136 TX3 Touch Screen Installation Manual
WX-053: USB on
PC board
Black
WX-077:
White
Microphone
Red
WX-110: TS1 on
Black −
+
Red
MD-1105
WX-030: Postal
lock switch
(optional)
Figure 143. Factory connections on the lobby controller board for
TX3-TOUCH-S22 and TX3-TOUCH-F22 for MD-1105
Optional Fan
WR-21160 and
+
Red
WR-21162: TS4 on
−
Black
MD-1105
WX-080: P4 on
MD-1105
WX-081: P5 on
MD-1105
BAT1A
Battery
Figure 144. Factory connections on the PC sub compact board for
TX3-TOUCH-S22 and TX3-TOUCH-F22 for MD-1105
TS5
TS4
CN3
CN32
CN6
CN2
CN14 CN15
CN1
WX-082: WX-089:
USB to display USB extension
Touch Screen Factory Wiring
JP1
Power switch
WX-070:
TS2 TS2 Ground wire
to MD-1236
Red Black
WX-109: TS8 on
MD-1105
(not polarity sensitive)
Touch Screen VGA
cable
USB
WX-053: JP1 on
telephone access
controller
CN31
Camera
WX-079: P1 on
MD-1105
