Danfoss VLT AutomationDrive FC 361 Programming Manual page 10

Introduction
1 1
Input polarity of control terminals
12 13
Illustration 1.3 PNP (Source)
12 13
Illustration 1.4 NPN (Sink)
NOTICE
Control cables must be shielded/armored.
See the section Grounding of Shielded Control Cables in the
design guide for the correct termination of control cables.
8
VLT® AutomationDrive FC 361
PNP (S our c e)
Dig ital input wir ing
18 19 27 29 32 33
NPN (Sink)
Dig ital input wir ing
18 19 27 29 32 33
Danfoss A/S © 03/2019 All rights reserved.
20
Illustration 1.5 Grounding of Shielded/Armored Control Cables
20
1.3.1 Start/Stop
Terminal 18 = Parameter 5-10 Terminal 18 Digital Input [8]
Start.
Terminal 27 = Parameter 5-12 Terminal 27 Digital Input [0]
No operation (Default [2] Coast inverse).
Speed
S tar t/S t op
[18]
Illustration 1.6 Start/Stop
12 13 18 19 27 29 32 33 20
S tar t/S t op
MG06J202
