Troubleshooting
Warning
Alarm
Trip locked
Table 6.2 Indicator Light
Bit Hex Dec Alarm word
Alarm Word Extended Status Word
0 00000001 1 Brake check (A28)
1 00000002 2 Pwr.card temp
(A69)
2 00000004 4 Earth fault (A14)
3 00000008 8 Ctrl.card temp
(A65)
4 00000010 16 Ctrl. word TO
(A17)
5 00000020 32 Overcurrent (A13)
6 00000040 64 Torque limit (A12)
7 00000080 128 Motor th over
(A11)
8 00000100 256 Motor ETR over
(A10)
9 00000200 512 Inverter overld.
(A9)
10 00000400 1024 DC under volt (A8) Start failed
11 00000800 2048 DC over volt (A7)
12 00001000 4096 Short circuit (A16) External
13 00002000 8192 Inrush fault (A33)
14 00004000 16384 Mains ph. loss (A4) No safety option Mains ph. loss
15 00008000 32768 AMA not OK
16 00010000 65536 Live zero error
(A2)
MG06J202
Programming Guide
Alarm word 2 Warning word
Servicetrip, read/ Brake check (W28) Start delayed Ramping
write
Servicetrip, Pwr.card temp
(reserved) (A69)
Servicetrip, Earth fault (W14)
typecode/spare
part
Servicetrip, Ctrl.card temp
(reserved) (W65)
Servicetrip, Ctrl. word TO
(reserved) (W17)
Reserved Overcurrent (W13) Reserved
Reserved Torque limit (W12) Reserved
Reserved Motor th over
(W11)
Reserved Motor ETR over
(W10)
Discharge high Inverter Overld
(W9)
DC under volt
(W8)
Speed limit DC over volt (W7) Multi-motor
DC voltage low
interlock (W6)
Illegal option DC voltage high
combi. (W5)
(W4)
Reserved No motor (W3)
Reserved Live zero error
(W2)
Danfoss A/S © 03/2019 All rights reserved.
Yellow
Flashing red
Yellow and red
Warning Extended
word 2 status word
Stop delayed AMA running
Reserved Start CW/CCW
start_possible is active, when the DI
selections [12] OR [13] are active
and the requested direction
matches the reference sign
Reserved Slow down
slow down command active, for
example via CTW bit 11 or DI
Catch up
catch up command active, for
example via CTW bit 12 or DI
Feedback high
feedback >parameter 4-57 Warning
Feedback High
Feedback low
feedback <parameter 4-56 Warning
Feedback Low
Reserved Output current high
current >parameter 4-51 Warning
Current High
Reserved Output current low
current <parameter 4-50 Warning
Current Low
Discharge Output freq high
high speed >parameter 4-53 Warning
Speed High
Multi-motor Output freq low
underload speed <parameter 4-52 Warning
Speed Low
Brake check OK
overload brake test NOT OK
Compressor Braking max.
interlock BrakePower > Brakepowerlimit
(2-12)
Mechanical Braking
brake sliding
Safe option Out of speed range
warning
Auto DC OVC active
braking
AC brake
