automati- for some reason. ple key. cally recovers Indicates a (about 1 sec after the The stapler is not message on...
  • Page 826 LANG Indicates a specific language: COMMON, JAPANESE, ENGLISH, FRENCH, GERMAN, DANISH, DUTCH, FINNISH, ITALIAN, NORWEGIAN, PORTUGESE, SPANISH, SWEDISH POWER_CPU Indicates the version number of the CPU on the composite power supply PBA. TSM Océ 3121 SDS Description...

  • Page 827: Display 06 Key/Editor Indication

    *1* DISPLAY 05 Version indication 2 The indication is given when an expansion board is installed and, therefore, no indication appears in the absence of such a board. Item Description PRCNT Indicates the version number of the Protocol Control PCB. Indicates the version number of the Network Interface Board (NIB).
  • Page 828 KEY-CHK code Code One-Touch Code One-Touch Code One-Touch Code Keypad 0 Keypad 1 Keypad 2 Keypad 3 Keypad 4 Keypad 5 Keypad 6 Keypad 7 Keypad 8 Keypad 9 Start Stop Clear Interrupt Guide User Mode TSM Océ 3121 SDS Description...

  • Page 829: Display 07 Copy Paper Size Indication

    *1* DISPLAY 07 Copy Paper Size Indication Use this mode to indicate the size of copy paper set in the multifeeder or in the cassettes and the output readings of the paper size sensors. Item Descriptions MULTI Refers to the multifeeder. Indicates the output (analog) of the multifeeder width sensor.
  • Page 830 List of Cassette Sizes Configuration Cassette Cassette code Cassette absent 11111 10010 10000 10001 10101 10100 10110 10111 10011 U1:FLSC 11011 OFICIO A-OFI E-OFI B-OFI A-LGL U2FOLIO 11010 U3A-FLS 11000 SPECAL1 11101 SPECAL2 11100 Envelope 1 11110 TSM Océ 3121 SDS Description...
  • Page 831 Configuration Cassette Cassette code Inch Cassette absent 11111 STMT 00010 STMTR 00000 00001 A-LTR LTRR 00101 A-LTRR 00100 11*17 00110 U4G-LTR 00111 U5G-LTRR 00011 U6G-LGL 01011 U7K-LGL 01010 U8K-LGLR 01000 SPECAL1 01101 SPECAL2 01100 Envelope 2 01110 ed.1 SDS Description 19...

  • Page 832: 2* I/O Display 01 Inputs/Outputs To And From The Image Processor Pcb

    PBA and (DC) control PBA’s. You cannot change the indicated val- ues/settings. *2* I/O DISPLAY 01 Inputs/Outputs to and from the Image Processor PCB Guide to the Screen: IP PA0:XXXXXXX bit 7..bit 0 TSM Océ 3121 SDS Description...
  • Page 833 Address Indication Logic PBA internal signal (input) PBA internal signal PBA internal signal PBA internal signal PBA internal signal PBA internal signal Not used Not used CORE/IP connect 1 0: not connected (input) CORE/IP connect 2 1: not connected editor board connect 0: connected CCF connect 0: connected...
  • Page 834 SW 0 laser control marker ON for editing board PAD OFF for editing board power SW1 laser control area signal switching 1: w/editing board installed Not used Post ratio change reversal switching TSM Océ 3121 SDS Description...

