15-10 Logging Source
Option:
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
4 4
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1657] Feedback
[RPM]
[1660] Digital Input
[1662] Analog Input
53
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1675] Analog In
X30/11
[1676] Analog In
X30/12
[1677] Analog Out
X30/8 [mA]
[1687] Bus Readout
Alarm/Warning
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status
Word
[1695] Ext. Status
Word 2
[1697] Alarm Word 3
[1698] Warning Word
3
15-11 Logging Interval
Array [4]
Range:
Size
related 0.000 ]
*
140
Function:
Function:
[ 0.000 - Enter the interval in ms between
each sampling of the variables to
be logged.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[33]
[34]
[35]
[36]
Function:
False
True
Running
In range
On reference
Torque limit
Current Limit
Out of current
range
Below I low
Above I high
Out of speed
range
Below speed
low
Above speed
high
Out of feedb.
range
Below feedb.
low
Above feedb.
high
Thermal
warning
Mains out of
range
Reversing
Warning
Alarm (trip)
Alarm (trip
lock)
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Digital input
DI18
Digital input
DI19
Digital input
DI27
Digital input
DI29
