Troubleshooting
WARNING
HIGH VOLTAGE
Drives contain high voltage when connected to AC mains
input, DC supply, or load sharing. Failure to perform
installation, start-up, and maintenance by qualified
personnel can result in death or serious injury.
•
Only qualified personnel must perform instal-
lation, start-up, and maintenance.
•
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that there is no remaining voltage on
the drive.
6 6
Troubleshooting
•
Remove the power from the drive and check
motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the drive and the motor is
missing.
WARNING
HIGH VOLTAGE
Drives contain high voltage when connected to AC mains
input, DC supply, or load sharing. Failure to perform
installation, start-up, and maintenance by qualified
personnel can result in death or serious injury.
•
Only qualified personnel must perform instal-
lation, start-up, and maintenance.
•
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that there is no remaining voltage on
the drive.
Troubleshooting
•
Remove the power from the drive and check
motor phase W.
ALARM 33, Inrush fault
Too many power-ups have occurred within a short time
period.
Troubleshooting
•
Let the unit cool to operating temperature.
•
Check potential DC-link fault to ground.
WARNING/ALARM 34, Fieldbus communication fault
The fieldbus on the communication option card is not
working.
WARNING/ALARM 35, Option fault
An option alarm is received. The alarm is option-specific.
The most likely cause is a power-up or a communication
fault.
186
VLT® AutomationDrive FC 361
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the drive is lost and parameter 14-10 Mains Failure is not
set to [0] No function.
Troubleshooting
•
ALARM 37, Phase imbalance
There is a current imbalance between the power units.
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
Table 6.4 is shown.
Troubleshooting
•
•
•
It may be necessary to contact the Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
Number
0
256–258
512–519
783
1024–1284
1299
1300
1302
1315
1316
1318
1379–2819
1792
1793
1794
1795
1796
2561
Danfoss A/S © 03/2019 All rights reserved.
Check the fuses to the drive and mains supply to
the unit.
Cycle power.
Check that the option is properly installed.
Check for loose or missing wiring.
Text
The serial port cannot be initialized. Contact the
Danfoss supplier or Danfoss service department.
The power EEPROM data is defective or too old.
Replace the power card.
Internal fault. Contact the Danfoss supplier or
Danfoss service department.
Parameter value outside of minimum/maximum
limits.
Internal fault. Contact the Danfoss supplier or
Danfoss service department.
The option software in slot A is too old.
The option software in slot B is too old.
The option software in slot C1 is too old.
The option software in slot A is not supported/
allowed.
The option software in slot B is not supported/
allowed.
The option software in slot C1 is not supported/
allowed.
Internal fault. Contact the Danfoss supplier or
Danfoss service department.
Hardware reset of digital signal processor.
Motor-derived parameters not transferred correctly
to the digital signal processor.
Power data not transferred correctly at power-up
to the digital signal processor.
The digital signal processor has received too many
unknown SPI telegrams. This situation can occur
due to poor EMC protection or improper
grounding.
RAM copy error.
Replace the control card.
