To fit the Touch Screen on the stand
Warning:
Attention: The 22" Touch Screen enclosure is heavy. Never attempt to lift
1.
2.
3.
58 TX3 Touch Screen Installation Manual
Use only the 22 inch flush mount Touch Screen
(TX3-TOUCH-F22) with this stand. Do not mount
TX3-TOUCH-S15B-WR and TX3-TOUCH-S15S-WR in any
of the TX3 Kiosks.
this product by yourself. At least two people should lift it
together.
Fit the Touch Screen on the six studs on the stand.
Attach the 6 included screws to the studs.
Run the wires through the knockout at the bottom of the Touch Screen.
Figure 44. Mount TX3-TOUCH-S22 on the stand
Installation
