Figure 10 Tx3-Touch-F15-B/C/D Dimensions; Figure 11 Tx3-Touch-F15-B/C/D Mounting Hole And Knockout Dimensions - Mircom TX3 Series Installation Manual
Hide thumbs
Also See for TX3 Series:
Table of Contents
Advertisement
22"
(559 mm)
1 1/4"
(32 mm)
Figure 10. TX3-TOUCH-F15-B/C/D dimensions
12 3/4"
(324 mm)
20 3/4"
(527 mm)
Figure 11.
TX3-TOUCH-F15-B/C/D mounting hole and knockout
dimensions
TX3 Touch Screen Installation Manual
17 1/2"
(445 mm)
16 19⁄64"
(414 mm)
12 19⁄32"
(320 mm)
4 1/2"
(114 mm)
Installation
3 31/32"
(101 mm)
3 51/64"
(96 mm)
17 9⁄16"
(446 mm)
2 7/32"
(57 mm)
