5.2.1 Installing the ionKey Source

Required materials
• Chemical-resistant, powder-free gloves
• Flat-blade screwdriver
• 1/4-inch open-end wrench
Warning:
To avoid personal contamination with biologically hazardous or toxic compounds,
wear clean, chemical-resistant, powder-free gloves when performing this procedure.
Warning:
working on the source before starting this procedure.
To install the ionKey source:
1. Prepare the instrument so that you can work safely on the source (see
instrument for working on the source (Page
2. Remove the probe from the currently installed source:
• If you are removing an ESI probe, see
• If you are removing an IonSABRE II probe, see
(Page
3. Remove the existing source enclosure (see
(Page 90)).
4. Open the access doors to the IntelliStart Fluidics system.
5. Loosen the two thumbscrews that secure the infill panel to the onboard fluidics panel.
To avoid static-like electric shock, ensure that the instrument is prepared for
Warning:
To avoid burn injuries, take great care while working with the source
components; these components can be hot.
51).
March 31, 2021, 715004496 Ver. 04 (previously released as Rev. D)
89)).
Removing the ESI probe (Page
Removing the IonSABRE II probe
Removing and refitting the source enclosure
Page 68
Preparing the
48).