  • Page 835: 2* I/O Display 02 I/O Ports On The Dc Controller Pba

    *2* I/O DISPLAY 02 I/O ports on the DC controller PBA Guide to the screen: DC PA0: XXXXXXXXXXXXXXXX = bit 15 ~ bit 0 Addre Indication Signal Jack Logic Fixing film detect PS2 J109-3 1: film detected (input) Copyboard cover PS3 CBCC J113-B9 1: closed...
  • Page 836 0: ON solenoid SL4 J103-5 paper deflecting plate 2 solenoid 0: ON delivery assembly paper deflect- 3SL2D J104-9 ing plate solenoid DFLD 0: ON bin 3 flapper solenoid * J105-A5 (*: 3-bin delivery unit) J104-10 TSM Océ 3121 SDS Description...
  • Page 837 Addre Indication Signal Jack Logic pick-up motor drive M4 J114-A6 (out- pick-up motor drive M4 J114-A7 put) pick-up motor drive M4 J114-A8 pick-up motor drive M4 J114-A9 fixing film drive M5 J109-10 fixing film drive M5 J109-11 fixing film drive M5 J109-12 fixing film drive M5 J109-13...
  • Page 838 PBA internal signal (input) PBA internal signal PBA internal signal PBA internal signal not used not used not used not used not used not used not used not used not used not used not used not used TSM Océ 3121 SDS Description...
  • Page 839 Addre Indication Signal Jack Logic PBA internal signal (out- PBA internal signal put) PBA internal signal primary charging roller cleaning PCLSD J113-B2 0: ON solenoid SL1 counter 3 drive (115V/230V CNT3D J107-B8 1: ON model) CNT3 electric. unit fan drive (opt.) J112-9 exhaust fan 1 half-speed (PBA internal signal)
  • Page 840 J102-A7 Not used. upper cassette paper detection 0 UCRMN J122-1 upper cassette paper detection 1 UCRMN J122-2 lower cassette paper detection 0 LCRMN J122-3 lower cassette paper detection 1 LCRMN J122-4 Not used. Not used. TSM Océ 3121 SDS Description...

  • Page 841: 2* I/O Display 04 Gate Array Input/Output Of The Dc Controller Pcb

    *2* I/O DISPLAY 04 Gate Array Input/Output of the DC Controller PCB *2* I/O DISPLAY 05 Input/Output Port 1 of the Feeder Guide to the Screen ed.1 SDS Description 29...
  • Page 842 0 during rotation PCB internal signal PCB internal signal Not used. Not used. Not used. DFP9 0 copier communication signal copier communication signal copier communication signal Not used. copier communication signal Not used. Not used. Not used. TSM Océ 3121 SDS Description...
  • Page 843 a: Input/Output Port of the RDF (2/2) Addr Indication Signal Jack Logic DFPA 0 PBA internal signal not used PBA internal signal belt motor drive signal M3 1: ON (PBA internal signal) PBA internal signal feeding motor drive signal M2 1: ON (PBA internal signal) PBA internal signal...

  • Page 844: 2* I/O Display 06 Input/Output Port 2 Of The Feeder

    In hexadecimal notation DF-AD2 original width volume VR1 DMPS J8-8 In hexadecimal notation DF-AD3 not used DF-AD4 not used DF-AD5 not used DF-DA0 original tray sensor LED1 ON signal DF-DA1 registration sensor LED3 ON signal TSM Océ 3121 SDS Description...

  • Page 845: 2* I/O Display 07 Input/Output Port 1 Of The Sorter

    *2* I/O DISPLAY 07 Input/Output Port 1 of the Sorter Address Bit Indication Signal Jack Logic ST-A Guide bar motor drive signal 1 M4 Pulse signal Guide bar motor drive signal 2 M4 Pulse signal Guide bar motor drive signal 2 M4 Pulse signal Guide bar motor drive signal 4 M4 Pulse signal...
  • Page 846 1: paper present tray B discharge paper detection PI9 J12-14 1: paper detect. tray A delivery detection PI8 J11-8 1: paper detect. tray feeding assembly inlet slot sensor TFPD J11-5 1: paper detect. PI 7 TSM Océ 3121 SDS Description...

  • Page 847: 2* I/O Display 08 Input/Output Port 2 Of The Sorter

    *2* I/O DISPLAY 08 Input/Output Port 2 of the Sorter Address Indication Signal Jack Logic ST-AD0 24V motor ST-AD1 Bin paper sensor PT1 BPDN J4-4 Analog input ST-AD2 not used ST-AD3 for factory/R&D ST-AD4 staple key MNSPT J9-6 0: key ON ST-AD5 push switch SW2 0: SW2 pressed...

