Keysight

A-Series FieldFox Analyzers

This manual provides documentation for the following models:

N9913A, N9914A, N9915A, N9916A, N9917A, N9918A N9925A,

N9926A, N9927A, N9928A

N9935A, N9936A, N9937A, N9938A

N9950A, N9951A, N9952A

N9960A, N9961A, N9962A

User's Guide

Table of Contents

Chapters

Table of Contents

Troubleshooting

Summary of Contents for Keysight Technologies FieldFox A Series

Page 1 User's Guide Keysight A-Series FieldFox Analyzers This manual provides documentation for the following models: N9913A, N9914A, N9915A, N9916A, N9917A, N9918A N9925A, N9926A, N9927A, N9928A N9935A, N9936A, N9937A, N9938A N9950A, N9951A, N9952A N9960A, N9961A, N9962A Distributed by: Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über info@datatec.de...
Page 2 THESE TERMS, THE WARRANTY Keysight shall be under no obligation TERMS IN THE SEPARATE to update, revise or otherwise modify © Keysight Technologies, Inc. the Software. With respect to any AGREEMENT WILL CONTROL. 2014-2020 technical data as defined by FAR Technology Licenses 2.101, pursuant to FAR 12.211 and...
Page 3 Where to Find the Latest Information Documentation is updated periodically. For the latest information about these products, including instrument software upgrades, application information, and product information, browse to one of the following URLs, according to the name of your product: http://www.keysight.com/find/fieldfox To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL: http://www.keysight.com/find/MyKeysight...
Page 4 A.08.19 Firmware Release (CPU1) Updates (N991xA/2xA/3xA with serial number prefixes <5607) For customers upgrading FieldFox firmware, the following is a list of changes from the previous release: Other updates: — Fix to FAB USB access A.12.00 Firmware Release (CPU2) Updates (Also, applies to: ≥...
Page 5 Contacting Keysight Assistance with test and measurements needs and information on finding a local Keysight office are available on the Web at: http://www.keysight.com/find/assist. If you do not have access to the Internet, please contact your Keysight field engineer. In any correspondence or telephone conversation, refer to the Keysight product by its model number and full serial number.
Page 7: Table Of Contents
Contents 1. Overview Models and Options ............23 Accessories .
Page 8 Smoothing ............. .51 Single or Continuous Measure .
Page 9 NA Mode Settings............87 About S-parameters.
Page 10 Transform Enable............117 Gate Enable .
Page 11 Attenuation Control ........... . . 154 Preamplifier Control (Opt 235) .
Page 12 Spectrum Emission Mask (SEM) — (SA Mode Only) ....... .218 How to select Spectrum Emission Mask (SEM) Measurement .
Page 13 How to Capture I/Q Data to a File ......... . 262 How to modify the I/Q data measurement parameters .
Page 14 How to Set Up Phased Array Antenna Settings ........341 Option 360 Setup Procedure .
Page 15 Connecting Using Remote Server ..........416 Changing Frequency Converter Head Settings .
Page 16 Zeroing..............453 Frequency .
Page 17 Grid ..............482 Trace Memory.
Page 18 Interpreting AM/FM Metrics Error Messages ........519 Test Tone Not Found .
Page 19 Marker Trace (CAT, NA, NF Modes) ......... 602 Marker Trace (IQA and SA Mode).
Page 20 Utilities ..............630 How to view and change Utilities Settings .
Page 21 Save Files ............. 672 Recall Files .
Page 22 Packaging Markings ............711 AC/DC Adapter Markings .
Page 23: Overview
Keysight Handheld Analyzers N99xxA User’s Guide Overview Models and Options Table 1-1 Models Model Max Freq Description (GHz) N9913A Vector Network Analyzer AND Spectrum Analyzer N9914A Vector Network Analyzer AND Spectrum Analyzer N9915A Vector Network Analyzer AND Spectrum Analyzer N9916A Vector Network Analyzer AND Spectrum Analyzer N9917A Vector Network Analyzer AND Spectrum Analyzer...
Page 24: Accessories
Overview Accessories FieldFox Options: For a comprehensive list, view the FieldFox Configuration Guide at: http://literature.cdn.keysight.com/litweb/pdf/5990-9836EN.pdf Accessories The following accessories are included with every FieldFox. Spare accessories can be ordered at any time. Refer to Table 1-2. Some of the optional accessories—not included unless requested—are listed in Table 1-3.
Page 25: Fieldfox Manuals, Software, And Supplemental Help
Overview FieldFox Manuals, Software, and Supplemental Help FieldFox Manuals, Software, and Supplemental Help The following manuals and software are available for the FieldFox. To access all of these, visit: www.keysight.com/find/fieldfoxsupport — User’s Guide –This manual, included with shipment. — Quick Reference Guide – Printed copy with laminated pages for outdoor use included with shipment.
Page 26 Overview FieldFox Manuals, Software, and Supplemental Help Denotes a hazard. It calls attention to a procedure which, if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond a warning note until the indicated conditions are fully understood and met.
Page 27: Preparing For Initial Use Of Your New Fieldfox
Keysight Handheld Analyzers N99xxA User’s Guide 2 Preparing for Initial Use of Your New FieldFox Check the Shipment When you receive your FieldFox, check the shipment according to the following procedure: 1. Inspect the shipping container for damage. Signs of damage may include a dented or torn shipping container or cushioning material that indicates signs of unusual stress or compacting.
Page 28: Install The Lithium-Ion Battery
Preparing for Initial Use of Your New FieldFox Install the Lithium-Ion Battery Install the Lithium-Ion Battery Step Notes 1. Open the battery door Push the button on the battery compartment door while sliding the door outward. 2. Insert the battery. The terminals end of the battery is inserted into the compartment.
Page 29: Fieldfox On/Off Settings
Preparing for Initial Use of Your New FieldFox FieldFox ON/OFF Settings — On the battery. Open the FieldFox battery compartment door to view the battery LCD. To conserve battery power: — Use Run/Hold to single-trigger a measurement when needed. Hold shown on the display.
Page 30: Power Button Led Status
Preparing for Initial Use of Your New FieldFox FieldFox High Temperature Protection — To turn Power OFF (very low battery drain), press the power button briefly and press the Shutdown softkey. Data and instrument state are NOT automatically saved when the FieldFox is powered OFF. Learn how to save data and instrument state in Chapter 31, “File Management”, on page 671.
Page 31: Temperature Control Mode
Preparing for Initial Use of Your New FieldFox FieldFox High Temperature Protection — The temperature at which the following events occur is the average of the RF1, RF2, SB1, SB2 temperatures. These temperatures come from internal sensors embedded within FieldFox. Temperature Control Mode The FieldFox’s internal temperature control preserves measurement accuracy and maintains the long-term reliability of the FieldFox.
Page 32 Preparing for Initial Use of Your New FieldFox FieldFox High Temperature Protection "Entering Maximum Auto Protect mode for thermal management" When temperature reaches the maximum protection threshold (~75°C), some applications take additional measures. Figure 2-1 Entering Auto Protect mode message (above ~64°C)—(Displays for 3 sec) Exiting Maximum Auto Protect Threshold Temperature Mode When the temperature drops to approximately 73.5°C, a message is displayed indicating that the FieldFox is leaving Temperature Control Mode and normal...
Page 33: High-Temp Shutdown Warning (Rtsa Mode Only)
Preparing for Initial Use of Your New FieldFox FieldFox High Temperature Protection High-Temp Shutdown Warning (RTSA Mode Only) In extreme situations, Temperature Control mode may not stop an increase in the FieldFox internal temperature. Just prior to shut down, the FieldFox will display a warning of imminent shut down and the instrument turns off.
Page 34: Avoid Overpowering The Fieldfox
Preparing for Initial Use of Your New FieldFox Avoid Overpowering the FieldFox Summary of FieldFox Average Internal Temperature Protection Behavior Table 2-1 Summary of FieldFox Temperature Protection Threshold Average Internal Description of Behavior Temperature Duty cycling ~64°C Duty cycling is enabled when the internal average temperature of the FieldFox reaches the duty cycling threshold of ~64°C.
Page 35: Take The Fieldfox Tour
Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Take the FieldFox Tour Front Panel Keysight N9927-90001 User’s Guide...
Page 36 Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Caption Description Learn More: Power ON: press momentarily. “FieldFox ON/OFF STAND BY: with FieldFox power ON, press briefly. Settings” OFF: press and hold until the FieldFox shuts off (about 4 seconds). page 29 Not lit: FieldFox OFF, not charging “Power...
Page 37 Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Caption Description Learn More: Limit Sets limit lines for quick Pass/Fail judgment “All about Limit Lines” on page 613 Run/Hold Toggles between free Run and Hold/Single operation. “Run/Hol d”...
Page 38: Top Panel
Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Top Panel Caption Descriptions Learn More: Port 1 For CAT and NA measurements, use to make reflection measurements. “CAT Mode Settings” RF Output Maximum: ±50 VDC, +27 dBm RF on page 47 “NA Mode Settings”...
Page 39 Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Connector Description Learn More: IF Out used in SA mode for external signal processing. “IF Output” on page 167 Frequency Reference Source Output Chapter 24, “ERTA (Extended Range Trigger Output (ERTA mode).
Page 40: Left Side Panel
Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Left Side Panel Connector Description Learn More: Audio output jack for use with SA Mode Tune and Listen. “Tune & Listen (AM/FM)” on page 161 DC Voltage Source for use with external DC Bias. “Variable Voltage Source (Opt.
Page 41: Screen Tour
Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Screen Tour Caption Description Learn More: Title – write your own text here “Title” on page 628 Current Mode Run / Hold “Run/Hold” on page 624 Display Format Mode dependent Scale/division Mode dependent...
Page 42 Preparing for Initial Use of Your New FieldFox Take the FieldFox Tour Caption Description Learn More: Bandpass / Lowpass setting (Fault Meas) “DTF Measurement IF BW in NA Mode Settings” on page 62 Output Power Level (CAT and NA) “Output Power” on page 53 Measurement Stop Freq or Distance Mode dependent...
Page 43: How To Enter Numeric Values
Preparing for Initial Use of Your New FieldFox How to Enter Numeric Values How to Enter Numeric Values Many settings on the FieldFox require the entry of numeric values. How to enter numeric values Use any combination of the following keys: —...
Page 44: Connector Care
Preparing for Initial Use of Your New FieldFox Connector Care Connector Care — Never store connectors, airlines, or calibration standards loose in a box. This is a common cause of connector damage. — Install protective end caps when connectors are not in use. —...
Page 45: Cat (Cable And Antenna Test) Mode
Keysight Handheld Analyzers N99xxA User’s Guide CAT (Cable and Antenna Test) Mode CAT Mode is typically used to test an entire transmission system, from the transmitter to the antenna. This process is sometimes referred to as Line Sweeping. CAT Mode is similar to NA (Network Analyzer) Mode.
Page 46 CAT (Cable and Antenna Test) Mode Procedures “Return Loss Measurements” on page 55 “1-Port Cable Loss Measurements” on page 55 “2-Port Insertion Loss Measurements” on page 57 See Also Chapter 8, “Calibration for NA, CAT, and VVM Modes”, on page 121 “All about Markers”...
Page 47: Cat Mode Settings
CAT (Cable and Antenna Test) Mode CAT Mode Settings CAT Mode Settings Select CAT Mode before making any setting in this chapter. How to select CAT Mode — Press Mode. — Then CAT/TDR. Measurement Selection How to select a CAT Mode Measurement Learn more about the following measurements in the Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm...
Page 48: Quick Settings Table
CAT (Cable and Antenna Test) Mode CAT Mode Settings — Cable Loss (1-Port) 1-port reflection measurement that displays the loss of a transmission line. Learn more on page 55 — Insertion Loss (2-Port) 2-port transmission measurement that accurately displays the loss through a cable or other device in dB. Both ends of the cable must be connected to the FieldFox.
Page 49: Frequency Range
CAT (Cable and Antenna Test) Mode CAT Mode Settings — Left The Settings table is shown to the left of the trace window — Bottom The Settings table is shown below the trace window — When finished changing ALL settings, press Done to save your settings Frequency Range...
Page 50: Averaging
CAT (Cable and Antenna Test) Mode CAT Mode Settings — Ref Level Manually set the value of the reference line. Enter a negative value by pressing Run/Hold (+/-) either before or after typing a value — Ref Pos Manually set the position of the reference line. Values must be between 0 (TOP line) and 10 (BOTTOM line) 3.
Page 51: Smoothing
CAT (Cable and Antenna Test) Mode CAT Mode Settings — Then Average N where N is the current count setting. — Enter a value using the numeric keypad. Enter 1 for NO averaging. — Press Enter. — While Trace Averaging is in process, press Sweep 3 then Restart to restart the averaging at 1.
Page 52: Resolution (Number Of Data Points)
CAT (Cable and Antenna Test) Mode CAT Mode Settings Resolution (Number of Data Points) Data points are individual measurements that are made and plotted across the X-axis to form a trace. Select more data points to increase measurement resolution. However, more data points require more time to complete an entire measurement sweep When the Resolution is changed after a calibration is performed, the cal becomes interpolated.
Page 53: Output Power
CAT (Cable and Antenna Test) Mode CAT Mode Settings Output Power Set the power level out of the FieldFox to High, Low, or manually set power level to a value between High and Low. Generally, the high power setting is used when measuring passive, high-loss devices to place the signal farther from the noise floor.
Page 54: Coupled Frequency
CAT (Cable and Antenna Test) Mode CAT Mode Settings toggle this setting between ON and OFF. If the measurement result decreases while ON, then there is an interfering signal in the area. Continue to make measurements with Interference Rejection ON. However, this will slow the measurement speed.
Page 55: Return Loss Measurements
CAT (Cable and Antenna Test) Mode Return Loss Measurements Return Loss Measurements Return loss can be thought of as the absolute value of the reflected power compared to the incident power. When measuring an OPEN or SHORT, all incident power is reflected and approximately 0 dB return loss is displayed.
Page 56: How To Make A 1-Port Cable Loss Measurement
CAT (Cable and Antenna Test) Mode 1-Port Cable Loss Measurements A 2-port Insertion Loss measurement is usually more accurate than a 1-port Cable Loss measurement. However, to perform a 2-port Insertion Loss measurement, both ends of the cable must be connected to the FieldFox. In high-loss conditions, a Cable Loss measurement becomes ‘noisy’...
Page 57: 2-Port Insertion Loss Measurements
CAT (Cable and Antenna Test) Mode 2-Port Insertion Loss Measurements 13.Press Data Math then Data – Mem. The ripple in the measurement is removed. These minor imperfections in the cable should not be considered in the Cable Loss measurement. 14.Use Averaging to remove random noise from high-loss measurements. Press BW 2 then Average.
Page 58 CAT (Cable and Antenna Test) Mode 2-Port Insertion Loss Measurements When measuring very long lengths of cable, it may be necessary to increase the sweep time. Learn how on page 52. Learn why in the Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm Keysight N9927-90001 User’s Guide...
Page 59 Keysight Handheld Analyzers N99xxA User’s Guide DTF (Distance to Fault) Measurements CAT Mode Distance to Fault (DTF) measurements are generally used to locate problems, or faults, in a length of cable or transmission line. In this chapter, the cable to be tested is referred to as the DUT (Device Under Test). Settings that are NOT unique to DTF measurements are documented in the CAT Mode Chapter 3, “CAT (Cable and Antenna Test) Mode.”...
Page 60: Dtf (Distance To Fault) Measurements How To Make Dtf Measurements
DTF (Distance to Fault) Measurements How to make DTF Measurements “Coupled Frequency” on page 64 “Cable (Correction) Specifications” on page 65 “Window Settings” on page 68 “DTF Units” on page 69 “Calculated DTF values” on page 69 “About Alias Faults” on page 69 Optional settings “All about Markers”...
Page 61 DTF (Distance to Fault) Measurements How to make DTF Measurements 9. Either press Edit/Save/Recall Cables then Recall Cable, or directly enter the Velocity Factor/Cable Loss of the DUT using the Velocity Factor and Cable Loss keys. 10. Connect the start end of the DUT to the FieldFox. 11.
Page 62: Dtf Measurement Settings
DTF (Distance to Fault) Measurements DTF Measurement Settings DTF Measurement Settings DTF Settings Table You can set and view all of the DTF settings, including some calculated values, on the DTF Settings table. Learn about the calculated values in “Calculated DTF values”...
Page 63: Dtf Start And Stop Distance
DTF (Distance to Fault) Measurements DTF Measurement Settings — More then DTF (Lin) Faults are displayed on the Y-axis in linear (unitless) format. DTF Start and Stop Distance In DTF measurements, you set the physical length of cable or other device to be tested.
Page 64: Coupled Frequency
DTF (Distance to Fault) Measurements DTF Measurement Settings — Bandpass (Default setting) The frequency range of a DTF measurement is set manually. Use Bandpass mode when the DUT contains a diplexer or other filtering device which does not pass some frequencies. Typically, you will set the frequency range of the measurement to the passband of the filter.
Page 65: Cable (Correction) Specifications
DTF (Distance to Fault) Measurements DTF Measurement Settings Cable (Correction) Specifications By default, the FieldFox does NOT correct DTF measurements to account for the inherent loss of a cable. However, to make more accurate DTF measurements, the Cable Loss and Velocity Factor values should be considered.
Page 66 DTF (Distance to Fault) Measurements DTF Measurement Settings — Press Meas Setup 4. — Then DTF Cable Specifications — Select Cable Corr — Auto Use Cable Loss and Velocity Factor values from a Cable file. See “How to Edit, Save, and Recall a Cable File” below. This will overwrite a manually-entered value.
Page 67 DTF (Distance to Fault) Measurements DTF Measurement Settings — Delete/Clear then: — Delete Row Remove the selected Freq/Loss pair from the table. — Clear All then Yes. Remove all Freq/Loss pairs from the table and resets header information — Press Done to close the Cable Editor.
