3.5 TX3-TOUCH-F22(-C/D) and TX3-TOUCH-S22(-C/D)
Inside Door, Boards, and Grounding
The 22" Touch Screen inside doors contain the following components as shown
in Figure 70:
•
•
•
•
•
•
•
80 TX3 Touch Screen Installation Manual
Speakers
Camera
Postal Lock (optional)
Fan (optional)
Microphone
P300 Card Reader
Keyhole
Speakers
Fan Keyhole
Figure 70. TX3-TOUCH-F22(-C/D) and TX3-TOUCH-S22(-C/D)
inside door
Touch Screen System and Setup
Camera
Microphone
Postal
Lock Switch
Postal
Lock
P300 Card Reader