  • Page 848: Adjust 01 Fine-Adjusting And Entering The Multifeeder Paper Width Basic Setting

    MF-A4R MF-A4R:Indicates the stored A4R ice handbook p. 2-15. (210mm) value of the multifeeder paper width sensor. MF-A4 MF-A4:Indicates the stored A4 (297mm) value of the multifeeder paper width sensor. TSM Océ 3121 SDS Description...

  • Page 849: Adjust 02 Primary Charging Roller/Transfer Charging Roller/Developing Bias

    *3* ADJUST 02 Primary Charging Roller/Transfer Charging Roller/Devel- oping Bias Item Description Remarks Settings PRI DC Indicates the primary charging DC If you have replaced the image 0~65536 (IMG) output effective when an image is processor PCB, be sure to enter exposed.

  • Page 850: Adjust 03 Back-Up Data For The Composite Power Supply Pcb

    Indicates transfer charg- ATVC OFST OFST ing offset. FL OFST Indicates scanning lamp FL OFST offset. DEV DC Indicates developing DDC OFST OFST bias DC component off- set. * Service label; attached to the composite power supply TSM Océ 3121 SDS Description...

  • Page 851: Adjust 04 Image Registration Adjustments

    *3* ADJUST 04 Image registration adjustments Item Description Settings Remarks H-ADJ To fine adjust the CCD reading start position (main scan- 0~500 unit: 1 mm. ning direction; book mode) (approx. at 23 mm.) An increment shifts the read start position to the right. V-ADJ To adjust the image reading start position (sub scanning 0~1000...

  • Page 852: Adjust 05 Scanner-, Cassette-, And Laser-Related Items

    MF-LOOP Use it to adjust arching (multifeeder 0~65535 pick-up; factory use). DENS-ADJ Use it to make adjustments if the copy image is foggy as a result of executing copy density auto correction. TSM Océ 3121 SDS Description...
  • Page 853 Item Description Settings Remarks ADJ-S Use it to fine-adjust the point at which 50~80 data for shading correction is measured on the standard white plate. The adjustment is in units of 1/12 The presence of scratches on the standard white plate can cause notice- able white, vertical lines on copies.

  • Page 854: Adjust 06 Adjusting The Ae/Fixing Assembly Settings

    AE mode with priority on image quality mode. AE_DARK Use it to increase the setting if the text density is 0~40 too low (light image) when executing AE mode with priority on image quality. TSM Océ 3121 SDS Description...

  • Page 855: Adjust 07 Shading Back-Up Data

    *3* ADJUST 07 Shading Back-Up Data Item Description Settings Remarks Indicates the standard paper data (density 0~65535 If you have initialized the data of the standard white plate). RAM or replaced the image processor PBA, be sure to W-LTP Indicates the standard white plate data 0~65535 enter the value recorded on (density data of the standard white plate).

  • Page 856: Function 01 Clearing Errors

    Description Reference page Clearing E000, E001, E003, To clear an error indication, press E004, E007-01, or E717 ‘ERROR’ on the screen to highlight; then, press the OK key, and turn OFF/ON the main power switch. TSM Océ 3121 SDS Description...

  • Page 857: Function 02 Stirring The Toner

    *4* FUNCTION 02 Stirring the Toner Item Description Reference page Stirring toner inside Press ‘START’ on the screen to highlight; then, press the OK key to start stirring the toner inside the the developing assem- developing assembly. bly at installation At the same time, ‘TONER_S’...

  • Page 858: Function 03 Shading Auto Correction

    Shading auto correc- 1)Press ‘AUTO SHADING START’ on the screen to highlight; then, press the OK key. tion (for servicing in 2)The notation ‘END’ indicates the end of the oper- the field) ation. Guide to the Screen TSM Océ 3121 SDS Description...

