4
Before turning on the system it is important to verify that the following
connections are firmly in place.
For additional information about the lobby controller board connectors and
jumpers, see LT-969 TX3 Telephone Access System Installation and Operation
Manual.
This chapter explains
•
•
•
•
TX3 Touch Screen Installation Manual
Version 7
LT-996 Copyright 2020

Touch Screen Factory Wiring

If you have a model that ends in -D, refer to section 4.1 on page 108.
If you have a model that ends in -C, refer to section 4.2 on page 117.
If you have a model that does not end in -C, refer to section 4.3 on
page 123.
you have TX3-TOUCH-S15B-WR or TX3-TOUCH-S15S-WR, see
If
section 4.4 on page 139.
107
