Parameter Descriptions
NOTICE
Changing parameter 4-16 Torque Limit Motor Mode when
parameter 1-00 Configuration Mode is set to [0] Speed
open loop, parameter 1-66 Min. Current at Low Speed is
automatically readjusted.
NOTICE
The torque limit reacts to the actual, non-filtered torque,
4 4
including torque spikes. This is not the torque that is
seen from the LCP or the fieldbus as that torque is
filtered.
4-17 Torque Limit Generator Mode
Range:
100 %
*
1000.0 %]
4-18 Current Limit
Range:
Size
related 1000.0 %]
*
4-19 Max Output Frequency
Range:
Size
related
*
62
Function:
[ 0 - This function limits the torque on
the shaft to protect the mechanical
installation.
Function:
NOTICE
[ 1.0 -
If [20] ATEX ETR is selected in
parameter 1-90 Motor Thermal
Protection, set
parameter 4-18 Current Limit
current limit to 150%.
This is a true current limit function
that continues in the oversyn-
chronous range. However, due to
field weakening the motor torque
at current limit will drop
accordingly when the voltage
increase stops above the
synchronized speed of the motor.
Function:
NOTICE
[ 1 - 590 Hz]
This parameter cannot be
adjusted while the motor is
running.
NOTICE
Maximum output frequency
cannot exceed 10% of the
inverter switching frequency
(parameter 14-01 Switching
Frequency).
Provides a final limit on the output
frequency for improved safety in
applications where overspeeding is
to be avoided. This limit is final in
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
4-19 Max Output Frequency
Range:
4.5.2 4-2* Limit Factors
4-20 Torque Limit Factor Source
Option:
[0]
*
[2]
[4]
[6]
[8]
[10]
[12]
[14]
[16]
4-21 Speed Limit Factor Source
Option:
[0]
*
Function:
all configurations (independent of
the setting in
parameter 1-00 Configuration Mode).
Function:
Select an analog input for scaling
the settings in
parameter 4-16 Torque Limit Motor
Mode and parameter 4-17 Torque
Limit Generator Mode 0–100% (or
inverse). The signal levels
corresponding to 0% and 100% are
defined in the analog input scaling,
for example parameter group 6-1*
Analog Input 1. This parameter is
only active when
parameter 1-00 Configuration Mode
is in Speed Open Loop or Speed
Closed Loop.
No function
Analog in 53
Analog in 53
inv
Analog in 54
Analog in 54
inv
Analog in
X30-11
Analog in
X30-11 inv
Analog in
X30-12
Analog in
X30-12 inv
Function:
Select an analog input for scaling
the settings in parameter 4-19 Max
Output Frequency 0–100% (or the
other way around). The signal levels
corresponding to 0% and 100% are
defined in the analog input scaling,
for example parameter group 6-1*
Analog Input 1. This parameter is
only active when
parameter 1-00 Configuration Mode
is in [4] Torque Open Loop.
No function