  • Page 859: Function 04 Pd Density Auto Correction

    *4* FUNCTION 04 PD Density Auto Correction This mode must be executed in combination with 200PWM density auto cor- rection and 600PWM density auto correction. Item Description Remarks PD density auto 1) Start ‘PD PRINT’. A, B or D not correction A 15-gradation test pattern will be generated.

  • Page 860: Function 05 200Pwm Density Auto Correction

    A, B, and D are approximate values so that optimum images may still be Note: obtained even if the values are outside the range; you may omit “temporary remedy” as long as the images are optimum. TSM Océ 3121 SDS Description...

  • Page 861: Function 06 600Pwm Density Auto Correction

    *4* FUNCTION 06 600PWM Density Auto Correction You must execute this mode in combination with PD density auto correction and 200PWM density auto correction. Item Description Remarks 600PWM density 1) Start ‘600PWM PRINT’. A, B or D not OK: auto correction A 15-gradation test pattern will be generated.

  • Page 862: Function 07 Registering The Multifeeder Paper Width

    ‘A4;’ to highlight, and press the OK key. The value will be stored under ‘A4’. 7) Press the Reset key twice to end service mode. 8) Turn off and then on the main power switch. TSM Océ 3121 SDS Description...

  • Page 863: Function 08 Checking The Control Panel Indications

    *4* FUNCTION 08 Checking the Control Panel Indications Item Description Reference page LCD-CHK 1)Press ‘LCD-CHK’ to highlight. checking for miss- 2)Press the OK key. The entire face of the LCD reverses (white video; keys ing dots on LCD and notations disappear). 3)Press the area where the OK key was shown.

  • Page 864: Function 09 Laser

    OK key. The laser scanner motor will start to rotate motor operation 2) Press ‘OFF’ to highlight; then, press the stopping operation OK key to stop the laser scanner motor (after 10 sec). TSM Océ 3121 SDS Description...

  • Page 865: Function 10 Test Print

    *4* FUNCTION 10 Test Print Item Description Reference page Test print output Select the desired test print (press the item to highlight); then, press the OK key. L-TEST1: solid black test print L-TEST2: halftone test print L-TEST3: blank test print L-TEST4: 17-gradation test print L-TEST5: grid test print L-TEST6: vertical line test print...
  • Page 866 If black lines are noted, suspect scratches on the drum or dirt on the primary charging roller. L-TEST3: blank test print Use it to check for fogging. If fogging is noted, suspect a fault in the photosensitive drum, developing system or laser system. TSM Océ 3121 SDS Description...
  • Page 867 17-gradation test print Use it to check gradation and check for fogging, white lines and uneven (left/right) density. If gradation is not good, suspect a fault in the laser system. If fogging is noted, suspect a fault in the photosensitive drum, developing as- sembly or laser system.
  • Page 868 If a discrepancy is noted, suspect a displaced laser beam or a fault in beam detection. L-TEST7: Horizontal line test print Use it to check straight lines. If a discrepancy is noted, suspect a displaced laser beam or a fault in beam detection. TSM Océ 3121 SDS Description...

  • Page 869: Function 11 Checking The Image Processor Pcb

    *4* FUNCTION 11 Checking the Image Processor PCB Item Description Reference page Image processor PBA 1) Press ‘IP-CHK’ to highlight. self check 2) Press the OK key to start a check on the image processor PBA. ‘OK’ or ‘NG’ will be indicated; if ‘NG’, re- place the image processor PBA.

  • Page 870: Function 12 Shading Adjustment (For R&D/Factory)

    If no beep is heard, turn VR1 on the DC controller PCB so that a beep will be heard; then, press the OK key. 4)End the operation when ‘END’ appears on the screen. Guide to the Screen TSM Océ 3121 SDS Description...

