1 Introduction

1.1 How to Read This Programming Guide

1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, parameter access,
programming, and troubleshooting.
The programming guide is intended for use by qualified
personnel who are familiar with VLT
361.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.
1.1.2 Additional Resources
Additional resources include:
•
®
VLT AutomationDrive FC 361 Operating Guide
provides the necessary information for getting
the frequency converter up and running.
•
®
VLT AutomationDrive FC 361 Design Guide
provides detailed technical information about the
frequency converter and customer design and
applications.
Contact the local Danfoss supplier for the documentation.
1.1.3 Document and Software Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
Update parameter descriptions and
MG06J2
manual cover.
Table 1.1 Document and Software Version
MG06J202
Programming Guide
®
AutomationDrive FC
Software
version
1.0x
Danfoss A/S © 03/2019 All rights reserved.
°C
Degrees Celsius
°F
Degrees Fahrenheit
AC Alternating current
AEO Automatic energy optimization
ACP Application control processor
AWG American wire gauge
AMA Automatic motor adaptation
DC Direct current
Electrically erasable programmable
EEPROM
read-only memory
EMC Electromagnetic compatibility
EMI Electromagnetic interference
ESD Electrostatic discharge
ETR Electronic thermal relay
f Nominal motor frequency
M,N
FC Frequency converter
IGBT Insulated-gate bipolar transistor
IP Ingress protection
I Current limit
LIM
I Rated inverter output current
INV
I Nominal motor current
M,N
I Maximum output current
VLT,MAX
Rated output current supplied by the
I
VLT,N
frequency converter
L Motor d-axis inductance
d
L Motor q-axis inductance
q
LCP Local control panel
LED Light-emitting diode
MCP Motor control processor
N.A. Not applicable
National Electrical Manufacturers
NEMA
Association
P Nominal motor power
M,N
PCB Printed circuit board
PE Protective earth
PELV Protective extra low voltage
PWM Pulse width modulation
R Stator resistance
s
Regen Regenerative terminals
RPM Revolutions per minute
RFI Radio frequency interference
SCR Silicon controlled rectifier
SMPS Switch mode power supply
T Torque limit
LIM
U Nominal motor voltage
M,N
X Motor main reactance
h
Table 1.2 Abbreviations
