Parameter Lists
5.2.17 18-** Data Readouts 2
Param Parameter description
eter
numb
er
18-5* Active Alarms/Warnings
18-55 Active Alarm Numbers
18-56 Active Warning Numbers
18-9* PID Readouts
18-90 Process PID Error
5 5
18-91 Process PID Output
18-92 Process PID Clamped Output
18-93 Process PID Gain Scaled Output
5.2.18 21-** Ext. Closed Loop
Param Parameter description
eter
numb
er
21-1* Ext. CL 1 Ref./Fb.
21-10 Ext. 1 Ref./Feedback Unit
21-11 Ext. 1 Minimum Reference
21-12 Ext. 1 Maximum Reference
21-13 Ext. 1 Reference Source
21-14 Ext. 1 Feedback Source
21-15 Ext. 1 Setpoint
21-17 Ext. 1 Reference [Unit]
21-18 Ext. 1 Feedback [Unit]
21-19 Ext. 1 Output [%]
21-2* Ext. CL 1 PID
21-20 Ext. 1 Normal/Inverse Control
21-21 Ext. 1 Proportional Gain
21-22 Ext. 1 Integral Time
21-23 Ext. 1 Differentation Time
21-24 Ext. 1 Dif. Gain Limit
176
VLT® AutomationDrive FC 361
Default value
0 N/A
0 N/A
0 %
0 %
0 %
0 %
Default value
[1] %
0 ExtPID1Unit
100 ExtPID1Unit
[0] No function
[0] No function
0 ExtPID1Unit
0 ExtPID1Unit
0 ExtPID1Unit
0 %
[0] Normal
0.01 N/A
10000 s
0 s
5 N/A
Danfoss A/S © 03/2019 All rights reserved.
4 set-up Change Conversion
during index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
4 set-up Change Conversion
during index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
0 Uint16
0 Uint16
-1 Int16
-1 Int16
-1 Int16
-1 Int16
Type
– Uint8
– Int32
– Int32
– Uint8
– Uint8
– Int32
– Int32
– Int32
– Int32
– Uint8
-2 Uint16
0 Uint32
0 Uint16
– Uint16
