132 TX3 Touch Screen Installation Manual
TS7 on
MD-1105
Notch
1 white
green
2
red (+)
3
4 black (−)
Figure 136. Factory connections on the power button for MD-1105
WX-053: USB on
PC board
Black
WX-077:
White
Microphone
Red
WX-110: TS1 on
Black −
+
Red
MD-1105
WX-030: Postal
lock switch
(optional)
Figure 137. Factory connections on the lobby controller board for
TX3-TOUCH-S15-B and TX3-TOUCH-F15-B for MD-1105
Button (bottom view)
red (+)
3
white green
1 2
black (−)
4
TS5
TS4
Touch Screen Factory Wiring
Button (side view)
Notch
JP1
Power switch
WX-070:
TS2 TS2 Ground wire
to MD-1236
Red Black
WX-109: TS8 on
MD-1105
(not polarity sensitive)
