Figure 7–112: IonSABRE II probe
Probe heater
Notice:
To avoid damaging the heater cartridge assembly wires, do not bend or
twist them when removing the assembly and ceramic heater mounting block from
the ion block.
2. Gripping the probe heater as shown, carefully pull it off the probe assembly.
Figure 7–113: Removing the probe heater
Probe heater
Warning:
To avoid spreading contamination with biologically hazardous, toxic, and
corrosive materials, dispose of all waste materials according to local environmental
regulations.
3. Dispose of the probe heater in accordance with local environmental regulations.
