TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR
Inside Door, Boards, and Grounding
3.6.1
Inside Door
The inside doors contain the following components as shown in Figure 73:
•
•
•
•
Note:
TX3 Touch Screen Installation Manual
Camera
Microphone
Display
P300 Card Reader
Figure 73. TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR
inside door
Mircom sells a postal lock adapter: part number DO-CR3.
Touch Screen System and Setup
Camera
Microphone
Display
P300 Card Reader
