Parameter Descriptions
16-70 Pulse Output #29 [Hz]
Range:
0
*
16-71 Relay Output [bin]
Range:
0
*
4 4
16-72 Counter A
Range:
0
*
- 2147483647]
16-73 Counter B
Range:
0
*
- 2147483647]
16-75 Analog In X30/11
Range:
0
*
148
Function:
[0 - 40000 ] View the actual value of pulses at
terminal 29 in digital output mode.
Function:
[0 - 511 ] View the settings of all relays.
R eadout choic e (P ar . 16-71):
R ela y output (bin):
0 0 0 0 0 bin
Reserved
Reserved
Reserved
P o w er car d r ela y 02
P o w er car d r ela y 01
Illustration 4.48 Relay Settings
Function:
[-2147483648 View the present value of counter
A. Counters are useful as
comparator operands, see
parameter 13-10 Comparator
Operand.
Reset or change the value either via
digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC
action (parameter 13-52 SL Controller
Action).
Function:
[-2147483648 View the present value of counter
B. Counters are useful as
comparator operands
(parameter 13-10 Comparator
Operand).
Reset or change the value either via
digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC
action (parameter 13-52 SL Controller
Action).
Function:
[-20 - 20 ] View the actual value at input
®
X30/11 of VLT General Purpose I/O
MCB 101.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
16-76 Analog In X30/12
Range:
0
*
16-77 Analog Out X30/8 [mA]
Range:
0
*
4.15.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range:
0
*
16-82 Fieldbus REF 1
Range:
0
*
16-84 Comm. Option STW
Range:
0
*
16-85 FC Port CTW 1
Range:
0
*
Function:
[-20 - 20 ] View the actual value at input
®
X30/12 of VLT General Purpose I/O
MCB 101.
Function:
[0 - 30 ] View the actual value at input
X30/8 in mA.
Function:
[0 - 65535 ] View the 2-byte control word (CTW)
received from the fieldbus master.
Interpretation of the control word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Profile.
For more information, refer to the
relevant fieldbus manual.
Function:
[-200 - 200 ] View the 2-byte word sent with the
control word from the fieldbus
master to set the reference value.
For more information, refer to the
relevant fieldbus manual.
Function:
[0 - 65535 ] Show the status word of the
extended fieldbus communication
option.
For more information, refer to the
relevant fieldbus manual.
Function:
[0 - 65535 ] View the 2-byte control word (CTW)
received from the fieldbus master.
Interpretation of the control word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Profile.
