Parameter Descriptions
8-36 Max Response Delay
Range: Function:
Size [ 11 - 10001 Specify the maximum allowed delay
related ms] time between transmitting a
*
request and receiving a response. If
a response from the frequency
converter is exceeding the time
setting, then it is discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size [ 0.00 - 35.00 Specify the maximum allowed time
related ms] interval between receipt of 2 bytes.
*
This parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1]
FC MC protocol.
4.9.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option: Function:
[1] Standard Enables use of freely configurable
*
telegram 1 telegrams or standard telegrams for
the FC port.
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom Enables use of freely configurable
telegram 1 telegrams or standard telegrams for
the FC port.
[202] Custom
telegram 3
8-41 Parameters for Signals
Option: Function:
[0] None This parameter contains a list of
*
signals available for selection in
parameter 8-42 PCD Write Configu-
ration and parameter 8-43 PCD Read
Configuration.
[302] Minimum
Reference
[303] Maximum
Reference
[312] Catch up/slow
Down Value
MG06J202
Programming Guide
8-41 Parameters for Signals
Option:
[341]
[342]
[351]
[352]
[380]
[381]
[411]
[412]
[413]
[414]
[416]
[417]
[553]
[558]
[590]
[593]
[595]
[597]
[615]
[625]
[653]
Danfoss A/S © 03/2019 All rights reserved.
Function:
Ramp 1 Ramp
Up Time
Ramp 1 Ramp
Down Time
Ramp 2 Ramp
Up Time
Ramp 2 Ramp
Down Time
Jog Ramp
Time
Quick Stop
Ramp Time
Motor Speed
Low Limit
[RPM]
Motor Speed
Low Limit [Hz]
Motor Speed
High Limit
[RPM]
Motor Speed
High Limit
[Hz]
Torque Limit
Motor Mode
Torque Limit
Generator
Mode
Term. 29 High
Ref./Feedb.
Value
Term. 33 High
Ref./Feedb.
Value
Digital & Relay
Bus Control
Pulse Out #27
Bus Control
Pulse Out #29
Bus Control
Pulse Out
#X30/6 Bus
Control
Terminal 53
High Ref./
Feedb. Value
Terminal 54
High Ref./
Feedb. Value
Term 42
Output Bus
Ctrl