Page 68: Window Settings
DTF (Distance to Fault) Measurements DTF Measurement Settings The center frequency for the measurement is determined from the calculated (Stop – Start) frequency values (seen on the second page of DTF Settings): Calculated Start = 2.0 MHz Calculated Stop = 3.598 GHz Center Freq = 1.80 GHz The Loss value for the measurement is interpolated from the Freq/Loss pairs at the Center Freq:...
Page 69: Dtf Units
DTF (Distance to Fault) Measurements DTF Measurement Settings DTF Units The DTF Units setting is available ONLY on the DTF Settings table. By default, X-axis units for DTF measurement settings are displayed in Meters. How to change DTF units — With a DTF measurement present, press Freq/Dist. —...
Page 70 DTF (Distance to Fault) Measurements DTF Measurement Settings Shorter stop distances (less than 10 meters) and a higher resolution (1001 points) will be more likely to result in Alias-free Range = Off. When the Alias-free Range = Off, the following procedure will help to determine if a response is true or an alias response: 1.
Page 71: Tdr (Time Domain Reflectometry) - Option
Keysight Handheld Analyzers N99xxA User’s Guide TDR (Time Domain Reflectometry) - Option 215 CAT Mode Time Domain Reflectometry (TDR) measurements are generally used to locate problems, and identify the type of problem, in a length of cable or transmission line. Settings that are NOT unique to TDR measurements are documented in Chapter 3, “CAT (Cable and Antenna Test) Mode”, on page In this chapter, the cable to be tested is referred to as the DUT (Device Under...
Page 72 TDR (Time Domain Reflectometry) - Option 215 “Frequency Mode” on page 76 “Cable (Correction) Specifications” on page 77 “Window Settings” on page 80 “TDR Units” on page 81 “Calculated TDR values” on page 81 “About Alias Faults” on page 82 “How to Prevent Undersampling”...
Page 73 TDR (Time Domain Reflectometry) - Option 215 9. Either press Edit/Save/Recall Cables then Recall Cable, or directly enter the Velocity Factor/Cable Loss of the DUT using the Velocity Factor and Cable Loss keys. 10. Connect the start end of the DUT to the FieldFox. 11.
Page 74: Tdr Measurement Settings
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings TDR Measurement Settings Select CAT Mode, then TDR before making any setting in this chapter. How to select CAT Mode — Press Mode. — Then CAT/TDR. TDR Measurement (Format) You can select from 3 different TDR Formats. —...
Page 75: Tdr Start And Stop Distance
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings — Press Dock Window to relocate the Settings table to a position relative to the trace window. The setting persists through a Preset. Choose from the following: — Full (Default setting) Only the Settings table is shown on the screen. The trace window is temporarily not shown.
Page 76: Frequency Mode
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings — Press Sweep 3 — Then TDR Sweep — Choose one of the following: — Auto Low pass frequency settings are calculated based on the current number of points. The Stop Frequency and Resolution settings can be changed to any value.
Page 77: Cable (Correction) Specifications
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings Cable (Correction) Specifications By default, the FieldFox does NOT correct TDR measurements to account for the inherent loss of a cable. However, to make more accurate TDR measurements, the Cable Loss and Velocity Factor values should be considered.
Page 78 TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings — Then DTF Cable Specifications — Select Cable Corr — Auto Use Cable Loss and Velocity Factor values from a Cable file. See “How to Edit, Save, and Recall a Cable File” below. This will overwrite a manually-entered value.
Page 79 TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings — Clear All then Yes. Remove all Freq/Loss pairs from the table and resets header information — Press Done to close the Cable Editor. How to Save or Recall a Cable —...
Page 80: Window Settings
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings The Loss value for the measurement is interpolated from the Freq/Loss pairs at the Center Freq: 1 GHz = 0.1 dB/m 1.8 GHz = 0.18 dB/m 2 GHz = 0.2 dB/m The correction for loss at 5 meters in one direction: 0.18 dB/m * 5m = 0.9 dB.
Page 81: Tdr Units
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings Network Analyzer Windows Frequency Span and TDR Window Selection for Step Rise Time (Approximated) The following table shows the approximated relationship between the frequency span and the window selection for impulse width and step rise time. Refer to Figure 5-1 on page Window...
Page 82: About Alias Faults
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings Start Frequency – Start frequency that is used to calculate TDR. Stop Frequency – Stop frequency that is used to calculate TDR. Range Resolution. Indicates the accuracy of the distance to fault measurement.
Page 83: How To Prevent Undersampling
TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings An un-terminated cable (with NO perfect load at the end) will show faults that appear to be beyond the end of the cable. These are NOT alias faults. These faults appear as the signal reflects off the open at the end of the cable and travels back down the cable toward the connection at the FieldFox.
Page 84 TDR (Time Domain Reflectometry) - Option 215 TDR Measurement Settings Keysight N9927-90001 User’s Guide...
Page 85: Na (Network Analyzer) Mode
Keysight Handheld Analyzers N99xxA User’s Guide 6 NA (Network Analyzer) Mode Learn more about NA Mode measurements in the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm. In this Chapter “About S-parameters” on page 87 “Mixed-Mode S-Parameters” on page 88 “Parameter Conversion” on page 89 “Receiver Measurements”...
Page 86 NA (Network Analyzer) Mode “Port Extensions” on page 104 “Velocity Factor” on page 105 “Increase Dynamic Range” on page 108 See Also “Why and When to Calibrate” on page 122 “All about Markers” on page 598 “All about Limit Lines” on page 613 “All about Trace Math”...
Page 87: Na Mode Settings
NA (Network Analyzer) Mode NA Mode Settings NA Mode Settings Select NA Mode before making any setting in this chapter. How to select NA Mode — Press Mode_. — Then NA. About S-parameters S-parameters (scattering parameters) are used to describe the way a device modifies a signal.
Page 88: Mixed-Mode S-Parameters
NA (Network Analyzer) Mode NA Mode Settings S21 and S12 transmission measurements are used to measure the loss or gain through a DUT over a specified frequency range. Both ends of the DUT must be connected to the FieldFox. The FieldFox signal source is transmitted out one of the test port connectors, through the DUT, and into the other test port connector How to measure S-parameters...
Page 89: Parameter Conversion
NA (Network Analyzer) Mode NA Mode Settings All FieldFox settings and features are supported (except Parameter Conversion) with mixed-mode S-parameters. Learn more about Balanced Measurements with the FieldFox in the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm How to make mixed-mode S-parameter measurements —...
Page 90: Receiver Measurements
NA (Network Analyzer) Mode NA Mode Settings ——Trans The displayed S-parameter is converted to Z or Y transmission, regardless of whether the S-parameter is reflection (S11 or S22) or transmission (S21 or S12). —1/1/S The displayed S-parameter is converted to 1/S-parameter. Receiver Measurements In NA Mode ONLY, you can make unratioed, uncorrected receiver measurements.
Page 91: Multi-Trace Configurations
NA (Network Analyzer) Mode NA Mode Settings Multi-Trace Configurations In NA Mode you can display multiple traces on the FieldFox screen. The graphic above shows a x3H configuration. Tr2 is the ACTIVE trace as indicated by the highlighted Tr2. Trace Setting Notes —...
Page 92: Quick Settings
NA (Network Analyzer) Mode NA Mode Settings How to select a multi-trace configuration — Press Trace 6 — Then Num of Traces — Then choose from the following: The default measurements depend on the options that are installed 1 trace standard configuration 2 traces overlayed on a single graticule 2 traces on separate graticules 3 traces on separate graticules...
Page 93: Calibration Settings
NA (Network Analyzer) Mode NA Mode Settings How to view and change Quick Settings — Press Meas Setup 4 — Then Settings. — Press Next Page Previous Page to view all settings. If these softkeys are NOT available, then all available settings fit on one page. —...
Page 94: Format
NA (Network Analyzer) Mode NA Mode Settings Format Select the display format in which to present measurement results. This setting can be changed at any time without affecting calibration accuracy. Learn more about Display Formats in the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm The marker on screen readout can be changed to formats other than the...
Page 95: Frequency Range
NA (Network Analyzer) Mode NA Mode Settings —Imaginary Displays only the reactive portion of the measured complex data. The Y-axis is Unitless. —Z Magnitude Displays the effective impedance in ohms. —Unwrap Phase Same as Phase, but without 180 degree wrapping. Phase is unwrapped by comparing the phase from one data point to the next.
Page 96: Magnitude Offset
NA (Network Analyzer) Mode NA Mode Settings How to set Scale — Press Scale / Amptd. — Then choose from the following method —Autoscale Automatically adjusts the Y-axis to comfortably fit the Minimum and Maximum amplitude of the trace on the screen. —Autoscale All Autoscales all of the traces on the screen, useful only for multi-trace configurations.
Page 97: Electrical Delay
NA (Network Analyzer) Mode NA Mode Settings —Then enter a positive or negative offset value in dB using the numeric keypad, the arrows, or the rotary knob. Press a multiplier key. Learn about multiplier abbreviations. — And/or press Slope - Offsets the data trace by a value that changes linearly with frequency.
Page 98: Averaging
NA (Network Analyzer) Mode NA Mode Settings Emulate a projected phase shift in your measurement. For example, if you know that you need to add a cable and that the length of that cable will add a certain phase shift to your measurement, you can use phase offset to add that amount and simulate the complete device measurement.
Page 99: If Bandwidth
NA (Network Analyzer) Mode NA Mode Settings —Point - Each data point is measured <n> times and averaged before going to the next data point. On subsequent sweeps, averaging restarts by measuring each data point again <n> times. The average counter is not updated because data is not displayed until all the averages have been applied.
Page 100: Single Or Continuous Measure
NA (Network Analyzer) Mode NA Mode Settings — Press Enter Single or Continuous Measure This setting determines whether the FieldFox sweeps continuously or only once each time the Single button is pressed. Use Single to conserve battery power or to allow you to save or analyze a specific measurement trace. This setting can be changed at any time without affecting calibration accuracy.
Page 101: Sweep Time
NA (Network Analyzer) Mode NA Mode Settings Sweep Time The fastest possible sweep time is always used as the default setting. Use the Min Swp Time setting to slow the sweep time when measuring long lengths of cable. Learn more at the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm The actual sweep time is shown on the FieldFox screen.
Page 102 NA (Network Analyzer) Mode NA Mode Settings ——A sweep can NOT be initiated by an external signal while a sweep is in progress. ——A sweep can NOT be initiated by an external signal when in HOLD mode. Learn more about HOLD mode in. —...
Page 103: Output Power
NA (Network Analyzer) Mode NA Mode Settings trigger will revert to Internal trigger. This includes turning on a CAL that requires forward and reverse sweeps or displaying multiple parameters that would require forward and reverse sweeps. — If the FieldFox is in a state requiring two sweeps and the user selects point mode triggering, an error "Error: Point trigger not compatible with 2-port cal."...
Page 104: System Impedance (Z0)
NA (Network Analyzer) Mode NA Mode Settings — Low Sets output power to approximately –45 dBm, FLAT across the displayed FieldFox frequency span. — Man (default setting at -15 dBm) Set output power to an arbitrary value, FLAT across the displayed FieldFox frequency span. If flattened power can NOT be achieved, a warning message and beep occurs.
Page 105: Velocity Factor
NA (Network Analyzer) Mode NA Mode Settings — With S11 and S22 reflection measurements, the FieldFox doubles the port extension valued that you enter to account for the additional delay in the forward and reverse directions. — With S21 and S12 transmission measurements, the port 1 and port 2 extensions are added together.
Page 106: Big Marker Display States (A And B)
NA (Network Analyzer) Mode NA Mode Settings Velocity factor is the ratio of the velocity of wave propagation in a coaxial cable to the velocity of wave propagation in free space. This velocity depends on the relative permittivity of the cable dielectric (er). Velocity factor = 1/sqrt(er) VF = 0.66 corresponds to wave propagation through a polyethylene dielectric.
Page 107 NA (Network Analyzer) Mode NA Mode Settings — Font Size – Choose either Big or Super Big. Super Big marker readout #3 will cover some of the measurement grid. — Trace Settings - For each possible trace (1, 2, and 3) select from the following: —Measurement –...
Page 108: Increase Dynamic Range
NA (Network Analyzer) Mode NA Mode Settings Increase Dynamic Range Dynamic range is the difference between maximum input power to the FieldFox receiver (without compressing the receiver), and the minimum measurable power (noise floor). Measurement accuracy is increased when the DUT response is at least 10 dB above the noise floor.
Page 109 Keysight Handheld Analyzers N99xxA User’s Guide Time Domain – Option 010 With NA Mode, Time Domain (Opt 010), frequency information is used to calculate and display measurements with time as the horizontal display axis. The response values appear separated in time allowing a different perspective of the test device's performance and limitations.
Page 110: Time Domain - Option 010
Time Domain – Option 010 Gating Settings “Start, Stop, Center, and Span Gate Times” on page 119 “Gating Type” on page 119 Keysight N9927-90001 User’s Guide...
Page 111: Overview
Time Domain – Option 010 Overview Overview In normal NA Mode operation, the FieldFox measures the characteristics of a test device as a function of frequency. With Time Domain (opt 010), frequency information is used to calculate the inverse Fourier transform and display measurements with time on the horizontal display axis.
Page 112: Time Domain (Transform) Settings
Time Domain – Option 010 Time Domain (Transform) Settings Time Domain (Transform) Settings You can set and view most of the Time Domain settings on the Transform Settings table. Transform Settings Table The following settings (from Transform Stimulus Settings to Data Processing) are listed in the order they appear on the Transform Settings menu selection.
Page 113: Stimulus (Mode)
Time Domain – Option 010 Time Domain (Transform) Settings Stimulus (Mode) — There are three variations on how the Time Domain transform algorithm is applied to the frequency domain measurement. Each method has a unique application. — Lowpass Impulse - Highest resolution. Most useful for seeing small responses in devices that pass low frequencies, such as cables.
Page 114: Distance Units
Time Domain – Option 010 Time Domain (Transform) Settings — Then choose from: — Start Sets the transform start time. — Stop Sets the transform stop time. Zero (0) seconds is always the calibration reference plane. Negative values are useful if moving the reference plane. Distance Units When markers are present on a Time Domain trace, marker X-axis values are shown both in units of time (seconds) and distance.
Page 115: Line Loss And Velocity Factor
Time Domain – Option 010 Time Domain (Transform) Settings The Window setting applies to ALL traces. How to make Window setting — Press Measure Setup 4 — Then Transform — Then More — Then Transform Window — A settings table appears that allows you to navigate and select the following settings.
Page 116: Data Chain
Time Domain – Option 010 Time Domain (Transform) Settings About Velocity Factor and Line Loss — Velocity Factor is a property of the physical material of a cable. A VF of 1.0 corresponds to the speed of light in a vacuum, or the fastest VF possible. A polyethylene dielectric cable has VF = 0.66 and a cable with PTFE dielectric has VF = 0.7.
Page 117: Trace Settings
Time Domain – Option 010 Trace Settings Trace Settings The following two settings apply to specific traces. Transform Enable Enable Time Domain transform for the specific trace. — Select the trace. — Press Measure Setup 4 — Then Transform — Then choose from: —...
Page 118: Gating
Time Domain – Option 010 Gating Gating Perhaps the most beneficial feature of Time Domain transform is the Gating function. When viewing the Time Domain response of a device, the gating function can be used to “virtually” remove undesired responses. You can then simultaneously view a frequency domain trace as if the undesired response did not exist.
Page 119: How To Make Time Domain Gating Settings
Time Domain – Option 010 Gating Trace 4 shows the frequency response with gating enabled. How to make Time Domain Gating settings — Press Measure Setup 4 — Then Transform — Then Gating — Then choose from: — Gating is being performed. —...
Page 120 Time Domain – Option 010 Gating Gating Shape This setting defines the filter characteristics of the gate function. Choose from Minimum, Normal, Wide, Maximum. Time domain Gate Shape setting is shown in the graphic above. Gate Shape Passband Sidelobe Cutoff Time Minimum Gate Ripple Levels...
Page 121: Chapter 8, "Calibration For Na, Cat, And Vvm Modes
Keysight Handheld Analyzers N99xxA User’s Guide Calibration for NA, CAT, and VVM Modes Calibration removes the systematic errors that are associated with measurements in NA, CAT, and VVM Modes. Key presses are identical in all of these Modes. In this Chapter “Why and When to Calibrate”...
Page 122: Calibration For Na, Cat, And Vvm Modes
Calibration for NA, CAT, and VVM Modes See Also Learn How to Make 75 ohm Measurements at the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm Why and When to Calibrate There are well-defined and understood systematic errors that are measured and calculated during the calibration process. These errors are caused by leakage signals inside the FieldFox, by the frequency response of the FieldFox receivers, and by reflections inside the FieldFox that interact with the DUT.
Page 123: Calready
Calibration for NA, CAT, and VVM Modes scope of this discussion. Although an OPEN standard is a precision component, simply leaving nothing connected at the end of a cable can be a reasonable substitute for an OPEN. — A LOAD standard absorbs almost ALL of the incident signal and very little signal is reflected back to the source.
Page 124 Calibration for NA, CAT, and VVM Modes The following appears: Choose Calibration Method screen — Response Cal – Used to quickly calibrate ONE type of measurement using mechanical standards. Measurement accuracy is generally low. Learn more “Simple Response Cals ” on page 132.
Page 125: Quickcal (N991Xa/2Xa/3Xa Only)
Calibration for NA, CAT, and VVM Modes Source Unleveled errors - During calibration, the frequency range of the measurement MAY be extended to provide maximum flexibility. During the calibration, the output power may become unleveled at the added high frequencies. You can ignore the “Source Unleveled” error, or to avoid the error, select either High power or -15 dBm before calibrating.
