Parameter Descriptions
4.12.1 13-0* SLC Settings
Use the SLC settings to activate, deactivate, and reset the
smart logic control sequence. The logic functions and
comparators are always running in the background, which
opens for separate control of digital inputs and outputs.
13-00 SL Controller Mode
Option: Function:
[0] Off Disables the smart logic controller.
[1] On Enables the smart logic controller.
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option: Function:
[0] False Select the boolean (true or false)
input to activate smart logic
control.
Enters the fixed value - false.
[1] True Enters the fixed value - true.
[2] Running The motor runs.
[3] In range The motor runs within the
programmed current and speed
ranges set in
parameter 4-50 Warning Current Low
to parameter 4-53 Warning Speed
High.
[4] On reference The motor runs on reference.
[5] Torque limit The torque limit set in
parameter 4-16 Torque Limit Motor
Mode or parameter 4-17 Torque Limit
Generator Mode is exceeded.
[6] Current Limit The motor current limit set in
parameter 4-18 Current Limit is
exceeded.
[7] Out of current The motor current is outside the
range range set in parameter 4-18 Current
Limit.
[8] Below I low The motor current is lower than set
in parameter 4-50 Warning Current
Low.
[9] Above I high The motor current is higher than
set in parameter 4-51 Warning
Current High.
[10] Out of speed The speed is outside the range set
range in parameter 4-52 Warning Speed
Low and parameter 4-53 Warning
Speed High.
[11] Below speed The output speed is lower than the
low setting in parameter 4-52 Warning
Speed Low.
MG06J202
Programming Guide
13-01 Start Event
Select the boolean (true or false) input to activate smart logic
control.
Option:
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
Danfoss A/S © 03/2019 All rights reserved.
Function:
Above speed The output speed is higher than
high the setting in
parameter 4-53 Warning Speed High.
Out of feedb. The feedback is outside the range
range set in parameter 4-56 Warning
Feedback Low and
parameter 4-57 Warning Feedback
High.
Below feedb. The feedback is below the limit set
low in parameter 4-56 Warning Feedback
Low.
Above feedb. The feedback is above the limit set
high in parameter 4-57 Warning Feedback
High.
Thermal The thermal warning turns on when
warning the temperature exceeds the limit
in the motor, the frequency
converter, the brake resistor, or the
thermistor.
Mains out of The mains voltage is outside the
range specified voltage range.
Reversing The output is high when the
frequency converter is running
counterclockwise (the logical
product of the status bits running
AND reverse).
Warning A warning is active.
Alarm (trip) A (trip) alarm is active.
Alarm (trip A (trip lock) alarm is active.
lock)
Comparator 0 Use the result of comparator 0.
Comparator 1 Use the result of comparator 1.
Comparator 2 Use the result of comparator 2.
Comparator 3 Use the result of comparator 3.
Logic rule 0 Use the result of logic rule 0.
Logic rule 1 Use the result of logic rule 1.
Logic rule 2 Use the result of logic rule 2.
Logic rule 3 Use the result of logic rule 3.
Digital input Use the result of digital input 18.
DI18
Digital input Use the result of digital input 19.
DI19
Digital input Use the result of digital input 27.
DI27
Digital input Use the result of digital input 29.
DI29
