3.4
TX3-TOUCH-F15-B/C/D and
TX3-TOUCH-S15-B/C/D Inside Door, Boards, and
Grounding
3.4.1
Inside Door
The inside doors of TX3-TOUCH-F15-B/C/D and TX3-TOUCH-S15-B/C/D
contain the following components as shown in Figure 66:
•
•
•
•
•
•
•
TX3 Touch Screen Installation Manual
Speakers
Camera
Postal Lock (optional)
Fan (optional)
Microphone
P300 Card Reader
Keyhole
Speakers
Keyhole
Fan
Figure 66. TX3-TOUCH-F15-B/C/D and TX3-TOUCH-S15-B/C/D
inside door
Touch Screen System and Setup
Camera
Microphone
Postal
Lock Switch
Postal
Lock
P300 Card Reader
77