Page 126 Calibration for NA, CAT, and VVM Modes — The connector choices that are offered depend on the frequency range. For example, if you have selected a frequency range that exceeds 18 GHz, the only connector options you will be presented with in QuickCal are 'other 50 ohm' or 'other 75 ohm'.
Page 127: Mechanical Cal
Calibration for NA, CAT, and VVM Modes — When your DUT has high return loss such as the reject band of a filter. Then measuring the load improves accuracy. Even with the optional Load, phase accuracy begins to degrade when the return loss is greater than about 20dB.
Page 128 Calibration for NA, CAT, and VVM Modes — If a jumper cable or adapter is required to connect the DUT to the FieldFox, then connect those components to the FieldFox connectors. The effects of those components will be measured and removed during the calibration, and only the effects of the DUT will be displayed in the measurement results.
Page 129 Calibration for NA, CAT, and VVM Modes — Press Change Gender to change the gender of the DUT connector. — Then press Next… to confirm the selection and continue the process. — For each port: — Use the arrows or rotary knob to select the Cal Kit that you have, and are going to use, for the specified ports.
Page 130: Ecal
Calibration for NA, CAT, and VVM Modes ECal ECals each have a recommended input power level. Depending on the measurement setup, the FieldFox may default to an input power level that exceeds your ECal’s recommended input power level. Refer to the reference guide for your ECal module to determine the correct input power levels.
Page 131 Calibration for NA, CAT, and VVM Modes Select an ECal module that has connectors of the same type and gender as the DUT. If such an ECal module is not available, a module with connectors different from the DUT can be used by selecting a User Characterization. This selection is located on the Mechanical Cal Setup page of the CalWizard.
Page 132: Simple Response Cals
Calibration for NA, CAT, and VVM Modes not. Without extended cal, if you adjust your frequency outside the calibrated range after the calibration has been completed, the error correction is turned off. — (default) The FieldFox does not measure any frequency points outside the current displayed frequency range.
Page 133 Calibration for NA, CAT, and VVM Modes Normalize uses a THRU standard or cable between port 1 and port 2 to cal an S21 and S12 Transmission measurement (NA Mode) and a 2-port Insertion Loss measurement (CAT Mode). In VVM Mode, this is performed using Zero. When a Normalization is performed, the forward and reverse transmission tracking terms from CalReady are updated to account for the THRU that is used during the normalization process.
Page 134: View Cal
Calibration for NA, CAT, and VVM Modes View Cal From the Choose Calibration screen (see “How to Perform a Calibration” on page 123), press View Cal to see the following screen: The top box shows the properties of the current calibration that you performed and the displayed S-parameters that it is correcting.
Page 135 Calibration for NA, CAT, and VVM Modes Definitions: Non-insertable DUT – A device whose Insertable DUT – A device whose connectors connectors could NOT mate together. They could mate together. They have the same type either do not have the same type of connector of connector and opposite or no gender.
Page 136 Calibration for NA, CAT, and VVM Modes Based on the SOLR/Unknown THRU calibration. For more information on the Unknown THRU process, see the FieldFox Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm Sweeps in BOTH directions. FULL 2-Port (QSOLT) – Mechanical Cal ONLY (May require an option) Quicker to perform QSOLT than Full 2-port.
Page 137: Isolation Step
Calibration for NA, CAT, and VVM Modes DUT: Non-Insertable or Insertable S-parameters Corrected: S11 or S22 Standards: OPEN or SHORT on ONE port Sweeps in BOTH directions. Isolation Step The optional isolation step of a calibration corrects for crosstalk which is the internal signal leakage between the test ports.
Page 138 Calibration for NA, CAT, and VVM Modes of the measurement WITHIN the frequency range of the waveguide Cal Kit. Otherwise, an error message will appear during the ‘Calculating Steps’ portion of the calibration. Waveguide Cal Kits Keysight sells two waveguide Cal Kit series: the premium 11644A series and the economy N9911X series.
Page 139: Enhanced Response Optimization
Calibration for NA, CAT, and VVM Modes — Press Meas Setup 4 — Then Transform — Then Transform Settings — Under Transform Stimulus Settings, set the Start and Stop frequencies to those of the Waveguide. — Set Stimulus = Bandpass Impulse —...
Page 140: Interpolation
Calibration for NA, CAT, and VVM Modes Interpolation * Highest measurement accuracy is achieved when the frequency range or resolution settings remain the same during the measurement as when the FieldFox was calibrated. If these settings change after performing a calibration, the FieldFox will interpolate the calibration so that VERY accurate measurements continue to be made.
Page 141: Calready Properties
Calibration for NA, CAT, and VVM Modes CalReady Properties There are several factory calibrations (CalReady) on every FieldFox. These can be selected based on the type of DUT that you measure most often, and the compromise that you prefer to make between measurement speed versus measurement accuracy.
Page 142: Verifying Calibration And Jumper Cable Integrity
Calibration for NA, CAT, and VVM Modes Verifying Calibration and Jumper Cable Integrity Verifying Calibration and Jumper Cable Integrity After calibrating, it is important to verify that the calibration is good. When using a jumper cable, also verify that the cable is of high quality. Verify a Calibration —...
Page 143: Calibration Method Summary
Calibration for NA, CAT, and VVM Modes Calibration Method Summary Calibration Method Summary — Mechanical Full 2-port Cal is ALWAYS the most accurate Cal method. The quality of a Mechanical Cal is completely dependent on the quality of the OPEN, SHORT, LOAD standards and the quality of the standard connections.
Page 144 Calibration for NA, CAT, and VVM Modes Calibration Method Summary Keysight N9927-90001 User’s Guide...
Page 145: Sa (Spectrum Analyzer) Mode
Keysight Handheld Analyzers N99xxA User’s Guide SA (Spectrum Analyzer) Mode To better reflect the enhancements implemented during the alignment > process, for firmware versions A.10.15 "IF Flatness Alignment" is now referred to as "Channel Equalization" or "Channel Equalization Alignment" (ChanEQ Alignment).
Page 146 SA (Spectrum Analyzer) Mode In this Chapter “Frequency Range” on page 148 “Radio Standard” on page 150 “Channel Selection” on page 151 “Reverse Swap” on page 153 “Scale and Units” on page 153 “External Gain” on page 154 “Attenuation Control” on page 154 “Preamplifier Control (Opt 235)”...
Page 147 SA (Spectrum Analyzer) Mode “RF Burst Amplitude Alignment” on page 186 “Detection Method” on page 188 “Display Line” on page 190 “Noise Marker” on page 191 “Band/Interval Power Marker” on page 191 “Frequency Counter at Marker” on page 192 “Audio Beep at Marker Power” on page 193 “Meas UNCAL Error”...
Page 148: Sa Mode Settings
SA (Spectrum Analyzer) Mode SA Mode Settings SA Mode Settings Select SA Mode before making any setting in this chapter. Because there is no calibration, these settings can be made in any order. How to select SA Mode — Press Mode_ —...
Page 149 SA (Spectrum Analyzer) Mode SA Mode Settings —Center Freq Span frequencies. This is the most common method of entering frequency range. Enter the frequency of interest. The Center frequency is at the exact center of the X-axis. The Frequency Span places half of the frequency range on either side of center. When the Center and Frequency Span values are entered, then the X-axis annotation on the screen shows the Center and Span frequencies.
Page 150: Radio Standard
SA (Spectrum Analyzer) Mode SA Mode Settings —Manual Type a step size value using the numeric keypad, then select a multiplier key. Learn more in “Multiplier Abbreviations” on page Radio Standard A Radio Standard is a collection of settings that are applied to the FieldFox for specific RF protocols.
Page 151: Channel Selection
SA (Spectrum Analyzer) Mode SA Mode Settings — Then Radio Standard — Then Radio Standard — Then Import Radio Standards — Then select the *.csv file using the arrows or rotary knob and press Enter. — Custom Radio Standards can be removed from the FieldFox by selecting Measure 1 then Radio Standard then...
Page 152 SA (Spectrum Analyzer) Mode SA Mode Settings —Freq Span Changes the span of frequencies while the center frequency remains unchanged. —Follow each of the above settings by entering a value using the numeric keypad or the rotary knob. —Use the arrows to increment the channel number by an amount specified by the Channel Step value (see below).
Page 153: Reverse Swap
SA (Spectrum Analyzer) Mode SA Mode Settings — Enter a step value using the numeric keypad, the arrows, or the rotary knob. Then press Enter. Reverse Swap Available ONLY with Opt. 209 and while in Step sweep mode. Each press of the softkey causes the Start and Stop frequencies to swap.
Page 154: External Gain
SA (Spectrum Analyzer) Mode SA Mode Settings — Ref Pos Manually set the position of the reference line. Values must be between 0 (TOP line) and 10 (BOTTOM line). Default position is zero (top). How to Set Y-axis Units The Unit setting appears for the reference line, marker readouts, and trigger level.
Page 155: Preamplifier Control (Opt 235)
SA (Spectrum Analyzer) Mode SA Mode Settings When too much power is present at the RF Input port, ADC Over Range appears on the FieldFox screen. This does not necessarily mean that damage has occurred, but that the measurement is probably compressed. When high power levels are present at the RF Input port, internal attenuation can be switched in to keep the FieldFox receiver from compressing.
Page 156: Check For Compressed Measurements
SA (Spectrum Analyzer) Mode SA Mode Settings Check for Compressed Measurements Compression occurs when too much power into an amplifier causes it to no longer amplify in a linear manner. When too much power goes into the FieldFox RF Input connector, the amplifiers in the SA receiver compress and signal power will not be displayed accurately.
Page 157 SA (Spectrum Analyzer) Mode SA Mode Settings Trace 2 - Uncorrected trace (Apply Corr = OFF). The Trace 2 trace state is “View.” For information, refer to “Trace Display States (SA Mode)” on page 178 Pink Trace - Current correction factor. See below. —...
Page 158: Using The Antenna/Cable Editor
SA (Spectrum Analyzer) Mode SA Mode Settings — Recall Antenna/Cable Read an existing Antenna/Cable file from the specified Storage Device. — Storage Device Choose from: Internal, USB, SD. Learn more about these selections in “Set File Type and Select Device” on page 677.
Page 159 SA (Spectrum Analyzer) Mode SA Mode Settings ——Choose from: dB μV/m - (dB micro Volts per meter), dB μA/m - (dB micro Amps per meter), dBG (gauss), dBpT (tesla). ——Freq Interpolation: Set to LINear and can NOT be edited. — To edit Frequency/Value pairs, enter numbers using the numeric keypad, and a frequency suffix when necessary.
Page 160: Source Tracking Offset And Offset Reversal
SA (Spectrum Analyzer) Mode SA Mode Settings — Antenna files are saved and recalled from the Antenna folder. — To DELETE Cable or Antenna files, use the Manage Files feature. Learn more “Manage Files” on page 680. — If the folder does not already exist on a USB or SD card, it is created automatically before storing the file.
Page 161: Tune & Listen (Am/Fm)
SA (Spectrum Analyzer) Mode SA Mode Settings —OffsetReversal Determines whether Receiver Freq is added to or subtracted from the Offset Freq. ——OFF SourceFreq = Offset + RecFreq. Use to measure Upconverters. ——ON SourceFreq = Offset - RecFreq. Use to measure Downconverters.
Page 162 SA (Spectrum Analyzer) Mode SA Mode Settings How to select Tune & Listen — Press Measure 1 — Then Analog Demod Tune & Listen — Then choose a demodulation type. Select a setting based on the type of interfering signal you suspect is being broadcast. —None Turns Tune &...
Page 163: Independent Source/Tracking Generator
SA (Spectrum Analyzer) Mode SA Mode Settings Listen Time While Tune & Listen is actively demodulating a signal, the SA does not sweep and update the display. Listen Time sets the amount of time that the FieldFox demodulates, then stops to perform a single sweep and update the display, then again demodulates.
Page 164 SA (Spectrum Analyzer) Mode SA Mode Settings Like a traditional tracking generator, the Independent Source feature can set the internal FieldFox source to track the SA receiver frequency range. It can also set the internal source to a CW frequency that is independent of the SA frequency.
Page 165: Resolution Bandwidth (Res Bw)
SA (Spectrum Analyzer) Mode SA Mode Settings — Source CW Freq Sets the CW frequency that is used when Source Mode is set to CW. By default, the source output will turn off momentarily at the end of each IQA and SA sweep and also every 300 seconds during the InstAlign process.
Page 166: Video Bandwidth (Video Bw)
SA (Spectrum Analyzer) Mode SA Mode Settings This setting could impact the accuracy of the measurement. See Specifications in Appendix B. The Res BW setting also affects the Sweep Type setting. Learn how in “Sweep Type” on page 166 Video Bandwidth (Video BW) Video BW is a smoothing operation that is performed after measurement data is acquired.
Page 167: If Output
SA (Spectrum Analyzer) Mode SA Mode Settings How to set Sweep Type — Press BW 2. — Then Advanced — Then Sweep Type — Then choose from the following: —Auto The FieldFox selects the most efficient sweep type based on the Res BW.
Page 168 SA (Spectrum Analyzer) Mode SA Mode Settings Figure 9-4 IF Output Wide with CF-33.75 MHz How to select IF Output The IF Output signal is useful only in Zero Span. Learn more about Zero Span in “Zero Span Measurements” on page 170.
Page 169: Sweep Acquisition
SA (Spectrum Analyzer) Mode SA Mode Settings Sweep Acquisition Available only in non-zero span measurements, when Sweep Acquisition is set to Auto, the fastest sweep rate is achieved while maintaining full amplitude accuracy. For zero span measurements, refer to “Zero Span Measurements” on page 170.
Page 170: Very Long Sweep Times
SA (Spectrum Analyzer) Mode SA Mode Settings — Then SwpAcquisition Auto Man. — Then choose from the following: ——Auto Sweep is set to the fastest sweep possible with the current settings. ——Man Enter a relative acquisition value between 1 and 5000, where: —...
Page 171 SA (Spectrum Analyzer) Mode SA Mode Settings For non-zero span measurements, refer to “Sweep Acquisition” on page 169. Figure 9-6 GSM Signal, Framed Data Format The graphic above shows a GSM signal, framed data format, with timeslot 0 and 3 “on”. Sweep Time is set to approximately the frame interval. Press Single several times until the waveform section of interest is viewable and stable.
Page 172: Triggering
SA (Spectrum Analyzer) Mode SA Mode Settings Previous FieldFox versions limited the sweep time / ResBW settings. This restriction is no longer necessary with release A.06.25. Learn more about SA mode Sweep Time in the Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm Triggering External, Video, and RF Burst triggering allows you to initiate an SA mode sweep using an external event such as a signal burst.
Page 173 SA (Spectrum Analyzer) Mode SA Mode Settings Trigger Slope Trigger Slope determines which edge of an External, Video, or RF Burst trigger signal initiates a sweep. — Press Sweep 3 — Then Trigger Settings — Then Trig Slope — Then choose from the following: —Po Sweep is triggered by the rising (positive) edge of signal.
Page 174 SA (Spectrum Analyzer) Mode SA Mode Settings — Press Sweep 3 — Then Trigger Settings — Then Trig Level — Enter a value using the numeric keypad, the arrows, or the rotary knob. — Then select a multiplier key or press Enter. Learn more in “Multiplier Abbreviations”...
Page 175: Fft Gating (Opt 238)
SA (Spectrum Analyzer) Mode SA Mode Settings —OFF: Select, then enter a position value from 0 to 10 using the numeric keypad, the arrows, or the rotary knob. ——0: T-zero occurs at the left graticule. ——5: T-zero occurs at the center of the screen. ——10: T-zero occurs at the far right graticule.
Page 176 SA (Spectrum Analyzer) Mode SA Mode Settings — Measure the spectrum of a signal in one time slot of a TDMA system. — Exclude the spectrum of interfering signals, such as periodic pulse edge transients that exist for only a limited time. FFT Gating is a simple, efficient way to set the proper amount of trigger delay and capture time so that signal artifacts of a repeating waveform or pulse can be examined in the frequency domain.
Page 177: Single / Continuous / Restart
SA (Spectrum Analyzer) Mode SA Mode Settings —Gate Delay Effectively moves the gating area left (negative delay) or right (positive delay) relative to the trigger event. Enter a value using the numeric keypad, the arrows, or the rotary knob. When you have properly setup the Gate Trigger, Width, and Delay using the Gate View measurement, you can turn Gate View OFF to return to the full screen non-zero span measurement with FFT Gating ON, the RBW set, and the Trigger settings active.
Page 178: Trace Display States (Sa Mode)
SA (Spectrum Analyzer) Mode SA Mode Settings — 101 | 201 | 401 | 601 | 801 | 1001 — # Points to enter a trace points value manually (Maximum = 20001). Trace Display States (SA Mode) In SA Mode you can display up to four of the following types of trace states. All SA settings are applied to all displayed traces.
Page 179: Average Type
SA (Spectrum Analyzer) Mode SA Mode Settings — Press Default All to return all traces to their default settings: Trace 1 (Clear/Write); all other traces (Blank). Trace 4 data WILL be overwritten by the FieldFox when using the Independent Source Normalize feature (“Independent Source/Tracking Generator ”...
Page 180: Average Count
SA (Spectrum Analyzer) Mode SA Mode Settings Average Count The Average Count setting is used mainly with the Average Trace State described above. In this Trace State, the Average Count setting determines the number of sweeps to average. The higher the average count, the greater the amount of noise reduction.
Page 181 SA (Spectrum Analyzer) Mode SA Mode Settings When All Alignment is enabled (by default) the FieldFox performs an alignment process using the internal RF source. Although some sweeps are delayed, measurement results are never disturbed. If the Independent Source (tracking generator) is enabled for your measurement, it will be borrowed to perform the alignment.
