Waters Xevo G2-XS QTof Overview And Maintenance Manual page 50

Location hole of the probe adjuster assembly
3. Tighten the probe locking ring to secure the probe in place.
Tip:
An automatic pressure test is performed when the probe is correctly seated in
position.
Figure 3–7: IonSABRE II probe mounted on the source enclosure
Vernier probe adjuster
APCI probe
Source enclosure release
Source enclosure door
4. Open the access door to the fluidics valves (see the figure in
G2-XS QTof systems (Page
Warning:
steel tubing to connect parts; use the PEEK tubing supplied with the instrument.
5. Using tubing ≥0.004-inch ID, connect port 2 (the top port) of the divert valve to the
IonSABRE II probe.
Recommendation:
flow rates ≤1.2 mL/min; use 0.005-inch ID tubing for sample flow rates >1.2 mL/min.
Requirements:
March 31, 2021, 715004496 Ver. 04 (previously released as Rev. D)
21)).
To avoid harmless, static-like electric shock, do not use stainless
To reduce peak broadening, use 0.004-inch ID tubing for sample
Page 50
ACQUITY UPLC/MS Xevo
