Parameter Descriptions
4.6.6 5-9* Bus-controlled
This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
0
*
4
4
2147483647]
Bit 0
Digital output terminal 27
Bit 1
Digital output terminal 29
Bit 2
Digital output terminal X 30/6
Bit 3
Digital output terminal X 30/7
Bit 4
Relay 1 output terminal
Bit 5
Relay 2 output terminal
Bit 6
Option B relay 1 output terminal
Bit 7
Option B relay 2 output terminal
Bit 8
Option B relay 3 output terminal
Bit 9–15
Reserved for future terminals
Bit 16
Option C relay 1 output terminal
Bit 17
Option C relay 2 output terminal
Bit 18
Option C relay 3 output terminal
Bit 19
Option C relay 4 output terminal
Bit 20
Option C relay 5 output terminal
Bit 21
Option C relay 6 output terminal
Bit 22
Option C relay 7 output terminal
Bit 23
Option C relay 8 output terminal
Bit 24–31
Reserved for future terminals
Table 4.14 Bus-controlled Digital Outputs and Relays
5-93 Pulse Out #27 Bus Control
Range:
0 %
*
5-94 Pulse Out #27 Timeout Preset
Range:
0 %
*
80
Function:
[0 -
This parameter holds the state of
the digital outputs and relays that
is controlled by bus.
A logical 1 indicates that the
output is high or active.
A logical 0 indicates that the
output is low or inactive.
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal 27
when the terminal is configured as
[45] Bus Controlled in
parameter 5-60 Terminal 27 Pulse
Output Variable.
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal 27
when the terminal is configured as
[48] Bus Ctrl Timeout in
parameter 5-60 Terminal 27 Pulse
Output Variable and a timeout is
detected.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
5-95 Pulse Out #29 Bus Control
Range:
0 %
*
5-96 Pulse Out #29 Timeout Preset
Range:
0 %
*
5-97 Pulse Out #X30/6 Bus Control
Range:
0 %
*
5-98 Pulse Out #X30/6 Timeout Preset
Range:
0 %
*
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal 29
when the terminal is configured as
[45] Bus Controlled in
parameter 5-63 Terminal 29 Pulse
Output Variable.
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal 29
when the terminal is configured as
[48] Bus Ctrl Timeout in
parameter 5-63 Terminal 29 Pulse
Output Variable and a timeout is
detected.
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal
X30/6 when the terminal is
configured as [45] Bus ctrl. in
parameter 5-66 Terminal X30/6 Pulse
Output Variable.
Function:
[0 - 100 %]
Set the output frequency
transferred to output terminal
X30/6 when the terminal is
configured as [48] Bus Ctrl Timeout
in parameter 5-66 Terminal X30/6
Pulse Output Variable and a timeout
is detected.
MG06J202