Page 182 SA (Spectrum Analyzer) Mode SA Mode Settings Default settings and recommended use model for many applications: — Coupled individual alignments — Coupled state is Auto — Individual alignments are not accessible via front panel soft-keys — Individual alignments cannot be UnCoupled For special cases, the individual alignments can be accessible via the front panel soft-keys using the Preference setting SA - Individual Alignment >...
Page 183 SA (Spectrum Analyzer) Mode SA Mode Settings The individual alignments may be: — Coupled (default) - when they are in the same state, or — UnCoupled - when at least one of them is in a different state than the other ones —...
Page 184 SA (Spectrum Analyzer) Mode SA Mode Settings — Then All Alignment [Auto] (to enable or disable the All Alignment) – Default is Auto. — or — Then Align All Now (to manually perform an Align All Now.) This performs an alignment on all three individual alignments: Amptd Align Now, Burst Align Now, and ChanEq Now).
Page 185 SA (Spectrum Analyzer) Mode SA Mode Settings How to Access Individual Alignments This section assumes access to individual alignments was activated using the FieldFox’s system settings’ Preferences. Once enabled, an Individual Alignments softkey is displayed. Refer to “Preferences” on page 637, in Chapter 29 System Settings.
Page 186: Rf Burst Amplitude Alignment
SA (Spectrum Analyzer) Mode SA Mode Settings Some examples of the conditions when alignments occur are: This could be a Center frequency change, or it could be as simple as requesting a Single sweep. Also, unique alignments are required at different FieldFox receiver frequency bands, so even if the temperature hasn't changed, an alignment may be required when one changes the Center frequency.
Page 187 SA (Spectrum Analyzer) Mode SA Mode Settings — Then Burst Alignment — Then choose from the following: — Auto (Default setting) SA measurement applications monitor changes in internal temperature and the time since last alignment update and trigger the need for a new update when the alignment becomes stale.
Page 188: Detection Method
SA (Spectrum Analyzer) Mode SA Mode Settings change in temperature or a significant time elapsed from the last update. The temperature change and time duration necessary to trigger an alignment update is predetermined in the factory. Some examples of the conditions when alignments occur are: This could be a Center frequency change, or it could be as simple as requesting a Single sweep.
Page 189 SA (Spectrum Analyzer) Mode SA Mode Settings Figure 9-7 Detection using One Bucket In the graphic above there is one bucket showing Positive peak, Sample, and Negative peak Detection methods. How to set Detection Method The current Detection method is labeled on the left edge of the screen. When a method is selected manually, a # precedes the label.
Page 190: Display Line
SA (Spectrum Analyzer) Mode SA Mode Settings —Negative Peak [#NPk] Displays the minimum value of all the measurements in each bucket. —Sample [#Smp] Displays the center measurement of all the measurements in each bucket. This setting gives a good representation of the random noise in each bucket. However, it does not ensure that all signals are represented.
Page 191: Noise Marker
SA (Spectrum Analyzer) Mode SA Mode Settings Noise Marker For comparison purposes, electronic noise measurements are often displayed as though the measurement was made in a 1 Hz Res BW. However, making an actual measurement at a 1 Hz Res BW is extremely slow. A Noise Marker, unique to SA Mode, mathematically calculates the noise measurement as though it were made using a 1 Hz bandwidth.
Page 192: Frequency Counter At Marker
SA (Spectrum Analyzer) Mode SA Mode Settings If the Detection method and Averaging type are set to Auto when you enable a Band/Interval Power marker, the Detection method will change to Average (RMS) and Averaging type will change to Power average. Other Detection methods or Averaging type settings will usually cause measurement inaccuracy.
Page 193: Time Zero Fixed Marker
SA (Spectrum Analyzer) Mode SA Mode Settings How to use Frequency Counter — Press Marker. — Press Normal, Delta, or Peak, or select an existing marker to use as a frequency counter. — Locate the marker somewhere on a CW signal. It does NOT have to be on the peak.
Page 194: Meas Uncal Error
SA (Spectrum Analyzer) Mode SA Mode Settings Band/Interval Power. Learn more in “Audio” on page 642. How to use Audio Beep — Press Marker — Optionally, press Marker 1 2 3 4 5 6 to select an existing marker to use with Audio Beep.
Page 195: Channel Measurements
SA (Spectrum Analyzer) Mode Channel Measurements Channel Measurements The following Channel Measurements are offered in SA Mode: Channel Power “Channel Power (CHP)” on page 196 Occupied Bandwidth “Occupied Bandwidth” on page 198 Adjacent Channel Power Ratio “Adjacent Channel Power Ratio (ACPR)” on page 200 Radio Standards and Channel Measurements To tune the frequency range of any of the Channel Measurements using...
Page 196: Traces
SA (Spectrum Analyzer) Mode Channel Measurements — Averaging Type is set to Power. — Trace State is set to Average. — Detector is set to Average. — Count is set to 15. Any of these settings can be changed manually during a Channel measurement.
Page 197 SA (Spectrum Analyzer) Mode Channel Measurements Figure 9-9 Channel Power Measurement The following two Channel Power levels are displayed: — Channel Power - measures total power over the specified Integrated BW. — Power Spectral Density – same measured power, but mathematically normalized to a 1 Hz bandwidth using the same algorithm as Noise Marker.
Page 198 SA (Spectrum Analyzer) Mode Channel Measurements By default, the displayed frequency span is automatically coupled to the Integration Bandwidth. As you change the Integration Bandwidth, the frequency span is adjusted so that the vertical posts appear to NOT move. However, when you manually change the frequency span, the Integration Bandwidth is no longer coupled to the frequency span.
Page 199 SA (Spectrum Analyzer) Mode Channel Measurements Figure 9-10 Occupied Bandwidth Measurement The graphic above shows an OBW measurement; Chan 190 Downlink; GSM850 Radio Standard How to Select Occupied Bandwidth — Press Measure__1 — Then Channel Measurements — Then Occupied BW When Occupied Bandwidth is selected, the following settings are maintained from a previous measurement: Center Frequency, Preamp ON|OFF, and RF Attenuation.
Page 200 SA (Spectrum Analyzer) Mode Channel Measurements — Then Freq Span — Enter a value using the numeric keypad, arrows, or the rotary knob. — Press Enter Power Percent This setting specifies the percentage of total measured power to display between the vertical posts. The measurement defaults to 99% of the occupied bandwidth power.
Page 201 SA (Spectrum Analyzer) Mode Channel Measurements Figure 9-11 GSM 850-Ch 251-Up with one Offset In the graphic above, frequencies (MHz) are added to illustrate offset and integ BW. Data in the ACPR graphical chart is always presented in dBm for the carrier, and dBc (dB below the carrier) for the offsets.
Page 202 SA (Spectrum Analyzer) Mode Channel Measurements Frequency Range/Channel When a Radio Standard is selected, the appropriate center frequency or channel and span is set automatically. The frequency or channel number can then be changed from the Freq/Dist menu. Learn how to select a Radio Standard and channels in “Radio Standard”...
Page 203 SA (Spectrum Analyzer) Mode Channel Measurements How to set limits for adjacent channels You can set a unique threshold power for each of the offsets that will cause a FAIL indication (RED bar). This occurs when the calculated dBc power (on top of the offset bar) is ABOVE the specified level.
Page 204 SA (Spectrum Analyzer) Mode Channel Measurements —Then enter a value to be used to reference the data using the numeric keypad, arrows, or the rotary knob. Other ACPR Settings All relevant FieldFox settings are made automatically to ensure the highest accuracy, such as ResBW, VideoBW, and sweep (SwpAcquisition) speed.
Page 205 SA (Spectrum Analyzer) Mode Channel Measurements — Enter a value between 0 (no smoothing) and 1 (most smoothing) using the numeric keypad, arrows, or the rotary knob. A standard level of filtering is 22. — Press Enter. Keysight N9927-90001 User’s Guide...
Page 206: How To Set Up Emf Settings (Requires Emf (Option 358), Gps (Option 307), And Sa Mode (Option 233-Mixed Analyzers))
SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) If OTA or SA mode does not detect an EMF Option 358 license, then the EMF application and the USB antenna’s axes must be set up manually.
Page 207: Emf Features
SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) — “EMF Features” on page 207 — EMF Setup Procedure EMF Features EMF has the following features: EMF Measurement Results: —...
Page 208 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) Figure 9-13 Example of EMF with Triaxial Antenna Keysight N9927-90001 User’s Guide...
Page 209: Emf Setup Procedure
SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) EMF Setup Procedure When the USB antenna correction factors are imported, EMF (Option 358) couples many settings to ease setting up the EMF measurement (e.g., Apply Corrections is enabled, all X, Y, and Z antenna axes are enabled, and Amp Corr Select is set to TriAxial XYZ).
Page 210 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) — Press Back > Back to exit the USB Antenna softkey menu. 4. Modifying the EMF settings: Press Meas Setup 4 —...
Page 211 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) — Default Receiver side only antenna measurements. — Src/Rcvr Split to work with non-triaxial receiver and source side antenna measurements. —...
Page 212 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) — Storage Device to select the storage device where your cable correction file is located (Internal/USB/SD Card) ii.
Page 213 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) Editing Antenna Correction Factors and Adding New Antenna Factors This section contains two procedures illustrating how to edit the Antenna Factors settings table values.
Page 214 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) — Press Edit Antenna to edit your existing antenna factors or press to add a a new antenna’s factors or to write over your existing antenna ’s file (i.e., Overwrite existing Antenna data?
Page 215 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) Figure 9-15 Example Editing and Adding a New X axis antenna is shown. Editing Cable Correction Factors and Adding New Cable Factors This section contains two procedures illustrating how to edit the Cable Factors settings table values.
Page 216 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) a. Then press Cable Off > Edit Cable to edit the existing cable’s Frequency and Cable Loss table values that are stored in the FieldFox [:Internal]:\Cable\ directory (Refer to Figure 9-15).
Page 217 SA (Spectrum Analyzer) Mode How to Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers)) c. Press Save Cable to save your changes. See also “File Saving Naming Options” on page 645 and then to “Alpha Numeric Editing”...
Page 218: Spectrum Emission Mask (Sem) - (Sa Mode Only)
SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) Spectrum Emission Mask (SEM) — (SA Mode Only) This section explains how to make the spectrum emission mask, (SEM), measurement. SEM compares the total power level within the defined carrier bandwidth and offset channels on both sides of the carrier frequency, to levels allowed by standard.
Page 219 SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) — Spectrum Emission Mask Pass/Fail – A PASS indicates the displayed SEM is within the current boundaries specified. A FAIL indicates the current signal fails with the specified parameters. Figure 9-17 SEM Example Keysight N9927-90001 User’s Guide...
Page 220: How To Select Spectrum Emission Mask (Sem) Measurement
SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) Figure 9-18 SEM Example FAIL Data - Absolute Limit (Blue), Relative Limit (Violet), Trace (Yellow), and Tabular Data How to select Spectrum Emission Mask (SEM) Measurement — Press Measure 1 —...
Page 221 SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) Measurement Type (Meas Type) enables the user to select the method used to calculate the reference power level. The displayed green power (dBm)/frequency (Hz) text changes as the Meas Type is toggled.
Page 222 SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) — Ofst Enable Enables/disables the currently selected Frequency Start/Stop Offset values. — Ofst Freq Start Sets the offset frequency start value. (Default/Maximum = Value varies with model and options, Minimum = 0 Hz).
Page 223 SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) — More - optional to set Radio Standard controls. Refer to “Radio Standard” on page 150. 4. Setting the Limit Lines Two Limit traces are available, an Absolute Limit and a Relative Limit. Both are defined and applied only over the Offset measurement regions.
Page 224 SA (Spectrum Analyzer) Mode Spectrum Emission Mask (SEM) — (SA Mode Only) — Relative - A data point that exceeds the value of the reference setting determined by the Measurement Type (Meas Type) generates a fail message. — Abs OR Rel - Either Abs or Rel data failure generates a fail message.
Page 225: Rtsa (Real-Time Spectrum Analyzer) Mode-Option 350 (Cpu2 Only)
Keysight Handheld Analyzers N99xxA User’s Guide 10 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode measures signals at the SA RF IN connector. For a comprehensive RTSA mode tutorial, see Understanding and Applying Probability of Intercept in Real-Time Spectrum Analysis (App Note) at http://literature.cdn.keysight.com/litweb/pdf/5991-4317EN.pdf Figure 10-1 RTSA Display using Markers The graphic above shows an RTSA display of a Bluetooth signal using...
Page 226 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) In this Chapter: “Frequency Range” on page 227 “Scale and Units” on page 228 “External Gain” on page 229 “Attenuation Control” on page 229 “Preamplifier Control (Opt 235)” on page 230 “Check for Compressed Measurements” on page 231 “Resolution Bandwidth (Res BW)”...
Page 227: Rtsa Mode Settings
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings RTSA Mode Settings Select RTSA Mode before making any setting in this chapter. Because there is no calibration, these settings can be made in any order. How to select RTSA Mode —...
Page 228: Scale And Units
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings —Center Freq Span frequencies. This is the most common method of entering frequency range. Enter the frequency of interest. The Center frequency is at the exact center of the X-axis. The Frequency Span places half of the frequency range on either side of center.
Page 229: External Gain
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings How to set Scale Press Scale / Amptd. Then choose from the following: Manually set Scale, acquisition, and Reference Position. — Scale Manually adjust the dB scale per division to view specific areas of the current trace.
Page 230: Preamplifier Control (Opt 235)
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings When high power levels are present at the RF Input port, internal attenuation can be switched in to keep the FieldFox receiver from compressing. At extremely high power levels, use external attenuation to protect the internal circuitry from being damaged.
Page 231: Check For Compressed Measurements
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Auto When Auto is selected, the preamp setting is coupled to the RF attenuation and to the acquisition. When the acquisition reaches a certain value, the preamp is turned on and is shown to the left of the graticules on the display.
Page 232 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Real-time Spectrum The signal is displayed as a real-time spectrum. Use real-time spectrogram to quickly display measurements. Refer to Figure 10-4 on page 234. In all three spectrum measurements, there are four available traces for representation of the real-time spectrum.Density Spectrum (Histogram) FM Signal with 1 MHz FM Deviation &...
Page 233 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings Figure 10-2 Density Spectrum (Histogram) with 2 Pulses (Blue color indicates pulse that occurs less frequently) Figure 10-3 Spectrogram Keysight N9927-90001 User’s Guide...
Page 234: Resolution Bandwidth (Res Bw)
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings Figure 10-4 Real-Time Spectrum Resolution Bandwidth (Res BW) For best results, use the AUTO setting for the Res BW values. Increasing the resolution BW could reduce pulse measurement capability by affecting the 100% POI duration and the minimum detectable signal level.
Page 235: Triggering
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Then choose from the following: — Auto Res BW is coupled to the frequency span. As the frequency span is narrowed, the Res BW is also narrowed providing increased ability to resolve signals.
Page 236 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Video A sweep is initiated when the amplitude of an incoming signal crosses the settable trigger level. The comparison is done in the time domain, before conversion to frequency domain. Refer to “Trigger Slope”, “Trigger...
Page 237 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Then Trigger Settings — Then Trig Delay — Enter a value using the numeric keypad, the arrows, or the rotary knob. (0 to 10 seconds) — Then select a multiplier key or press Enter. Learn more in “Multiplier Abbreviations”...
Page 238: Single / Continuous / Restart / Time Per Div
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Enter 0 to set Auto Trigger OFF or press the Auto Trigger softkey a second time to turn OFF Auto Trigger. Trigger Hold-Off Used with External, Video, and RF Burst triggering, sets the hold-off time between triggers.
Page 239: Acq Time
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings How to set Single or Continuous — Press Sweep 3. — Then choose one of the following: — Continuous ——ON Causes the RTSA to make continuous sweeps. This is the typical setting for making measurements.
Page 240: Trace Display States
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings Trace Display States You can use the FieldFox’s Remote Server mode (89600 VSA software connectivity) to parse playback files and captured data as MATLAB files (*.mat). Learn more about FieldFox and 89600 VSA software, refer to Chapter 16, “Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233)”...
Page 241: Detection Method
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings — Press Default All to return all traces to their default settings: Trace 1 (Clear/Write); all other traces, including trace detectors (Blank). Detection Method In RTSA Mode, the X-axis is comprised of data points, also known as “buckets”. Learn more in “Points (not user settable)”...
Page 242: Average Count, Show Density, Blue, And Red Percentage Limits
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings —Sample [S] Displays the center measurement of all the measurements in each bucket. This setting gives a good representation of the random noise in each bucket. However, it does not ensure that all signals are represented.
Page 243: Alignments
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings Average Count The Average Count setting is used mainly with the RMS Average Trace State described above. (But, also applies to the MaxHold or MinHold trace states.) In the RMS Average Trace State, the Average Count setting determines the number of sweeps to average.
Page 244 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) RTSA Mode Settings Figure 10-5 Display Line with Annotations How to create and move a Display Line — Press Limit __8 — Then Display Line OFF ON — Then enter a Y-axis value using the arrows or the rotary knob, then press Enter.
Page 245: Spectrogram Display
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Spectrogram Display Spectrogram Display Spectrogram display provides a visual history of the measured spectrum. This display type can be used to locate intermittent signals or to view signal levels and frequencies over time. This display can NOT be used with Channel Measurements.
Page 246: Common Settings For Spectrogram
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Spectrogram Display — Displays the data trace below the spectrogram. Total trace records: 130. — Bottom Displays the data trace above the spectrogram. Total trace records: 130. Common Settings for Spectrogram Set Red and Blue Limits The colors displayed on the Waterfall and Spectrogram represent the various measured power levels: —...
Page 247: Record/Playback (Rtsa Option)
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) Record/Playback (RTSA Option) Density Spectrum information is not recorded. Only the trace data is saved. See “How to Record a Session” on page 250 Record/Playback is only available in Density Spectrum and Real-Time Spectrum measurements.
