Posts(x2)
Bracket
Figure 94. Card reader and new bracket
4.
Slide the bracket on to the 4 posts on the Touch Screen door and secure it
with the 4 nuts as shown in Figure 95 and Figure 96.
Posts(x4)
Figure 95. Old card reader bracket
TX3 Touch Screen Installation Manual
Touch Screen System and Setup
Card Reader
Card Reader
and Bracket
Screws (x2)
Nuts (x4)
105
