2.6 Installing TX3-TOUCH-S15B-WR and
TX3-TOUCH-S15S-WR
Warning:
Warning:
The unit mounts on the wall. Mount the unit with the right side up (the Mircom
logo is on the bottom).
To mount the unit
You need:
4 fasteners appropriate for the wall that you are mounting the unit on.
1.
2.
3.
4.
5.
6.
38 TX3 Touch Screen Installation Manual
To prevent overheating, do not install any of the TX3 Touch
Screens in direct sunlight.
To prevent water from entering the unit, use an elbow
connector to run the wires to one of the three knockouts on the
back. The elbow connector must point downwards.
Do not mount TX3-TOUCH-S15B-WR and
TX3-TOUCH-S15S-WR in any of the TX3 Kiosks.
Find a suitable location for the unit.
Using the unit as a template, mark the back mounting locations of the two
keyholes shown in Figure 18. Ensure that at least one side is over a wall
stud.
Remove the unit and place the fasteners halfway into the wall into the
marked hole locations.
Place the unit onto the fasteners and lower it so that the fasteners fit in the
narrow part of the keyholes.
Screw the other two fasteners into the two holes at the bottom of the unit.
Tighten all fasteners into place.
