Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
4 4
[1639] Control Card Temp.
[1644] Speed Error [RPM]
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase W
Current
[1648] Speed Ref. After
Ramp [RPM]
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input
[1661] Terminal 53 Switch
Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch
Setting
[1664] Analog Input 54
[1665] Analog Output 42
[mA]
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Freq. Input #29
[Hz]
[1668] Freq. Input #33
[Hz]
[1669] Pulse Output #27
[Hz]
28
VLT® AutomationDrive FC 361
Function:
Percentage load of the inverters.
Nominal current of the frequency
converter.
Maximum current of the frequency
converter.
State of the event executed by the
control.
Temperature of the control card.
Sum of the external reference as a
percentage, that is the sum of
analog/pulse/bus.
Frequency in Hz connected to the
digital inputs (18, 19 or 32, 33).
Reference value from programmed
digital inputs.
Signal states from the 6 digital
terminals (18, 19, 27, 29, 32, and
33). There are 16 bits in total, but
only 6 of them are used. Input 18
corresponds to the far left of the
used bits. Signal low = 0; Signal
high = 1.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 53 either as a
reference or protection value.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 54 either as
reference or protection value.
Actual value at output 42 in mA.
Use parameter 6-50 Terminal 42
Output to select the value to be
shown.
Actual value of the frequency
applied at terminal 29 as an
impulse input.
Actual value of the frequency
applied at terminal 33 as an
impulse input.
Actual value of impulses applied to
terminal 27 in digital output mode.
Danfoss A/S © 03/2019 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[1670] Pulse Output #29 Actual value of impulses applied to
[Hz] terminal 29 in digital output mode.
[1671] Relay Output [bin]
[1672] Counter A Application-dependent (for
example SLC control).
[1673] Counter B Application-dependent (for
example SLC control).
[1675] Analog In X30/11 Actual value at input X30/11 either
as reference or protection value.
[1676] Analog In X30/12 Actual value at input X30/12 either
as reference or protection value.
[1677] Analog Out X30/8 Actual value at output X30/8 in
[mA] mA. Use parameter 6-60 Terminal
X30/8 Output to select the value to
be shown.
[1678] Analog Out X45/1
[mA]
[1679] Analog Out X45/3
[mA]
[1680] Fieldbus CTW 1 Control word (CTW) received from
the bus master.
[1682] Fieldbus REF 1 Main reference value sent with
control word from the bus master.
[1684] Comm. Option STW Extended fieldbus communication
option status word.
[1685] FC Port CTW 1 Control word (CTW) received from
the bus master.
[1686] FC Port REF 1 Status word (STW) sent to the bus
master.
[1687] Bus Readout
Alarm/Warning
[1690] Alarm Word 1 or more alarms in a hex code.
[1691] Alarm Word 2 1 or more alarms in a hex code.
[1692] Warning Word 1 or more warnings in a hex code.
[1693] Warning Word 2 1 or more warnings in a hex code.
[1694] Ext. Status Word 1 or more status conditions in a
hex code.
[1695] Ext. Status Word 2 1 or more status conditions in a
hex code.
[1697] Alarm Word 3 1 or more alarms in a hex code.
[1698] Warning Word 3 1 or more warnings in a hex code.
[1890] Process PID Error
[1891] Process PID Output
[1892] Process PID
Clamped Output
[1893] Process PID Gain
Scaled Output
[2117] Ext. 1 Reference
[Unit]
[2118] Ext. 1 Feedback
[Unit]
[2119] Ext. 1 Output [%]
