Parameter Descriptions
13-02 Stop Event
Select the boolean (true or false) input to deactivate smart logic
control.
Option: Function:
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key [OK] is pressed. Only available on
the graphical LCP.
[44] Reset key [Reset] is pressed. Only available on
the graphical LCP.
[45] Left key [◄] is pressed. Only available on the
graphical LCP.
[46] Right key [►] is pressed. Only available on the
graphical LCP.
▲
[47] Up key
[
graphical LCP.
▼
[48] Down key
[
graphical LCP.
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3 Smart logic controller timer 3 is
timed out.
[71] SL Time-out 4 Smart logic controller timer 4 is
timed out.
[72] SL Time-out 5 Smart logic controller timer 5 is
timed out.
[73] SL Time-out 6 Smart logic controller timer 6 is
timed out.
[74] SL Time-out 7 Smart logic controller timer 7 is
timed out.
[75] Start
command
given
[76] Digital input
x30/2
[77] Digital input
x30/3
[78] Digital input
x30/4
[83] Broken Belt
[102] Relay 1
[103] Relay 2
MG06J202
Programming Guide
] is pressed. Only available on the
] is pressed. Only available on the
Danfoss A/S © 03/2019 All rights reserved.
13-03 Reset SLC
Option: Function:
[0] Do not reset Retain programmed settings in
*
SLC parameter group 13-** Smart Logic.
[1] Reset SLC Reset all parameters in parameter
group 13-** Smart Logic to default
settings.
4.12.2 13-1* Comparators
Comparators are used for comparing continuous variables
(that is output frequency, output current, analog input, and
so on) to fixed preset values.
Par. 13-11
Comparator Operator
Par. 13-10
Comparator Operand
=
TRUE longer than.
Par. 13-12
Comparator Value . . .
. . .
Illustration 4.38 Comparators
There are digital values that are compared to fixed time
values. See the explanation in parameter 13-10 Comparator
Operand. Comparators are evaluated once in each scan
interval. Use the result (true or false) directly. All
parameters in this parameter group are array parameters
with index 0–5. Select index 0 to program comparator 0,
select index 1 to program comparator 1, and so on.
13-10 Comparator Operand
Option: Function:
Options [1] Reference % to [31]
Counter B are variables which are
compared based on their values.
Options [50] FALSE to [186] Drive in
auto mode are digital values (true/
false) where the comparison is
based on the amount of time
during which they are set to true or
false. See
parameter 13-11 Comparator
Operator.
Select the variable to be monitored
by the comparator.
[0] DISABLED The comparator is disabled.
[1] Reference % The resulting remote reference in
percent.
[2] Feedback % [RPM] or [Hz], as set in
parameter 0-02 Motor Speed Unit.
4 4
