130
TX3 Touch Screen Installation Manual
CN32 on PC sub
compact board
WC-25019: TS10B on
MD-1236
Figure 134. Display connections on TX3-TOUCH-S22 and
TX3-TOUCH-F22 for MD-1236
Touch Screen Factory Wiring
WX-082: USB
extension on PC
sub compact
board
