WX-054: CN26 on PC
sub compact board
WX-057: CN20 on PC
sub compact board
Figure 128. Display connections on TX3-TOUCH-S15-B and
TX3-TOUCH-F15-B for MD-1236
Attention: The bottom cable must be connected so that the arrow is on the
outside.
Arrow
Figure 129. Make sure that the arrow is visible
TX3 Touch Screen Installation Manual
Touch Screen Factory Wiring
WX-055: CN27
on PC sub
compact board
127