Page 248: Fieldfox Setting Changes During Record And Playback
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) You can determine the length of time over which recording can occur by setting the Record Interval (the time between recorded traces) and other settings. Learn more in “Recording Configuration” on page 252.
Page 249: About State And User Tags
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) Table 10-1 Summary of RTSA State Settings Option Settings RTSA Acquisition Time Detector(s) External Gain Frequency Range Preamp On/Off Resolution BW RF Attenuation Trace State(s) Trigger Settings Other display settings, such as Scale and acquisition, can also be changed during recording but are not saved with the session file.
Page 250: How To Record A Session
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) In addition, you can insert a ‘User Tag’ at any time during a recording session to indicate an external event, such as when an antenna is moved. During playback, you can move quickly to any of these tags, or scroll through these tags.
Page 251: How To Playback A Session
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) — New Session — Recall Session then Open and select a session. — Then Recorder Player — Then Record is displayed in the left of screen graticules. During recording, choose from the following: —...
Page 252: Recording Configuration
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) — Playback State/Tag Allows you to continue playback from a state tag, or scroll through the state tags. Enter a value between 1 and the total number of state tags using the numeric keypad, arrows, or the rotary knob.
Page 253: Record Source
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) — Record Interval Sets the amount of time to wait between individual trace recordings. Default is MIN, which is to wait 0 seconds (record traces as fast as possible). Enter a value in seconds between 0 (no delay) and 10,000 seconds - about 3 hrs) using the numeric keypad, arrows, or the rotary knob.
Page 254: Playback Configuration
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) — Data is ALWAYS played back into the same trace number that was recorded. If four traces were active during the recording, but only one trace was recorded, then during Playback only that one recorded trace is visible. Playback Configuration By default, trace sweeps are played back as fast as the trace can be drawn on the screen.
Page 255: Record Playback Example (Rtsa Mode Only)
RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) — Rename Using the FieldFox labeler, change the name of the session. AutoSession (n) is the default name where (n) is the next-available number. Learn more in “How to use the FieldFox labeler ” on page 674.
Page 256 RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only) Record/Playback (RTSA Option) Keysight N9927-90001 User’s Guide...
Page 257: Iq Analyzer (Iqa) - Option 351 (Cpu2 Only)
Keysight Handheld Analyzers N99xxA User’s Guide 11 IQ Analyzer (IQA) – Option 351 (CPU2 Only) IQA mode measures signals at the SA RF IN connector. IQA mode requires the FieldFox to have SA mode and CPU2 installed. The FieldFox can be used with an OML frequency extender. Refer to “Utilities”...
Page 258 IQ Analyzer (IQA) – Option 351 (CPU2 Only) In this Chapter “About I/Q Analyzer (IQA) Measurements” on page 260 “I/Q Analyzer (IQA) Mode Settings” on page 261 “How to Make Measurements Using the I/Q Analyzer Mode” on — page 261 “How to Capture I/Q Data to a File”...
Page 259 IQ Analyzer (IQA) – Option 351 (CPU2 Only) Also “Why and When to Calibrate” on page 122 “All about Markers” on page 598 “All about Limit Lines” on page 613 “All about Trace Math” on page 618 Chapter 28, “Data Analysis Features.” Chapter 31, “File Management.”...
Page 260: About I/Q Analyzer (Iqa) Measurements
IQ Analyzer (IQA) – Option 351 (CPU2 Only) About I/Q Analyzer (IQA) Measurements About I/Q Analyzer (IQA) Measurements The I/Q Analyzer Mode makes general purpose frequency domain and time domain measurements. The mode enables two types of I/Q measurements: — frequency domain and —...
Page 261: I/Q Analyzer (Iqa) Mode Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings I/Q Analyzer (IQA) Mode Settings When you initially select I/Q Analyzer, Real-Time SA, or some of the other spectrum settings (such as center frequency) a factory channel Equalization measurement is applied to the signal.
Page 262: How To Capture I/Q Data To A File
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings — The real component of the I/Q data versus time — The imaginary component of the I/Q data versus time The user defined measurement can be modified to change the number of displays from 4 to 3, 2, or 1.
Page 263 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings If you do not have an external device connected and attempt to save your data, a warning message is displayed: "Warning: Only an external storage device can be used in multiple file mode."...
Page 264 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Each time you press the Start softkey the I/Q data writes to the current filename (i.e., Single capture default is IQDataFile.csv or for Multiple format is IQDataFile_yyyymmdd hh.mm.ss.ffff.csv). To avoid overwriting your Single capture data or to add a unique filename for Single or Multiple capture data, use the Measure 1 >...
Page 265: How To Modify The I/Q Data Measurement Parameters
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Example: Single: ——If the Capture Time is set to 100 µs, and you press the Start softkey, in Single mode the FieldFox saves 100 µs of the current I/Q data.
Page 266 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings — Res BW (Spectrum only) – Sets the resolution bandwidth of the FFT analysis. Changing this value changes the FFT window size, analysis length, and the sweep time (data acquisition capture length). This softkey is only available when IQA is set to Spectrum (Freq Domain).
Page 267 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings FFT Window Description Flat 4 This is a four-term flat-top window. Flat Top (default) This is the five-term flat-top window. Flat 6 This is a six-term flat-top window. Flat 7 This is a seven-term flat-top window.
Page 268: Changing Between The Continuous And Single Captures And Adjusting The Trigger Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Changing between the Continuous and Single captures and adjusting the Trigger settings — Press Sweep 3. — Then choose from the following: — Single When pressed, Single automatically sets Continuous to OFF and causes the application to make one acquisition.
Page 269 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings refresh rate when the acquisition time is long. Changing the Stop Time changes which data point is displayed on the right side of the screen. Couplings: When the change of Stop Time makes time domain display length exceed the limitation, the Start Time will change to satisfy time domain display length limitation: ——The maximum value is determined by current Sample Rate and...
Page 270: Adjusting The Measurement Setup Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Softkey Description Periodic Periodic sets a trigger that repeats at the period rate entered. Periodic trigger's phase can be altered by the Trigger Offset value. ——Then depending on the trigger type selected, choose from the following: Trig Level –...
Page 271: Adjusting The Trace Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings ——Log Averaging (default) – Best for displaying Trace Averaging. Also known as video averaging. LgAvg annotation is displayed. ——Voltage (Magnitude) Averaging – Converts the amplitudes to a magnitude unit before averaging (e.g., Volts, Amps, microVolts, milliVolts, etc.) VAvg...
Page 272: Adjusting The Frequency Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Time Summary – Time Summary result includes the capture time, spectrum analysis time and waveform start/stop time. For Waveform Measurement: I vs. Time – Imaginary vs. Time Q vs.
Page 273: Adjusting The Scale And Amplitude Settings
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings — Freq Span (Spectrum Only) Sets the frequency span of the measurement trace. The analyzer's digital IF bandwidth is always equal to this value. Changing the span causes the IF bandwidth and the sample rate to change automatically: Span = IF bandwidth, sample rate = 1.25 * IF bandwidth Res BW = Span /50, if resolution bandwidth = Auto.
Page 274 IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings Manually set Scale, Unit, Acquisition, and Reference Position. — Autoscale Automatically adjusts the Y-axis to comfortably fit the Minimum and Maximum amplitude of the trace on the screen. Also, optimizes the FieldFox’s signal level at the mixer and adjusts the reference level to with the autoscale settings.
Page 275: Preamplifier Control (Opt 235)
IQ Analyzer (IQA) – Option 351 (CPU2 Only) I/Q Analyzer (IQA) Mode Settings — Then RF Atten Auto Man. — Auto RF Attenuation is set by adjusting the input power level. As the acquisition is lowered, for example from –10 dBm to –30 dBm, the FieldFox assumes that you are looking at low-level signals.
Page 276: Using Markers (Iqa)
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Using Markers (IQA) Using Markers (IQA) The markers described here are for I/Q Analyzer mode (exceptions are noted). For additional marker features, refer to “All about Markers” on page 598. IMPORTANT! When using I/Q markers, it is important to either be in Single acquisition mode or for Continuous acquisition mode, to set the measurement in advance on the FieldFox to Waveform or to Spectrum.
Page 277: Band/Interval Power Marker
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Using Markers (IQA) Noise Markers can be used like regular markers. A Noise Marker is distinguished from a regular marker by (1Hz) after the marker readout value. Learn more about regular markers in “All about Markers”...
Page 278: Band Span Marker (Spectrum Only)
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Using Markers (IQA) Band Span Marker (Spectrum Only) Sets the width of the span (Hz) for the selected marker. How to measure with the Band Span marker — Press Marker to create or select a Normal or Delta marker to use to measure Band/Interval Power.
Page 279 IQ Analyzer (IQA) – Option 351 (CPU2 Only) Using Markers (IQA) Four windows are displayed (Spectrum, Waveform, Real, and Imaginary) 3. Using the arrows or the rotary knob, move so Window 2 Waveform is selected (green border). 4. Press Marker > Marker 1 >...
Page 280: Continuous Peak Search Marker
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Using Markers (IQA) Continuous Peak Search Marker When the Continuous Peak Search marker is on, a peak search is automatically performed for the selected marker after each acquisition. For additional marker functionality, refer to “All about Markers”...
Page 281: Alignments
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Alignments Alignments The IQA mode requires all three alignment types: amplitude, RF burst, and channel equalization. Refer to the SA chapter’s “Alignments” on page 180 information on all alignments. Trace Display States (IQA Mode) If you have Option 351 I/Q Analyzer option, you can directly save your data as MATLAB files (*.mat).
Page 282 IQ Analyzer (IQA) – Option 351 (CPU2 Only) Trace Display States (IQA Mode) —MinHold Displays the minimum response of the input signal at each data point over multiple acquisitions. See also Average Count in “Adjusting the Measurement Setup Settings” on page 270.
Page 283: Other Features Available
IQ Analyzer (IQA) – Option 351 (CPU2 Only) Other Features Available Other Features Available — External Gain - Refer to refer to the SA chapter’s section, “External Gain” on page 154. — Limit Lines - For information on using Limit Lines, refer to “All about Limit Lines”...
Page 284 IQ Analyzer (IQA) – Option 351 (CPU2 Only) Other Features Available Keysight N9927-90001 User’s Guide...
Page 285 Keysight Handheld Analyzers N99xxA User’s Guide 12 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) OTA mode measures signals at the SA RF Input Port 2 connector. OTA mode requires the FieldFox to have SA mode (Option 233 on combination analyzers), GPS (Option 307), and CPU2 installed.
Page 286 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) In this Chapter “Using OTA (Options 370 – LTE FDD and 377 – 5GTF)” on page 287 “About Over–the–Air (OTA) Measurements” on page 288 “LTE FDD Features (Option 370)” on page 288 —...
Page 287: Using Ota (Options 370 - Lte Fdd And 377 - 5Gtf)
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) Using OTA (Options 370 – LTE FDD and 377 – 5GTF) Using OTA (Options 370 – LTE FDD and 377 – 5GTF) OTA enables you to do the following: Measure and display one component carrier (CC) with multiple cells or multiple cells with multiple component carriers (CCs) Four Display Types:...
Page 288: About Over-The-Air (Ota) Measurements
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements About Over–the–Air (OTA) Measurements OTA mode supports these standards: — LTE FDD and — 5GTF measurements Some measurement parameters are auto-coupled and are not user-settable. LTE FDD Features (Option 370) IMPORTANT! LTE FDD and 5GTF only demodulate PSS and SSS signals using the FieldFox’s 10 MHz demodulation path.
Page 289 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements — Strip Chart – Magnitude of selectable cell scan result metric graphed over time Figure 12-1 Example of the LTE FDD with Four Multiple Display Options Keysight N9927-90001 User’s Guide...
Page 290 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements Figure 12-2 LTE FDD Bar Chart – CC Example Figure 12-3 LTE FDD Bar Chart – PCC Example Keysight N9927-90001 User’s Guide...
Page 291 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements Figure 12-4 LTE FDD Bar Chart – Level Example Figure 12-5 Example of the 5GTF with Four Multiple Display Options Keysight N9927-90001 User’s Guide...
Page 292: 5Gtf Features (Option 377)
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements 5GTF Features (Option 377) IMPORTANT! LTE FDD and 5GTF only demodulate PSS and SSS signals using the FieldFox’s 10 MHz demodulation path. User data channels are not demodulated.
Page 293 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) About Over–the–Air (OTA) Measurements Figure 12-6 Example of 5GTF Single Carrier and Single Cell Keysight N9927-90001 User’s Guide...
Page 294: How To Set Up Over-The-Air (Ota) Mode Settings
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings How to Set Up Over–the–Air (OTA) Mode Settings IMPORTANT! See also, “Alignments” on page 180, in NA mode,Chapter 9, “SA (Spectrum Analyzer) Mode,”...
Page 295 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings 2. Selecting OTA mode: — Press Mode_. — Then More (may not be available—number of installed options dependent) —...
Page 296 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings — Spectrum — Strip Chart The Spectrum view in 5GTF uses a center frequency that is +2.6 MHz offset from the carrier’s center frequency.
Page 297 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Then Sort Order and choose Down (Default: Auto). Refer to “About Over–the–Air (OTA) Measurements” on page 288. 10. Modify RF attenuator, Preamp, and other settings: Press Scale/Amptd >...
Page 298 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings than 900 Hz, no data is displayed. 5GTF: Default = 1%, i.e., if a carrier signal’s sync correlation is smaller than 1%, no data is displayed).
Page 299 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings ——Optional: Then Meas Interval > ON ——Then Interval Type > choose Time or Distance. ——Then, if applicable Time Interval enter time interval in seconds.
Page 300 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-7 Single cell selected, but other cells displayed when CC0 to CCn has been enabled. If ALL is selected, only the CC with the highest power is displayed. (Not all of the detected data is displayed.) Figure 12-8 Example of the LTE FDD Scan Results Table (Five CCs and one cell)
Page 301 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-9 Example of the 5GTF Scan Results Table (Two cc and one cell) Keysight N9927-90001 User’s Guide...
Page 302 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Additional LTE FDD Examples Figure 12-10 Example of LTE FDD with Single Carrier, Multiple Cell Sites, KPIs Keysight N9927-90001 User’s Guide...
Page 303 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-11 Example of LTE FDD with Multiple Carriers, Single Cell Site, and KPI’s Keysight N9927-90001 User’s Guide...
Page 304: Optional: Using Rtsa To Verify The Signal Quality
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Optional: Using RTSA to verify the signal quality (Requires Option 350 and Preamp Option 235) — Press Mode > RTSA —...
Page 305: How To Define A Cell Or Cell(S) And Use Ota
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings How to Define a Cell or Cell(s) and Use OTA LTE FDD and 5GTF have only one predefined view (Table). You can define measurements, which can be used to display up to four different views (windows) simultaneously on the display screen.
Page 306 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings — Set the System > System Configuration > Frequency Ref > Freq Ref Source [GPS] >Back — Set the GNSS (GPS+) >...
Page 307 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Repeat process as needed for additional Windows, Data, and CC settings. IMPORTANT! When you select a multiple CCs (e.g., CC0, CC1, etcetera) and record data, you may actually see other cell signals that do not have sufficient power to be displayed, but are still detectable.
Page 308: Step 2: Select Trace Type
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings — Press System > FrequencyRef > Internal > Back IMPORTANT! It is not sufficient to be locked to the GNSS satellite, the frequency reference must be locked to GPS.
Page 309: Step 3. Modify Scale And The Display Color Bar Settings
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-15 Spectrum and Strip Chart Display Type – 5GTF Step 3. Modify Scale and the Display Color Bar Settings To assign colors to low and high power values: 1.
Page 310: Step 4: Enable Recording And Record Data Logging Results
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-16 Outdoor Display Colors Figure 12-17 Indoor Display Colors Step 4: Enable Recording and Record Data Logging Results Spectrum and Strip Chart information is not recorded.
Page 311 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Features — Log files contain cell results for different component carriers (CCs) including timestamps and/or distance stamps. — Timestamps are included in log files with or without GPS. —...
Page 312: Save 5: Save The Log Results
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings 7. Press Back >Back Playing a Recorded Log and Viewing the Data To play the log results: 1. Press Playback >...
Page 313: Step 6: Import And Play Back Kml Files Into 3Rd Party Software (Example: Google Earth With Animation Tool)
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Else, edit the file name, under Settings > File Settings where the file results will be stored and set the File Overwrite settings.
Page 314 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up Over–the–Air (OTA) Mode Settings Figure 12-18 Importing a KML File Into Google Earth Keysight N9927-90001 User’s Guide...
Page 315: How To Set Up Emf Settings (Requires Emf (Option 358))
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) How to Set Up EMF Settings (Requires EMF (Option 358)) If OTA or SA mode does not detect an EMF Option 358 license, then the EMF application and the USB antenna’s axes must be set up manually.
Page 316 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) — Field Strength units: — dBµV/m – For use with E-field signals — dBµA/m – For use with H-field signals —...
Page 317 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) Figure 12-19 Example of EMF with Triaxial Antenna Keysight N9927-90001 User’s Guide...
Page 318: Emf Setup Procedure
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) EMF Setup Procedure When the USB antenna correction factors are imported, EMF (Option 358) couples many settings to ease setting up the EMF measurement (e.g., Apply Corrections is enabled, all X, Y, and Z antenna axes are enabled, and Amp Corr Select is set to TriAxial XYZ).
Page 319 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) — Then USB Antenna [Tri Axial] verify Tri Axial (default) is selected. — Optional: Press Antenna Axis the antenna axis should be set to Auto for default operation.
Page 320 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) 6. Verify EMF in 5G NR Mode: a. Press Mode > > 5G NR then b. Press Meas Setup 4 > More >...
