4.1.2 Factory Wiring for TX3-TOUCH-S22-D and TX3-TOUCH-F22-D
SW-207: Button
Red
Black
White
Green
WX-095: JP19 on MD-1346
WX-070: Ground
wire to MD-1245
WX-026:
Ground wire to
chassis ground
112 TX3 Touch Screen Installation Manual
WX-079: CN9 on MD-1346
SW1: all switches off
MD-1236
TS11
P3
SW3 on the LEFT
TS9
P2
+ −
Red Black
Red Black
WR-21160 and
WX-080:
WR-21162: Power
CN5 on MD-1346
terminals
Figure 104. Factory connections on the power supply and audio
mixer board for TX3-TOUCH-S22-D and
TX3-TOUCH-F22-D
TS11 on
MD-1236
green
Notch
white
black (−)
red (+)
4 3 2 1
Figure 105. Factory connections on the power button
P1
TS1
TS4B
TS10B
TS12
WX-109: TS2 on MD-1245
(not polarity sensitive)
Button (bottom view)
red (+)
1
white green
3 4
black (−)
2
Touch Screen Factory Wiring
− WX-110:
Black
+
Red
TS4 (top) on MD-1245
TS4A
− WR-12223 and WR-12224:
Orange
+
Yellow
Left Speaker
− WR-12223 and WR-12224:
Orange
+
Yellow
Right Speaker
TS10A
− WR-22160 and WR-22162:
Black
+
Red
CN7 on MD-1346
WC-25019:
−
Black
+
Red
Power on display
Button (side view)
Notch
