Installing TX3-T-KIOSK2
Warning:
46
TX3 Touch Screen Installation Manual
To prevent overheating, do not install any of the TX3 Touch
Screens in direct sunlight.
Do not mount TX3-TOUCH-S15B-WR and
TX3-TOUCH-S15S-WR in any of the TX3 Kiosks.
18" (457 mm)
18 13/64" (462 mm)
Figure 28. Dimensions of TX3-T-KIOSK2 with TX3-TOUCH-S22
Installation
15 3/16" (386 mm)
22 3/16" (563 mm)