Page 321 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Set Up EMF Settings (Requires EMF (Option 358)) Figure 12-21 Using SA Mode (Example) to Verify the Triaxial Values – Axis Y is Displayed Keysight N9927-90001 User’s Guide...
Page 322: How To Use Data Logging (Ota Options 370 And 377)
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Use Data Logging (OTA Options 370 and 377) How to Use Data Logging (OTA Options 370 and 377) Spectrum and Strip Chart information is not recorded. Only the Table data is saved.
Page 323: Data Logging Procedure
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Use Data Logging (OTA Options 370 and 377) When GPS is enabled, GPS R is indicated at the bottom of the FieldFox display. Learn more in “GNSS (GPS+) and GPS”...
Page 324: How To Playback
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) How to Use Data Logging (OTA Options 370 and 377) — Optional: Then Meas Interval > ON — Then Interval Type > choose Time or Distance. —...
Page 325: Other Features Available
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) Other Features Available — Play Start playback from trace 1. — Recall Logs Opens a list of stored data files. Select a file to playback. — Recall File —...
Page 326: Troubleshooting
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) Troubleshooting Troubleshooting If your OTA setup is not behaving as expected: — Verify setup is correct by referring to “How to Set Up Over–the–Air (OTA) Mode Settings” on page 294.
Page 327: Glossary (Ota)
Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) Glossary (OTA) Glossary (OTA) This section provides a description of some of the terms used in the FieldFox’s OTA mode. Table 12-1 OTA Abbreviations and Descriptions Abbreviation Description LTE FDD...
Page 328 Over–the–Air Measurements (OTA) – LTE FDD Option 370 and 5GTF Option 377 (CPU2 Only) Glossary (OTA) Keysight N9927-90001 User’s Guide...
Page 329 Keysight Handheld Analyzers N99xxA User’s Guide - Option 360 Phased Array Antenna 13 5G Rapid Prototype Phased Array Antenna – Option 360 IMPORTANT! 85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable for use in wet locations. PAA is compatible with the frequency converter heads, but cannot apply or edit the frequency head corrections.
Page 330 5G Rapid Prototype Phased Array Antenna – Option 360 “Phased Array Antenna Features (Option 360)” on page 332 — “How to Set Up Phased Array Antenna Settings” on page 341 “Option 360 Setup Procedure” on page 341 — “How to Define a Set Up a Scan and Use Option 360” on page 352 —...
Page 331: Using The Phased Array Antenna (Option 360)
5G Rapid Prototype Phased Array Antenna – Option 360 Using the Phased Array Antenna (Option 360) Using the Phased Array Antenna (Option 360) Option 360 enables you to do the following: Measure and display phased array antenna elevation and azimuth Four Display Types: —...
Page 332: About Phased Array Antenna Measurements
5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements About Phased Array Antenna Measurements Some measurement parameters are auto-coupled and are not user-settable. Phased Array Antenna Features (Option 360) IMPORTANT! Option 360 antenna requires a static IP address. If it is required to have available an IP address that can be accessed over your company’s network, work with your company’s IT team to set up a static IP that works over the network.
Page 333 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 1 Example of local point-to-point LAN connection Tripod not included. Keysight N9927-90001 User’s Guide...
Page 334 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 2 Bore-Sight Scan – CW RF Figure 3 Polar Scan with compass displayed Keysight N9927-90001 User’s Guide...
Page 335 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 4 Heat Map (Azimuth vs. Elevation) - Parked Antenna Keysight N9927-90001 User’s Guide...
Page 336 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 5 Heat Map and Undocked Active Entry – Parked Antenna Scan elevation angles ±90 degrees and azimuth ±60 degrees Keysight N9927-90001 User’s Guide...
Page 337 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 6 Polar Assign Orientation and Polar with Compass Orientation Keysight N9927-90001 User’s Guide...
Page 338 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 7 Polar Measurement with Compass with Recalled Image of Indoor Auditorium Keysight N9927-90001 User’s Guide...
Page 339 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements CW vs. Pulsed RF Measurements IMPORTANT! For pulsed RF measurements, increasing the Dwell Time is recommended for faster throughput and accurate signal capture in a single sweep.
Page 340 5G Rapid Prototype Phased Array Antenna – Option 360 About Phased Array Antenna Measurements Figure 8 Bore-Site Measurement with Pulsed RF (Dwell Time=10 ms, Max Hold=OFF) Figure 9 Bore-Site Measurement with Pulsed RF (Dwell Time=100 ms, Max Hold=OFF) Keysight N9927-90001 User’s Guide...
Page 341: How To Set Up Phased Array Antenna Settings
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings How to Set Up Phased Array Antenna Settings IMPORTANT! See also, “Alignments” on page 180, in NA mode,Chapter 9, “SA (Spectrum Analyzer) Mode,” Chapter 10, “RTSA (Real-Time Spectrum Analyzer) Mode—Option 350 (CPU2 Only)”...
Page 342 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings c. Press Done Edit > Done IMPORTANT! The LAN address for first 3 fields must match the Static IP address of FieldFox. For example, if the Ball Antenna IP address is 192.168.1.10, set FieldFox Static IP address to 192.168.1.xx.
Page 343 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Figure 12 Site Wide LAN Configurations and Field Measurements Configurations Keysight N9927-90001 User’s Guide...
Page 344 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Figure 13 Site Wide LAN Configurations and Field Measurements Configurations Azimuth and Elevation Alignment Orientation Diagram Keysight N9927-90001 User’s Guide...
Page 345 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings 5. Entering the phased array antenna measurement type: Refer to “Data Formats:” on page 332. Select Measure: — Measure—choose: — Bore-Sight — Heat Map —...
Page 346 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — Clear Graphics If applicable, this clears the current displayed PNG graphic from the screen. If after making the setting changes in the steps below, no data is displayed, refer to “Troubleshooting”...
Page 347 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Record-Play files are saved to: Record-Play files are save-recalled to: —— "[CurrentDevice]\RecordPlayback\PAA\" Learn more about file settings, refer to Chapter 31, “File Management.” —...
Page 348 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings 11. Select Trace 6—choose: For this step, refer to Figure 6 on page 337. — Polar Size Max Med Min Sets the size of the polar display. Smaller sizes used to overlay PNG maps.
Page 349 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Learn more, refer to Chapter 9, “SA (Spectrum Analyzer) Mode.” — Restart 14. Optional: choose devices and save files: Press Save/Recall Then choose: —...
Page 350 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Figure 14 Example of Phased Array Antenna and FieldFox Static IP Setup - First Three Static IP Fields Are the Same Setting the phased array antenna IP address Setting the FieldFox static IP address - First three fields the same as the antenna Keysight N9927-90001 User’s Guide...
Page 351 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings Figure 15 Example Antenna Settings Table Keysight N9927-90001 User’s Guide...
Page 352: How To Define A Set Up A Scan And Use Option 360
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings How to Define a Set Up a Scan and Use Option You can define measurements by selecting which type of data to display. Data definitions consist of the following: —...
Page 353: Step 3. Define The Measurement
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — Then System Configuration > More > 1. In the Setting screen, use the arrows, the rotary knob, or numeric keypad to highlight Obtain IP. 2.
Page 354 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — Array Antenna: Center frequency, Azimuth Ref, and Elevation — Polar Display: Ref See also “How to Set Up Phased Array Antenna Settings” on page 341.
Page 355: Step 4: Select Polar Settings
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — Max Hold For pulsed RF measurements, it is recommended that Max Hold is set to OFF when using the Heat Map display. (Default = OFF) IMPORTANT! It is not sufficient to be locked to the GNSS satellite, the frequency reference must be locked to GPS.
Page 356: Step 6: Enable Recording And Record Data Logging Results
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — Edit Cable — — Save Cable — Recall Cable — Storage Device 2. Press Scale/Amptd then choose: — Autoscale — Unit dBm —...
Page 357 5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings — When done, press Back 3. Press Save Recall Rec-Playback > File Type CSV, DREC, or KLM (Default: KLM) Three file types are supported for save or recall log results: —...
Page 358: Step 7: Import And Play Back Kml Files Into 3Rd Party Software (Example: Google Earth With Animation Tool)
5G Rapid Prototype Phased Array Antenna – Option 360 How to Set Up Phased Array Antenna Settings 3. Press Stop to exit the log playing. To pause the log play: 1. Press Pause Resume to pause or resume the log playing. 2.
Page 359: How To Record/Playback (Option 360)
5G Rapid Prototype Phased Array Antenna – Option 360 How to Record/Playback (Option 360) How to Record/Playback (Option 360) Record-Play files are saved to: — Record-Play files are save-recalled to: "[CurrentDevice]\RecordPlayback\PAA\" Record Playback allows you to record phased array antenna trace data and play them back at a later time.
Page 360: G Rapid Prototype Phased Array Antenna - Option
5G Rapid Prototype Phased Array Antenna – Option 360 How to Record/Playback (Option 360) Figure 17 Field Strength Annotation that can be Recorded and Played Back If Recording or Playback is not occurring when you think it should, check the following: —...
Page 361: To Change Recording Configuration Settings
5G Rapid Prototype Phased Array Antenna – Option 360 How to Record/Playback (Option 360) — Then Record is displayed in the left of screen graticules. During recording, choose from the following: — Pause Resume Temporarily halts recording until pressed again. The incoming trace continues to sweep.
Page 362 5G Rapid Prototype Phased Array Antenna – Option 360 How to Record/Playback (Option 360) — Then Data Logging > Save Recall Rec-Playback If these are large recordings on a device, it could take several seconds for the FieldFox to display the list. —...
Page 363: Other Features Available
5G Rapid Prototype Phased Array Antenna – Option 360 Other Features Available Other Features Available — Alignments - For information on using alignments, refer to the SA chapter’s section, “Alignments” on page 180. — Scale Settings – For information on using scale settings, refer to the Data Analysis chapter’s section, “All about Scale Settings”...
Page 364: Troubleshooting
5G Rapid Prototype Phased Array Antenna – Option 360 Troubleshooting Troubleshooting If your Phased Array Antenna setup is not behaving as expected: — Verify setup is correct by referring to “How to Set Up Phased Array Antenna Settings” on page 341.
Page 365: Usb Antennas - (Full Capability Requires Emf Option 358, And Sa Mode (Option 233 Mixed Analyzers))
Keysight Handheld Analyzers N99xxA User’s Guide 14 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) Triaxial USB antennas can be used without EMF Option 358, but with limited capability and doing so is not recommended or supported by Keysight.
Page 366 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) — Triaxial antenna performance verification showing bore sight, polar antenna pattern with compass, heat map and beam sweep to map display views — Measure and display corrected field strength in RMS average power —...
Page 367 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) In this Chapter “Using USB Antennas” on page 368 “About USB Antenna Measurements” on page 369 “USB Antenna Features” on page 369 — “How to Set Up a USB Antenna” on page 371 “USB Antenna Setup Procedure”...
Page 368: Using Usb Antennas
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) Using USB Antennas Using USB Antennas Triaxial USB antennas can be used without EMF Option 358, but with limited capability and doing so is not recommended by Keysight. USB antennas enables you to do the following: Measures electro-magnetic fields (EMF) for radio frequencies in proximity of radio and television stations, and repeaters for cell phones...
Page 369: About Usb Antenna Measurements
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) About USB Antenna Measurements About USB Antenna Measurements USB antenna feature supports these standards: — — OTA — 5G NR Some measurement parameters are auto-coupled and are not user-settable. USB Antenna Features For more information on the SDIA-6000 Triaxial Lsotropic Antenna, refer to http://en.agos.co.kr/emf_measurement.do.
Page 370 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) About USB Antenna Measurements Figure 14-3 Example Verifying the Triaxial Values – Axis Y is Displayed Keysight N9927-90001 User’s Guide...
Page 371: How To Set Up A Usb Antenna
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) How to Set Up a USB Antenna How to Set Up a USB Antenna IMPORTANT! See also, “Alignments” on page 180, in NA mode,Chapter 9, “SA (Spectrum Analyzer) Mode,”...
Page 372 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) How to Set Up a USB Antenna — Then Import Antenna – to import the antenna factors from the USB antenna connected to the FieldFox. If the antenna factor import is successful, the FieldFox displays: "Success: Antenna Factors Imported: Tri-Ax Antenna ID: ->[R] Antenna ID: SDIA-6000-1006 ->[]".
Page 373 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) How to Set Up a USB Antenna Figure 14-4 Example Summing of Triaxial Values Figure 14-5 Example Verifying EMF Keysight N9927-90001 User’s Guide...
Page 374 USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) How to Set Up a USB Antenna Editing Antenna Correction Factors and Adding New Antenna Factors Keysight does not recommend editing a USB antenna’s correction factors. If New is selected under the X, Y, or Z Antenna or Cable softkey menu, whatever antenna or cable factors that have been imported as the default values and are displayed in the Settings table.
Page 375: Other Features Available
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) Other Features Available Other Features Available — Alignments - For information on using alignments, refer to the SA chapter’s section, “Alignments” on page 180. —...
Page 376: Troubleshooting
USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)) Troubleshooting Troubleshooting If your USB antenna setup is not behaving as expected: — Verify setup is correct by referring to “How to Set Up a USB Antenna” on page 371.
Page 377: On-The-Box Mapping - Option 352 (Requires Spectrum Analyzer Mode (Option 233 On N991Xb), Gps (Option 307) And Gps Receiver (Option 307))
Keysight Handheld Analyzers N99xxA User’s Guide 15 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) IMPORTANT! 85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable for use in wet locations. B Model FieldFoxes measurements require an OML head .
Page 378 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Using a direct wired LAN connection, FieldFox will automatically access OSM once location coordinates (latitude and longitude) and zoom levels are entered the Map Explorer menu.
Page 379 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) In this Chapter “How to Install Node.js and Running the FieldFox Mapping Software” on page 382 “Downloading and Using the FieldFox Map Support Tool” on page 384 “Importing a .zip File to the FieldFox”...
Page 380 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Option 352 enables you to do the following: Measure and display indoor and outdoor mapping Two Mapping Types: — Indoor Maps —...
Page 381 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Figure 15-2 Maps With Current Position Marker Displayed - (Open Street Maps) Figure 15-3 Using Mapping (Option 352) - Satellite View for Indoor Mapping Keysight N9927-90001 User’s Guide...
Page 382: How To Install Node.js And Running The Fieldfox Mapping Software
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Install Node.js and Running the FieldFox Mapping Software How to Install Node.js and Running the FieldFox Mapping Software IMPORTANT! If your FieldFox is connected directly to the LAN, you can skip the section on downloading Node.js and go to “How to Set Up Mapping...
Page 383 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Install Node.js and Running the FieldFox Mapping Software Figure 15-4 Downloading the Node.js Installer to a PC Figure 15-5 Default Download Path for Node.js Installer to a PC IMPORTANT! Do not change path.
Page 384: Downloading And Using The Fieldfox Map Support Tool
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Downloading and Using the FieldFox Map Support Tool Downloading and Using the FieldFox Map Support Tool 1. Download the FieldFox Mapping software ("FFMapSupportInstall.msi") to a PC’s Downloads folder.
Page 385 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Downloading and Using the FieldFox Map Support Tool Figure 15-7 Command Window Opens With Address Copied to Clipboard 4. If you FieldFox is connected directly to the LAN, begin here: Select Draw An Area to map and download the selected area: For this step and sub-steps, refer to Figure 15-8 on page...
Page 386 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Downloading and Using the FieldFox Map Support Tool — To select Zoom levels, click the zoom boxes. — The more Zoom levels checked, the more map images that have to be saved and it will take longer to download the images.
Page 387 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Downloading and Using the FieldFox Map Support Tool 5. Saving your *.zip file to a storage device and importing your *.zip to the FieldFox: Using FTP with FieldFox FieldFox Programming...
Page 388: Importing A .Zip File To The Fieldfox
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Importing a .zip File to the FieldFox Importing a .zip File to the FieldFox For FTP, refer to Using FTP with FieldFox and to the FieldFox Programming Guide...
Page 389 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Importing a .zip File to the FieldFox Figure 15-11 Example of Maps Folder Containing Imported Maps *.zip Files to the FieldFox’s InternalSD\UserData\Maps Folder Keysight N9927-90001 User’s Guide...
Page 390: How To Set Up Mapping Settings
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings How to Set Up Mapping Settings IMPORTANT! See also, “Alignments” on page 180, in SA mode. This section reviews the steps in setting up an Option 352 Mapping measurement.
Page 391 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Display a Map File 1. Press System 7 > Utilities > Mapping > Map Explorer (Get Maps) 2.
Page 392: Option 352 Indoor Maps Setup Procedure
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Option 352 Indoor Maps Setup Procedure 1. Set up your measurements in Channel Scanner, OTA, or Phased Array Antenna.
Page 393 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings — Press Auto Save On > then Back, to exit the Record Playback menu.
Page 394 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Figure 15-15 Example of an Indoor Building Map with Pointer Keysight N9927-90001 User’s Guide...
Page 395: Option 352 Outdoor Maps Setup Procedure
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Option 352 Outdoor Maps Setup Procedure Outdoor mapping requires GPS Option 307. Saving and importing maps can be done now or after the outdoor map locations have been measured.
Page 396 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings — Then use the arrows, the rotary knob, or numeric keypad locate the position cursor to current location.
Page 397 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Figure 15-16 Example of England Displayed Text Import ZIP file using FieldFox Map Support Tool with Do Import softkey 3.
Page 398 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings — For setting up a USB antenna, refer to Chapter 14, “USB Antennas – (Full Capability Requires EMF Option 358, and SA mode (Option 233 Mixed Analyzers)).”...
Page 399 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Figure 15-17 Using Maps Explorer to Set the Red and Blue Power Limits c.
Page 400 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings d. Save results to KML file. 9. View KML with map tools. — On the FieldFox, see the data results overlaying open street map pictures.
