4.2.2 Factory Wiring for TX3-TOUCH-S22-C and TX3-TOUCH-F22-C
Red
Black
SW-207: Button
White Green
WX-081: CN1 on PC board
WX-070: Ground
wire to telephone
access controller
WX-070:
Ground wire to
chassis ground
120 TX3 Touch Screen Installation Manual
WX-079: CN31 on PC board
SW1: all switches off
MD-1236
TS11
P3
SW3 on the LEFT
SW3
TS9
P2
+ −
Red Black
Red Black
WR-21160 and
WX-080:
WR-21162: Power
CN2 on PC board
terminals
Figure 117. Factory connections on the power supply and audio
mixer board for TX3-TOUCH-S22-C and
TX3-TOUCH-F22-C
TS11 on
MD-1236
green
Notch
white
black (−)
red (+)
4 3 2 1
Figure 118. Factory connections on the power button
P1
TS1
TS4B
TS10B
TS12
WX-109: TS2 on telephone
access controller (not
polarity sensitive)
Button (bottom view)
red (+)
1
white green
3 4
black (−)
2
Touch Screen Factory Wiring
WX-110:
TS4 (top) on telephone
−
Black
+
Red access controller
TS4A
WR-12223 and WR-12224:
−
Orange
+
Yellow
Left Speaker
−
WR-12223 and WR-12224:
Orange
+
Yellow
Right Speaker
TS10A
−
WR-22160 and WR-22162:
Black
+
Red
Power (CN6)
on PC board
WC-25019: Power on
−
Black
+
Red
22 inch display
Button (side view)
Notch
