RFC 1483
If you know the specific local and remote IP addresses, enter the following CLI
command where
x.x.x.x
address.
OCG-Adsl>>set profile <pppoa> protocol ip
local_ip_address <x.x.x.x> remote_ip_address <y.y.y.y>
OCG-Adsl>>set profile <pppoa> protocol ip default_route_option
enable routing both routing_protocols ripv2
OCG-Adsl>>add atmaal5 pvc <pvc35> vpi <0> vci <35>
OCG-Adsl>>add datalink ppp interface <atmaal:1/pvc35> profile
<pppoa>
3 Configure your NAT/PAT policies.
To configure NAT, perform the following from the CLI:
OCG-Adsl>>set nat interface <interface name> option <NAT>
To configure PAT, perform the following from the CLI:
OCG-Adsl>>set nat interface <interface name> option <PAT>
To configure SuperNAT, perform the following from the CLI:
OCG-Adsl>>set nat interface <interface name> option
<SUPERNAT>
4 Determine your public IP addresses for your LAN and WAN by entering the
following CLI commands:
OCG-Adsl>>list ip networks
Your WAN IP address is associated with your interface name. An example of a
WAN interface name is
5 Enter the following CLI commands:
OCG-Adsl>>add pat <tcp> interface <interface name>
private_address <ip address range> public_address <ip
address range> public_port <port range>
OCG-Adsl>>add pat <udp> interface <interface name>
private_address <ip address range> public_address <ip
address range> public_port <port range>
The following example shows the CLI commands that are used to configure RFC
1483 from the CLI:
1 Create an interface:
OCG-Adsl>> add atmaal5 pvc <atmpvc> vpi <0> vci <35> interface
atmaal:1
(This creates an Interface with the name:
2 Enter the following command if using DHCP:
OCG-Adsl>> add ip network <1483> interface <atmaal:1/atmpvc> frame
atm1483 wan_type auto enabled yes
is the local IP address and
.
atmaal1:/pvc34
atmaal:1/atmpvc
RFC 1483
is the remote IP
y.y.y.y
16-3
