Parameter Descriptions
0-30 Unit for User-defined Readout
Option:
4 4
[0] None
[1] %
*
[5] PPM
[10] 1/min
[11] rpm
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
30
VLT® AutomationDrive FC 361
Function:
It is possible to program a value to
be shown in the display of the LCP.
The value has a linear, squared, or
cubed relation to speed. This
relation depends on the unit
selected (see Table 4.2). The actual
calculated value can be read in
parameter 16-09 Custom Readout,
and/or shown in the display by
selecting [16-09] Custom Readout in
parameter 0-20 Display Line 1.1
Small to parameter 0-24 Display Line
3 Large.
Danfoss A/S © 03/2019 All rights reserved.
0-30 Unit for User-defined Readout
Option: Function:
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range: Function:
0 Custom- [ -999999.99 - This parameter sets the minimum
ReadoutUni par. 0-32 value of the custom-defined
t CustomRea- readout (occurs at 0 speed). Only
*
doutUnit] possible to set different from 0
when selecting a linear unit in
parameter 0-30 Unit for User-defined
Readout. For quadratic and cubic
units, the minimum value is 0.
0-32 Max Value of User-defined Readout
Range: Function:
100 [ par. 0-31 - This parameter sets the maximum
Custom- 999999.99 value to be shown when the speed
ReadoutUni CustomRea- of the motor has reached the set
t doutUnit] value for parameter 4-13 Motor
*
Speed High Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed Unit).
0-37 Display Text 1
Range: Function:
0 [0 - 25] Enter a text which can be viewed in
*
the graphical display by selecting
[37] Display Text 1 in
0-38 Display Text 2
Range: Function:
0 [0 - 25] Enter a text which can be viewed in
*
the graphical display by selecting
[38] Display Text 2 in
•
Parameter 0-20 Display Line
1.1 Small,
•
Parameter 0-21 Display Line
1.2 Small,
•
Parameter 0-22 Display Line
1.3 Small,
•
Parameter 0-23 Display Line
2 Large, or
•
Parameter 0-24 Display Line
3 Large.
