3.3 TX3-TOUCH-K15-A, TX3-TOUCH-F15-A,
TX3-TOUCH-S15-A Main Panel, Boards, and
Grounding
3.3.1 Main Panel
On the Kiosk, the Touch Screen Panel is situated behind the front cover. To
access the panel, unlock the Touch Screen and pull open the front cover.
The 15" Touch Screen Panel contains the following main components as shown
in Figure 64:
•
•
•
•
•
3.3.2 Controller Boards
The following Touch Screen controller boards are situated on a panel behind the
15" Touch Screen Panel as shown in Figure 65:
•
TX3 Touch Screen Installation Manual
On/Off Switch
USB Port for keyboard configuration
Camera
Postal Lock (optional)
Microphone
ON/OFF
USB Port
Switch
Figure 64. TX3-TOUCH-K15-A, TX3-TOUCH-F15-A,
TX3-TOUCH-S15-A panel components
Lobby Controller Board (also called Telephone Access controller board)
Touch Screen System and Setup
Postal Lock
Camera
Microphone
Touch Screen
Screw
Screw
