Parameter Descriptions
16-86 FC Port REF 1
Range: Function:
0 [-200 - 200 ] View the 2-byte status word (STW)
*
sent to the fieldbus master.
Interpretation of the status word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Profile.
16-87 Bus Readout Alarm/Warning
Range: Function:
0 [0 - 65535] Alarm and warning numbers in hex
*
as shown in the alarm log. The high
byte contains the alarm, the low
byte contains the warning. The
alarm number is the 1
occurred after the last reset.
4.15.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range: Function:
0 [0 - Show the alarm word sent via the
*
4294967295 ] serial communication port in hex
code.
16-91 Alarm Word 2
Range: Function:
0 [0 - View the alarm word sent via the
*
4294967295] serial communication port in hex
code.
16-92 Warning Word
Range: Function:
0 [0 - Show the warning word sent via
*
4294967295 ] the serial communication port in
hex code.
16-93 Warning Word 2
Range: Function:
0 [0 - View the warning word sent via the
*
4294967295] serial communication port in hex
code.
MG06J202
Programming Guide
16-94 Ext. Status Word
Range:
0
*
16-95 Ext. Status Word 2
Range:
0
*
16-97 Alarm Word 3
Range:
0
*
st
one that
16-98 Warning Word 3
Range:
0
*

4.16 Parameters: 17-** Feedback

More parameters to configure the feedback from the
encoder (VLT
Resolver Input MCB 103), or the frequency converter itself.
4.16.1 17-1* Inc. Enc. Interface
Parameters in this group configure the incremental
interface of the VLT
incremental and absolute interfaces are active at the same
time.
NOTICE
These parameters cannot be adjusted while the motor is
running.
17-10 Signal Type
Select the incremental type (A/B channel) of the encoder in use.
Find the information on the encoder datasheet.
Select [0] None if the feedback sensor is an absolute encoder
only.
Option:
[0]
[1]
*
[2]
Danfoss A/S © 03/2019 All rights reserved.
Function:
[0 - Returns the extended warning word
4294967295] sent via the serial communication
port in hex code.
Function:
[0 - Returns the extended status word 2
4294967295 ] sent via the serial communication
port in hex code.
Function:
[0 - Show the alarm word 3 sent via the
4294967295 ] serial communication port in hex
code.
Function:
[0 - View the warning word sent via the
4294967295 ] serial communication port in hex
code.
®
Encoder Input MCB 102), resolver (VLT
®
Encoder Input MCB 102. Both the
Function:
None
RS422 (5V
TTL)
Sinusoidal
1Vpp
4 4
®
