122
TX3 Touch Screen Installation Manual
CN32 on PC sub
compact board
WC-25019: TS10B on
MD-1236
Figure 121. Display connections on TX3-TOUCH-S22-C and
TX3-TOUCH-F22-C
Touch Screen Factory Wiring
MD-813:
WX-082 to CN14
on PC sub
compact board
