2.5 Installing TX3-TOUCH-S22(-C/D) and
TX3-TOUCH-F22(-C/D)
Attention: The 22" Touch Screen enclosures are heavy (80 lbs or 37 kg). Never
2.5.1 Installing TX3-TOUCH-S22(-C/D)
Warning:
The surface mount enclosure mounts on the wall. Mount the enclosure right-side
up (the Mircom logo on the door is on the bottom).
You need:
6 fasteners appropriate for the wall that you are mounting the enclosure on.
To mount the enclosure
1.
32 TX3 Touch Screen Installation Manual
attempt to lift this product by yourself. At least two people should
lift it together.
To prevent overheating, do not install any of the TX3 Touch
Screens in direct sunlight.
Find a suitable location for the surface mount enclosure over a wall stud.
The wall must be able to support a weight of 80 lbs (37 kg).
Installation