  • Page 871: Function 13 Downloading Mode (Updating Flash Rom)

    *4* FUNCTION 13 Downloading Mode (updating FLASH ROM) Item Description Reference page FLASH ROM updating 1) Perform the following in advance: mode Turn off the main power switch. Open the front door, and remove the connector IP DOWNLOAD: cover for servicing; then, connect the copier to for updating FALSH a PC with an RS232C cable.

  • Page 872: Function 14 Adjusting The Fixing Film

    Indicates the measured film speed. LOCATION from TOP Indicates the position of the rear end of the fixing film from the V-cut. LEVEL Indicates the position of the fixing film (4 or 5 is optimum). TSM Océ 3121 SDS Description...

  • Page 873: Function 15 Measuring The Drum Resistance

    *4* FUNCTION 15 Measuring the Drum Resistance Item Description Photosensitive drum 1) Bring up the screen, and press the Copy Start key. resistance measurement The resistance of the photosensitive drum will be measured, and the result will be indicated. Execute this mode before changing ‘AGSNON’ of ‘OPTION’ in service mode *5* to ‘0’, so that the measurement may be used as a reference.

  • Page 874: Function 17 Initializing The Memory (Ram)

    1)Press ‘PRM_PRINT’ to highlight; then, press the service mode *3*, *5*, and *6*; OK key. however, the machine must be *3*:ADJUST installed with a FAX Board. *5*:OPTION *6*:COUNTER The machine must be equipped with fax functions. TSM Océ 3121 SDS Description...

  • Page 875: Option 01 Setting The Copy Count And Shut-Off Slant Mode

    7 *5* OPTION (settings mode) Use this mode to set/change various machine settings (specifications). Each press on the key brings up the next screen; each press on the key, on the other hand, brings up the previous screen. Press the desired item (notation on the screen) to highlight. Use the keypad to enter numbers.

  • Page 876: Option 02 Switching The Baud Rate, Drum Resistance Measurements, And Thick Paper Mode

    ‘1’ so normal images may be obtained. However, if such a problem occurs, you must suspect a fault in the image processor PCB, DC controller PCB, or composite power supply PCB. TSM Océ 3121 SDS Description...
  • Page 877 Item Function Description SPCL-PPR Use it to change thick 0:The thick paper mode remains off. paper mode. 1:Switching the fixing temperature, the thick paper mode is supported. 2:The fixing temperature is switched so that paper thicker than that supported under ‘1’ may be supported.

  • Page 878: Option 03 Setting The Mode Of Notation For The U1 Cassette

    0: FLSC’, standing for FOOLSCAP. 2:E-OFI 1: ‘OFFI’, standing for OFICIO. 3:A-LGL 2: ‘OFI’, standing for Ecuadorian OFICIO. 4:B-OFI 3: ‘LGL’, standing for Argentine LEGAL. 5:A-OFI 4: ‘OFFI’, standing for Bolivian OFICIO. 5: ‘OFFI’, standing for Argentine OFICIO. TSM Océ 3121 SDS Description...

  • Page 879: Option 04 Setting The Mode Of Notation For The U2 Through U8 Cassettes (Universal Cassettes 2 Through 8)

    *5* OPTION 04 Setting the Mode of Notation for the U2 through U8 Cas- settes (universal cassettes 2 through 8) Item Function Description CST-U2 Use it to turn on/off the 0:If the paper size dial of the cassette is set to U2 CST-U3 U-size cassette name.