Page 401 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Figure 15-20 FieldFox Display with View Map ON and OFF Displayed Import and Play back KML Files into 3rd Party Software (Example: Google Earth with Animation Tool) Features Use the Playback Slider to replay measurement results.
Page 402 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings — Open the FieldFox *.KML file in Google Earth. The time slider appears in upper left of the map.
Page 403: Setting Up Data Logging
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings Setting up Data Logging — Enable the Data Logging settings: — Press Trace 6 —...
Page 404 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Set Up Mapping Settings ——The Save the log file menu opens. Edit the filename and press Done to exit menu. See Settings below and “To change Recording Configuration settings:”...
Page 405: How To Record/Playback (Option 352)
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Record/Playback (Option 352) How to Record/Playback (Option 352) Record-Play files are saved to: — Record-Play files are save-recalled to: "[CurrentDevice]\ RecordPlayback\Maps \"...
Page 406: How To Record
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Record/Playback (Option 352) Figure 15-22 Field Strength Annotation that can be Recorded and Played Back If Recording or Playback is not occurring when you think it should, check the following: —...
Page 407: To Change Recording Configuration Settings
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Record/Playback (Option 352) — Then Record is displayed in the left of screen graticules. During recording, choose from the following: —...
Page 408 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) How to Record/Playback (Option 352) — Then Data Logging > Save Recall Rec-Playback If these are large recordings on a device, it could take several seconds for the FieldFox to display the list.
Page 409: Other Features Available
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Other Features Available Other Features Available — Alignments - For information on using alignments, refer to the SA chapter’s section, “Alignments”...
Page 410: Troubleshooting
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Troubleshooting Troubleshooting If your Mapping setup is not behaving as expected: — Verify setup is correct by referring to “How to Set Up Mapping Settings”...
Page 411 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Troubleshooting Refer to Figure 15-23. Figure 15-23 Example of "This port...because 5000 is in use." Error If the Map Support Tool displays the error shown in Figure 15-23, it means the selected map area is outside the current viewable area.
Page 412 On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on N991xB), GPS (Option 307) and GPS Receiver (Option 307)) Troubleshooting Keysight N9927-90001 User’s Guide...
Page 413 Keysight Handheld Analyzers N99xxA User’s Guide 16 Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) Remote server mode enables you to connect your FieldFox to compatible PC-based licensed software applications (e.g., 89600 VSA software ). Refer to http://www.keysight.com/find/assist. 89600 VSA (via the Remote Server feature) is compatible with the frequency converter heads, but cannot apply or edit the frequency head corrections.
Page 414 Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) FieldFox with a Remote Server mode (available with FieldFox firmware ≥A.10.00) does not display a mode softkey, because Remote Server mode is only enabled when you have a SA Option 233 on the FieldFox, compatible 89600 VSA software license loaded and running on a remote PC, and connected via LAN to your FieldFox.
Page 415: Remote Server Mode (Requires Cpu2 And Sa Hardware/Sa Option 233) In This Chapter
Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) In this Chapter: In this Chapter: “Connecting Using Remote Server” on page 416 “89600 VSA Software Overview (Requires CPU2 and N991xA/3x/A5x/A6xA and SA Option 233)” on page 418 See Also Optional Settings: “LAN Settings”...
Page 416: Connecting Using Remote Server
Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) Connecting Using Remote Server Connecting Using Remote Server IMPORTANT! When using a frequency converter head with remote server and 89600A VSA software, first verify the head has been selected in SA mode, before connecting to the VSA using IO Libraries.
Page 417: Changing Frequency Converter Head Settings
Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) Connecting Using Remote Server Figure 16-2 FieldFox Display When Remotely Connected to a PC-based Software The graphic above shows the FieldFox successfully connected to a PC—with an example hostname "PC123"—and to a compatible licensed PC-based software.
Page 418: 89600 Vsa Software Overview (Requires Cpu2 And N991Xa/3X/A5X/A6Xa And Sa Option 233)
Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) 89600 VSA Software Overview (Requires CPU2 and N991xA/3x/A5x/A6xA and SA Option 233) 89600 VSA Software Overview (Requires CPU2 and N991xA/3x/A5x/A6xA and SA Option 233) IMPORTANT! The following is a description of the 89600 VSA Software’s overall capabilities.
Page 419 Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) 89600 VSA Software Overview (Requires CPU2 and N991xA/3x/A5x/A6xA and SA Option 233) — Easy-to-use Microsoft Windows graphical user interface For a comprehensive FieldFox VSA mode help, refer to http://rfmw.em.keysight.com/wireless/helpfiles/89600B/WebHelp/89600.ht For additional information on the 89600 VSA Software brochure, refer to http://literature.cdn.keysight.com/litweb/pdf/5990-6553EN.pdf For Technical Overview, refer to http://literature.cdn.keysight.com/litweb/pdf/5990-6405EN.pdf...
Page 420 Remote Server Mode (Requires CPU2 and SA Hardware/SA Option 233) 89600 VSA Software Overview (Requires CPU2 and N991xA/3x/A5x/A6xA and SA Option 233) Keysight N9927-90001 User’s Guide...
Page 421 Keysight Handheld Analyzers N99xxA User’s Guide 17 Interference Analyzer (SA Mode) – Option 236 Option 236 provides Spectrogram display, Waterfall display, and Record/Playback. In this Chapter “Spectrogram Display (SA Option)” on page 422 “Common Settings for Waterfall and Spectrogram” on page 424 “Waterfall Display”...
Page 422: Spectrogram And Waterfall Displays
Interference Analyzer (SA Mode) – Option 236 Spectrogram and Waterfall Displays Spectrogram and Waterfall Displays Spectrogram and Waterfall displays provide a visual history of the measured spectrum. Each display type can be used to locate intermittent signals or to view signal levels and frequencies over time. Spectrogram is a single horizontal line of color-coded power while Waterfall uses a 3-D color-coded display.
Page 423 Interference Analyzer (SA Mode) – Option 236 Spectrogram and Waterfall Displays — Resolution (Number of Points). Learn more in “Points ” on page 177. How to select Spectrogram — Press Meas 1 — Then Interference Analysis — Then Spectrogram How to modify the Spectrogram You can change how the spectrogram is displayed relative to the data trace.
Page 424: Common Settings For Waterfall And Spectrogram
Interference Analyzer (SA Mode) – Option 236 Spectrogram and Waterfall Displays — At the current sweep speed, the difference in time between these two markers appears at the upper-right corner of the view as Delta Time: hh:mm:ss Sec. — An invalid number (very large positive or negative) appears when a trace record is not available at either marker.
Page 425: Waterfall Display
Interference Analyzer (SA Mode) – Option 236 Spectrogram and Waterfall Displays Averaging Averaging can be enabled on the underlying measurement. Press Meas 4 then Average Type. Learn more in “Average Type” on page 179. Mode Preset Mode Preset resets ONLY the Spectrogram and Waterfall display settings. It does not reset the measurement settings.
Page 426 Interference Analyzer (SA Mode) – Option 236 Spectrogram and Waterfall Displays — Resolution (Number of Points). Learn more in “Points ” on page 177. Waterfall Angle This setting allows you to show more or less detail. More detail provides fewer (time) records.
Page 427: Record/Playback (Sa Option)
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) Record/Playback (SA Option) Record Playback allows you to record SA trace sweeps and play them back at a later time. Use this feature to monitor spectrum activity over a period of time. You can record traces continuously, record a specified number of traces (segments), or record when triggered by a specified power level.
Page 428: Fieldfox Setting Changes During Record And Playback
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) To view and edit the maximum number of records Just after opening or initiating a session... — Press Session Data — Then TraceRecordLimit <n> (n = Max number of traces that can be recorded).
Page 429: About State And User Tags
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) Other display settings, such as Scale and acquisition, can also be changed during recording but are not saved with the session file. Think of these as settings that help YOU see the recording and playback activity. They do NOT change the data that is recorded.
Page 430: How To Record A Session
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) — AutoSession is an auto-generated name for sessions. is the auto-generated number, incremented with each new session. The name can be changed using Manage Sessions. Learn more in “Manage Sessions” on page 435.
Page 431: How To Playback A Session
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) — Press Play to start replaying the recording from the beginning. — Press Record to continue recording. How to Playback a Session — Press Trace 6 — If the session is already open, skip the following step. Otherwise: —...
Page 432 Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) — Press Trace 6 — Then Record Playback — Then New Session Recall an existing session. New Session is selected: — Then Session Data and choose one of the following: —...
Page 433: Frequency Mask Trigger Configuration (Sa Mode Only)
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) When set, a counter appears in the lower-left corner which counts UP to the specified number of recordings. — FreqMaskTrigger OFF ON Sets the power level which will trigger a recording. Set these power levels (mask) exactly as you would set Limit Lines.
Page 434: Record Source
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) Although they are created in the same manner, Limit Line files and FreqMask files can NOT be used interchangeably. — Press Trace 6 — Then Record Playback — Then New Session Recall an existing session.
Page 435: Playback Configuration
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) SA Data Recording: — Data can be recorded at the Raw Meas block where data is acquired after ResBW, VideoBW, and Detector processing, but before any trace state processing. — Data can be recorded from Traces 1,2,3, or 4 which includes the trace state (Max Hold, Min Hold, and so forth).
Page 436: Record Playback Example (Sa Only)
Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) — Then Record Playback SetupThe following selections are available ONLY when a session is NOT open. — Then Storage Device to select the media which stores the sessions to be managed.
Page 437 Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) — Then Record At the end of each 10 second record interval, the Max Hold trace is recorded and the Max Hold processing is reset for the next 10 second record interval. —...
Page 438 Interference Analyzer (SA Mode) – Option 236 Record/Playback (SA Option) Keysight N9927-90001 User’s Guide...
Page 439: Reflection Mode (Sa Models) - Option
Keysight Handheld Analyzers N99xxA User’s Guide 18 Reflection Mode (SA Models) - Option 320 Option 320 requires Option 220 Tracking Generator. N9938A models require Option 100 3.5 mm connectors and Option 220. Option 100 3.5 mm connectors must be installed by the factory. Option —...
Page 440 Reflection Mode (SA Models) - Option 320 SA mode reflection measurements are CalReady. Learn more in “CalReady” on page 123. In addition, Normalization is available. Learn how “Normalize” on page 442. However, other calibration types are NOT offered. In this Chapter “How to select Reflection Mode”...
Page 441 Reflection Mode (SA Models) - Option 320 The following settings are available exactly as they function in CAT mode: “Frequency Range” on page 49 “Scale Settings” on page 49 “Averaging” on page 50 “Single or Continuous Measure” on page 51 “Resolution (Number of Data Points)”...
Page 442: Reflection Mode Settings
Reflection Mode (SA Models) - Option 320 Reflection Mode Settings Reflection Mode Settings Select Reflection Mode before making any setting in this chapter. How to select Reflection Mode — Press Mode — Then Reflection Measurement Selection How to select a Reflection Mode Measurement Learn more about these two measurements in the Supplemental Online Help: http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm —...
Page 443 Reflection Mode (SA Models) - Option 320 Reflection Mode Settings — Press Trace 6 — Then Normalize The yellow data trace displays the current measurement with trace math applied. The math operation symbol [D/M] is displayed on the lower left corner of the screen.
Page 444 Reflection Mode (SA Models) - Option 320 Reflection Mode Settings Keysight N9927-90001 User’s Guide...
Page 445: Built-In Power Meter Mode - Option
Keysight Handheld Analyzers N99xxA User’s Guide 19 Built-in Power Meter Mode – Option 310 Built-in Power Meter (also known as Channel Power Meter) uses the SA input connector to make quick and simple power measurements over a selectable frequency band. A power sensor is NOT required. In this Chapter “Frequency/ Span / Step”...
Page 446 Built-in Power Meter Mode – Option 310 “Limits” on page 458 The following Built-in Power Meter settings are identical to SA Mode settings: “Radio Standard” on page 448 “How to Access Individual Alignments” on page 185 Keysight N9927-90001 User’s Guide...
Page 447: Built-In Power Meter Settings
Built-in Power Meter Mode – Option 310 Built-in Power Meter Settings Built-in Power Meter Settings Select Built-in Power Meter Mode before making any setting in this section. How to select Built-in Power Meter Mode — Press Mode — Then More —...
Page 448: Attenuation
Built-in Power Meter Mode – Option 310 Built-in Power Meter Settings Radio Standard A Radio Standard can used to integrate power within specific radio channels. When a Radio Standard is selected, the Span setting is automatically coupled to the defined Channel Width for that standard. (Width is the same for all channels within a standard.) Also, Unit is set to Chan, and CF is set to the nearest specific Channel defined in the standard.
Page 449: Power Meter (Usb) Mode - Option
Keysight Handheld Analyzers N99xxA User’s Guide 20 Power Meter (USB) Mode - Option 302 Power Meter measurements, available with Option 302, are made with Keysight USB power sensors. Power readings are displayed on the FieldFox screen. In this Chapter “Supported Power Sensors” on page 451 “How to Connect the Power Sensor”...
Page 450 Power Meter (USB) Mode - Option 302 “Step Detection Mode” on page 458 “Limits” on page 458 See Also “FOPS Settings” on page 463 Keysight N9927-90001 User’s Guide...
Page 451: Supported Power Sensors
Power Meter (USB) Mode - Option 302 Supported Power Sensors For a complete list of supported Keysight USB Power Sensors, please visit: www.keysight.com/find/usbsensorsforfieldfox The FieldFox does NOT support the following Keysight USB Power Sensor features: External Triggering (Time Gated Burst Power Measurement), Power Sweep Operation, and Frequency Sweep Operation.
Page 452 Power Meter (USB) Mode - Option 302 — No light indicates the FieldFox is not communicating with the power sensor. This is the case when in Hold mode or when NOT in Power Meter Mode. Keysight N9927-90001 User’s Guide...
Page 453: Usb Power Meter Settings
Power Meter (USB) Mode - Option 302 USB Power Meter Settings USB Power Meter Settings Select Power Meter Mode before making any setting in this section. How to select Power Meter Mode — Press Mode_. — Then Power Meter (USB Sensor).
Page 454: Frequency
Power Meter (USB) Mode - Option 302 USB Power Meter Settings In addition, once External Zeroing has started, the power source must be OFF for the entire time that the Zeroing message is present. Otherwise, the calibration will be compromised but NO warning is shown. Frequency A table of correction factors versus frequency is stored within Keysight Power Sensors.
Page 455 Power Meter (USB) Mode - Option 302 USB Power Meter Settings — Then Advanced When Option 208 (FOPS) is enabled, to access Source Control, press Sweep 3, then Power Setup Learn more about FOPS beginning on page Chapter 21, “Frequency Offset Using Power Sensor (FOPS) – Option 208”, on page 459 —...
Page 456: Relative And Offset Power Measurements
Power Meter (USB) Mode - Option 302 USB Power Meter Settings Relative and Offset Power Measurements Power measurements can be made that are relative to another reading or that are offset by a fixed value. — Use Relative to measure the difference between power levels. —...
Page 457: Averaging
Power Meter (USB) Mode - Option 302 USB Power Meter Settings How to set Resolution — Press Scale / Amptd. — Then More. — Then, in Resolution, choose from 0, 1, 2, or 3. Averaging Averaging is used to improve measurement accuracy in low power or noisy power situations.
Page 458: Step Detection Mode
Power Meter (USB) Mode - Option 302 USB Power Meter Settings You can also use Run / Hold +/- to toggle between Single and Continuous. Step Detection Mode The FieldFox supports the Step Detection feature that is present in Keysight USB power sensors.
Page 459: 21 Frequency Offset Using Power Sensor (Fops) - Option
Keysight Handheld Analyzers N99xxA User’s Guide 21 Frequency Offset Using Power Sensor (FOPS) – Option FOPS is accessed through (and requires) Option 302 USB Power Meter Mode. With both options installed, you can send a signal with the FieldFox internal source at one frequency, and measure this signal with a Keysight U-Series USB Power Sensor at another frequency.
Page 460 Frequency Offset Using Power Sensor (FOPS) – Option 208 “Amplitude Markers” on page 467 “Trace Math” on page 467 See Also “All about Scale Settings” on page 620 Keysight N9927-90001 User’s Guide...
Page 461: Overview
Frequency Offset Using Power Sensor (FOPS) – Option 208 Overview Overview This feature allows the FieldFox source frequency to be set independently from the power sensor (receiver) frequency. With frequency offset using power sensor (FOPS), the frequency of both the source and receiver are swept, and the two track each other.
Page 462 Frequency Offset Using Power Sensor (FOPS) – Option 208 Overview The dynamic range with FOPS may be significantly different when using various power sensors. In general, the lower frequency range sensors have better dynamic range. Keysight N9927-90001 User’s Guide...
Page 463: Fops Settings
Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings FOPS Settings The following settings are unique to FOPS. Standard USB Power Meter mode settings, which may be useful with FOPS, are documented in that chapter starting in “USB Power Meter Settings” on page 453 Select Power Meter (USB Sensor) before making any setting in this section.
Page 464: Sweep Type And Frequency
Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings — Gain Not available until source data is stored into memory. Displays the Output power / Source power (memory trace). — Rx Power Displays the raw received power at the USB power sensor. Sweep Type and Frequency Set the source and receiver frequencies for the FOPS measurements.
Page 465 Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings ——Then Freq Display. This determines how the receiver frequencies below the graticules are displayed. Choose from the following: ——Start Annotated as Start and Stop frequencies. ——Center Annotated as Center and Span frequencies. ——Then choose from the following two methods to determine the offset frequency (the frequency that the receiver is offset from the source).
Page 466: Power Sensor Settling
Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings Src = 2 GHz to 3 GHz Offset = 3.8 GHz Rx = 5.8 GHz to 6.8 GHz Power Sensor Settling The following two settings work together to allow you to choose the right compromise between measurement speed and accuracy.
