Danfoss VLT AutomationDrive FC 361 Programming Manual page 70

Parameter Descriptions
[20] Freeze
output
4 4
[21] Speed
up
Unchanged speed
Reduced by %-value
Increased by %-value
Reduced by %-value
Table 4.10 Shut Down/Catch Up
[22] Speed
down
[23] Set-up
select bit 0
[24] Set-up
select bit 1
[28] Catch up
[29] Slow down Reduces reference value by percentage
[34] Ramp bit 0 Enables a selection between 1 of the 4 ramps
[35] Ramp bit 1 Same as [34] Ramp bit 0.
Preset ramp bit
Ramp 1
Ramp 2
Ramp 3
Ramp 4
Table 4.11 Preset Ramp Bit
68
Freezes the actual motor frequency (Hz), which is
now the point of enable/condition to be used for
[21] Speed up and [22] Speed down. If speed up/
speed down is used, the speed change always
follows ramp 2 (parameter 3-51 Ramp 2 Ramp Up
Time and parameter 3-52 Ramp 2 Ramp Down Time)
in the range 0–parameter 1-23 Motor Frequency.
NOTICE
When freeze output is active, the frequency
converter cannot be stopped via a low [8]
Start signal. Stop the frequency converter
via a terminal programmed for [2] Coasting
inverse or [3] Coast and reset inverse.
Select [21] Speed up and [22] Speed down for digital
control of the up/down speed (motor potenti-
ometer). Activate this function by selecting either
[19] Freeze ref or [20] Freeze output. When speed
up/speed down is activated for less than 400 ms,
the resulting reference is increased/decreased by
0.1%. If speed up/speed down is activated for
more than 400 ms, the resulting reference follows
the setting in ramping up/down parameters 3-
x1/3-x2.
Shut down
0
1
0
1
Same as [21] Speed up.
Select [23] Set-up select bit 0 or select [24] Set-
up select bit 1 to select 1 of the 4 set-ups. Set
parameter 0-10 Active Set-up to Multi Set-up.
(Default digital input 32): Same as [23] Set-up
select bit 0.
Increases reference value by percentage
(relative) set in parameter 3-12 Catch up/slow
Down Value.
(relative) set in parameter 3-12 Catch up/slow
Down Value.
available, according to Table 4.11.
1
0
0
1
1
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
[51] External
interlock
[55] DigiPot
Increase
[56] DigiPot
Decrease
[57] DigiPot
Clear
[62] Reset
Counter A
[65] Reset
Counter B
[66] Sleep Mode
[72] PID error
inverse
[73] PID reset I-
part
Catch up
0
0
[74] PID enable
1
1
5-10 Terminal 18 Digital Input
Option:
[8] Start Functions are described in parameter group 5-1*
*
5-11 Terminal 19 Digital Input
Option:
[10] Reversing Functions are described in parameter group
*
5–12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described in parameter group
*
5-13 Terminal 29 Digital Input
Option:
0
0
1
0
1
[14] Jog Functions are described in parameter group 5-1*
*
This function makes it possible to give an
external fault to the frequency converter. This
fault is treated in the same way as an
internally generated alarm.
Increase signal to the digital potentiometer
function described in parameter group 3-9*
Digital Pot. Meter.
Decrease signal to the digital potentiometer
function described in parameter group 3-9*
Digital Pot. Meter.
Clears the digital potentiometer reference
described in parameter group 3-9* Digital Pot.
Meter.
Input for reset of counter A.
Input for reset of counter B.
When enabled, this option inverts the
resulting error from the process PID controller.
Available only if parameter 1-00 Configuration
Mode is set to [7] Extended PID Speed OL.
When enabled, this option resets the I-part of
the process PID controller. Equivalent to
parameter 7-40 Process PID I-part Reset.
Available only if parameter 1-00 Configuration
Mode is set to [7] Extended PID Speed OL.
Enables the extended process PID controller.
Equivalent to parameter 7-50 Process PID
Extended PID. Available only if
parameter 1-00 Configuration Mode is set to [7]
Extended PID Speed OL.
Function:
Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
5-1* Digital Inputs.
Function:
Select the function from the available digital input
range and the additional options [60] Counter A, [61]
Counter A, [63] Counter B, and [64] Counter B.
Counters are used in smart logic control functions.
Digital Inputs.
MG06J202