  • Page 880: Option 05 Setting The Mode Of Notation For The Ltr/Ltrr Cassette

    ‘LTRR’ will be indicated on the LCD. name notation for the 1: If the paper size dial of the cassette is set to LTRR-size cassette LTRR, ‘LTRR’ will be indicated to stand for Argentine LETTER-R. TSM Océ 3121 SDS Description...
  • Page 881 8 *6* COUNTER (counter mode) Use this mode to find out the numbers of specific operations the machine has performed. To clear the counter reading, press the item to highlight; then, press the key. When a dialogue box appears asking you whether to clear the counter read- ing, press the OK key to reset the counter reading to ‘0’.
  • Page 882 Indicates the small-size copy counter from the cassette 3. S_CAST4 Indicates the small-size copy counter from the cassette 4 S_CAST5 Indicates the small-size copy counter from the cassette 5. S_CAST6 Indicates the small-size copy counter from the cassette 6. *6* COUNTER 03 TSM Océ 3121 SDS Description...
  • Page 883 Indication Description S_OVLY_TRAY Indicates the small-size overlay copy 2nd side count. S_DUP_TRAY Indicates the small-size two-sided 2nd side count. COPY_L_PRINT Indicates the large-size copy cont. FAX_L_PRINT Indicates the large-size fax print count. PDL_L_PRINT Indicates the large-size printer print count. ETC_L_PRINT Indicates the large-size print count by other system.

  • Page 884: Acc 01 Adjusting The Original Stop Position For The Rdf

    When this mode is selected, the sheets set on the RF’s original tray will be picked up and stopped on the copyboard glass. Check how they are stopped, and make adjustments so that they are stopped correctly. TSM Océ 3121 SDS Description...

  • Page 885: Making Adjustments

    Making Adjustments Start service mode. Select the appropriate item. Press the appropriate item to highlight. Place copy paper on the RF’s original tray as follows: In the case of ‘DOC_ST_T’ or ‘DOC_ST_B, place one A3 sheet of copy pa- per. In the case of ‘P_INTRVL_T’...

  • Page 886: Adjusting The Rdf Sensor/Cleaning The Belt

    5)Open the RF’s top cover, and remove the sheet of copy paper. Then, close the RF’s top cover. The foregoing adjustment is the same as using bit 6 of DIPS1 on the RF controller PCB. TSM Océ 3121 SDS Description...

  • Page 887: * Fax

    10 * 8 * FAX Using the (REPORT) button, a printout can be made of the system data, com- plete with the FAX SDS settings, dump list, error transmission report and a re- ception report. *8* #1 SSSW Service Soft Switch This menu contains very detailed fax settings.

  • Page 888: Menu ' Menu Switch Settings

    Use it to set the frequency of the pseudo CI signal. Increase the frequency of the pseudo CI signal if the ringing sound fails, due to the type of extension, when fax to telephone switching is initiated. DATE To change the format of the presentation of the date. TSM Océ 3121 SDS Description...

  • Page 889: Numeric ' Parameter

    ‘ * 8 * 3 NUMERIC ‘ Parameter The values are set automatically when you select a country in ( * 5 * TYPE ). ‘* 8 * 4 NCU’ The values are set automatically when you select a country in ( * 5 * TYPE ). ed.1 SDS Description 77...

  • Page 890: Type

    Selection of the appropriate country in this menu sets all the service data: to match the country’s domestic telecommunication standards. ‘ * 8 * 6 GENESIS ‘ Do not change the settings. A change could reduce the quality level of the read- ing image. TSM Océ 3121 SDS Description...

  • Page 891: Printer

    ‘ * 8 * 7 PRINTER ‘ Service soft switch settings SW bit Description setting = 0 setting = 1 Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Priority on LTR recording paper Priority on LGL recording paper Change prohibited Change prohibited...
  • Page 892 Use it to specify whether priority should be given to recording in reverse scan- ning direction. Set it to ‘No’ if a B4 image should be printed on B5 recording paper, through division, when both B5 and A4 are selected. TSM Océ 3121 SDS Description...
  • Page 893 SW bit Description setting = 0 setting = 1 Reduction for image division Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited Change prohibited bit 0 To specify whether printing should be on two sheets through reduction, or in Direct, when a long original consisting of two or more pages (Direct) is re- ceived.

  • Page 894: Numeric ' Parameter Settings

    ‘ 7 NUMERIC ‘ Parameter settings TSM Océ 3121 SDS Description...
  • Page 895 Parameter Setting Range (mm) Maximum non-image 0 to 9999 Leading edge margin 0 to 9999 Trailing edge margin 0 to 9999 06 through 30 No. 1 To specify the non-image area, when a long-length reception image is received. If you want to avoid a non-image area along the trailing edge, when receiving a long-length image in excess of the effective recording length, lower the pa- rameter to decrease the non-image range.

