1. INTRODUCTION

1.1 About This Manual

1.2 Overview of Components

Controllers Description
ECL 2000 Temperature controller 230V AC. Type 1 without LON communication
ECL 2000 Temperature controller 230V AC. Type 1 with LON TP/XF-78
ECL 2000 Temperature controller 230V AC. Type 1 with LON FTT-10A
ECL 2000 Temperature controller 24V AC. Type 1 without LON communication
ECL 2000 Temperature controller 24V AC. Type 1 with LON TP/XF-78
ECL 2000 Temperature controller 24V AC. Type 1 with LON FTT-10A
ECL 2000 Temperature controller 24V AC. Type 2 without LON communication
ECL 2000 Temperature controller 24V AC. Type 2 with LON TP/XF-78
ECL 2000 Temperature controller 24V AC. Type 2 with LON FTT-10A
Mounting Description
Base plate Base plate including terminal blocks and frame in black plastic
Panel spring ac- 4 retainer springs and two terminal blocks. Used when controller is placed in a
cessory panel cutout.
ECL 2000 is available in two versions with different input/output configurations.
ECL 2000 Type 1 has 14 preprogrammed applications designed as 14 standard
system setups and type 2 has 17 preprogrammed applications.
The purpose of this installation manual is:
• To describe how to install and configure ECL 2000, and
• To provide the installer with system and wiring diagrams for each application
and type.
For a detailed description of regulation and setting parameters, see ECL 2000
User's Guide, ref. [2].
The list below provides an overview of the various ECL 2000 products including
code numbers. In the following chapters, the individual products and their instal-
lation are described. See also data sheet on ECL 2000, ref. [4].
EI.65.D4.02
Introduction
Code No.
087B8000
087B8001
087B8011
087B8002
087B8003
087B8013
087B8006
087B8007
087B8017
Code No.
087B8099
087B3076
1