Page 467: Amplitude Markers
Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings — Num Points Freq Step Size Both settings control the number of power sensor measurements between the Start and Stop frequencies. Enter one setting and the other will be changed automatically. There must be at least two data points.
Page 468 Frequency Offset Using Power Sensor (FOPS) – Option 208 FOPS Settings 3. View Data & Memory 4. Meas Src Power. Keysight N9927-90001 User’s Guide...
Page 469: Pulse Measurements Mode - Option
Keysight Handheld Analyzers N99xxA User’s Guide 22 Pulse Measurements Mode – Option 330 Pulsed power meter measurements, available with Option 330, are made with Keysight U2020 X-Series USB Peak Power Sensors. These sensors are capable of detecting, measuring, and storing data from a train of pulses at the RF input. This data is queried from the USB Power Sensor and displayed on the FieldFox screen.
Page 470 Pulse Measurements Mode – Option 330 “Triggering” on page 476 “Marker Settings” on page 479 “Amplitude Markers” on page 480 “How to Search with Markers” on page 480 “How to enable Auto Analysis” on page 482 “Pulse Top” on page 482 “Grid”...
Page 471: Supported Power Sensors
Pulse Measurements Mode – Option 330 Supported Power Sensors Supported Power Sensors Pulse measurements are made using any of the Keysight U2020 X-Series USB Peak Power Sensors. Zeroing of the U2020 X-Series USB Peak Power Sensors is performed automatically at power up, every 5 seconds, and prior to measuring low level signals.
Page 472: Pulse Measurement Settings
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Pulse Measurement Settings Select Pulse Measurement Mode before making any setting in this section. How to select Pulse Measurement Mode — Press Mode — Then More if your FieldFox contains more than five measurement modes. —...
Page 473: Zoom Window
Pulse Measurements Mode – Option 330 Pulse Measurement Settings — Frequency Sets the center frequency of the carrier on which pulse modulation resides. This is used to set amplitude correction of the USB Power Sensor. How to set Time Specify the time over which data will be acquired by the USB Power Sensor. When Trace Graph is selected, Tr 1 is annotated with these values.
Page 474: Scale
Pulse Measurements Mode – Option 330 Pulse Measurement Settings — Zoom Time/div While monitoring the blue vertical posts on the primary trace, enter a value for the zoom window span using the numeric keypad, the ?|? arrows, or the rotary knob. —...
Page 475: Video Bandwidth
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Annotation in the left pane shows the state of the Average setting. When Manual is selected, the ‘Num of Averages’ is setting is also shown. How to set Averaging — Press BW 2. —...
Page 476: Resolution
Pulse Measurements Mode – Option 330 Pulse Measurement Settings How to set Single or Continuous — Press Sweep 3 — Then choose one of the following: — Single Automatically sets Continuous OFF and causes the FieldFox to query the USB Power Sensor ONCE, then hold for the next Single key press.
Page 477 Pulse Measurements Mode – Option 330 Pulse Measurement Settings — Then Trig Type — Then choose from the following: — Freerun The USB Power Sensor acquires data without waiting for a trigger. This mode is NOT supported for Trace Graph measurements. —...
Page 478 Pulse Measurements Mode – Option 330 Pulse Measurement Settings — Then Auto Trigger — Then choose from the following: — Trigger level is determined by the USB Power Sensor firmware. — The trigger level is set manually using the Trigger Level setting. Trigger Level Used when Trigger Type = Internal AND Auto Trigger = OFF (Manual).
Page 479: Marker Settings
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Trigger Settings Annotation Trigger settings are annotated on the FieldFox screen as highlighted in the following image: In the previous graphic, the settings are: Trig Level = -10 dBm, Trig Type (Int), Pos Slope (/), Delay Marker Settings Markers are not allowed with Meter-style measurements.
Page 480: Amplitude Markers
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Amplitude Markers Amplitude markers are horizontal dotted lines that you can move to any amplitude level on the screen. The two amplitude markers can be set independently or used as a pair of delta markers. Amplitude markers can be used as a visual comparison aid with the pulse measurement traces.
Page 481: Auto Analysis
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Then choose from the following: — Target, Peak, and Minimum. Learn more about these standard features beginning in “Searching with Markers” on page 604. — Rise Time Select, then set a value in dB. Delta markers are created and placed at the Peak and at the specified value BEFORE the Peak.
Page 482: Pulse Top
Pulse Measurements Mode – Option 330 Pulse Measurement Settings 9 - Duty Cycle The ratio of the pulse width / pulse period. 10 - Pulse Rep Freq The rate, in pulses / sec, at which pulses recur. How to enable Auto Analysis —...
Page 483: Trace Memory
Pulse Measurements Mode – Option 330 Pulse Measurement Settings Trace Memory A memory trace is a pulse measurement Tr 1 data trace (NOT the trace in the Zoom window) that has been stored in the FieldFox volatile memory. It then becomes static, meaning it is not updated with normal pulse measurements.
Page 484 Pulse Measurements Mode – Option 330 Pulse Measurement Settings Keysight N9927-90001 User’s Guide...
Page 485 Keysight Handheld Analyzers N99xxA User’s Guide 23 VVM (Vector Voltmeter) Mode - Option 308 VVM Mode (Option 308) measures the electrical length of cables and other devices. The 1-Port Cable Trimming and 2-Port Transmission measurement displays the electrical length in both Magnitude and Phase. Figure 23-1 Display for the 1-Port Cable Trimming measurement In this Chapter...
Page 486 VVM (Vector Voltmeter) Mode - Option 308 Procedures “1-Port Cable Trimming Measurements ” on page 493 “2-Port Transmission Measurements” on page 495 “A/B and B/A Measurements” on page 497 Keysight N9927-90001 User’s Guide...
Page 487: Overview
VVM (Vector Voltmeter) Mode - Option 308 Overview Overview In the FieldFox, both 1-port and 2-port measurement types use a different configuration setup from the HP/Keysight 8508A Vector Voltmeter. Figure 23-2 Typical 8508A measurement configuration –as shown in the 8508A manual. The above block diagram requires an external source and directional coupler to measure the electrical length of a DUT or cable to be trimmed.
Page 488: Vvm Mode Settings
VVM (Vector Voltmeter) Mode - Option 308 VVM Mode Settings VVM Mode Settings Select VVM Mode before making any setting in this section. How to select VVM Mode — Press Mode — Then Measurement Selection How to select a VVM Measurement —...
Page 489: If Bandwidth
VVM (Vector Voltmeter) Mode - Option 308 VVM Mode Settings This setting survives a Preset and Mode Preset. How to set Resolution — Press Scale/Amptd — Then Resolution — Then choose: — 0.0 (default) — 0.00 IF Bandwidth Reducing the IF receiver bandwidth reduces the effect of random noise on a measurement.
Page 490: Averaging
VVM (Vector Voltmeter) Mode - Option 308 VVM Mode Settings How to set Output Power — Press Meas Setup 4. — Then More — Then Output Power — High (Default setting) Sets output power to the maximum achievable power at all displayed frequency. —...
Page 491: Single Or Continuous Measure
VVM (Vector Voltmeter) Mode - Option 308 VVM Mode Settings Single or Continuous Measure This setting determines whether the FieldFox measures continuously or only once each time the Single button is pressed. Use Single to conserve battery power or to allow you to save or analyze a specific measurement. This setting can be changed at any time without affecting calibration accuracy.
Page 492 VVM (Vector Voltmeter) Mode - Option 308 VVM Mode Settings — For 2-port measurements, Zero is typically pressed when a THRU connection is made in place of a DUT. Learn more in “2-Port Transmission Measurements” on page 495. Press Zero OFF before performing a QuickCal or Mechanical Cal (sets Zero to OFF).
Page 493: 1-Port Cable Trimming Measurements
VVM (Vector Voltmeter) Mode - Option 308 1-Port Cable Trimming Measurements 1-Port Cable Trimming Measurements A 1-Port Cable Trimming measurement is used in a cable fabrication procedure to validate proper electrical length. — The R receiver measures incident signal (green line) out of the source. —...
Page 494 VVM (Vector Voltmeter) Mode - Option 308 1-Port Cable Trimming Measurements 9. Remove the reference cable from the FieldFox PORT 1 connector. 10.Connect an unterminated, longer cable to the FieldFox PORT 1 connector. 11.Observe the displayed phase difference between the reference cable and the untrimmed cable.
Page 495: 2-Port Transmission Measurements
VVM (Vector Voltmeter) Mode - Option 308 2-Port Transmission Measurements 2-Port Transmission Measurements A 2-Port Transmission measurement is used for measuring electrical length, insertion loss, gain, or isolation of a DUT at a single CW frequency. The FieldFox signal source is transmitted out the port 1 connector, through the DUT, and into the port 2 connector.
Page 496 VVM (Vector Voltmeter) Mode - Option 308 2-Port Transmission Measurements — To measure isolation of the amplifier, reverse the connection to the amplifier (PORT 1 to the amplifier output). Keysight N9927-90001 User’s Guide...
Page 497: A/B And B/A Measurements
VVM (Vector Voltmeter) Mode - Option 308 A/B and B/A Measurements A/B and B/A Measurements These measurements allow you to use the FieldFox A and B receivers, along with an external source, to make ratioed measurements. These measurements require the “Full 2-port S-parameters” option. The image below shows a typical configuration for a B/A magnitude and phase measurement of a 2-port DUT.
Page 498 VVM (Vector Voltmeter) Mode - Option 308 A/B and B/A Measurements Keysight N9927-90001 User’s Guide...
Page 499: Erta (Extended Range Transmission Analysis) Mode - Option
Keysight Handheld Analyzers N99xxA User’s Guide 24 ERTA (Extended Range Transmission Analysis) Mode - Option 209 ERTA (also known as FoxTrot) uses two FieldFox units to make long-distance scalar transmission measurements. One unit is the source and the other unit is the Receiver.
Page 500: Overview
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Overview Overview ERTA uses two FieldFox units to make long-distance scalar, tracking transmission measurements. One unit is the source and the other unit is the Receiver. Communication takes place between the two units with a LAN connection and hard-wired trigger signals.
Page 501: Requirements And Limitations
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Requirements and Limitations Requirements and Limitations Requirements — Two FieldFox units with option 209 installed. SA Mode is required for option 209. — Ethernet LAN cable(s). Either TWO cables that are used to connect both units to the internet or ONE cable that is long enough to connect the two FieldFox units.
Page 502: Start Connection Wizard
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Start Connection Wizard Start Connection Wizard Use the FieldFox Connection Wizard to guide you through the following physical setup. On the Receiver unit: — Press Mode then ERTA — Then Meas Setup 4 then Connection Wizard then Start.
Page 503 ERTA (Extended Range Transmission Analysis) Mode - Option 209 Start Connection Wizard — On the Source unit, connect the Port 1 RF Output connector to the input of a power splitter. — Connect one power splitter output to the Source unit Port 2 RF Input. —...
Page 504 ERTA (Extended Range Transmission Analysis) Mode - Option 209 Start Connection Wizard — Press Continue. STEP 5: Measure Jumper Cables These steps can be used to characterize an Input and Output jumper cable that may be connect the DUT to the FieldFox. The loss of the characterized jumper cables can then be removed from the DUT measurements.
Page 505 ERTA (Extended Range Transmission Analysis) Mode - Option 209 Start Connection Wizard — Press Re-measure or Continue. — Press Apply Corrections ON to remove the jumper cables from subsequent DUT measurements. — Press Done to exit the Connection Wizard. — On the Receiver unit, press LEAD ERTA Partnership.
Page 506: Configure Measurement Settings
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Configure Measurement Settings Configure Measurement Settings On the Receiver unit, select measurement settings such as Frequency range, Res Be, Points, and so forth. Zeros pan frequency is allowed even though the frequency is fixed and no stepping is required.
Page 507: Normalize
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Configure Measurement Settings Learn more about Trace Display States in “Trace Display States (SA Mode)” on page 178. Normalize Normalize can be used to quickly provide ‘zeroing’ for any of the ERTA (B, R, or G) traces.
Page 508: Improve Dynamic Range
ERTA (Extended Range Transmission Analysis) Mode - Option 209 Configure Measurement Settings Improve Dynamic Range The following settings can be made to reduce measurement noise which improves Dynamic Range. Increase source power as much as possible while maintaining a leveled source. How to set Source Power —...
Page 509: Am/Fm Metrics (Sa Only And Option 355)
Keysight Handheld Analyzers N99xxA User’s Guide 25 AM/FM Metrics (SA Only and Option 355) The FieldFox assumes you have manually set up the CF, span, and amplitude settings. Refer to Chapter 9, “SA (Spectrum Analyzer) Mode.” In this Chapter “Using AM/FM Metrics” on page 509 “SINAD and THD Calculations”...
Page 510 AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics Table 25-1 Measurement Details Measurement details Modulation Rate The modulation rate quantifies how fast the modulation is and equates to the frequency of the baseband signal that modulates the carrier. SINAD (Signal to Noise Another commonly used distortion measure is signal to noise and distortion and Distortion Ratio)
Page 511 AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics Table 25-1 Measurement Details Modulation Metrics FM deviation The FM deviation reflects the amount of the frequency modulation to which the baseband signal modulates the carrier signal. The quantity being measured is the peak frequency deviation that is the maximum frequency excursion from the carrier frequency.
Page 512: How To Set Up Am/Fm Metrics
AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics How to Set Up AM/FM Metrics — Connect a test tone to the FieldFox SA Port 2 (Port 2) — Press Measure — Then Analog Demod / Tune & Listen —...
Page 513 AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics Figure 25-1 AM Metrics - Example 1 Keysight N9927-90001 User’s Guide...
Page 514 AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics Figure 25-2 AM Metrics - Example 2 Keysight N9927-90001 User’s Guide...
Page 515 AM/FM Metrics (SA Only and Option 355) Using AM/FM Metrics Figure 25-3 FM Metrics - Wide band Example Keysight N9927-90001 User’s Guide...
Page 516: Sinad And Thd Calculations
AM/FM Metrics (SA Only and Option 355) SINAD and THD Calculations SINAD and THD Calculations — FieldFox converts the audio waveform to the audio frequency spectrum using an FFT (i.e., The FFT result is not displayed). Refer to Figure 25-4 on page 516.
Page 517 AM/FM Metrics (SA Only and Option 355) SINAD and THD Calculations Figure 25-5 SINAD and THD Results - Example 1 Keysight N9927-90001 User’s Guide...
Page 518 AM/FM Metrics (SA Only and Option 355) SINAD and THD Calculations Figure 25-6 SINAD and THD Results - Example 2 Keysight N9927-90001 User’s Guide...
Page 519: Interpreting Am/Fm Metrics Error Messages
AM/FM Metrics (SA Only and Option 355) Interpreting AM/FM Metrics Error Messages Interpreting AM/FM Metrics Error Messages This section discusses possible AM/FM Metrics error messages and how to correct them. Test Tone Not Found A Test Tone Not Found message is displayed under the following circumstances: —...
Page 520 AM/FM Metrics (SA Only and Option 355) Interpreting AM/FM Metrics Error Messages Test Tone Not Found - Example The following response had the following settings: — Source CF: 140 MHz — FM Deviation: 18 kHz — Modulation Rate: 1 kHz Reasons for error: —...
Page 521 AM/FM Metrics (SA Only and Option 355) Interpreting AM/FM Metrics Error Messages Test Tone Not Found - Corrected Example The following response was corrected with these setting changes: — Frequency set to narrower frequency span of 50 kHz — Ideally the frequency span should show the modulation envelope down to –60 dB below the RF power level Response corrected, because: —...
Page 522 AM/FM Metrics (SA Only and Option 355) Interpreting AM/FM Metrics Error Messages Keysight N9927-90001 User’s Guide...
Page 523: Channel Scanner (Option 312)
Keysight Handheld Analyzers N99xxA User’s Guide 26 Channel Scanner (Option 312) In this Chapter: “Using Channel Scanners” on page 523 “How to Set Up Channel Scanner” on page 524 “Field Strength Measurements” on page 538 — “Using the Antenna/Cable Editor” on page 544 —...
Page 524: How To Set Up Channel Scanner
Channel Scanner (Option 312) How to Set Up Channel Scanner Figure 26-1 Display Example: Measure 5 Channels Spaced 2 MHz Apart How to Set Up Channel Scanner This section briefly reviews the steps in setting up a channel scan measurement. If you are not familiar with this process or would like more information, refer to “How to Define a Channel and Use Channel Scanner”.
Page 525 Channel Scanner (Option 312) How to Set Up Channel Scanner Press Scale/Amptd Then one of the following: — Red Limit to set the power level and color scale for high power channels. — Blue Limit to set the power level and color scale for low power channels.
Page 526: How To Define A Channel And Use Channel Scanner
Channel Scanner (Option 312) How to Set Up Channel Scanner — Then File Type — KML (default) or — CSV — Then Save Log File. 6. Export KML file into 3rd party mapping software (i.e., Google or Google Earth) How to Define a Channel and Use Channel Scanner Channel definitions consist of the following: —...
Page 527 Channel Scanner (Option 312) How to Set Up Channel Scanner Figure 26-2 Channel Definition Step 1A: Scan Mode: Range Channel Defined 1. Define some channels: Press Measure > Scan Mode > Range 2. Press Edit Range and modify table items: —...
Page 528 Channel Scanner (Option 312) How to Set Up Channel Scanner Figure 26-3 Range Table Settings 3. Press Done Step 1B: Scan Mode: Custom List Channel Defined 1. Define some channels: Press Measure > Scan Mode > Custom List 2. Press Edit Custom List and modify table items: —...
Page 529 Channel Scanner (Option 312) How to Set Up Channel Scanner Figure 26-4 Custom List Table Settings 3. Press Done 4. Press Save Recall List > Save List to save a custom list. See also “How to use the FieldFox labeler ” on page 674.