  • Page 896: Clear

    The same function as ‘ DISPLAY 04 ’ in the copier service mode ( * 1 * ). It cannot be executed. To check the ROM version, execute ‘ DISPLAY 04 ’ in the copier service mode ( * 1 * ). TSM Océ 3121 SDS Description...
  • Page 897 ‘ * 8 * 10 ‘ Test mode D-RAM: To execute a write or read check of data for all areas of the D-RAM (D-RAM A, D-RAM B). A check will be made on the expansion memory (option), if any. PRINT: Use it to generate a test print.
  • Page 898 A D-RAM test will be executed. If the results of the test are correct, the following will be displayed: D-RAM size ( in bytes ); a different value will be indicated to represent any increase TSM Océ 3121 SDS Description...
  • Page 899 If an error is found during the D-RAM test, the test will be suspended. The er- ror display screen will appear. If this is the case, press ‘ OK ‘ to run the test once again. The error end screen will appear. Error display screen Notations: D-RAM: type of RAM with error...
  • Page 900 STRIPES (vertical lines) BIAS (slanted lines) Rotation: yes, if A4H; no if A4R Using the mode Select the appropriate print pattern on the screen. Then, press ‘ OK ‘. A test print will be made. TSM Océ 3121 SDS Description...
  • Page 901 ‘ * 8 * 10 TEST ‘, 3 VIDEO test To store the scanned images in the image memory, without coding, and print- ing them. Position of document: platen or feeder Document size: A4 Recording paper size: A4 (A4R not permitted) Resolution: fine Density: standard Rotation: set for reading: yes, if original size is A4H;...
  • Page 902 Select an item so that the frequency selected by closing the DC circuit will be transmitted, using the tone transmission function of the modem. Simulta- neously monitoring the transmission signal from the speaker. To interrupt, press the CANCEL key. TSM Océ 3121 SDS Description...
  • Page 903 G3 signal transmission test (G3 TX) Press ’G3 TX’ on the MODEM NCU menu screen and press ‘ OK ‘. This will start the G3 signal transmission test mode and invoke the corresponding screen. Select an item to transmit the frequency selected by closing the DC circuit, using the G3 signal transmission function of the modem.
  • Page 904 The tone input source may be selected as follows: External: from line; Internal: from re- mote ‘ * 8 * 10 TEST ‘, 5 PRINT Function test (Faculty) Use this mode to activate each function for testing. TSM Océ 3121 SDS Description...
  • Page 905 G3 signal transmission test (G3 4800 bps TX) Press ‘G3 4800 Tx’ and press ‘ OK ‘ to start the G3 signal transmission test and to invoke the corresponding screen. The DC circuit will be closed and a signal of a frequency of 4800 bps will be transmitted by the G3 signal transmission function of the modem.
  • Page 906 Press ‘LINE DETECT 1. Press ‘ OK ‘ to invoke the corresponding screen This function will check CI, Fc and hook state (ON/OFF) from the line. For CI, the appropriate frequency (0 if CI is off; the current CI frequency if ON). TSM Océ 3121 SDS Description...
  • Page 907 (2) LINE DETECT 2 Press ‘LINE DETECT ‘2. Press ‘ OK ‘ to invoke the corresponding screen This function will switch ON the CNL and P-relay. Checking the absence or presence of a single signal from the line and the frequency of the signal, if any. Be sure to set the appropriate level, in advance Level Level of detection (dBm)
  • Page 908 (4) VOICE Tx Press ‘VOICE TX’. Press ‘ OK ‘ to invoke the corresponding screen. The func- tioning of OMG is checked by transmitting two types of OMG to the line and to the speaker. TSM Océ 3121 SDS Description...

This manual is also suitable for:

3122

Table of Contents
