Parameter Descriptions
4.6.2 5-3* Digital Outputs
The 2 solid-state digital outputs are common for terminals
27 and 29. Set the I/O function for terminal 27 in
parameter 5-01 Terminal 27 Mode, and set the I/O function
for terminal 29 in parameter 5-02 Terminal 29 Mode.
NOTICE
4 4
These parameters cannot be adjusted while the motor is
running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready/
remote
control
[4] Enable/no
warning
[5] VLT running
[6] Running/no
warning
[7] Run in
range/no
warning
[8] Run on
reference/no
warning
[9] Alarm
[10] Alarm or
warning
[11] At torque
limit
[12] Out of
current range
[13] Below
current, low
[14] Above
current, high
70
VLT® AutomationDrive FC 361
Default for all digital outputs and relay
outputs.
The control card is ready, for example:
Feedback from a frequency converter
controlled by a 24 V external supply (VLT
24 V DC Supply MCB 107) and the main
power to the unit is not detected.
The frequency converter is ready for
operation and applies a supply signal on
the control board.
The frequency converter is ready for
operation and is in auto-on mode.
Ready for operation. No start or stop
command has been given (start/disable).
No warnings are active.
The motor runs and shaft torque is
present.
The output speed is higher than the speed
set in parameter 1-81 Min Speed for
Function at Stop [RPM]. The motor runs and
there are no warnings.
Motor runs within the programmed current
and speed ranges set in
parameter 4-50 Warning Current Low to
parameter 4-53 Warning Speed High. There
are no warnings.
Motor runs at reference speed. No
warnings.
An alarm activates the output. There are
no warnings.
An alarm or a warning activates the
output.
The torque limit set in
parameter 4-16 Torque Limit Motor Mode or
parameter 4-17 Torque Limit Generator Mode
has been exceeded.
The motor current is outside the range set
in parameter 4-18 Current Limit.
Motor current is lower than set in
parameter 4-50 Warning Current Low.
Motor current is higher than set in
parameter 4-51 Warning Current High.
Danfoss A/S © 03/2019 All rights reserved.
[15] Out of speed Output frequency is outside the frequency
range range set in parameter 4-52 Warning Speed
Low and parameter 4-53 Warning Speed
High.
[16] Below speed, Output speed is lower than the setting in
low parameter 4-52 Warning Speed Low.
[17] Above speed, Output speed is higher than the setting in
high parameter 4-53 Warning Speed High.
[18] Out of Feedback is outside the range set in
feedback parameter 4-56 Warning Feedback Low and
range parameter 4-57 Warning Feedback High.
[19] Below Feedback is below the limit set in
feedback low parameter 4-56 Warning Feedback Low.
[20] Above Feedback is above the limit set in
feedback high parameter 4-57 Warning Feedback High.
[21] Thermal The thermal warning turns on when the
®
warning temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
[22] Ready, no Frequency converter is ready for operation,
thermal and there is no overtemperature warning.
warning
[23] Remote, Frequency converter is ready for operation
ready, no and is in auto-on mode. There is no
thermal overtemperature warning.
warning
[24] Ready, Frequency converter is ready for operation
Voltage OK and the mains voltage is within the
specified voltage range (see the section
General Specifications in the frequency
converter design guide).
[25] Reverse The motor runs (or is ready to run)
clockwise when logic = 0 and counter-
clockwise when logic = 1. The output
changes when the reversing signal is
applied.
[26] Bus OK Active communication (no timeout) via the
serial communication port.
[27] Torque limit & Use in performing a coast stop and in
stop torque limit condition. If the frequency
converter has received a stop signal and is
at the torque limit, the signal is logic 0.
[31] Relay 123 Relay is activated when [0] Control word is
selected in parameter group 8-** Communi-
cations and Options.
[35] External
Interlock
[38] Motor
feedback
error
[40] Out of ref Active when the actual speed is outside
range settings in parameter 4-52 Warning Speed
Low to parameter 4-55 Warning Reference
High.
[41] Below Active when actual speed is below speed
reference low reference setting.
