Note: There are two possible styles of card reader bracket, depending on
the date of manufacture. In these instructions they are referred to as
old and new brackets.
Old card reader bracket
Figure 90. Old and new card reader brackets
2. Remove the card reader bracket from the Touch Screen door as shown in
Figure 91 and Figure 92.
Posts(x4)
Figure 91. Old card reader bracket
TX3 Touch Screen Installation Manual
Touch Screen System and Setup
New card reader bracket
Card Reader
and Bracket
Nuts (x4)
103
