Installing The Optional Tx3-Delta5 Card Reader; Figure 89 Position Of The Card Reader - Mircom TX3 Series Installation Manual

3.18

Installing the Optional TX3-DELTA5 Card Reader

These instructions explain how to replace the factory-installed card reader with
the optional TX3-DELTA5 card reader in these models:
•
•
•
•
•
•
1.
102 TX3 Touch Screen Installation Manual
TX3-TOUCH-S22(-C/D)
TX3-TOUCH-F22(-C/D)
TX3-TOUCH-S15-B/C/D
TX3-TOUCH-F15-B/C/D
TX3-TOUCH-S15B-WR
TX3-TOUCH-S15S-WR
Open the Touch Screen door.
The card reader is in the lower right corner of the inside of the door, as
shown in Figure 89.
Figure 89. Position of the card reader
Touch Screen System and Setup
Card Reader
Card Reader
