Danfoss VLT AutomationDrive FC 361 Programming Manual page 146

Parameter Descriptions
16-01 Reference [Unit]
Range:
0 Referen-
ceFeedback 999999
Unit Reference-
*
FeedbackUnit]
4 4
16-02 Reference [%]
Range:
0 %
*
200 %]
16-03 Status Word
Range:
0
*
16-05 Main Actual Value [%]
Range:
0 %
*
100 %]
16-09 Custom Readout
Range:
0 Custom-
ReadoutUni 999999.99
t CustomRea-
*
doutUnit]
4.15.2 16-1* Motor Status
16-10 Power [kW]
Range:
0 kW
*
kW]
144
Function:
[-999999 - View the present reference value
applied on impulse or analog basis
in the unit resulting from the
configuration selected in
parameter 1-00 Configuration Mode
(Hz, Nm, or RPM).
Function:
[-200 - View the total reference. The total
reference is the sum of digital,
analog, preset, bus, and freeze
references, plus catch up and slow
down.
Function:
[0 - 65535 ] View the status word sent from the
frequency converter via the serial
communication port in hex code.
Function:
[-100 - View the 2-byte word sent with the
status word to the fieldbus master
reporting the main actual value.
Function:
[0 - View the value of custom readout
from parameter 0-30 Unit for User-
defined Readout to
parameter 0-32 Custom Readout Max
Value.
Function:
[0 - 10000 Shows motor power in kW. The
value shown is calculated based on
the actual motor voltage and motor
current. The value is filtered, and
therefore approximately 1.3 s may
pass from when an input value
changes to when the data readout
values change. The resolution of
readout value on fieldbus is in
10 W steps.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
16-11 Power [hp]
Range:
0 hp
*
16-12 Motor Voltage
Range:
0 V
*
16-13 Frequency
Range:
0 Hz
*
16-14 Motor current
Range:
0 A
*
16-15 Frequency [%]
Range:
0 %
*
16-16 Torque [Nm]
Range:
0 Nm
*
Function:
[0 - 10000 View the motor power in hp. The
hp] value shown is calculated based on
the actual motor voltage and motor
current. The value is filtered, and
therefore approximately 1.3 ms may
pass from when an input value
changes to when the data readout
values change.
Function:
[0 - 6000 V] View the motor voltage, a
calculated value used for
controlling the motor.
Function:
[0 - 6500 Hz] View the motor frequency without
resonance damping.
Function:
[0 - 10000 A] View the motor current measured
as an average value, I
is filtered, and thus approximately
1.3 s may pass from when an input
value changes to when the data
readout values change.
Function:
[-100 - View a 2-byte word reporting the
100 %] actual motor frequency (without
resonance damping) as a
percentage (scale 0000–4000 hex)
of parameter 4-19 Max Output
Frequency. Set parameter 9-16 PCD
Read Configuration index 1 to send
it with the status word instead of
the MAV.
Function:
[-3000 - 3000 View the torque value with sign,
Nm] applied to the motor shaft. Linearity
is not exact between 160% motor
current and torque in relation to
the rated torque. Some motors
supply more than 160% torque.
Therefore, the minimum value and
the maximum value depend on the
maximum motor current and the
motor used. The value is filtered,
. The value
RMS
MG06J202
